Biomechanics of Locomotion

1
Biomechanics of Locomotion

• D. Gordon E. Robertson, PhD, FCSB
• Biomechanics, Laboratory,
• School of Human Kinetics,
• University of Ottawa, Ottawa, Canada

2
Quantitative Domains

• Temporal
• phases (stance/swing) and events (foot-strike,
  toe-off), stride rate
• Electromyography
• muscle activation patterns
• Kinematic (motion description)
• stride length, velocity, ranges of motion,
  acceleration
• Kinetic (causes of motion)
• ground reaction forces, pressure patterns, joint
  forces, moments of force, work, energy and power

3
Temporal Analysis

• Stride time (s)
• Stride rate 1/time (/s)
• Stride cadence 120 rate (b/min)
• Instrumentation
• Photocells and timers
• Videography (1 frame
  1/30 second)
• Metronome

4
Donovan Bailey sets world record (9.835) despite
slowest reaction time (0.174) of finalists
5
Electromyography
Noraxon system
Bortec system
Delsys electrodes
Mega system
6
EMG of normal walking
7
EMG of normal walking
8
EMG of normal walking
rectus femoris
vastus lateralis
tibialis anterior
gastrocnemius
biceps femoris
heel switch
9
EMG of normal walking
rectus femoris
vastus lateralis
tibialis anterior
gastrocnemius
biceps femoris
heel switch
10
EMG of normal walking
rectus femoris
vastus lateralis
tibialis anterior
gastrocnemius
biceps femoris
heel switch
11
Kinematic Analysis

• Linear position
• Ruler, tape measure, optical
• Linear velocity
• radar gun, photo-optical timer
• Linear acceleration
• Accelerometry, videography

radar gun
miniature accelerometers
12
Motion Capture

• Cinefilm, video or infrared video
• Subject is filmed and locations of joint centres
  are digitized

Panasonic videocamera
13
Gait Characteristics - Walking
14
Gait Characteristics Running/Sprinting
15
Motion Capture(e.g., SIMI or Vicon)
16
Passive Infrared Motion Capture (e.g., Vicon or
M.A.C.)
17
Active Infrared Motion Capture

• NDIs Optotrak

18
Gait and Movement Analysis Laboratory

• Motion capture system for marker trajectories
• Force platforms for ground reactions
• Electromyography for muscle activity
• Pressure mapping systems for in-shoe pressure
  patterns

19
3D Geometric Model(Visual3D)
20
Kinetic Analysis

• Causes of motion
• Forces and moments of force
• Work, energy and power
• Impulse and momentum
• Inverse Dynamics derives forces and moments from
  kinematics and body segment parameters (mass,
  centre of gravity, and moment of inertia)

21
Normal Walking Example

• Female subject
• Speed was 1.77 m/s (fast)
• IFS ipsilateral foot-strike
• ITO ipsilateral toe-off
• CFS contralateral foot-strike
• CTO contralateral toe-off

22
Results
Dorsiflexion
Trial 2SFN3
Plantar flexion
Ang. velocity
Moment
Power
Dorsiflexors
Plantar flexors
Concentric
Eccentric
IFS
CTO
CFS
ITO
CFS
ITO
23
Ankle angular velocity, moment of force and power
Dorsiflexion
Trial 2SFN3
Plantar flexion
Ang. velocity
Moment

• Dorsiflexors produce dorsiflexion during swing

Power
Dorsiflexors
Plantar flexors

• Plantar flexors control dorsiflexion

Concentric

• Large burst of power by plantar flexors for
  push-off

Eccentric
IFS
CTO
CFS
ITO
CFS
ITO
24
Knee angular velocity, moment of force and power
Extension
Trial 2SFN3
Flexion

• Negative work by knee flexors to control knee
  extension prior to foot-strike

Ang. velocity
Moment
Power
Extensors
Flexors

• another to cushion weight-acceptance

Concentric

• Negative work by knee extensors to control
  flexion at push-off

Eccentric
IFS
CTO
CFS
ITO
CFS
ITO
25
Hip angular velocity, moment of force and power
10
Flexion
0
Trial 2SFN3
Extension
-10
Ang. velocity

• Positive work by hip flexors to swing thigh
  flex knee

Moment
Power
100
Flexors
0
Power (W) Moment (N.m)
A ng. Vel. (rad/s)
Extensors

• Positive work by hip extensors to extend hip in
  early stance

-100
Concentric
100
0
Eccentric
-100

• Negative work by hip flexors to control extension

IFS
CTO
CFS
ITO
CFS
ITO
-200
0.0
0.2
0.4
0.6
0.8
1.0
1.2
Time (s)
26
Solid-Ankle, Cushioned Heel (SACH) Prostheses
27
Ankle angular velocity, moment of force and power
of SACH foot prosthesis
Dorsiflexing
Trial WB24MH-S
Plantar flexing
Ang. velocity
Net moment
Dorsiflexor
Power

• Power dissipation during weight acceptance and
  push-off

Plantar flexor
Concentric

• No power produced during push-off

Eccentric
ITO
IFS
CTO
CFS
ITO
28
FlexFoot Prostheses(energy-storing)
Original model
Recent models
29
Ankle angular velocity, moment of force and power
of FlexFoot prosthesis
Dorsiflexing
Trial WB13MH-F
Plantar flexing
Ang. velocity
Net moment
Dorsiflexor
Power

• Some energy returned during push-off

Plantar flexor
Concentric
250.
0.
-250.
Eccentric
ITO
IFS
CTO
CFS
ITO
-500.
0.0
0.2
0.4
0.6
0.8
1.0
1.2
Time (s)
30
Above-knee Prostheses
31
Running Prostheses
