Alkylation On Graphite: Introduction to Green Technologies

1
Alkylation On Graphite Introduction to Green
Technologies
2
Friedel Crafts Alkylation

• Synthesis of alkyl benzenes from alkyl halides
  and a Lewis acid, usually AlCl3.

3
Friedel Crafts Alkylation

• Reactions of alkyl halide with Lewis acid
  produces a carbocation.
• The carbocation will act as an electrophile.

4
Friedel Crafts Alkylation
5
Limitations of Friedel Crafts Alkylation

• Only alkyl halides can be used (F, Cl, I, Br).
• Aryl halides and vinylic halides do not react
  (their carbocations are too hard to form).

6
Limitations of Friedel Crafts Alkylation

• If you have electron withdrawing group, then
  there wont be any alkylation.

7
Limitations of Friedel Crafts Alkylation

• Multiple alkylations occur because first one
  activate the ring.

8
Limitations of Friedel Crafts Alkylation
Rearrangement of Carbocations are Possible!!!
9
Todays Task

• Alkylation of p Xylene with 2 bromobutane
  using graphite.
• Learn about Green Technologies.
• Characterization by 1H and COSY NMR.

10
Allotropes of Carbon

• Diamond is very strong due to tetrahedral
  arrangement.

11
Allotropes of Carbon

• Graphite is a soft material due to hexagonal
  arrangement.

12
Allotropes of Carbon

• Fullerene and Carbon Nanotubes have similar
  structure to Graphite.

13
Allotropes of Carbon

• Amorphous Carbon does not have any crystalline
  structure like Diamond or Graphite.

14
Why we choose Graphite???

• It is Cheaper.
• Graphite acted as catalyst for
• 1. Friedel Crafts Benzoylation of Aromatic
  Compounds
• 2. Cleavage of Ethers by Acyl Halides.
• Graphite Doped Metal Halides acted as catalyst
  for electrophilic alkylation of aromatic
  compounds.

15
Procedure

• Take 100 mL RB flask and add
• 1. 5 mL of p Xylene.
• 2. 0.44 mL of 2 bromobutane.
• 3. 0.5 gram of graphite.
• Set up a refluxion apparatus and do the refluxion
  for 1 ½ hour.
• Circulate Cold water during refluxion.

16
Procedure

• Cool the reaction mixture to room temperature.
• Filter the graphite using Frit funnel.
• Wash the Graphite with 15 mL of hexane.
• Dry the Graphite in the air for 10 more minutes
  and return to me.

17
Procedure

• Transfer the filtrate into a fresh and dry RB
  flask.
• Evaporate all the solvents using rotary
  evaporator.
• Once you removed all the solvents weigh the
  product (its a liquid).

18
Procedure

• Do the evaporation one more time and weigh the
  product.
• If you get the consistent weight then you
  calculate the percent of yield.
• If you dont get the consistent value, do the
  evaporation till you get consistent weight.

19
Chemical Reaction
20
Mechanism

• Partial Charge on alkyl halide may be produced
  by
• 1. Metal Impurities in the Graphite
• 2. ? electrons in the Graphite
• Formation of the Transition State is still
  Enigmatic.
• Dr. Seradas research group is trying to find the
  exact mechanism and they found reactivity of
  halide in the following order.
• Tertiary Halide gt Secondary Halide.
• No Reaction occurred with Primary Halide

21
Green Chemistry

• By definition
• Green Chemistry is the design, development, and
  implementation of chemical products and processes
  to reduce or eliminate the use and generation of
  substances hazardous to human health and the
  environment.
• Advantages
• 1. Reduce Pollution
• 2. Low Cost
• 3. Simplicity in Process and Handling

22
Green Chemistry Example
Carcinogenic
Dangerous to Handle
Flammable
Synthesis of 1, 8 Dimethoxy 9, 10 -
anthraquinone
23
Green Chemistry

• Why Todays reaction is Environmental Free???
• 1. No need of using strong Lewis Acid catalysts.
• 2. Catalysts can be Reusable.
• 3. Produces Minimum Waste.
• 4. Simple Procedure.
• 5. Low cost.
• 6. No Toxic Reagents.
• 7. High Yield and less by products.

24
Characterization

• 1H NMR and COSY Spectrum.
• COSY (CORRLATED SPECTROSCOPY) is 2D NMR.
• One dimensional NMR involves with only one Radio
  Frequency pulse.
• Where as 2D consists of a sequence of Radio
  Frequency (RF) pulses with delay period of time.

25
Characterization

• Involves a series of one dimensional (1D)
  experiments.
• 1. COSY use to have two 1D 1H NMR spectrum

26
Characterization

• Intensities of the peaks in the spectrum can be
  represented using 3D.
• 1. Contours
• 2. Different Color
• The diagonal peaks are intensities for particular
  signal.

27
Characterization

• Two kinds of peaks are in 2D NMR.
• 1. Diagonal Peak The peaks on the diagonal
  called Diagonal Peaks.
• 2. Cross Peak The peaks off the diagonal
  called Cross Peaks.
• The peaks on the diagonal when matched with
  cross-peaks are coupled each other (means those
  two protons are from adjacent carbon).

28
Cross Peak
Diagonal Peak
29
Characterization

• ID proton NMR can tell about
• 1. Chemical Shift value
• 2. Number of Protons
• 3. Multiplicity
• You cannot easily differentiate between two
  singlet and a doublet using 1D 1H NMR.
• It is not very easy to interpret a complex 1D 1H
  NMR (NMR of Natural Products).
• But COSY helps very well to solve the above
  difficulties.

30
Characterization
Singlet
Doublet

• We have Nine different protons, so we will get
  Nine signals in 1H NMR.
• We are using COSY to differentiate these two
  singlet and doublet

Singlet
31
Notes

• Work Four People together.
• Do not throw the used Graphite.
• Do not contaminate any chemicals.
