Interactive and semiautomatic performance evaluation

1
Interactive and semiautomatic performance
evaluation

• W. Funika, B. Balis
• M. Bubak, R. Wismueller

2
Outline

• Motivation
• Tools Environment Architecture
• Tools Extensions for GRID
• Semiautomatic Analysis
• Prediction model for Grid execution
• Summary

3
Motivation

• Large number of tools, but mainly off-line and
  non-Grid oriented ones
• Highly dynamic character of Grid-bound
  performance data
• Tool development needs a monitoring system
• accessible via well-defined interface
• with a comprehensive range of possibilities
• not only to observe but also to control
• Recent initiatives (DAMS no perf, PARMON no
  MP, OMIS)
• Re-usability of existing tools
• Enhancing the functionality to support new
  programming models
• Interoperability of tools to support each other
• When interactive tools are difficult or
  impossible to apply, (semi)automatic ones are of
  help

4
Component Structure of Environment
5
X Task 2.4 - Workflow and Interfaces
requirements from
WP 1,3,4
2.1
6
Application analysis

• Basic blocks of all applications dataflow for
  input and output
• CPU-intensive cores
• Parallel tasks / threads
• Communication
• Basic structures of the (Cross-) Grid
• Flow charts, diagrams, basic blocks from the
  applications
• Optional information on applications design
  patterns e.g. SPMD, master/worker, pipeline,
  divide conquer

7
Categories of performance evaluation tools

• Interactive, manual performance analysis
• Off-line tools
• track based (combined with visualization)
• profile based (no time reference)
• problem strong influence when fine grained
  measurements
• On-line tools
• possible definition (restriction) of the
  measurements at run-time
• suitable with cyclic programs new measurements
  based to the previous results. gt Automation of
  the bottleneck search is possible
• Semi-automatic and automatic tools
• Batch-oriented use of the computational
  environment (e.g. Grid)
• Basis Search-model enables possible refining of
  measurements

8
Defining new functionality of performance tool

• Types of measurements
• Types of presentation
• Levels of measurement granularity
• Measurement scopes
• Program
• Procedure
• Loop
• Function call
• Statement
• Code region identification
• Object types to be handled within an application

9
Definition and design Work

• architecture of the tools, based on their
  functional description
• hierarchy and naming policy of objects to be
  monitored
• the tool/monitor interface, based on the
  expressing of measurement requests in terms of
  monitoring specification standard services
• the filtering and grouping policy for the tools
• functions for handling the measurement requests
  and the modes of their operation
• granularity of measurement representation and
  visualization modes
• the modes of delivering performance data for
  particular measurements

10
Modes of delivering performance data
11
Interoperability of tools

• Capability to run multiple tools concurrently
  and apply them to the same application''Motivati
  on- concurrent use of tools for different
  tasks- combined use can lead to additional
  benefits- enhanced modularityProblemsStructu
  ral conflicts due to incompatible monitoring
  modulesLogical conflicts e.g. a tool modifies
  the state of an object while another tool still
  keeps outdated information about it

12
Semiautomatic Analysis

• Why (semi-)automatic on-line performance
  evaluation?
• ease of use - guide programmers to performance
  problems
• Grid exact performance characteristics of
  computing resources and network often unknown to
  user
• tool should assess actual performance w.r.t.
  achievable performance
• interactive applications not well suited for
  tracing
• applications run 'all the time'
• detailed trace files would be too large
• on-line analysis can focus on specific execution
  phases
• detailed information via selective refinement

13
The APART approach

• object oriented performance data model
• available performance data
• different kinds and sources, e.g. profiles,
  traces, ...
• make use of existing monitoring tools
• formal specification of performance properties
• possible bottlenecks in an application
• specific to programming paradigm
• APART specification language (ASL)
• specification of automatic analysis process

14
APART specification language

• specification of performance property has three
  parts
• CONDITION when does a property hold?
• CONFIDENCE how sure are we? (depends on data
  source) (0-1)
• SEVERITY how important is the property?
• basis for determining the most important
  performance problems
• specification can combine different types of
  performance data
• data from different hosts gt global properties,
  e.g. load imbalance
• templates for simplified specification of related
  properties

15
Supporting different performance analysis goals

• performance analysis tool may be used to
• optimize an application (independent of execution
  platform)
• find out how well it runs on a particular Grid
  configuration
• can be supported via different definitions of
  SEVERITY
• e.g. communication cost
• relative amount of execution time spent for
  communication
• relative amount of available bandwidth used for
  communication
• also provides hints why there is a performance
  problem (resources not well used vs. resources
  exhausted)

16
Analytical model for predicting performance on
GRID

• Extract the relationship between the application
  and execution features, and the actual execution
  time.
• Focus on the relevant kernels in the applications
  included in WP1.
• Assuming message-passing paradigm
• (in particular MPI).

17
Taking features into a model

• HW features
• Networks speeds
• CPU speeds
• Memory bandwith
• Application features
• Matrix and vector sizes
• Number of the required coomunications
• Size of these communications
• Memory access patterns

18
Building a model

• Through statistical analysis, a model to predict
  the influence of several aspects on the execution
  of the kernels will be extracted.
• Then, a particular model for each aspect will be
  obtained. A linear combination of them will be
  used to predict the whole execution time.
• Every particular model will be a function of the
  above features.
• Aspects to be included in the model
• computations time as a function of the above
  features
• memory access time as a function of the features
• communications time as a function of the features
• synchronization time as a function of the
  features

19
X WP2.4 Tools w.r.t. DataGrid WP3
20
Summary

• New requirements for performance tools in Grid
• Adaptation of int. performance ev. tool to GRID
• New measurements
• New dialogue window
• New presentations
• New objects
• Need in semiautomatic performance analysis
• Performance properties
• APART specification language
• Search strategy
• Prediction model construction

21
Performance Measurements with PATOP

• Possible Types of Measurement
• CPU time
• Delay in Remote Procedure Calls (system calls
  executed on front-end)
• Delay in send and receive calls
• Amount of data sent and received
• Time in marked areas (code regions)
• Numer of executions of a specific point in the
  source code
• Scope of Measurement
• System Related
• Whole computing system,
• Individual nodes,
• Individual threads,
• Pairs of nodes (communication partners, for
  send/receive),
• Set of nodes specified by a performance condition
• Program Related
• Whole program,
• Individual functions

22
PATOP
23
Performance evaluation tools on top of the OCM
24
On-line Monitoring Interface Specification

• The interface should provide the following
  properties
• support for interoperable tools
• efficiency (minimal intrusion, scalability)
• support for on-line monitoring (new objects,
  control)
• platform-independence (HW, OS, programming
  library)
• usability for any kind of run-time tool
  (observing/manipulating, interactive/automatic,
  centralized/distributed)

25
Object based approach to monitoring

• observed system is a hierarchical set of objects
• classes nodes, processes, threads, messages, and
  message queues
• node/process model suitable for DMPs, NOWs, SMPs,
  and SMP clusters
• access via abstract identifiers (tokens)
• services observe and manipulate objects
• OMIS core services platform independent
• others platform (HW, OS, environment) specific
  extensions
• tools define their own view of the observed system

26
Classification of overheads

• Synchronisation (e.g. barriers and locks)
• coordination of accessing data, maintaining
  consistency
• Control of parallelism (e.g. fork/join operations
  and loop scheduling)
• control and manage parallelism of a program
  (user, compiler)
• Additional computation - changes to sequential
  code to increase paralellism or data locality
• e.g. eliminating data dependences
• Loss of parallelism imperfect parallelisation
• un- or partially parallelised code, replicated
  code
• Data movement
• any data transfer within a process or between
  processes

27
Interoperability of PATOP and DETOP

• PATOP provides a high-level performance
  measurement and visualisation
• DETOP provides a source-code level debugging
• Possible scenarios
• Erroneous behaviour observed via PATOP
• Suspend application with DETOP, examine source
  code
• Measurement of execution phases
• Start/stop measurement at breakpoint
• Measurement on dynamic objects
• Start measurement at breakpoint when object is
  created
