MAGNETISM

1
MAGNETISM
Chapter 21
2
Magnetic Levitation Train (Shanghai) Maglev
uses powerful magnets to hold a train a few
millimeters from the track and propel it with
little noise or vibration.
3
Earths Magnetic Field
4
Earths Magnetic Field
5
Properties of Magnets
1. North and South Poles
6
Properties of Magnets
2. Law of magnetic poles
Unlike poles attract
7
Properties of Magnets
2. Law of magnetic poles
Like poles repel
8
LAWS OF ATTRACTION

• LIKE POLES REPEL
• UNLIKE POLES ATTRACT

N S
S N
N S
N S
9
LAWS OF ATTRACTION

• LIKE POLES REPEL

10
Properties of Magnets
Testing a magnet
1. Bring one end of an unknown object to a
suspended magnet. 2. If repulsion occurs, then
the unknown object is a magnet since repulsion
occurs between like poles.
11
Magnetic Induction
Magnetic Induction is the process of inducing
magnetism in an unmagnetised ferromagnetic
material without any contact with the magnet.
12

• Induced Magnetism
• Making of magnetic materials (e.g. steel and
  Iron) into Magnets
• Inducing magnetism in an ordinary piece of
  magnetic material
• Induced magnetism is a temporary process

13
Induced Magnetism
The two iron nails become induced magnets and
show a repulsion between the far ends
14
Induced Magnetism
Repulsion between the two iron nails increases as
a bar magnet is brought towards the nails
15
MAGNETIC POLES

• A magnet is a dipole (two pole)
• There is no monopole (single pole)

16
MAGNETIC POLES

• A magnet is a dipole (two pole)
• There is no monopole (single pole)

17
Magnetic Materials

• Most materials are NOT magnetic
• Naturally occurring magnetic materials are called
  FERROMAGNETIC (Iron-Like)
• FERROMAGNETIC MATERIALS are
• Iron, Steel
• Cobalt
• Nickel
• Alloys of above metals

18
Magnetic Domains
These are small regions in a FERROMAGNETIC
Material where all the magnetic fields of the
atoms are aligned
19
Magnetization
S
N

• If the domains are aligned, the material is
  polarized and becomes magnetized

20
Magnetization
Unmagnetised bar
A magnetised bar
21
Methods of Magnetisation Demagnetisation
Making a magnet by stroking
Single Touch
Divided Touch
22
Methods of Magnetisation Demagnetisation
Making a magnet by stroking
Single Touch
23
Methods of Magnetisation Demagnetisation
Making a magnet by stroking
Single Touch
24
Methods of Magnetisation Demagnetisation
Making a magnet by electrically
25
Methods of Magnetisation Demagnetisation
Making a magnet by electrically
26
Methods of Magnetisation Demagnetisation
Polarity of the magnet determined by
(i) Right-Hand Grip Rule

• Polarity of the
• magnetised specimen

27
Methods of Magnetisation Demagnetisation
Methods of demagnetising magnets

• Heating
• - misalignment of tiny magnets, increase
  vibration
• of atoms
• 2. Hammering

28
Methods of Magnetisation Demagnetisation
Methods of demagnetising magnets
3. Alternating Current
29
Methods of Magnetisation Demagnetisation
Methods of demagnetising magnets
3. Alternating Current
30
Magnetic Fields the Plotting Compass
A magnetic field is the region where a magnetic
force is exerted on any magnetic object placed
within the influence of the field.
31
Magnetic Fields the Plotting Compass
32
Magnetic Fields the Plotting Compass
33
Magnetic Fields the Plotting Compass
34
Magnetic Fields the Plotting Compass
X neutral point
35
Magnetic Fields the Plotting Compass
X neutral point
36
Magnetic Fields the Plotting Compass
37
Earths Magnetic Field
38
Earths Magnetic Field
39
Magnetic Properties ofIron Steel
Question Comment on the magnetic properties of
Iron Steel
40
Magnetic Properties ofIron Steel

41
Magnetic Properties ofIron Steel
Iron (soft Magnet) Steel (Hard Magnet)
Easy to magnetize Can be magnetized by a weak magnetic field Harder to magnetize Required a strong magnetic field to magnetise
Easy to demagnetize Harder to demagnetize
Used in Electromagnets, transformer cores and magnetic shields Good in making permanent magnets and bar magnets

42
Magnetic Field Near A Wire
43
Magnetic Field Near A Wire
44
Magnetic Field Near A Wire
Right-Hand Grip Rule
45
Magnetic Field Near A Wire
46
Magnetic Field Near A Wire
47
Magnetic Field Near A Wire
48
Magnetic Field Near A Wire
Iron Filings around a current-carrying wire
49
Magnetic Field Near A Wire
50
Magnetic Field Near A Loop
Iron Filings around a current-carrying loop
51
Magnetic Field due to a solenoid
52
Magnetic Field due to a solenoid
Iron Filings around a current-carrying coils of
loops
53
Magnetic Field due to a solenoid
54
Magnetic Field due to a solenoid

• The strength of the magnetic field can be
• increased by
• Increasing the current
• Increasing the number of turns per unit length of
  the solenoid
• Using a soft-iron core within the solenoid

55
Magnetic Field due to a solenoid

• Electromagnets are far more useful than
  permanent magnets because
• They can be switched on and off.
• 2. The strength of the magnetic field can be
  changed, by altering the current.
• 3. They can easily be made into a variety of
  shapes and are less expensive to make

56
Uses of electromagnets
The electric Bell
57
Uses of electromagnets
The electric Bell
-The current flows in the coil making an
electromagnet -The armature is attracted to
the core -As it moves, the circuit is broken
at the contact screw.

• -The electromagnet is switched
• off, so the armature moves back.
• The armature keeps vibrating
• back and forth making the
• hammer strike the gong.

58
Uses of electromagnets
Magnetic Relay
Relays are used as safety devices. A large
current circuit can be switched on by a small
current circuit When the small current/voltage
(that is safe) in the input circuit is switched
on, the electromagnet becomes magnetic and
attracts the iron armature. The armature
rotates towards the electromagnet, pushing the
contacts together. This switches on the large
current/voltage (that is dangerous) in the output
circuit. This type of relay circuit is used in
the ignition of a car.
59
Uses of electromagnets
Magnetic Relay
60
Uses of electromagnets
Magnetic Relay
61
Uses of electromagnets
Magnetic Relay
62
Uses of electromagnets
Magnetic Relay
