Band Loop Space Maintainer

1
Band Loop Space Maintainer

• Jabbarifar Pedo- Technique Lab
• 2009

2
Progression of Skills
Space Maintainer
Flame Soldering
Wire Bending
3
Background Information

• The most common situation requiring the use of a
  band loop space maintainer is the premature loss
  of a first or second primary molar.

4
What You Need Today!

• your patient (maxillary model)
• 14 metal impression tray
• green stick compound
• alginate (provided)
• band adapter/band seater/band removing pliers
  (optional)
• bird beak, 3 prong, wire cutters
• soldering materials
• molar band (RU 34)

5
Band Selection

• Select smallest band that will fit over the
  height of contour of the tooth
• First seat band with digital pressure

6
Band Adaptation

• Utilizing band seater with the lead peg on the
  occlusal margin of the band fully seat the band

7
Band Adaptation

• Utilizing the band adapter adapt margins to the
  tooth morphology

8
Properly Adapted Molar Band

• Occlusal margin of band is apical to the proximal
  ridges
• Gingival margin of the band is in the gingival
  sulcus
• Band is snugly adapted to the tooths surface
• Band is out of occlusion

9
Band Removal

• Utilize the band removing pliers
• Pliers have a plastic covered knob which is
  placed on the occlusal surface of the tooth and
  the sharp lower edge is placed under the gingival
  margin of the band
• Pliers are squeezed which raises the band onto
  the upper beak of the pliers

10
Compound Index

• Make compound index
• lubricate tooth
• do not overheat compound
• Compound index should completely cover occlusal
  surface of band, extending 2mm past the band
• if index is too large it will be dislodged when
  impression tray with alginate is placed

11
Alginate Impression

• Take alginate impression
• Compound index should come off tooth and be
  embedded in the alginate impression
• Check that the occlusal margin of the band is
  clearly reproduced
• Remove band and orient in compound index
• Stabilize band with sticky wax
• on buccal and lingual at the occlusal aspect of
  band

Sticky Wax
12
Pour Impression

• Use white plaster
• if you are going to abrade cast might want to use
  stone
• Prepare flat base so that cast does not rock
  during fabrication of appliance

13
Draw Design of Band Loop Space Maintainer on Cast

• The mesial end of the loop contacts the distal
  surface of the first primary molar at a point
  just below the height of contour
• The wire should be above the gingiva at the point
  of contact with the abutment tooth

14
Design of Band Loop Space Maintainer

• The central portion of the loop is shaped wide
  enough to allow the full eruption of the
  permanent tooth
• the bucco-lingual width of a maxillary premolar
  is 9mm
• The loop should be contoured to follow the
  edentulous ridge, but 1mm off the tissue
• The anterior curve of the loop is shaped to
  approximate the shape of the distal surface of
  the abutment tooth and to match its width

15
Bending the Wire

• Cut about a 3 inch segment of .036 wire
• At the midpoint of the wire make a w shaped
  curve

16
Check Anterior Curve

• Check the curve against the abutment tooth on the
  cast to see that it is approximately the width of
  the first primary molar and does not extend
  beyond the disto-buccal line angle

17
Lowering the Sides

• Position the pliers with the single beak on the
  gingival surface of the wire under the center of
  the w shaped curve
• Squeeze pliers gently

18
Check Resultant Bend
19
Mesial End of Distal Legs

• Form a gradual curve to parallel the gingival
  crest of the alveolar ridge by walking the 3
  prong pliers distally over the wire
• Complete one leg before proceeding to other leg

20
Mesial End of Distal Legs

• Continue bending in small increments until the
  desired arc is achieved
• The wire should be approximately 1mm off the
  tissue

21
Step Bend

• Mark wire far enough mesially to allow the
  finished s-bend to be completed before reaching
  the band.

22
Step Bend

• Place the conical beak of the bird beak pliers on
  the occlusal portion of the wire and bend the
  distal portion of the wire upward against the
  conical beak

23
Step Bend

• Place the conical beak of the bird beak pliers on
  the gingival portion of the wire and bend the
  distal portion of the wire downward against the
  conical beak

24
Step Bend

• Purpose of S-bend
• allows transition of wire from the ridge to band
  without impinging on the gingival tissues

25
Distal Ends

• Bend distal ends of loop to rest passively
  against the junction of the middle and occlusal
  third of the clinically exposed band

26
Distal Ends

• Use simple bends to contour the wire so it
  contacts the band near the mesial line angle and
  remains in contact for the full length of the
  band
• Cut away any excess wire or plaster that
  interferes with fitting

27
Completed Wire
28
Completed Wire
29
Prepare to Solder

• Stabilize the wire in position on the cast with
  wax
• Wet anterior end of cast to prepare it for the
  application of plaster which will be used to
  secure the loop
• Apply creamy mix of quick setting plaster

Plaster
Wax
30
Prepare to Solder

• When plaster has reached its initial set, remove
  sticky wax
• Remove the plaster from the inside of the bands
  adjacent to the soldering sites
• Remove all particles of wax, plaster and debris
  from soldering site

Plaster
31
Criteria for Solder

• The solder
• encircles the wire
• extends the full length of the contact area
  between the wire and the band
• The occlusal and gingival margins of the band are
  free of solder
• The surface of the solder joints are free of
  pitting and voids
• The wire mesial to the solder joints has not been
  annealed

32
Polishing

• Use a heatless stone to reduce the distal ends of
  wire to form to a smooth curve continuous with
  the band
• The ideal solder joint is concave
• If a minimum of solder has been used, the joints
  will be concave and solder will not extend to the
  margins of the band
• Appliance is finely polished, cleaned and dried

W
Band
Distal Cross-section
33
Summary

• With correct diagnosis and implementation of wire
  bending and soldering techniques, the potential
  problems associated with premature loss of a
  primary molar can be successfully averted.

34
