1
 Crystallographic Point Groups

•  Elizabeth Mojarro
• Senior Colloquium
• April 8, 2010

2
Outline

• Group Theory
• Definitions
• Examples
• Isometries
• Lattices
• Crystalline Restriction Theorem
• Bravais Lattices
• Point Groups
• Hexagonal Lattice Examples
• We will be considering all of the above in R2 and
  R3

3
Groups Theory Definitions

• DEFINITION  Let G denote a non-empty set and let
  denote a binary operation closed on G. Then
  (G,) forms a group if
• (1) is associative (2) An identity element e
  exists in G (3) Every element g has an inverse
  in G
• Example 1 The integers under addition. The
  identity element is 0 and the (additive) inverse
  of x is x.
• Example 2 R-0 under multiplication.
• Example 3 Integers mod n. Zn 0,1,2,,n-1.
• If H is a subset of G, and a group in its own
  right, call H a subgroup of G.

4
Group Theory Definitions

• DEFINITION Let X be a nonempty set. Then a
  bijection f X?X is called a permutation. The set
  of all permutations forms a group under
  composition called SX. These permutations are
  also called symmetries, and the group is called
  the Symmetric Group on X.
• DEFINITION Let G be a group. If g ? G, then
  ltggtgn n ? Z is a subgroup of G. G is called
  a cyclic group if ?g ? G with Gltggt. The element
  g is called a generator of G.
• Example Integers mod n generated by 1. Zn
  0,1,2,,n-1.
• All cyclic finite groups of n elements are the
  same (isomorphic) and are often denoted by
  Cn1,g,g2,,gn-1 , of n elements.
•

5
Other Groups

• Example The Klein Group (denoted V) is a
  4-element group, which classifies the symmetries
  of a rectangle.

6
More Groups

• DEFINITION A dihedral group (Dn for n2,3,) is
  the group of symmetries of a regular polygon of
  n-sides including both rotations and reflections.

• n3
  n4

7

• The general dihedral group for a n-sided regular
  polygon is
• Dn e,f, f2,, fn-1,g,fg, f2g,,fn-1g, where
  gfi f-i g, ?i. Dn is generated by the two
  elements f and g , such that f is a rotation of
  2p/n and g is the flip (reflection) for a total
  of 2n elements.

f
8
Isometries in R2

• DEFINITION An isometry is a permutation ? R2
  ? R2 which preserves Euclidean distance the
  distance between the points of u and v equals the
  distance between of ?(u) and ?(v). Points that
  are close together remain close together after ?.

9
Isometries in R2

• The isometries in are Reflections, Rotations,
  Translations, and Glide Reflections.
•

10
Invariance

• Lemma The set of all isometries that leave an
  object invariant form a group under composition.
•  Proof Let L denote a set of all isometries
  that map an object B?B.
• The composition of two bijections is a bijection
  and composition is associative.
• Let a,ß ? L.

• aß(B) a(ß(B))
• a(B) Since ß(B)B
• B
• Identity The identity isometry I satisfies
  I(B)B and Ia aI a for ?a? L.
• Inverse
• Moreover the composition of two isometries will
  preserve distance.

11
Crystal Groups in R2

• DEFINITION A crystallography group (or space
  group) is a group of isometries that map R2 to
  itself.
• DEFINITION If an isometry leaves at least one
  point fixed then it is a point isometry.
• DEFINITION A crystallographic group G whose
  isometries leave a common point fixed is called a
  crystallographic point group.
• Example D4

12
Lattices in R2

• Two non-collinear vectors a, b of minimal length
  form a unit cell.
• DEFINITION If vectors a, b is a set of two
  non-collinear nonzero vectors in R2, then the
  integral linear combinations of these vectors
  (points) is called a lattice.
• Unit Cell Lattice

13
Lattice Unit Cell

• Crystal in R2 superimposed on a lattice.

14
Crystalline Restriction Theorem in R2

• What are the possible rotations around a fixed
  point?
• THEOREM The only possible rotational symmetries
  of a lattice are 2-fold, 3-fold, 4-fold, and
  6-fold rotations (i.e. 2p/n where n 1,2,3,4 or
  6).

15
Crystalline Restriction Theorem in R2

• Proof Let A and B be two distinct points at
  minimal distance.
• Rotate A by an angle a , yielding A

Rotating B by - a yields
Together the two rotations yield
B
r
r
r
-a
a
A
B
16
Possible rotations

• Case 1 r'0

• Case 2 r' r

a p/3 2p/6
a p/2 2p/4
Case 3 r' 2r
Case 4 r' 3r
a p 2p/2
a 2p/3
17
Bravais Lattices in R2

• Given the Crystalline Restriction Theorem,
  Bravais Lattices are the only lattices preserved
  by translations, and the allowable rotational
  symmetry.

18
Bravais Lattices in R2 (two vectors of equal
length)
Case 1 Case 2
19
Bravais Lattices in R2 (two vectors of unequal
length)
Case 1
Case 2
Case 3
20
Point Groups in R2 Some Examples

• Three examples

Point groups C2, D3 , D6, C3 , C6 , V
Point groups C2, C4 , D4
21
C3
22
Isometries in R3 (see handout)

• Rotations
• Reflections
• Improper Rotations
• Inverse Operations

23
Lattices in R3

• Three non-coplanar vectors a, b, c of minimal
  length form a unit cell.
• DEFINITION The integral combinations of three
  non-zero, non-coplanar vectors (points) is called
  a space lattice.
• Unit Cell Lattice

24
Bravais Lattices in R3

• The Crystalline Restriction Theorem in R3 yields

• 14 BRAVAIS LATTICES in
• 7 CRYSTAL SYSTEMS
• Described by centerings on different facings
  of the unit cell

25
The Seven Crystal Systems Yielding 14 Bravais
Latttices
Triclinic Monoclinic Orthorhombic
Tetragonal Trigonal Orthorhombic
26
Hexagonal Cubic
27
Crystallography Groups and Point Groups in R3

• Crystallography group (space group)
• (Crystallographic) point group
• 32 Total Point Groups in R3 for the 7 Crystal
  Systems

28
Table of Point Groups in R3
Crystal system/Lattice system Point Groups (3-D)
Triclinic C1, (Ci )
Monoclinic C2, Cs, C2h
Orthorhombic D2 , C2v, D2h
Tetragonal C4, S4, C4h, D4 C4v, D2d, D4h
Trigonal C3, S6 (C3i), D3 C3v, D3d
Hexagonal C6, C3h, C6h, D6 C6v, D3h, D6h
Cubic T, Th ,O ,Td ,Oh
29
The Hexagonal Lattice
30
1,6?6,5
31
1,6?5,4 5,4?12,11
32
1,6?6,5 6,5?13,12
33
1,6?6,5 6,5?13,8
34
1,6?5,4 5,4?8,9 8,9?1,2
35
1,6?6,5 6,5?8,13 8,13?6,1
36
1,6? 6,5 6,5?2,3
37
Boron Nitride (BN)
38
Main References

• Boisen, M.B. Jr., Gibbs, G.V., (1985).
  Mathematical Crystallography An Introduction to
  the Mathematical Foundations of Crystallography.
  Washington, D.C. Bookcrafters, Inc.
• Crystal System. Wikipedia. Retrieved (2009
  November 25) from http//en.wikipedia.org/wiki/Cry
  stal_system
• Evans, J. W., Davies, G. M. (1924). Elementary
  Crystallography. London The Woodbridge Press,
  LTD.
• Rousseau, J.-J. (1998). Basic Crystallography.
  New York John Wiley Sons, Inc.
• Sands, D. E (1993). Introduction to
  Crystallography. New York Dover Publication,
  Inc.
• Saracino, D. (1992). Abstract Algebra A First
  Course. Prospect Heights, IL Waverland Press,
  Inc.
