ELECTRODYNAMICS
2
Force on a current-carrying wire in a magnetic
field.
  • When a wire carrying a current is placed inside a
    magnetic field, it experiences a force that
    causes the wire to move.
  • The force is the result of the interaction
    between the magnetic field of the magnets and the
    magnetic field of the wire.

3
  • The force is at a maximum when the wire moves at
    90o to the magnetic field and the force is zero
    when the wire moves parallel to the magnetic
    field.
  • The direction of the force can be found by using
    right hand screw rule
  • Conventional current is used,
  • that is, current that flows from
  • the positive towards the
  • negative terminal.

4
The Direct Current (DC) Motor
  • Electrical energy (current) in the motor is
    converted into mechanical energy (the movement of
    the motor).
  • Using the Left Hand Motor Rule, the left side is
    forced up and the right side is forced down.

5
  • A simple DC motor consists of a rectangular coil
    of wire mounted on an axle that can rotate
    between the two poles of a magnet.
  • Each end of the coil is connected to half of a
    split-ring commutator that consists of two copper
    segments that rotate with the coil.
  • Two carbon blocks, the brushes, are pressed
    lightly against the split rings.
  • The brushes are connected to the power supply.
  • The split-ring commutator ensures that the coil
    turns in one direction only.

6
  • Step 1 shows the coil in the horizontal position.
    ab experiences an upward force and cd a downward
    force.
  • Step 2. The torque causes the coil to rotate into
    a vertical position. Now the openings between the
    half-rings of the split-ring commutator are
    opposite the brushes and the commutator loses
    contact with the brushes. The current stops
    flowing through the coil. However, the momentum
    of the coil carries it past the vertical position.

7
  • Step 3 The commutator makes contact with the
    brushes again, but the current in the coil is
    reversed (in the direction abcd). This allows the
    torque to continue acting in the same direction.
    The side ab now experiences a downward force, and
    side cd an upward force.
  • Step 4 The coil continues to rotate until it
    reaches a vertical position again and the current
    is broken.
  • The rotating shaft is usually connected to other
    rotating parts in the system, by means of gears
    or pulleys.

8
The turning effect on the coil can be increased
by
  • Increasing the current in the coil.
  • Increasing the number of turns on the coil.
  • Increasing the strength of the magnetic field.

9
Motors in everyday life
  • The changing force experienced by the coil as it
    rotates through 360o, results in the simple motor
    not running smoothly.
  • In practice, motors turn very smoothly and at
    high speeds.
  • In these motors the coil consists of a soft iron
    core, surrounded by many loops.
  • Such a coil is called an armature.
  • Most armatures have many coils which are placed
    at different angles.
  • Each coil in the armature has its own commutator.

10
  • Some motors, such as those in electric drills,
    can run on AC, because they contain
    electromagnets, rather than permanent magnets.
  • As the current flows through the coil, the
    magnetic field changes direction to match it.
  • This enables the motor to keep turning in the
    same direction.
  • Electric motors have almost limitless useful
    applications. These vary from the tiny motors
    found in moving electric toys and disc players,
    to the driving force behind water pumps all the
    way to the giant motors that drive the winches on
    construction cranes.

11
  • The design of an electric motor depends on the
    task it must perform sometimes it must turn
    fast as in the dentist drill, or slower as in a
    clock and sometimes in steps as in the motor in a
    printer which feeds the paper line by line.

12
ELECTROMAGNETIC INDUCTION
  • When a magnet moves near a conductor or when a
    wire moves in the magnetic field of a magnet, the
    change in the magnetic field induces an emf and a
    current flows in the conductor.
  • This phenomenon is called electromagnetic
    induction.
  • The induced current will be maximised when the
    motion of the conductor is perpendicular to the
    direction of the magnetic field, and minimised
    when it travels parallel to the field.

13
Moving a conductor in a magnetic field
14
Faradays Law
  • The size of the induced current is directly
    proportional to the rate of change of magnetic
    flux linkage.
  • What this means is that the induced current is
    most effectively produced when the number of
    magnetic field lines being cut by the conductor
    is greatest.
  • The size of the induced emf (and hence the
    induced current) can be increased by
  • Moving the conductor faster
  • Using stronger magnets
  • Increasing the length of the conductor (more
    turns on the coil)

15
THE AC GENERATOR
  • N S are the field magnets that provide the
    magnetic flux.
  • abcd indicates one turn of a rectangular coil of
    insulated copper wire and represents the
    armature.
  • S1 S2 are a pair of slip-rings consisting of
    copper around an insulated cylinder. Each end of
    the coil remains connected to its own slip ring.

16
  • B1 B2 are carbon or copper brushes for
    collecting the induced current.
  • A is an insulated shaft that enables the coil and
    slip-rings to rotate as a single unit.
  • The handle stresses the fact that kinetic energy
    must be supplied to the armature and the lamp,L,
    represents the electrical device in which the
    generated current is used.
  • Generators use mechanical energy to produce
    electrical energy.

17
Working of an AC generator
  • When the coil is in the vertical position, no
    magnetic field lines are cut by ab and dc no emf
    is induced and no current flows.
  • While the coil rotates it cuts the field lines
    and causes a change in magnetic flux, an emf is
    induced which causes an electric current flow in
    the circuit.

18
  • As the coil stats moving to the vertical position
    again, the induced emf decreases so the current
    also decreases, till it is zero.
  • When the coil is rotated further, there is a
    change in magnetic flux again, but now the
    induced current flows in the opposite direction.

19
  • When the coil of an AC generator rotates in a
    magnetic field, a constantly varying emf is
    induced across the coils ends.
  • One complete change in the direction of the
    current during one revolution of the coil is
    called a cycle of alternating current.
  • The induced emf varies according to a sine wave
    and the induced current is slightly less than the
    induced emf.

20
Uses of the AC generator
  • Alternators in cars, the movement of the cars
    engine produces electricity via the alternatort
    to recharge the cars battery.
  • Back-up power generators are used to produce
    electricity where there is a power outage. Places
    that are left vulnerable or cannot function in
    the event of a power cut, such as hospitals,
    fresh produce distributors and high security
    areas, use generators.
  • Power stations huge dynamos are turned using
    steam from heated water, to produce electricity.

21
The DC Generator (dynamo)
  • The slip-rings of the AC generator are replaced
    by a split-ring commutator to convert the AC
    generator to a DC generator.
  • The DC generator produces current that flows in
    one direction only.
  • The carbon brushes are arranged in such a way
    that contact is broken between the coil and the
    brushes for a brief instant when the coil is
    vertical.
  • When contact is re-established, the brushes come
    into contact with a different part of the coil.
  • So the current continues to flow through the
    brushes with no switch in its direction.

22
(No Transcript)
23
  • Uses of AC Generators
  • The main generators in nearly all electric power
    plants
  • are AC generators. This is because a simple
  • electromagnetic device called a transformer makes
    it
  • easy to increase or decrease the voltage of
    alternating
  • current. Almost all household appliances utilize
    AC.
  • Uses of DC Generators
  • Factories that do electroplating and those that
    produce
  • aluminium, chlorine, and some other industrial
  • materials need large amounts of direct current
    and use
  • DC generators. So do locomotives and ships driven
    by
  • diesel-electric motors. Because commutators are
  • complex and costly, many DC generators are being
  • replaced by AC generators combined with
    electronic
  • rectifiers.

24
Alternating Current
  • Alternating current (AC) is an electric current
    which reverses its direction of flow fifty times
    every second it has a frequency of 50 Hz.
  • Why do we use AC and not DC?
  • Electricity needs to be distributed through the
    country at high voltages to reduce energy losses
    in the power cables.
  • To increase the voltage at the power stations and
    reduce it again before it reaches your home,
    transformers must be used.
  • Transformers can only work on AC, since a
    changing magnetic field is required to induce a
    current.

25
  • In addition, generating AC at the power stations
    is easier no complex modifications to the AC
    generator is necessary.
  • Most appliances can operate on AC, including all
    those with a heating element (light bulbs,
    kettles, toasters, stoves), but some require the
    AC to be converted to DC first as they are
    direction sensitive (laptops, cell phone
    chargers)
  • Characteristics of AC
  • One of the characteristics of alternating current
    is that it causes self-inductance in the wires
    that carry it.
  • It means that when the current changes direction,
    the magnetic field associated with it is in such
    a way as to oppose that change (Lenzs Law).

26
  • Because of self-inductance, some of the
    electrical energy of the current is wasted
    appliances will get a lower maximum voltage than
    the peak value.
  • This lower maximum voltage is known as the
    root-mean-square value (RMS value)

27
  • In SA our mains supply is 220V (rms) AC (50 Hz).
    What is the peak or maximum voltage?
