Classification of Immunosuppressants

1
(No Transcript)
2
??? ???? ?????? ??????
3
Kidney Transplantation

• Dr. Anmar Nassir, FRCS(C)
• Canadian board in General Urology
• Fellowship in Andrology (U of Ottawa)
• Fellowship in EndoUrology and Laparoscopy
  (McMaster Univ)
• Assisstent Prof Umm Al-Qura
• Consultant Urology King Faisal Specialist
  Hospital

4
Kidney Transplantation Objectives

• Why transplantation?
• Types of transplantations
• Assessment of transplant recipient and donor
• Transplant immunology
• Immunosuppressants
• Complications
• New advances in transplantation
• Challenges

5
ESRD Incidence PMP
6
Incidence of ESRD KSA
PMP
Fourth Urology Course KAUH, 2004
7
ESRD Modality of Treatment in USA
8
Modality of Renal Replacement Therapy in KSA
2001
9
Performed Cadaveric Renal Transplant in KSA
10
Kidney Transplantation Why?

• Better quality of life
• Restoring healthy productive life
• May restore sexuality and fertility
• Dialysis-associated morbidity
• Access problems and other infections
• Bone disease and dialysis-associated amyloidosis

• Lower mortality

11
ESRD Mortality
12
ESRD Risk of Death
13
Kidney Transplantation Why?Special Reasons in
KSA

• Increasing number of ESRD patients.
• Negative image of dialysis.
• High Incidence and prevalence of HCV infection.
• Poor dialysis therapy inadequacy.
• Improper treatment of anaemia and bone disease.

14
Causes of Morbidity and Mortality

• Hemodialysis
• Access problems
• Blood Stream Infection
• HCV
• Bone disease
• Dialysis-associated amyloidosis
• Acquired cystic diseases RCC
• IHD

• Peritoneal Dialysis
• CAPD peritonitis
• Loss of Peritoneal membrane
• Hyperglycaemia
• Hyperlipidemia
• Acquired cystic diseases RCC
• IHD

15
ESRD HCV-Ab Status in HD Patients in KSA
16
HCV in HD Population in KSA
17
Kidney Transplantation Types

• Living-related
• Cadaveric
• Emotionally-related
• Living-non-related

18
(No Transcript)
19
Allograft
Hx Background

• In 1933 the 1st Renal allograft by Voronoy in
  Ukraine

• (homograft)
• Genetically disparate individuals of the same
  species

20
Transplant Immunology Components of Immune
System

• Antigen presenting cells (APC)
• Macrophages dendritic cells, Langarhans cells
  vascular cells
• T lymphocytes
• CD4 (helper T cells)
• CD8 (suppressor or Cytotoxic T cells)
• B lymphocytes (antibody-forming)

21
What can happen ?
22
Graft destruction
Ag specific graft-destructive T-cell
Complement-dependent cell-mediated cytotoxicity
Effector T-cell NK cell stimulated by
granzyme B perforin IL-2 IL-10 plays
important role
IFN-g TNF-a up-regulating HLA molecules
co-stim (B7) upon graft APCs
Ab-dependent cell-mediated cytotoxicity
23

• In 1954 the 1st long term renal transplant in
  Boston

HOW ?
24
(No Transcript)
25
Isograft
26
Then.

• 1958 1st histocompatibility Ag was described
• 1969 radiation was used

27
What is this coming drug?
28
(No Transcript)
29
Azathioprine(Imuran)
Became available for human use in 1951
?
30
ImmunosuppressantsAzathioprine

• Imidazole analogue
• Purine antagonist thus inhibiting cellualr
  proliferation
• Poorly selective (suppress all cells population)
• Dose 1-2mg/kg/day
• Allopurinol blocks its catabolism

Fourth Urology Course KAUH, 2004
31
ImmunosuppressantsAzathioprine, Complications

• Bone marrow suppression usually one cell line
  (especially with allopurinol)
• Granulocytopenia
• Red cell aplasia
• Isolated thrombocytopenia

Fourth Urology Course KAUH, 2004
32
Prednisone
Became part of therapy w AZA in 1962
?
33
ImmunosuppressantsCorticosteroids

• Maximal effect on macrophages lymphocytes
• Inhibits cytokines gene transcription
• Inhibit IL-1, IL-2, IL-6
• Inhibits INF-gamma TNF
• This will lead to inhibition of T cell
  proliferation
• Used as maintenance therapy (PO) and as a
  treatment for acute rejection (IV)

Fourth Urology Course KAUH, 2004
34
Then .

• 1962 tissue matching
• 1966 direct cross match

35

• The strongest of the Tx Ag is the expression of a
  single chromosomal region called MHC
• large gene that control traits which influence
  the entire immune response
• located on chromosome 6
• the gene products of MHC were first investigated
  on leukocyte named HLA

Many Ag can serve as histocompatibility
Ag ABO Xenografts
36

• Can be detected on the cell surface of almost all
  nucleated cells
• The best trigger of the proliferation of
  allogenic lymphocytes

• Only on the cells of immune system mac. dend.
  B, activated T
• Not as strong

• On each chromosome 6 there are 6 genetic loci ,
  and on each pair there are 12 loci

37
HLA Major Histocompatibility Complex (MHC)
Chromosome 6
A B C
Class I
DP DQ DR
Class II
A B C
Class I
DP DQ DR
Class II
38
HLA Mendelian Transmission
Father
Mother
DR01 DP43 DQ7
A03 B14 C28
DR20 DP19 DQ31
A14 B8 C24
DR05 DP12 DQ 03
A18 B53 C11
DR22 DP18 DQ20
A31 B22 C10
1
5
4
3
2
A31,B22,C10 DR5, DP12,DQ3
A14, B8, C24 DR1,DP43,DQ7
A14, B8, C24 DR1,DP43,DQ7
A03, B14, C28 DR5, DP12, DQ3
A18, B53, C11 DR20, DP19, DQ31
39
(No Transcript)
40
T-cell Activation
APC
IL-2
T Cell
Nucleus
41
MHC/Ag
APC
IL-2
T Cell
IL-2R
Nucleus
Calcineurin
G0
42
B-cell stimulation

• T-cell derived IL-2, IL-4
• Physical contact w T-cell

43
(No Transcript)
44
First Cadaveric LRD (non-identical)

• Intra-op
• Methylprednisolone
• CyA
• Post-op
• CyA--gt Neoral
• MMF
• Prednisone

45
First Cadaveric LRD (non-identical)

• Out pt
• Neoral
• Prednisone
• Taper gradually
• MMF
• Maintain for 1 yr, then D/C
• Switch to Azatioprine if concern about rejection

46
Repeated Tx

• (Same protocol as 1st Tx)
• Polyclonal Ab (ALG)
• should be started in RR
• Few days then start Neoral
• Most pts will remain on CyA, MMF, Pred.

47
First Living related (HLA identical)

• Same protocol as above w/o MMF (or Azathioprine)

48
Therapy of rejection

• Prednisone pulse therapy
• 500 mg--10 mg / 9 days
• Sever or Steroid resistant
• Monoclocal OKT3 for 14 days
• Polyclonal ATG, ALG

49
There are 4 key needs which, if not met, could
marginalize Tx as a form of therapy

• 1-Achieving optimal immunosuppression
• 2-Overcoming chronic rejection
• 3-New therapeutic targets
• 4-Increasing the of organ donation

50
2-Overcoming chronic rejection

• Immune factors
• Non-immune factors

51
Immune factors

• Multifactorial
• Needs more Ix of
• endothelial cell activation
• expression of adhesion molecules
• cytokines
• chemokinse

52
Rapa
?
53
Sirolimus (Rapamycin) Side Effects

• Hyperlipidemia
• Impair wound healing
• More potent Immunosuppression when combined with
  CNI
• Pneumonitis
• Thrombocytopenia
• Hypokalemic
• Early vascular thrombosis

Fourth Urology Course KAUH, 2004
54
Rapamycin

• It is a macrocylic ABx produced by Streptomyces
  hygroscopicus
• binds to
• FKBP
• TOR1 TOR2

55
MHC/Ag
APC
IL-2
T Cell
IL-2R
Nucleus
Calcineurin
G0
56
RAPA
FKBP
P70 S6 pr kinase
57
Immunosuppressantsrapamycin (Sirolimus)

• Macrolide analogue
• It binds to FKBP (TOR) but does not inhibit
  calcineurin
• It has different mechanism of action than CSA and
  tacrolimus
• It inhibits growth factor cell transduction
• No nephrotoxicity

58
Non-immune factors

• Its implication concerns clinical groups across
  the world
• Only 25-30 of R.Tx are normotensive
• Causes are multifactorial
• angiotensin system
• can be worse w hyperlipidemia

59
3-New Therapeutic Targets

• Tolerance
• Gene therapy
• Complement inhibition

60
Tolerance

• specific absence of an immune response to an
  Ag.
• but may also involve active immune response !
• 1-clonal deletion
• 2-clonal ignorance
• 3-active suppression

61
Donor B.M. infusion in renal Tx
62
4-Increasing Of Organ Donors

• Live donation
• education
• 3yrs f/u of 134 pt revealed
• 1.3 morbidity
• No mortality
• Better results in term of graft survival
• non-heart beating
• Xenotransplantation

Melchor, 1998
63
(No Transcript)
64
Xenograft

• (hetrograft)Between different species (animal to
  human)

65
Ethical issues

• Potential recipient
• Psychological stress
• Risk of xenozoonoses

66
1-Achieving optimal immunosuppression

• ?

67
Antilymphocyte

• ALG
• ATGAM
• Thymoglobulin

?
68
OKT3
?
69
Antibody Therapy

• Types
• Monoclonal e.g. OKT3
• Polyclonal e.g. ATG
• M/A
• Indications
• Induction
• Steroid-resistant rejection
• Side effects

70
Ag
Myeloma
B-cell
Hybridoma
Cloning
Mono Clonal Abx
71
MHC/Ag
B7
APC
OKT3
IL-2
T Cell
CD28
TCR/CD3
IL-2R
Nucleus
Calcineurin
G0
IL2 gene
72
TCR/CD3
73
CyA
K
?
74
ImmunosuppressantsCyclosporine A

• Inhibit cell growth by inhibiting of gene
  transcription of IL-2
• It binds with cytoplasmic receptor protein
  (cyclophillin)
• CSA-cyclophillin complex binds with Calcineurins
  and inhibits its phosphatase activity
• This will lead to inhibition of IL-2 gene
  transcription subsequently IL-2 production

Fourth Urology Course KAUH, 2004
75
Cyclosporine
Achieving optimal immunosuppression

• The introduction of CyA in 1980s established Tx
  as a routine procedure.
• Fungal peptide
• M/A
• Effect reversible specific for T-lymphocyte
• Side effects

76
MHC/Ag
APC
IL-2
T Cell
IL-2R
Nucleus
Calcineurin
G0
77
FK 506(Tacrolimus)
K
?
78
ImmunosuppressantsFK506 (Tacrolimus)

• Inhibit cell growth by inhibiting of gene
  transcription of IL-2
• It binds with cytoplasmic receptor protein (FKBP)

• FK506-FKBP complex binds with calcineurin and
  inhibits its phosphatase activity
• This will lead to inhibition of IL-2 gene
  transcription subsequently IL-2 production

Fourth Urology Course KAUH, 2004
79
ImmunosuppressantsCyclosporine A FK506 Use

• CSA
• Maintenance Immunosuppressants for all organ
  transplant
• Dose 4-8mg/kg/day in divided doses
• Tacrolimus (FK506) 0.15-.3mg/kg
• For female patients
• Rescue therapy for renal transplant
• High immunogenicity

Fourth Urology Course KAUH, 2004
80
Immunosuppressantsdifferences Between
Cyclosporine A Tacrolimus

• Cyclosporine
• More gingival hyper-plasia
• More hirsuitism
• More Hepato-toxic

• Tacrolimus
• More potent than CSA
• More neurotoxicity
• Allopecia
• Hyperglycaemia (25 Vs 4 for CSA)

Fourth Urology Course KAUH, 2004
81
MHC/Ag
APC
IL-2
T Cell
IL-2R
Nucleus
Calcineurin
G0
82
MMF(Cellcept)
?
83
MHC/Ag
APC
IL-2
T Cell
IL-2R
Nucleus
Calcineurin
G0
84
Immunosuppressants

• Site of action
• Classifications
• Immunosuppressants and their side effects
• Adjuvant therapy

85
(No Transcript)
86
Immunosuppressants Classification

• Inhibitors of transcription
• Corticosteroids (IL-1, IL-2, IL-3, IL-6,
  TNF-alpha, gamma-interferon)
• CSA IL-2
• FK506 (tacrolimus) IL-2
• Inhibitors of growth factors signal Transduction
• Rapamycin (sirolimus) IL-2

87
Inhibition of Gene Transcription

• Azathioprine
• Broad myelocytic suppressant (poorly selective)
• Inhibit T-cell proliferation

88
Inhibition of Gene Transcription

• Mycophenolate mofetil (MMF) Cellcept
• Selective lymphocyte suppressant
• Down-regulate the expression of adhesion
  molecules
• Mycophenolate salt (MPS) Myofortic
• Selective lymphocyte suppressant
• Less GI symptoms ?
• More potent ?

89
Kidney Transplantation Workup of Recipient

• Comprehensive history and physical
• Biochemistry tests
• CBC
• HBsAg, HCV-Ab, HIV, CMV, EBV
• PPD
• EKG, Echo, stress test, coronary catheterisation
• CXR, US abdomen and pelvis , Mammogram, MRI and
  VCUG
• Dental, cardiology, urology, GI and ID
  consultations

90
Transplant Workup of the Recipient
History Physical
Radiological Assessment
Laboratory Tests
Consultations
-Full detailed History -The cause of ESRD
-History of TB Examination
-Detailed examination -Examination of
Peripheral blood Vessels
-Cardiopulmonary and CNS assessment

-CBC Differential -PT. PTT
-Urea, Creatinine , And
Electrolytes -Calcium, phosphate
Alkaline phosphate -Liver enzymes,
Bilirubin, protein, alb. -Urine analysis, 24 h
alb. -HCV, HBsAg, HIV -CMV, EBV,HSV,
-Toxoplasma. PPD
-CXR, US abdomen -US Pelvis -EKG,
Echo -Stress test
-Coronary Angiogram -MRA or Angiogram If
indicated -CT scan if indicated -VCUG if
indicated
-Cardiac consultation -Dental check up
-Gynaecologic assessment in
female -ID consultation if Indicated
-Urologic consultation -Psychiatric
consultation if indicated
91
Kidney Transplantation Contraindication to Tx.

• Active infection Bacterial, TB, HCV, CMV
• Malignancies
• Active auto-immune disease
• High cardiac risk
• High operative risk
• Pregnancy

92
Kidney Transplantation Workup of the Donor

• Same as recipient plus
• Three 24 hour urine collections for protein and
  Creatinine clearance
• Three urine sediment exam
• Renal Angiogram or MRA
• Psychiatric consultation

93
Transplantation Pre-Tx. Match

• ABO match
• As preformed natural anti-a, or anti-b abs will
  cause accelerated rejection
• HLA match
• Lymphocyte match
• Circulating preformed Abs against major HLA
  (donors class-i HLA) cause hyperacute rejection

94
Kidney Transplant Complications

• Hypertension
• Metabolic abnormalities
• DM and hyperglycemias
• Hyperlipidemia
• Hyper hypokalemia, hypomagnesaemia
• RTA
• Hyperuricemia
• Hypophosphatemia
• Osteoporosis

95
Transplant Complications

• Gastro-intestinal tract
• Peptic ulcer disease
• Pseudo-membranous colitis
• CMV colitis
• Pancreatitis
• Polycythemia

96
Transplant Complications(Continued)

• Long and short term complications
• Malignancies
• Cardiovascular CAD
• HTN , DM Immunosuppressants
• Renal artery Stenosis
• Obesity

97
(No Transcript)
98
Infectious Complications of Transplantation
0-3 weeks Usual infections
1-6 months Opportunistic

• 6 months
• Community-acquired

• Wound infections
• UTI
• Line-related infections
• HSV
• Oral candida

• -CMV
• -VZV
• EBV
• PCP
• Hepatitis
• Nocardia
• Listeria
• TB

• - CMV
• -TB
• Papilloma virus
• Other community-acquired infections

99
(No Transcript)
100
Transplant Complications Malignancies

• Cancer (1.6).
• Skin cancer (squamous cell ca, basal cell ca
  melanoma).
• PTLD.
• NHL.
• EBV-related lympho proliferative syndrome.
• Reticulum cell sarcoma.
• Caposis sarcoma.
• Others kidney, GU etc...

101
Renal Transplant Rejection

• Hyperacute rejection
• Acute Rejection
• Cellular
• Vascular
• Chronic rejection

102
(No Transcript)
103
(No Transcript)
104
(No Transcript)
105
(No Transcript)
106
Causes of Morbidity and Mortality

• Dialysis
• Access problems
• Line-related sepsis
• HCV
• Anaemia
• Bone disease
• Dialysis-associated amyloidosis
• IHD

• Transplantation
• IHD
• DM and hyperlipidemia
• Osteoporosis
• Opportunistic infections
• Malignancies
• PTLD
• Skin cancer
• Osteoporosis

107
(No Transcript)
108
Kidney Transplantation Challenges

• Over or under-immune suppression
• Individualization and minimization
• Chronic Rejection and Tx Glomerulopathy
• CNI avoidance
• New agents
• Immune tolerance
• IHD
• More aggressive approach to co-morbid conditions
• Hyperlipidemia and DM

109
Future of Transplantation

• Individualization and Minimization
• Immune tolerance
• New agents
• Gene therapy
• Xeno-transplantation

110
Thank you
111
(No Transcript)
