Gene expression testing in cardiac and lung transplantation

1
Gene expression testing in cardiac and lung
transplantation
Banff Congress Jay Wohlgemuth MD July 16, 2005
2
Scientific assumptions

• Gene expression profiling of the immune system
  may anticipate tissue injury
• Multiple genes from multiple pathways are
  required to overcome complexity and variability
• Complex multi-pathway signals can be reduced to
  simple, clinically actionable test result(s)
• Use of genomic information may enable proactive
  therapy, reduction in un-necessary
  immunosuppression and monitoring procedures

3
The transplant patient management challenge
4
Clinical need for molecular testing in cardiac
transplantation

• Monitoring for rejection
• Rejection rates are very low (2-3 for Grade 3A)
• Biopsy has limitations for patients and
  physicians
• Reduction in burden of immunosuppression
• Complications of IS are a major cause of M M
  beyond the 1st year post-transplant
• Minimization may be facilitated with molecular
  testing
• Clarification of uncertain clinical and
  pathological cases
• Mild rejection
• Need for augmentation or change in Rx

5
CARGO Clinical Study

• Goal discover, develop and validate gene
  expression testing for rejection and quiescence
  in cardiac transplant recipients
• Multi-center observational study initiated in
  2001 (centers represent 22 of US cardiac
  transplants)
• Followed 650 patients during gt 5500
  post-transplant encounters
• Microarrays used for gene discovery, real-time
  PCR for development and validation of a
  multi-gene, multi-pathway molecular test
• Prospective, blinded validation study of 20 gene
  algorithm demonstrated ability to distinguish
  rejection from quiescence

6
CARGO Study Overview

• Candidate gene selection
• Leukocyte microarray derived from 25K cDNAs and
  human genome information
• 285 CARGO samples used in microarray experiments
• Database and literature mining
• Identification of 252 candidate genes

Phase I Exploratory

Phase II Development

• Algorithm development
• Sensitive and reproducible real-time PCR methods
• Development of a 20-gene algorithm to distinguish
  rejection from quiescence (AlloMap)

• Validation
• Prospective, blinded, statistically-powered
  clinical study (n 270)
• Additional samples were tested to further define
  performance (n gt 1000)

Phase III Validation Study
7
Rejection Associated Gene Expression Pathways

• Of 252 PCR-assayed genes, 68 genes correlated
  with rejection (p lt 0.01) and/or have a median
  ratio more than 25.
• Measuring both gene expression and shifts of cell
  populations
• CD8 T cell and NK markers
• Markers of hematopoiesis up-regulated with
  rejection

Activated Macrophage / PMN
Steroid responsive
Megakaryocyte
Hematopoiesis
Cytokines, IFN induced
T lymphocyte
B lymphocyte
8
Monitoring Multiple Pathways Associated with
Rejection
Inflammation
Platelet Activation
IL-6
PF4, G6B
T cell Priming
PDCD-1, ITGA4
Lymph node
Mobilization of Hematopoietic precursors
WDR40A, MIR
Lymph and Lymphocytes
Rejection Rx
IL1R2, ITGAM, FLT3
9
AlloMap Diagnostic Algorithm
10
CARGO Study Results Summary

• AlloMap distinguishes grade 3A rejection from
  grade 0 at all times post-transplant (p lt0.0001)
• Grade 1B samples have high algorithm scores on
  average, grades 0, 1A and 2 are indistinguishable
• Patients with low scores have very low risk of
  moderate-severe acute rejection

11
CARGO Study Results Summary

• AlloMap correlates more closely to centralized
  than local pathology
• Algorithm predicts future rejection and graft
  dysfunction in grade 0 cases
• Pediatric samples look qualitatively similar
• CMV signature identified which does not confound
  the AlloMap test result

12
AlloMap Score Increases with Decreased Steroid
Dose
AlloMap score and steroid dose vs. days post
transplant
AlloMap
AlloMap score, quiescent samples
Prednisone dose mg/day
Prednisone
Days post transplant
13
Steroid Responsive Genes and Pathways

• 5 of 11 informative algorithm genes significantly
  correlate with steroids
• Steroid and rejection gene expression responses
  are opposite
• Predominance of monocyte and PMN expressed genes
• ITGAM and IL1R2 are most responsive to steroid
  dose

SteroidGene Rejection Response Description Cell
Type ITGAM Integrin, alpha M Monos, PMN,
NK IL1R2 Interleukin 1 Monos,
PMN receptor G6b lg superfamily Hemotopoiet
ic cell lines FLT3 fms-related lymphoid/m
yeloid tyr kinase progenitors ITGA4
integrin, alpha 4 Monos, PMN, lymphocytes
14
Individual Patients Have Varied Responses to
SteroidsSteroid Resistant Rejection and Steroid
Sensitivity
Gene expression based estimate of steroid dose
Quiescent gold Rejection blue
15
Identification of Quiescence

• Samples below threshold are unlikely to have 3A
  or higher biopsy NPV gt 99
• Samples above threshold are enriched for
  concurrent biopsy 3A
• 12X increased risk for 3A rejection vs. low
  scores
• Still, low PPV relative to biopsy Why?

Below threshold (high NPV)
Above threshold (moderate PPV)
16
Molecular Testing Correlation to Biopsy and
Graft Dysfunction
Humoral Rejection
Cellular Rejection
Molecular Rejection
Graft Dysfunction
Biopsy (late)
AlloMap Test (early)
Graft Failure (too late)
17
Risk of graft dysfunction with high score,
negative biopsy

• Risk of graft dysfunction (PCW gt20) within 45
  days

RR 6.8 p 0.03
High
Low
18
Cardiac biopsy interpretation variability
contributes to discordance between molecular and
pathological results

• Pathology panel (Billingham, Marboe and Berry)
  re-read all biopsy slides for the study (n 827)
  Marboe et al., JHLT 2005
• The maximum concordance between two central
  pathologists for grade 3A rejection was 77
• The average concordance between the local and
  central pathologists grade 3A rejection was 40
• Local pathologists call grade 3A rejection 50
  more frequently than central pathologists
• Quilty lesions cause significant uncertainty and
  overcalls for rejection

19
Quilty lesions cause over diagnosis of ISHLT
Grade 2 and 3A rejection

• Serial sections of 18 cases performed
• All cases involved local Grade 2 or 3A
• All cases had been identified as likely Grade 0-1
  and Quilty B by centralized panel
• 17 of 18 confirmed to be Grade 0-1
• 12/12 Local Grade 2s
• 5/6 Local Grade 3As

20
Local Pathologist Rejection
21
Consensus Quilty B
22
Discordance between molecular and pathological
results

• Positive biopsy, low molecular score
• gt50 of Grade 3As after year 1 may resolve
  without therapy
• Quilty lesions or other causes of over diagnosis
  by biopsy
• Molecular test and biopsy measure different
  processes which may be discordant
• Negative biopsy, high molecular score
• Early, focal rejection, negative on biopsy
• Sensitivity of test for humoral rejection?
• Patients may have peripheral alloimmune activity,
  no cellular rejection
• Risk of vasculopathy?

23
AlloMap Scores by ISHLT Grade
472 samples 6 months post-transplant

• Grade 1B sample scores were significantly higher
  than Grades 0 (p0.02) and 1A (p0.002)
• Grade 1B scores were not significantly different
  than grade 3
• Grades 0, 1A and 2 scores were not significantly
  different
• Mild rejection (0-2) with high scores have
  significant increased risk of progression to
  grade 3A on next biopsy (p 0.0015)

AlloMap Score
Local ISHLT grade
24
Molecular response to rejection therapy
25
Clinical uses of molecular testing in cardiac
transplantation

• Rejection surveillance
• Stable outpatients with low scores are low risk
  biopsy reduction
• Access issues
• Immunosuppression titration
• Guide weaning of immunosuppression
• Follow after rejection therapy
• Risk stratification
• Mild rejection or possible Quilty on biopsy
• Uncertain clinical picture

26
CARGO Ongoing Studies, CARGO II Study

• Prediction of clinical outcomes
• Immunosuppression / Rejection Rx monitoring
• Humoral rejection
• Vasculopathy
• Pediatrics
• Infection

27
LARGO Study

• Ongoing 14 center international study of
  molecular testing in Lung transplantation
• Endpoints Acute rejection, BOS, infection
• Infectious complications may be addressed with
  development of new molecular information
• Common relevant pathways for multiple solid organ
  transplant settings will be sought

28
Thank You
29
CARGO Centers and Collaborators

• Transplant cardiology programs
• Cleveland Clinic Randall Starling, MD, MPH
• Columbia University Mario Deng, MD, Helen Baron,
  MD
• Columbia University (peds) Seema Mital MD, Linda
  Addonizio, MD
• Ochsner Clinic Mandeep Mehra, MD
• Stanford University, PAVAMC Sharon Hunt, MD,
  Fran Johnson MD
• Stanford University (peds) Daniel Bernstein, MD
• Temple University Howard Eisen, MD
• UCLA Medical Center Jon Kobashigawa, MD
• University of Florida James Hill,MD, Dan Pauly,
  MD, PhD
• University of Pittsburgh Srinivas Murali, MD,
  Adrianna Zeevi, PhD
• University of Pittsburgh (peds) Steven Webber,
  MBChB
• Centralized reading of biopsy pathology
• Gerald Berry, MD (Stanford)
• Margaret Billingham, MD (Stanford)
• Charles Marboe, MD (Columbia)
