Suspension

1
Suspension Vehicle Dynamics
WPI Motorsports Club Presents
2
The Basics

• Purpose
• Control vehicle to road surface interaction ?
  grip
• Translate Driver inputs ? response
• Critical Topics
• Vehicle Dynamics What the car does and why
• Forces Acting on the body
• Physics and Kinematics of Suspension
• Components of the System

3
The Basics

• Only 2 Parameters matter
• Grip (Mechanical)
• Holding to the road
• Mechanical Chemical interaction of tire and
  surface
• Response
• Lag between input and output ?Hysteresis
• Multi-Order partial diff EQ Control problem in
  space-time

4
Wait Say What?

• What Is Suspension?!

5
Is it Suspension?
Double Wishbone (Pontiac Solstice)
6
Is it Suspension?
F1 Springless Wheel w/Heave Spring a T-bar ARB
7
Is it Suspension?
Monoshock (Shuttle Style) Dallara
8
Is it Suspension?
Mono Leaf
9
Is it Suspension?
Live Axle
Watts Linkage
DeDion Tube
DeDion Tube
10
Is it Suspension?
Race Kart Suspension?
11
Load Transfer
Start With a FBD!

• Forces act on CG
• Reactions from suspension
• Bumps produce force ?displacement
• Roll/Weight Transfer produces moments

12
Load Transfer

• Lateral Load Transfer (Roll)
• Governed by relative Height of C.G.
• Wider track less transfer
• Impact suspension dynamic behavior
• Longitudinal
• Longer wheelbase less transfer
• Weight Distribution
• Why 50/50 understeers (load inside/outside and
  front to rear)
• Suspension kinematics can impact magnitude

13
Load Transfer

• FBD - Front View

14
Kinematics and Alignment

• (Insert Picture of Alignment setup here)

15
Camber
16
Camber

• Angle of the tire (from Vertical)
• Influences tire contact patch in cornering
  conditions
• Keeps the rubber on the road F. Puhn
• Impact on temperature, wear and steering
• Best compromise
• Creates Camber Thrust
• Force perpendicular to the direction of travel
• A tire leaned on edge wants to turn i.e.
  Motorcycles

17
Tire Wear and Failure
18
Toe

• Angle defined by the wheel and longitudinal axis
  of the vehicle

19
Toe

• Impacts turning and vehicle stability
• Positive Toe (in) Increases stability,
  decreases steering response, counteracts camber
  thrust from positive camber (Inverse for Toe out)

• Front
• Too much in Wandering under braking, refusal to
  turn in or hard turn in followed by understeer
• Too much out Instability during braking
  Straight-line instability, understeer

• Rear
• Too much in Slow transient, midcorner
  understeer, instability at turn in
• Too much out Violent throttle on, off and trail
  braking rotation/oversteer

20
Caster, KPI, Scrub, Trail
21
Caster, KPI, Scrub, Trail

• Caster and KPI angle will cause the tire to
  camber as it is turned
• ? Camber KPI (COS(Steering Angle)) Caster
  (SIN(Steering Angle))
• Caster and mechanical trail produces a self
  centering torque to the tire
• High caster increases steering effort
• Caster adds damping (hysteresis), Trail adds
  feel
• Mechanical Trail and Scrub radius determine
  forces on steering linkages
• Too large Heavy Stering
• Too little no feedback

22
Roll Centers
23
Roll Centers

• Instant Center
• Point about which a wheel pivots in
  jounce/rebound
• Roll Center
• The axis about which the car rolls
• Kinematic vs Force Based
• Distance from the RC to the COG creates rolling
  moment
• Determines load transfer
• RC Migration
• Roll center will move during roll
• NEVER CROSS THE GROUND PLANE!

24
Tires
TIRES ARE THE MOST IMPORTANT PAR OF ANY
SUSPENSION!
25
Tires The Basics

• Cross Ply (Slicks) or Radial (Modern Street/Wets)
• Many Compounds for both kinds
• 2 Components
• Tread and Sidewall
• Inflation
• Higher Pressures Stiffer, smaller contact patch,
  Less rolling resistance, less mechanical grip,
  better turn in response, lower temps

26
Tires - Sizing

• Sizing
• Wheels
• Big enough for tire size to clear brakes
• Bigger More rotating mass (Weight Inertia)
• Tires
• Width Contact patch
• Aspect Ratio (Sidewall) ? smaller stiffer
• Less flex but twitchy , less give ? Harsh
  Ride

27
Tires Contact Patch

• Tire deforms to road Surface
• Impacted by
• Tire Pressure-Higher pressure smaller contact
  patch
• Vehicle Weight/Load- Higher load larger contact
  patch
• Tire Construction
• Bigger not always better
• Suspension Design, Sidewall, Camber Sensitivity,
  etc

28
Slip Angle

• Angle between the direction of the tire and the
  direction of travel
• Caused by deformation in tire carcass and tread
  and Steering Geometry (Ackerman-different
  steering angle inner vs. outer tire)

• Results in a force perpendicular to the wheel's
  direction of travel Cornering Force
• Graph on Next Slide
• Occurs away from contact patch center
• Pneumatic Trail

29
Slip Angle

• Note Curve changes as load changes!
• Tires are load sensitive!!
• Not Linear Doesnt follow classic friction
  theory
• Max cornering Vertical Load 0.7 to 0.9

30
Slip Angle Why?

• Ratio Effect (Front/Rear)
• gt11 Understeer
• lt11 Oversteer
• Instantaneous Slip Angle depends on a multitude
  of factors
• Suspension design can promote certain dynamic
  characteristics
• Alter Relative Roll Couple varying weight
  transfer front vs rear
• Adjusting Roll Centers
• Roll Stiffness (spring or ARB)
• Steering Geometry
• Ackerman (pro or anti) or Parallel
• Toe

31
The Parts

• Main Components are
• Springs
• Wheel and Anti Roll Bars
• Holds the car up
• Dampers
• Control the springs (oscillations/bouncing)
• Combine with springs to change handling
• Linkages
• Holds it all together
• Mind your compliance

32
Springs

• Main contributor to stiffness
• Stiffer Better Response
• Can achive lower ride height and COG with out
  bottoming
• Softer Better Grip
• Spring rate determined by natural frequency
• Basis for all calulations and physic
• All cars are the same stiffness for the same for
  the same frequency regardless of differences

33
Springs
If you dont watch your units, you cant have
any pudding! Kg or lbm N/m or lbf/in! (refer
to optimum G website)
34
Roll

• Controlled by anti-roll bars (sway bars) and Ride
  Springs
• Roll rate defined at Deg/g
• 0.2-0.7 Aero Cars, 1.0-1.8 Sedans
• Stiffer Quicker transient response, less grip
• Front/Rear Distribution impacts balance
• Typically
• Front roll stiffness 5gt Weight Distribution
• i.e. 40/60 weight will have roll split 45/55

35
Roll
36
Dampers

• Controls Spring
• Damping Force dependent on input Force and
  velocity
• Basically just a pump for fluid
• Valves determine rate of fluid flow ? Damping

37
Review and Compare
38
Review and Compare
Questions??
39
What does it all mean?

• Suspension is complex
• No perfect system ? Best Compromise
• Systems can be broken down into much simpler
  systems using basic mechanical principles
• ANYONE can learn, design and work on these
  systems!
• Its Just physics
