DNA, RNA and Protein Synthesis

1
DNA, RNA and Protein Synthesis

• Chapter 12
• Pgs. 287-312

2
I. DNA discovery

• A. Franklin Wilkins- used X-ray diffraction,
  discovered DNA shape double helix like twisted
  ladder

Franklin
Wilkins
3
I.
B. Watson Crick- Nobel prize, first
structural model of DNA
1953
4
I.

• C. Chargaff- discovered amounts of
• Thymine Adenine,
• Cytosine Guanine,
• Nitrogen base-pairing rule

5
I.

Double Helix
6
II. DNADeoxyribonucleic acid
II.
DEOXYRIBOSE SUGAR (5C)
PHOSPHATE
NITROGEN BASE

• Monomer nucleotide
• 1. 5 C deoxyribose sugar
• 2. Phosphate group
• 3. Nitrogen base

7

• B. Shape
• Ladders sides, also called backbone of
  alternating
• Deoxyribose sugars phosphates
• 2. Rungs nitrogen bases
• a. Bonded to each other by
• weak hydrogen bonds
• b. The nitrogen bases
• are bonded to the
• sugars of the ladder,
• NOT the phosphates

II.
D P D
D P D
A-T
G-C
P D P
P D P
C-G
T-A
D P D
D P D
G-C
8
DNA Double Helix
C. Base pairing rule Adenine to Thymine
A-T Cytosine to Guanine G-C
II.
A
T
A
T
C
G
A
T
C
G
9
1. Example Base Pairing
II.

• DNA Strand
• A T T C G G T A G
• T A A G C C A T C
• Complimentary DNA Strand

10
II.

• D. DNA- forms chromosomes in nucleus and is found
  in mitochondria and chloroplasts

X
X
Chromosomes
11
1. Stores genetic info Ex eye color 2. Tells
ribosomes which proteins to make
Eye color
12
II.
3. DNA replication - DNA must make EXACT copy
of itself before cellular division enables new
cell to have SAME genetic info as dividing cell-
13
III. DNA Replication-occurs in the nucleus BEFORE
cell division

• A. DNA unzips totally
• 1. ATP energy DNA helicase enzymes break the
  weak hydrogen bond between nitrogen
  basesseparates the 2 strands of DNA

14
III.

• 2. Each parent strand of DNA is a template
  (pattern) for a new complementary strand
  additional proteins hold strands apart
• 3. DNA Polymerase enzymes add new nucleotides
  according to base pairing rule 2 new helices
  formed

15
III.

• 4. Replication produces 2 DNA molecules each
  composed of a
• new original strand
• 5. Exact 2 copies of DNA that make up each
  chromosome are called chromatids
• 6. Two chromatids attached at centromere

16
IV. RNARibonucleic Acid

• Monomer Nucleotides
• 5 C ribose sugar
• Phosphate group
• Nitrogen base
• Cytosine to Guanine
• Adenine to URACIL (replaces thymine)
• Shape single stranded

17
V. Transcription- RNA synthesis (building RNA)

• A. DNA is copied into a complementary single
  strand of RNA occurs in nucleus b/c DNA never
  leaves nucleus
• B. mRNA- RNA that carries genetic message from
  DNA to the ribosomes in the cytoplasm (ribosomes
  make proteins)

18
V. Transcription (cont.)

• C. Making RNA from DNA
• 1. RNA polymerase (enzyme)- unzips a short
  section of DNA
• 2.RNA polymerase adds, then links complementary
  RNA nucleotides as it reads the gene on the
  unzipped DNA

19
V. Transcription (cont.)

• 3.Base pairing C to G/ A to U NO THYMINE in RNA
• 4. The 2 DNA strands close up by forming hydrogen
  bonds between complementary DNA bases, reforming
  the double helix.

20
Example RNA Base Pairing

• DNA template strand
• A T G C G A T T A
• U A C G C U A A U
• RNA complementary strand

21
V. Transcription (cont.)

• 5. In eukaryotic cells RNA goes through RNA
  splicing
• a. DNA contains regions that will not code for
  proteins
• b. Non-coding regions introns
• c. Coding regionsexons
• d. Spliceosomes- complex assemblies of proteins
  RNA, cut out introns and splice(put together)
  exons to form a smaller mRNA that will leave the
  nucleus through the nuclear pore.

22
VI. Protein Synthesis

• A. Monomer- amino acids
• B. 20 different amino acids form all proteins
• C. DNA bases are arranged in triplets producing
  64 different 3 letter code words ex ATC, CAG

23
VI. Protein Synthesis

• D. RNA bases written in 3 nucleotide sequences on
  the mRNA, called codons
• E. Each codon corresponds to an amino acid or a
  start or stop codon for translation into a
  protein
• AUG the start codon the amino acid methionine
• UAA, UAG, UGA stop codons, do not code for amino
  acid, protein stops here

24
VI. Protein Synthesis

• F. mRNA leaves nucleus, attaches to ribosome in
  cytoplasm where protein synthesis will take place
• G. rRNA ribosomal RNA- most abundant RNA, rRNA
  and proteins form ribosomes

25

26
IIV. Translation- RNA to Protein

• A. tRNA- single strand of RNA that temporarily
  carries a SPECIFIC amino acid
• B. tRNA is folded into a compact shape with an
  anticodon (a 3 nucleotide sequence on one end
  that it complementary to a codon on mRNA)

27
IV. Translation (cont.)

• 1.Translation begins on the ribosome
• 2. A tRNA carrying amino acid, methionine, finds
  the mRNAs start codon AUG
• 3. tRNAs anticodon will pair with their
  complementary bases of the codon on the mRNA
  strand decoding the mRNA message into a specific
  protein

28
IV. Translation (cont.)

• 4. Peptide bonds form between each amino acid as
  the protein chain grows C-N
• 5. The amino acid chain will grow until the tRNA
  reaches a stop codon on the mRNA UAA, UGA OR UAG
• 6. The ribosome complex falls apart and the newly
  made protein is released

29
How do we know what Amino Acid to add?
USE THE mRNA CODE TO TRANSLATEINTO AMINO ACIDS
mRNA 1) CCC 2) CGG 3) ACU 4) UGA
30
PRACTICE

• DNA T A C G A C G T A A A A A C T
• mRNA

31

• DNA T A C - G A C - G T A - A A A - A C T
• mRNA A U G - C U G - C A U - U U U - U G A
• tRNA

32

• DNA T A C - G A C - G T A - A A A - A C T
• mRNA A U G - C U G - C A U - U U U - U G A
• tRNA U A C - G A C - G U A - A A A - A C U
• AA Seq

33

• DNA T A C - G A C - G T A - A A A - A C T
• mRNA A U G - C U G - C A U - U U U - U G A
• tRNA U A C - G A C - G U A - A A A - A C U
• AA Seq MET - LEU - HIS - PHE

34
V. Mutations pg. 307-308

• A. Mutation- any change in the DNAs sequence of
  a gene or chromosome of a cell a mistake
• 1.Causes
• a. Radiation x-rays, cosmic rays, UV light
  nuclear radiation
• b. Chemicals dioxins, asbestos, benzene
  formaldehyde

35
V. Mutation (cont.)

• B .Gene- section of DNA on a chromosome that
  directs the making of a protein or trait
• 1. A change in gene or chromosome a change in
  trait
• 2. Some mutations harmful

36
V. Mutation (cont.)

• 3. Harmful mutations prevent the survival of an
  organism
• 4. Some mutations add genetic variety to a
  species

37
V. Mutation (cont.)

• C. Gene Mutations
• 1. Point Mutation- a change in a single base pair
  of DNA which affects ONE codon can affect a
  single amino acid in a protein

Ex A T T G A A A C G U A A C C U U G C
38
V. Mutation (cont.)

• a. Point mutation examples
• Sickle cell anemia GAA Glu, GUAVal causes a
  sickle shaped red blood cell these cells cannot
  deliver enough oxygen, causes tissue damage, clog
  capillaries

39
V. Mutation (cont.)

• b. Cystic Fibrosis mutation produces thick mucus
  in lungs, liver and pancreas prevents oxygen
  intake in lungs prevents enzymes from reaching
  food in the digestive tract

40
V. Mutation (cont.)

• 2. Frameshift Mutation- addition or deletion of a
  base

• Ex
• THE CAT ATE THE RAT
• THE ATA TET HER AT Deletion of base
• THE CAT ATE THE RAT
• THE CCA TAT ETH ERA T Addition of base

41
V. Mutations (cont.)

• D. Chromosomal Mutations- occur when chromosomes
  break and rejoin incorrectly causing severe harm
• 1. Deletion part of a chromosome is left out
• Ex ABCDEFG- deletion- ABCEFG

42
Chromosomal Mutations (cont)

• 2. Insertion part of chromosome breaks off and
  attaches to its sister chromatid, causing a
  duplication of genes on the same chromosome
  (duplication)
• Ex ABCDEFG-insertion-ABCBCDEF

43
Chromosomal Mutations (cont)

• 3. Inversion part of a chromosome breaks off and
  reattaches backwards
• Ex ABCDEFG-inversion-ADCBEFG

44
Chromosomal Mutations (cont)

• 4. Translocation part of one chromosome breaks
  off and is added to a different chromosome,
  results in too many genes on one chromosome and
  not enough on the other
• Ex ABCDEF- translocation- WXABCDEF
• WXYZ YZ

45

46
The end of this unit!
STUDY!
