Die Casting

1
Die Casting

• By Jonathan Gordon and Lee

2

• Gravity Die Casting

3
Gravity die casting process

• Mazak, an alloy of Zinc and aluminium, is first
  melted in a crucible furnace.
• Molten metal is then poured by ladle in to an
  open steel mould where it is allowed to cool and
  solidify.

4
Gravity die casting process

• The mould is then turned upside down and tapped
  with a hammer to release the finished casting.
• Gravity die casting requires minimal finishing
  and waste as minimal because excess metal can be
  melted down and used again.

5
Things that you may recognise

• Things that are made from gravity die
  casting are
• Toaster -
• Lawnmowers -
• Car wheel rims -

6
Identifying the process

• When something has been created by gravity
  pressure die casting there would be
• Section hair lines
• ejector pin marks
• sprue and runner marks

7
Materials

• The materials used in gravity die casting is a
  mixture of Zinc and aluminium.
• Zinc -
• Aluminium -

8

• High pressure die casting

9
High Pressure Die Casting

• Forcing metal under high pressure to form a
  mould.
• These moulds are called dies and are made from
  steel.
• This produces non-ferrous metals.

10
Materials used

• Metals that are commonly used are also
• Aluminium -
• Zinc -

11
What is made from the process

• In this process you can make
• Golf club heads -
• Car engine blocks -
• Radiators -

12
High pressure die casting process

•  First the mould is sprayed with lubricant
  and closed.
• Molten metal is then injected into
• the mould under high pressure.

13
High pressure die casting process

• Once the cavity is filled, the pressure is kept
  at a steady level until the casting has become
  solid.
• Finally, the die is opened and the casting
• is injected.

14
Identifying the process

• When something has been created dy high pressure
  die casting there would also be
• Section hair lines
• ejector pin marks
• sprue and runner marks
