Electrospinning: Not just for DJs anymore

1
(No Transcript)
2
Electrospinning Not just for DJs anymore

• Kendra A. Erk
• Advisor Dr. Jeffrey P. Youngblood

REU Final Presentation August 5, 2004
3
Presentation Outline

• Introduction to electrospinning and conducting
  polymers
• Electrospinning observations and results
• Resistance and resistivity analysis
• Summary and future work

4
Electrospinning Basics

• Process by which high static voltages are used to
  produce fibers from a polymer solution
• Micron to submicron diameter
• Fibers have huge SAVolume ratio
• Applications filters, wound dressing, composite
  reinforcement

5
ES Process

• Polymer solution with sufficient viscosity
• High voltages applied to solution
• Fibers deposit on collection target

Rutledge Group, MIT
6
ES Apparatus
7
Conducting Polymers

• synthetic metals which combine chemical and
  mechanical properties of polymers with electronic
  properties of metals
• Easy and inexpensive to make, flexible,
  light-weight, and stable
• Replace metals used in some applications like
  molecular wires in nanostructures

8
Polymers v. Metals
N.J. Pinto
9
My Research Direction

• Original Project Goals
• Electrospin conducting fibers from water-soluble
  conducting polymers or conducting/structural
  polymer blends
• Polyaniline sulfonic acid, 5 wt in water (PAS)
• Polyvinyl alcohol (PVA)
• Examine the effect of polymer blending on
  spinning parameters and conductivity

10
Conducting Polymer PAS

• Early Spinning
• Spun conducting polymer as purchased
• Sufficient viscosity
• Result spray, fibrous chunks

5 wt polyaniline sulfonic acid in water
11
Structural Polymer PVA

• Poly(vinyl alcohol)
• Soluble in water
• Semicrystalline
• Chemically and thermally stable
• Highly biocompatible, nontoxic
• Ribbon fibers formed at low PVA concentrations

1.04 wt PVA in water, 14.96 kV at 26 cm
12
Structural Polymer PVA
5.36 wt PVA, 17.55 kV, 26.5 cm
7.43 wt PVA, 16.68 kV, 26 cm

• Optimal concentration 7.45 wt PVA in water
• Result smooth fibers, d 0.6 3 microns

13
Polymer Blends PAS PVA
14 PASPVA
11.5 PASPVA

• PASPVA ? 10.5 to 14 in 0.5 PVA increments
• Results visible fibers, brown/yellow in color,
  0.6-3 micron diameters, best spun by drops

14
Polymer Blends PAS PVA
11.5

• Best spinning from 11-12.5
• At low PVA conc. fibers bridge to frame, high
  fiber yield
• At high PVA conc. fibers mat to slide, low fiber
  yield

13.5
15
Resistance Analysis of PAS/PVA Blends

• MPJA 9903 Autoranging Multimeter (max 30 MO)
• 1x1 cm thin films
• Electrospun fibers

16
(No Transcript)
17
Summary

• Water-soluble conducting polymer PAS blended with
  PVA was successfully electrospun
• PAS/PVA high yield, smooth, 0.6-3 micron fibers
• For resistance testing, thin films and fibers
  were produced from the various PAS/PVA blend
  ratios
• Resistivity increased with increasing PVA
  concentrations
• Solutions with PVA lt 67 wt produce fibers and
  films more conducting than silicon, a
  semiconductor

18
Future Work

• Try other structural polymers
• Refine electrospinning techniques (capillary
  pump, charged box)
• Isolate specific fibers and use SEM to determine
  more accurate diameters and cross-sectional areas
• Photovoltaic applications

19
Acknowledgements

• Dr. Youngblood and the Y-team
• Ben Eick, John Howarter, Phil Sellenet, Allen
  Mackey, Alicia Certain
• Dr. Kvam and Dr. Trice
• Fellow REU students
• NSF

20
Questions?
