E6B Flight Computer

1
E6B Flight Computer
2
(No Transcript)
3
MET Quiz 1
4
(No Transcript)
5
1
TIME SPEED DISTANCE ______ 120 80 ___
___ 85 30 ______ 90 24 ______ 100 45 ______ 7
5 90
6
2

• TIME SPEED DISTANCE
• 15 ______ 24
• 20 ______ 35
• 06 ______ 15
• 30 ______ 45
• 03 ______ 8

7
3

• TIME SPEED DISTANCE
• 25 90 ______
• 45 100 ______
• 30 120 ______
• 10 85 ______
• 15 115 ______

8
4

• AIR TIME FUEL RATE FUEL REQUIRED
• Lbs. /hr. U.S. gal/hr. Lbs. U.S. gal
• 30 30 ______ ______ ______
• 145 50 ______ ______ ______
• 230 ______ 5.0 ______ ______
• 45 ______ 7.0 ______ ______
• ______ 40 ______ 120 ______
• 320 ______ 6.5 ______ ______

9
5

• CARs 602.88 Fuel Reserves
• day-30 minutes night-45 minutes
• A night VFR aircraft flies 120 miles at
• 90 mph burning fuel _at_30 lbs./hr.
• Including reserves, what amount of
• fuel is needed? ______

10
6

• Fuel rate- 50 lb./hr. Trip- 180 miles
• a/s- 120 mph FUEL -______

7
Time/leg- 12 minutes for 18 miles Distance- 90
miles TIME-______
11
8

• Time/leg - 6 minutes for 10 miles
• Fuel rate- 50 lb./hr.
• Distance- 150 miles
• TOTAL FUEL -______

12
ANSWERS Questions 1 to 8
13
1
TIME SPEED DISTANCE 040 120 80 021
85 30 016 90 24 027 100 45 072 or
112 75 90
14
2

• TIME SPEED DISTANCE
• 15 96 24
• 20 105 35
• 06 150 15
• 30 90 45
• 03 160 8

15
3

• TIME SPEED DISTANCE
• 25 90 37.5
• 45 100 75
• 30 120 60
• 10 85 14
• 15 115 29

16
4

• AIR TIME FUEL RATE FUEL REQUIRED
• Lbs. /hr. U.S. gal/hr. Lbs. U.S. gal
• 30 30 __5___ __15_ _ 2.5_
• 145 50 __8.3_ _87.5_ _14.5_
• 230 _30__ 5.0 __75 _ _12.5_
• 45 _42__ 7.0 _31.5_ _52.5_
• 300_ 40 __6.6_ 120 __20 _
• 320 _39__ 6.5 _130 _ _21.6_

17
5

• CARs 602.88 Fuel Reserves
• day-30 minutes night-45 minutes
• A night VFR aircraft flies 120 miles at
• 90 mph burning fuel _at_30 lbs./hr.
• Including reserves, what amount of
• fuel is needed? ______
• 120 statute miles at 90 mph takes 1 hour 20
  minutes or 80 min.
• Night VFR must have another 45 minutes of cruise
  fuel on board.
• Total fuel on board at takeoff must be 80 45
  minutes 125 min.
• 125 minutes of fuel at 30 lb per hour is 62.5 US
  gallons.

18
6

• Fuel rate- 50 lb./hr. Trip- 180 miles
• a/s- 120 mph FUEL -______
• 180 miles at 120 mph takes 90 min. 90 minutes of
  fuel use at 50 lb/hr is 75 pounds. 75 lb. of
  fuel is 12.5 US gallons.

7
Time/leg- 12 minutes for 18 miles Distance- 90
miles TIME- __1 hour_
19
8

• Time/leg - 6 minutes for 10 miles
• Fuel rate- 50 lb./hr.
• Distance- 150 miles
• TOTAL FUEL -______
• 6 min. for 10 miles is 100 mph. 150 miles at 100
  mph is 1 hour and 30 minutes. At 50 lb/hr this
  requires 75 pounds. 75 lb. of avgas is 12.5 US
  gallons.
