Active Noise Cancellation

1
Active Noise Cancellation

• Dr. Farrukh
• Department of Electrical Electronics
  Engineering,
• College of Engineering,
• University Tenaga Nasional,
• Jalan Kajang-Puchong,
• 43009 Kajang,
• Selangor, MALAYSIA.
• Farrukh_at_uniten.edu.my

2
Description of paper

• Use of TMS320C5402 DSK-single TMS320C6701 EVM
  dual channel channel Active Noise Cancellation in
  duct system
• Uses feedback feedforward topology -designed to
  cancel narrowband periodic tones.

3
Problem Description!!!!
What is Noise ?????

• Unwanted sound that
• is often loud and irritating
• Industrial equipment
• Damaging to human from both
• a physical and psychological aspect

Active Noise Cancellation???
Reason
4
How does Active Noise Cancellation (ANC) works ?

• Identical and in phase
• Volumes increases

• Out of phase
• Volumes decreases

Active noise cancellation

• Basic principles by introducing a canceling
  anti-noise signal that has the same amplitude but
  the exact opposite phase and resulting a
  reduction noise signal

5
Approaches of ANC
Hardware

• Feedforward Topology
• Reference noise and
• cancelled noise are used
• 2 inputs and 1 output

• Feedback Topology
• only cancelled noise
• are used one input and one output
• Use of TMS320C5402 DSK-single
• channel Active Noise Cancellation
• in duct system

6
Feedback Topology
Hardware
x(n)
e(n)

• to estimate primary
  noise and use it as a reference

X(z) E(z) S(z)Y(z)
Duct system
y(n)

• Need to estimate the secondary path transfer
  function

W(z)
S(z)
L MS
y(n)
x(n)
DSP System
7
Feedback Experimental Setup-ANC
Hardware
Noise loudspeaker
S(z)
x(n)
e(n)
Amplifier
Secondary Path
IN
OUT
y(n)
LMS Algorithm
DSP TMS320C5402 DSK
8
Feedforward Topology
x(n)

• Coherent input is captured, filtered and feed
  into LMS

e(n)
d(n)
Primary function, P(z)
y(n)
Secondary Path,S(z)
Duct system

• Estimation of the secondary path transfer
  function is obtained by identification process

y(n)
W(z)
Estimation of S(z), S(z)
LMS
e(n)
x(n)
DSP System
9
Feedforward Experimental Setup
Hardware
Canceling zone
Noise speaker
microphone
x(n)
S(z)
e(n)
Secondary Path
Input noise
y(n)
Canceling speaker
Amplifier
TMS320C6701 EVM DSP
10
Least Mean Square (LMS) Algorithm
Software
11
Secondary path S(z) duct modeling
Result of identification of the secondary path
12
Single channel cancellation results
Input Frequency 120Hz
13
(No Transcript)
14
Cancellation result on 7080100110120130Hz
15
Dual Channel cancellation Results
Input Frequency 80Hz
No cancellation With cancellation
16
Input Frequency 4070Hz
17
Cancellation result on 40 70 80Hz
18
Conclusions

• ANC was first time attempted in Malaysia and
  obtained compatible results.
• Integrated programming of DSP was achieved
  without any external aid or training.
• This work yields Masters thesis and research
  papers accepted by local and international
  conferences.
• The expertise developed is now being shared with
  other groups, projects and laboratory work in COE.

19
Future Scope

• Acoustic wave propagation in duct boundary is
  investigated with PDE Finite Element method will
  be the future direction
• Boundary value conditions at the exhaust of duct
  can be studied with FEM
• Build dedicated DSP hardware for embedded
  standalone ANC system
• PCB for audio amplifiers and speakers are needed
  for mobility of test rig

20
FINITE ELEMENT METHOD ANALYSIS OF DUCT SYSTEM
21
ACCOUSTIC ENERGY INSIDE THE DUCT
22
The end
