Title: AUTOMATIC TRANSMISSION


1
AUTOMATIC TRANSMISSION
  • Presented By,
    Guided By,
  • Muhammed Riyas Gopinathan.V
  • S7MB AsstProf
  • NO103 Dept of Mechanical Engg

2
Introduction
  • Device which changes gear ratios automatically
  • Deliver maximum efficiency
  • Difference between automatic and manual
    transmission
  • Easier to drive because they do not have a clutch
    pedal or gearshift lever
  • There are two type of automatic transmissions

3
CLASSIFICATION
  • AUTOMATIC TRANSMISSIONS USING PLANETARY GEARS
  • CONTINUOUSLY VARIABLE
    TRANSMISSION(CVT)

4
AUTOMATIC TRANSMISSIONS USING PLANETARY GEARS
  • Components
  • PLANETARY GEAR SYSTEM
  • TORQUE CONVERTER
  • HYDRAULIC SYSTEM
  • GOVERNOR
  • COMPUTER CONTROLS

5
  • Sun gear 2. Planet gear 3. Ring gear 4.
    Planetary carrier
  • PLANETARY GEAR SYSTEM

6
PLANETARY GEAR SYSTEM (SIDE VIEW)
7
HOW PLANETARY GEARS WORK
  • Power transfer can only take place when one of
    the members is held at rest or if two of the
    members are locked.

Input Output Stationary Calculation Gear Ratio
A Sun (S) Planet Carrier (C) Ring (R) 1 R/S 3.41
B Planet Carrier (C) Ring (R) Sun (S) 1 / (1 S/R) 0.711
C Sun (S) Ring (R) Planet Carrier (C) -R/S -2.41
Gear Input Output Fixed Gear Ratio
1st 30-tooth sun 72-tooth ring Planet carrier 2.41
2nd 30-tooth sun Planet carrier 36-tooth sun 2.21
2nd Planet carrier 72-tooth ring 36-tooth sun 0.671
2nd Total 2nd 1.471
3rd 30- and 36-tooth suns 72-tooth ring 1.01
OD Planet carrier 72-tooth ring 36-tooth sun 0.671
Reverse 36-tooth sun 72-tooth ring Planet carrier -2.01
8
TORQUE CONVERTOR
  • takes the place of the clutch
  • found on standard shift vehicles
  • large doughnut shaped device that is mounted
  • between the engine and the transmission

  • it uses oil or transmission fluid to transmit
    power
  • three internal elements that work together
  • to transmit power to the transmission.

9
TORQUE CONVERTOR
10
  • THE HYDRAULIC SYSTEM
  • complex maze of passages and tubes that sends
    transmission fluid under under pressure
    to all parts of the transmission
  • and torque converter.
  • Transmission fluid serves in shift control,
    general lubrication and transmission cooling.
  • Keeps the transmission at normal operating
    temperature
  • OIL PUMP
  • VALVE BODY
  • SHIFT VALVES
  • BANDS

11
Gear
pumpOil Pump
  • Produce all the oil pressure that is
  • required in the transmission
  • The oil is then sent, under
  • pressure to the pressure regulator,
  • the valve body and the rest of the
  • components, as required.

12
Valve Body
  • The brain of the automatic transmission
  • Contains a maze of channels and passages that
    direct hydraulic fluid to the numerous valves
  • These valves activate the appropriate clutch pack
    or band servo to smoothly shift to the
    appropriate gear for each driving situation.

13
  • Shift Valves
  • Supply hydraulic pressure to
  • the clutches and bands to
  • engage each gear
  • Determines when to shift from
  • one gear to the next
  • The 1 to 2 shift valves determines when to shift
    from first to second gear.

14
Band
  • A band is a steel strap with
  • friction material bonded to the
  • inside surface.

15
GOVERNER
  • provides the inputs that tell the transmission
    when to shift
  • connected to the output shaft and regulates
    hydraulic pressure based on vehicle speed

16
COMPUTER CONTROLLS
  • Detect such things as throttle position, vehicle
    speed, engine speed, engine load,etc. to control
    exact shift points
  • Downshift automatically when going downhill, to
    control speed and reduce wear on the brakes.
  • Up shift when braking on a slippery surface to
    reduce the braking torque applied by the engine.
  • Inhibit the Up shift when going into a turn on a
    winding road.

17
CONCLUSION
Automatic transmissions contain mechanical
systems, hydraulic systems, electrical systems
and computer controls, all working together in
perfect harmony
18
  • THANK YOU
