Title: Respiratory Distress Syndrome
1Respiratory Distress Syndrome
- PREPARED BY Dr. SALEH BANAT
- Moderator Dr. Y. ABU OSBA
2Pathophysiology
- RDS is caused by A relative deficiency of
surfactant. - which leads to
- 1- a decrease in lung compliance and functional
residual capacity with increased dead space. -
- 2- large ventilation-perfusion mismatch.
3Pathophysiology cont.
- Macroscopically the lungs appear airless and
ruddy (i.e., liverlike). - And so the lungs of these infants require a
higher critical opening pressure to inflate. - Microscopically Diffuse atelectasis of distal
airspaces along with distension of some distal
airways and perilymphatic areas.
4Pathophysiology cont.
- With progressive atelectasis endothelial and
epithelial cells lining these distal airways are
damaged, resulting in exudation of fibrinous
matrix derived from blood (Hyaline membranes). - Hyaline Membranes that line the alveoli are
formed within a half hour after birth. - Hyaline membranes interstitial edema make the
lungs less compliant so greater pressure is
needed to expand the small alveoli. -
5Pathophysiology cont.
- ?? surfactant
- ? Atelectasis
- ? Hypoxia, Hypercapnia Acidosis
- ? Pulmonary arterial vasoconstriction ? Rt to
Lt shunting through foramen ovale Ductus
Arteriosus - ? reduced pulmonary blood flow ischemic injury
to surfactant-producing cells.
6Surfactant
- Surfactant a complex lipoprotein comprised of 6
phospholipids and 4 apoproteins. - Functionally lecithin ( dipalmitoyl
phosphatidylcholine), is the principle
phospholipid (65). - Apoproteins (SP-B SP-C) and other substances
(e.g., nonionic detergent tyloxapol, C160
alcohol hexadecanol Exosurf) facilitates
adsorption and spreading of Lecithin as a
monolayer. - Lecithin lowers the surface tension at the
alveolar air-fluid interface so maintain
alveolar stability by preventing collapse of
small airways at end expiration.
7Surfactant cont.
- Surfactant is synthesized in the Golgi apparatus
of the endoplasmic reticulum of the type II
alveolar cell. - It appears in amniotic fluid between 28 32 wks.
- Mature levels of pulmonary surfactant are present
after 35 wks.
8Surfactant cont.
- Factors that may impair surfactant production or
secretion - 1- Hypoxia.
- 2- Acidosis.
- 3- Hypothermia.
- 4- Hypotension.
9Frequency
- The greatest risk factor for developing RDS is
prematurity. - RDS occur in as many as 60-80 of infants lt 28
wks gestation. - Approximately 50 of infants born at 28-32 wks
gestation develop RDS. - RDS affect 15-30 of those between 32 36 wks.
- Only 5 of infants are affected after 37 wks.
10Frequency cont.
- Incidence of RDS increases with decreasing
gestational age BW. - Not all premature infants develop RDS.
- RDS has been reported in all races worldwide,
however it occurs more often in premature infants
of Caucasian ancestry.
11Clinical Features
- RDS frequently occurs in the following
individuals - Male infants
- Infants of diabetic mothers
- Infants delivered via cesarean without maternal
labor - Second-born twins
- Infants with a family history of RDS
- Asphyxia cold stress.
12Clinical Features cont.
- In contrast, the incidence of RDS decreases with
the following - Use of antenatal steroids
- Pregnancy-induced or chronic maternal HTN
- Prolonged rupture of membranes
- Maternal narcotic addiction
13Clinical Features cont.
- Secondary surfactant deficiency may occur in
infants with the following - Intrapartum asphyxia
- Pulmonary infections
- Pulmonary hemorrhage
- Meconium aspiration pneumonia
- Oxygen toxicity along with barotrauma or
volutrauma to the lungs
14Physical Exam
- Physical findings are consistent with the
infant's maturity assessed by The Ballard Scoring
System. - Progressive signs of respiratory distress are
noted soon after birth and include the following - Tachypnea
- Expiratory grunting (from partial closure of
glottis) - Subcostal and intercostal retractions
- Cyanosis
- Nasal flaring
- apnea and/or hypothermia in extremely immature
infants.
15Physical Exam cont.
- Breath sounds may be normal or diminished with a
harsh tubular quality. - On deep inspiration, fine rales may be heard,
esp. over the lung bases posteriorly. - If untreated progressive worsening of dyspnea,
cyanosis, ? BP disappearance of grunting occur. - Apnea is an ominous sign require immediate
intervention.
16Physical Exam cont.
- Patients with HMD may also have edema, ileus
oliguria. - Symptoms signs reach a peak within 3 days,
after which improvement is gradual. - Improvement is heralded by spontaneous diuresis
the ability to oxygenate the infant at lower
inspired O2 levels. - Death usually occur between days 2-7, and usually
associated with alveolar air leaks, pulmonary
hemorrhage IVH.
17Lab Studies
- Blood gases are usually obtained as clinically
indicated from either an indwelling arterial
(umbilical) catheter or an arterial puncture. - Blood gases exhibit respiratory and metabolic
acidosis along with hypoxia. - Respiratory acidosis occurs because of alveolar
atelectasis and/or overdistension of terminal
airways.
18Lab Studies cont.
- Metabolic acidosis is primarily lactic acidosis,
which results from poor tissue perfusion and
anaerobic metabolism. - Hypoxia occurs from right-to-left shunting of
blood through the pulmonary vessels, PDA, and/or
foramen ovale. - Pulse oximetry is used as a noninvasive tool to
monitor oxygen saturation, which should be
maintained at 90-95.
19Imaging Studies
- Chest x-ray of an infant with RDS exhibit
- 1- bilateral diffuse reticular granular or
ground glass appearance. - 2- air bronchograms more prominent in Lt
lower lobe because of superimposition of cardiac
shadow. - 3- poor lung expansion.
- The prominent air bronchograms represent aerated
bronchioles superimposed on a background of
collapsed alveoli. - Typical x-ray pattern develops at 6-12 hrs.
20Imaging Studies cont.
- The cardiac silhouette may be normal or enlarged.
- Cardiomegaly may be the result of
- prenatal asphyxia
- maternal diabetes
- PDA
- an associated congenital heart anomaly
- simply poor lung expansion.
21Imaging Studies cont.
- These findings may be altered with either early
surfactant therapy or indomethacin treatment with
mechanical ventilation. - The radiologic findings of RDS cannot be
differentiated reliably from those of pneumonia,
which is caused most commonly by GBBS.
22(No Transcript)
23(No Transcript)
24Imaging Studies cont.
- Echocardiography
- Performed in selected infants to
- 1- assist the clinician in diagnosing PDA and
determine the direction and degree of shunting. - 2- diagnose pulmonary hypertension.
- 3- excluding structural heart disease.
25Pulmonary Mechanics Testing
- Newer ventilators are equipped with PMT
capabilities to assist the neonatologist in
adequately managing the changing pulmonary course
of RDS. - Constant PMT monitoring may be helpful in
- 1- Preventing volutrauma from alveolar and airway
overdistension. - 2- Facilitate weaning the infant from the
ventilator after surfactant therapy or
determining if the infant can be extubated.
26PMT cont.
- Infants with RDS have significant decrease in
lung compliance. - And so the delivered tidal volume is reduced in
infants with RDS. - The airway resistance may be normal or increased.
- The anatomic dead space is increased and the
functional residual capacity (FRC) is decreased.
27Differential Diagnosis
- Pneumonia often caused by group B beta hemolytic
streptococci (GBBS) and may coexists with RDS. - X-ray may be identical to that for HMD.
- Factors that may suggest the diagnosis include
- 1- Maternal GBS colonization.
- 2- Organisms on Gram-stain of gastric or tracheal
aspirates. - 3- Marked neutropenia.
28Differential Diagnosis cont.
- Transient tachypnea of the newborn (TTN)
- Usually occurs in term or near-term infants
usually after C/S delivery. - The chest x-ray of an infant with transient
tachypnea exhibits good lung expansion and,
often, fluid in the horizontal fissure.
29Differential Diagnosis cont.
- Aspiration syndromes may result from aspiration
of amniotic fluid, blood, or meconium. - Congenital anomalies of the lungs (eg,
diaphragmatic hernia, chylothorax, congenital
cystic adenomatoid malformation of the lung,
lobar emphysema, bronchogenic cyst, pulmonary
sequestration) and heart (e.g., total anomalous
pulmonary venous return) are rare in premature
infants.
30Differential Diagnosis cont.
- Congenital alveolar proteinosis (congenital
surfactant protein B deficiency) - Rare familial disease.
- Manifest as severe lethal RDS in both term
premature infants.
31Other Problems
- Other problems that may be associated with RDS
include - Metabolic problems (e.g., hypothermia,
hypoglycemia). - Hematologic problems (e.g., anemia,
polycythemia). - Pulmonary air leaks (e.g., pneumothorax,
interstitial emphysema, pneumomediastinum,
pneumopericardium). In premature infants, these
complications may occur from excessive positive
pressure ventilation, or they may be spontaneous.
32Prevention
- Starts during Fetal Life
- Obstetricians with experience in fetal medicine
should care for mothers whose infants are at an
increased risk for developing RDS. - Strategies to prevent premature birth including
- 1- bed rest
- 2- tocolytics
- 3- appropriate antibiotics
- 4- the use of antenatal steroids
- may decrease the incidence and severity of RDS.
33Prevention cont.
- Fetal lung maturity can be predicted by
- Estimating the lecithin-to-sphingomyelin ratio
(L/S Ratio). - - The presence of phosphatidylglycerol in the
amniotic fluid obtained via amniocentesis (used
in cases of infants of diabetic mothers).
34Prevention cont.
- Antenatal steroids
- - Betamethasone administered to women before
delivery of fetuses between 24-34 wks
significantly reduces the incidence mortality
morbidity of RDS. - Steroids also reduce the incidence of other
prematurity complications IVH, PDA
Pneumothorax. - No effect on neonatal growth or the incidence of
infection.
35Prevention cont.
- It is suitable to give steroids to all pregnant
women who are likely to deliver a fetus in 1 wk
that is between 24-34 wks. - Dexamethasone may be associated with a higher
incidence of periventricular leukomalacia than
betamethasone.
36Thank You
37Treatment Complications of Respiratory Distress
Syndrome.
- Prepared By Dr. Saleh Banat
- Directed By Dr. Y.Abu Osba
38Medical Care
- Delivery and resuscitation
- - A neonatologist experienced in the
resuscitation and care of premature infants
should attend deliveries of fetuses when lt 28
weeks' gestation.
39Surfactant replacement therapy
- The mortality rate of RDS has decreased 50
during the last decade with the advent of
surfactant therapy. - Indicated in Infants diagnosed with RDS who
require assisted ventilation with (FIO2) of gt
40. - Should be given as soon as possible, preferably
within 2 hours after birth.
40Surfactant Therapy cont.
- Prophylactic use is recommended following
resuscitation in extremely premature infants (lt27
weeks' gestation). -
- Rapid bolus administration of surfactant after
adequate lung recruitment using a (PEEP) of 2-4
cm adequate positive pressure may lead to a
more homogenous distribution.
41Surfactant Therapy cont.
- Following inhaled administration, surface tension
is reduced and alveoli are stabilized, thus
decreasing the work of breathing and increasing
lung compliance. - Most infants require 2 doses.
- However, as many as 4 doses at 6-12 hr intervals
have been used in several clinical trials. - If the infant improves rapidly after only 1 dose,
the infant most likely does not have RDS.
42Surfactant Therapy cont.
- Conversely, in infants who respond poorly or are
nonresponders to surfactant, exclude - PDA
- Pneumonia
- Complications of ventilation (air leak).
especially prior to using 3rd and subsequent
doses.
43Surfactant Therapy cont.
- 2 Types
- 1- Natural e.g.
- A- Survanta (Beractant, Alveofact)
- Natural bovine lung extract.
- Composed of Dipalmitoyl phosphatidyl- choline
(DPPC), tripalmitin SP (Blt0.5, C99 of TP) - Given as 4 mL/kg (100 mg/kg) divided in 4
aliquots administered at least 6 hrs apart for
1-4 doses.
44Surfactant Therapy cont.
- Survanta must be warmed to room temperature
administered only under carefully supervised
conditions because of risk of acute airway
obstruction. -
- Marked improvement in oxygenation may occur after
administration and so a decrease in oxygen and
ventilator pressures may be needed as suggested
by blood gases, after administration.
45Surfactant Therapy cont.
- During administration
- - suction infant's ET tube (preferably using
closed suction system) prior to administering
surfactant because ET may rarely become
occluded. - - monitor HR BP.
- - Complications include
- 1- pulmonary hemorrhage(esp. in extremely
premature infants). - 2- apnea, cyanosis bradycardia,
- 3- nosocomial sepsis.
46Surfactant Therapy cont.
- B- Calfactant (Infasurf)
- A natural calf lung extract.
- Composed of phospholipids (DPPC, Tripalmitin),
fatty acids and SP-B (260 mcg/mL) SP-C (390
mcg/mL). - Dose 3 mL/kg (105 mg/kg) q6-12h for 1-4 doses.
47Surfactant Therapy cont.
- C- Curosurf (Poractant)
- Minced pig lung extract
- - Composed of DPPC, SP-B and SP-C (? amount)
- Dose 2.5 mL/kg (200 mg/kg) then 1.25 mL/kg (100
mg/kg) at 12-h intervals prn in 2 subsequent
doses. - Complications of Curosurf Infasurf are similar
to Survanta.
48Surfactant Therapy cont.
- 2- Synthetic e.g.
- Colfosceril (Exosurf)
- Composed of 85 DPPC, 9 hexadecanol 6
tyloxapol. - Dose 5 mL/kg (67.5 mg/kg) q12h for 1-4 doses.
- Complications include pulmonary hemorrhage (esp.
in infants weighing lt700 g), nosocomial sepsis
apnea.
49Surfactant Therapy cont.
- Clinical trials with protein-containing natural
surfactants result in fewer complications and a
more rapid improvement in the infant's
respiratory status than synthetic ones.
50Ventilation Therapy
- O2 Warm humidified Oxygen via hood or nasal
cannula is used for treating infants with mild
RDS. - Given in a concentration sufficient to keep PaO2
between 55-70 mm Hg (SpO2 gt 90). - Mechanical Ventilation in the form of-
- 1- CPAP
- 2- SIMV
- 3- HFV.
51CPAP
- Keeps the alveoli open at the end of expiration.
- May be administered via the endotracheal tube,
nasal prongs, or nasopharyngeal tubes (in larger
infants). - It is an adjunct therapy following surfactant
administration, if prolonged assisted ventilation
is not required. -
52CPAP cont.
- Nasal CPAP is indicated if the PaO2 cannot be
maintained above 50 mm Hg at inspired O2
concentrations of 60 or greater. - Nasal CPAP applied at a pressure of 6-10 cm H2O
produce a rise in PaO2. - May be used following extubation in individuals
with RDS to prevent atelectasis and/or prevent
apnea in premature infants.
53SIMV
- Synchronous intermittent mandatory ventilation
- Is a technique wherein some of the patient's
respirations are synchronized with breaths
delivered by the ventilator. - The incidence of BPD was reduced significantly
when compared with standard intermittent
mandatory ventilation (47 vs 72).
54SIMV cont.
- Indications include
- 1- pH lt 7.20.
- 2- PCO2 gt 60 mm Hg.
- 3- PO2 lt 50 mm Hg at O2 concentrations of 70-100
CPAP of 8-10 cm H2O. - 4- Persistent Apnea.
55SIMV cont.
- The goal of therapy for patients with RDS is to
maintain a - pH of 7.25-7.4.
- - PaO2 of 50-70 mm Hg.
- PCO2 of 40-65 mm Hg.
- And so improving oxygenation eliminating CO2
without causing barutrauma or oxygen toxicity.
56SIMV cont.
- During Mechanical Ventilation, oxygenation is
improved by - 1- ? FiO2.
- 2- ? Mean Airway Pressure (MAP) which is
achieved by - Increasing PIP, gas flow, IE ratio or PEEP.
57SIMV cont.
- CO2 elimination is achieved by
- 1- ? PIP (tidal volume).
- 2- ? rate of ventilator.
- PEEP levels of 4-6 cm H2O are safe effective.
- Excessive PEEP may impede venous return so ?
cardiac output O2 delivery.
58HFV
- High-frequency ventilation (HFV)
- Is a technique wherein small tidal volumes (less
than anatomic dead space) are usually delivered
at rapid frequencies. - HFV was originally designed to treat patients
with air leak.
59HFV cont.
- Numerous studies in animal models of RDS
demonstrate that HFV - promotes more uniform lung inflation.
- improves lung mechanics and gas exchange.
- reduces exudative alveolar edema, air leak, and
lung inflammation. - Some clinical trials demonstrated that HFV can
reduce the occurrence of chronic lung disease.
60Supportive Therapy
- Temperature regulation
- Hypothermia increases oxygen consumption.
- And so further compromising infants with RDS who
are born prematurely. - Hypothermia should be prevented in infants with
RDS during delivery, resuscitation, and
transport. - Infants with RDS should be kept in a neutral
thermal environment.
61Supportive Therapy cont.
- Fluids, metabolism, and nutrition
- In infants with In infants with RDS, initially
administer 5 or 10 dextrose intravenously at
60-80 mL/kg/day. - Closely monitor blood glucose level,
electrolytes, Ca, PO4, renal function, and
hydration (determined by body weight and urine
output) to prevent any imbalance. - Gradually increase the intake of fluid to 120-140
mL/kg/day.
62Supportive Therapy cont.
- Excessive fluids should be avoided because it
contribute to PDA BPD. - - Once the infant is stable, intravenous
nutrition with amino acids and lipid can be
started. - - After the respiratory status is stable,
initiate a small volume of gastric feeds
(preferably breast milk) via NGT to initially
stimulate gut development.
63Supportive Therapy cont.
- Circulation and anemia
- Assess the baby's circulatory status by
monitoring HR, peripheral perfusion, and BP. - Administer blood or volume expanders, and use
vasopressors to support circulation. - Monitor blood withdrawn for laboratory tests
closely in tiny infants and replace the blood by
PRBCs when it has reached 10 of the infant's
estimated blood volume or if the PCV level is lt
40-45.
64Supportive Therapy cont.
- Antibiotic administration
-
- Start antibiotics in all infants who present with
respiratory distress at birth after obtaining
blood cultures. - Discontinue antibiotics after 3-5 days if blood
cultures are negative.
65Supportive Therapy cont.
- Exceptions to the use of antibiotics include
- 1- a recent negative maternal cervical
culture for GBBS. - 2- an infant delivered by a mother with intact
amniotic membranes. - 3- no clinical or laboratory findings suggestive
of chorioamnionitis. - 4- adequate antenatal care.
66Supportive Therapy cont.
- Support of parents and family
- Often parents undergo much emotional and/or
financial stress with the birth of a critically
ill premature infant with RDS and the associated
complications. - The parents may feel guilty and be anxious about
the prognosis for the infant. - These factors interact to prevent maternal-infant
bonding.
67Supportive Therapy cont.
- Medical staff should provide adequate support for
these parents and other family members to prevent
or minimize these problems. - The parents should be
- 1- Well-informed about the childs status.
- 2- Encouraged to touch, feed, and care for their
infant as soon as possible.
68Complications
- Divided into Acute Chronic.
- Acute Complications
- 1- Alveolar rupture
- pneumothorax
- pneumomediastinum
- pneumopericardium
- interstitial emphysema
69Acute Complications
- Alveolar rupture should be suspected when an
infant with RDS suddenly deteriorates with
hypotension, apnea, or bradycardia. - or when metabolic acidosis is persistent.
70Acute Complications cont.
- 2- Infections
- may manifest in a variety of ways, including
- failure to improve, sudden deterioration, or a
change in white blood cell count or
thrombocytopenia. - the use of invasive procedures (e.g.,
venipunctures, catheter insertion, use of
respiratory equipment) provide access for
organisms that may invade the immunologically
compromised host.
71Acute Complications cont.
- With the advent of surfactant therapy, infants
who are smaller and more ill are surviving with
an increase in the incidence of septicemia
secondary to staphylococcal epidermidis and/or
infection by Candida species. - When septicemia is suspected, we should obtain
blood cultures from 2 sites and place the infant
on appropriate antibiotics until the culture
results are obtained.
72Acute Complications cont.
- 3- Intracranial hemorrhage and periventricular
leukomalacia - Intraventricular hemorrhage (IVH) is observed in
20-40 of premature infants with greater
frequency in infants with RDS who require
mechanical ventilation. - Cranial ultrasound is performed within the first
week and thereafter as indicated in premature
infants younger than 32 weeks' gestation.
73Acute Complications cont.
- Prophylactic indomethacin therapy and antenatal
steroids have decreased the frequency of
intracranial hemorrhage in these patients with
RDS. - Hypocarbia and chorioamnionitis are associated
with an increase in periventricular leukomalacia.
74Acute Complications cont.
- 4- PDA
- Should be suspected in any infant who
deteriorates after initial improvement or has
bloody tracheal secretions. - Although helpful in the diagnosis of PDA, cardiac
murmur and wide pulse pressure are not always
apparent in critically ill infants.
75Acute Complications cont.
- An echocardiogram enables the clinician to
confirm the diagnosis. - Treat PDA with indomethacin, which can be
repeated during the first 2 weeks if the PDA
reopens. - In refractory incidents of RDS or in infants in
whom indomethacin is contraindicated, surgically
close the PDA.
76Acute Complications cont.
- 5- Pulmonary Hemorrhage
- Occurrence of pulmonary hemorrhage increases in
tiny premature infants, especially following
surfactant therapy. - Pulmonary hemorrhage may be associated with PDA.
- Increasing PEEP on the ventilator and
administering intratracheal epinephrine manages
pulmonary hemorrhage.
77Acute Complications cont.
- 6- Necrotizing enterocolitis and/or
gastrointestinal perforation. - Should be suspected in any infant with abnormal
abdominal findings on physical examination. - A radiograph of the abdomen assists in confirming
the diagnosis. - Spontaneous perforation may occasionally occur in
critically ill premature infants and has been
associated with the use of steroids and/or
indomethacin.
78Acute Complications cont.
- 7- Apnea of prematurity
- Its incidence has increased with surfactant
therapy, possibly due to early extubation. - Exclude septicemia, seizures, GER, and metabolic
and other causes in infants with apnea of
prematurity. - Rx modalities include methylxanthines
(theophylline, caffeine) and CPAP or assisted
ventilation in refractory incidents.
79Chronic Complications
- 1- Bronchopulmonary dysplasia (BPD)
- is a chronic lung disease and is defined as
oxygen requirement at a corrected gestational age
of 36 weeks. - is related directly to high volume and/or
pressures that are used in mechanical
ventilation, infections, inflammation, and
vitamin A deficiency. - BPD increases with decreasing gestational age.
80Chronic Complications cont.
- Factors that decrease severity of BPD
- A- The postnatal use of surfactant therapy.
- B- Gentler ventilation.
- C- Vitamin A.
- D- Steroids.
- - The increased incidence of BPD, is attributed
to an increase in the survival of smaller and
more ill infants with RDS following the
introduction of the above therapies.
81Chronic Complications cont.
- - BPD may also be associated with
Gastroesophageal Reflux or Sudden Infant Death
Syndrome and so these conditions should be
considered in infants with unexplained apnea
prior to discharge from the hospital.
82Chronic Complications cont.
- 2- Retinopathy of prematurity (ROP)
- - Infants with RDS and a PaO2 gt 100 mm Hg are at
a greater risk of developing ROP. - - And so PaO2 should be monitored closely and
maintained at 50-70 mm Hg. - - Eyes of all premature infants are examined at
34 weeks' gestation by an ophthalmologist and
thereafter as indicated.
83Chronic Complications cont.
- If ROP progresses, laser therapy or cryotherapy
is used to prevent retinal detachment and
blindness. - Monitor infants with ROP closely for refractive
errors.
84Chronic Complications cont.
- 3- Neurologic impairment
- Occurs in approximately 10-70 of infants.
- Related to
- A- The infant's gestational age.
- B- The extent and type of intracranial pathology.
- C- The presence of hypoxia.
- D- The presence of infections.
85Chronic Complications cont.
- Hearing and visual handicaps may result further
compromise the development of these infants. - They may develop a specific learning disability
and aberrant behavior. - Therefore, these infants need to be followed-up
to detect those with neurologic impairment, and
to take appropriate interventions.
86Chronic Complications cont.
- 4- Familial psychopathology
- Infants with RDS are at a greater risk of child
abuse failure to thrive. - To deal with these problems
- A- Encourage and document parental visits and the
parent's interaction with the infant. - B- Advise parents to spend time with their
infants with RDS in a separate room prior to
discharge.
87Chronic Complications cont.
- C- Counsel parents because an increased risk of
prematurity and RDS exists for subsequent
pregnancies.
