Title: IFC Industry Foundation Classes


1
IFC (Industry Foundation Classes)
  • What is it? What it does? How it works?
  • Christopher Groome
  • Business Manager
  • IAI International

2
Agenda
  • What is IFC?
  • IFC Chronology
  • IFC2x3 Architecture
  • What encloses IFC2x3
  • IFC and ISO
  • What IFC does?
  • IFC and Interoperability
  • IFC and Building Information Model
  • IFC and AEC-FM lifecycle
  • IFC and ICT technologies
  • How IFC works and who uses IFC?
  • Application domains to IFC
  • Practical collaboration scenario using IFC
  • eGovernment best-practice using IFC
  • Concluding remarks
  • IFC Statements
  • Future of IFC

3
What is IFC (Industry Foundation Classes)?
  • IFC represents a data model structure for sharing
    construction and facility management data across
    various applications used in the AEC-FM sector.
  • IFC data model is an object-oriented data model
    based on class definitions representing the
    things (elements, processes, shapes, etc.) that
    are used by software applications during a
    construction or facility management project.
  • IFC data model focuses on those classes that are
    needed to share information (rather then
    processing it in a particular proprietary
    software application).
  • IFC data model is a neutral and open
    specification that is not controlled by a
    singular vendor or group of vendors.
  • IFC data model is defined, promoted and published
    by the IAI (International Alliance for
    Interoperability) a non-profit, global alliance
    of construction and facilities management
    industries with about 500 member organizations in
    35 countries and being organized within 13
    regional chapters.
  • IFC data model is available as ISO PAS (Publicly
    Available Specification) 16739.

4
Chronology of IFC development
Prototype for linking BIM to geographical
geospatial information
New meeting ground for all application - basis
for next years
Scope
IFC 2x3G
New implementation, e.g. code checking
IFC 2x3
IFC 2x2
  • Introduction of platform concept
  • First stable applications

2nd round of early implementations
Early prototypes
first products released
IFC 2.0
IFC 2x
IFC2x 1st Add.
IFC 1.5
IFC 1.5.1
IFC 1.0
1997
1998
1999
2000
2001
2002
2003
2004
2005
2006
2007
5
IFC2x3 Architecture
6
What does IFC2x3 encloses
7
IFC progressing to full ISO standard
  • IFC not (yet) a full ISO standard available
    under PAS specification (until 2011)
  • Agreement with NWI-AP241 team
  • NWI241 to focus on life cycle support and high
    level aspects of AEC facilities
  • Results in view of IFC/IAI
  • No impact on IFC development, direction or
    schedule.
  • IFC continues to focus on bringing neutral BIM
    into use.
  • The realisation of NWI-AP241 scope and NWI-AP241
    team now support the goal of IFC progressing
    towards becoming an ISO standard.
  • New NWI-AP241 scope facilitates collaboration
    between both teams.

8
What IFC does?
1. IFC and Interoperability
2. IFC and Building Information Modelling
3. IFC and AEC-FM life-cycle
4. IFC and ICT technologies
9
1. IFC and Interoperability
  • What is (Software) Interoperability?
  • Interoperability could define as the ability of
    two or more systems or elements to exchange
    information and to use the information that has
    been exchanged IEEE 2006
  • Software interoperability might be defined as
    seamless exchange of data among multiple
    software tools
  • IFC and (Software) Interoperability
  • Direct exchange of data eliminates the need for
    duplicate data generation, repetitive entry of
    the same data, and human errors
  • A general data model of buildings is the basis
    for seamless multi-directional data exchange
    (i.e. Software Interoperability)
  • An open data model permits independence from
    software and software houses
  • IFC neutral specification enables
    Interoperability of systems in BC

10
Why Interoperability matters?
Source
  • Interoperability is expensive
  • 30-40 of companies IT budget spent on
    integration (Gartner AMR)
  • 29billion by 2006 for application integration by
    IT professional services (Gartner Group, 2003)
  • Interoperability is time-critical
  • Integration of single interface takes 2
    person-months on average
  • Interoperability is complex
  • Proliferation of standards and with frequent
    changes
  • Fragmented solutions Islands of interoperability
    providing Industry or application specific
    solutions
  • Wide variety of business network types with
    different requirements from more stable
    alliances (e.g. Supply Chains) to more transitory
    alliances (e.g. Virtual Organisations)
  • Interoperability is an enabling technology
  • Interoperability is not a product or a service
  • Interoperability matters in AEC-FM industries
  • NIST 2004 Report on Cost Analysis of
    InadequateInteroperability in the U.S. Capital
    Facilities Industry in 2002
  • Architects/Engineers 1,170 Million
  • General Contractors 1,802 Million
  • Specialty Trades 2,204 Million
  • Owner/Operators 10,658 Million
  • TOTAL 15,824 Million
  • 4.25 of total value of 2002 construction Wasted!

11
Interoperability in EU high level political agenda
  • i2010 Initiative A European Information Society
    for growth and employment
  • Single European Information Space pillar
    Interoperability enhancing devices and
    platforms that talk to one another and services
    that are portable from platform to platform
    Develop modern and interoperable ICT-enabled
    public services
  • Innovation and Investment in Research pillar
    Deployment and adoption of ICT Businesses are
    getting productivity gains from ICT but still
    face a lack of interoperability ... A new era of
    e-business solutions is coming, based on
    integrated ICT solutions, secure web-services and
    collaboration tools to raise worker
    productivity.
  • e-Europe Action Plan
  • EIC (Enterprise Interoperability Centre) is an
    open, neutral, and independent organization,
    serving as a common and inclusive platform that
    adds value to its members, to the
    interoperability stakeholders, and to the
    established and ongoing work of existing
    standards development organizations
  • EIC is chaired by the IAI, namely by Executive
    Committee Vice Chair Mr. Nick Terry (IAI-UK).

12
2. IFC and Building Information Model (BIM)
  • What is BIM?
  • As a noun Building Information Model
  • An instance of a populated data model of
    buildings that contains multi-disciplinary data
    specific to a particular building which they
    describe unambiguously
  • As a verb Building Information Modelling
  • The act of creating a Building Information Model
    (BIM a noun)
  • Building Information Modelling is a process
  • IFC and BIM
  • IFC scope detailed BIM specification
  • IFC focuses in (BIM-based) process change in BC
  • IAIs buildingSMART programme is about promoting
    BIM using IFC

13
BIM improves the processes
  • A project/building BIM is the digital repository
    for all computer generated data for that
    project/building
  • Reuse of same data model makes professional
    services more efficient and better
  • No errors, omissions and misrepresentation from
    recreating same data
  • More effort/time devoted to design and design
    analysis
  • Issues in design coordination, conflicts and code
    compliance can be addressed much earlier (in
    design phase)
  • Design errors and omissions can be detected and
    corrected before construction
  • Unprecedented opportunity to provide enhanced
    scope of services
  • Building design and performance analyses
    integrated among different disciplines (resulting
    in more sustainable, energy efficient buildings)
  • Professional services and BIM coordination
    throughout a buildings life
  • New project delivery system that will change the
    stereotype business model
  • Project delivery based on BIM, not on volumes of
    drawings and text
  • Business model that capitalizes on continuous
    reuse of the BIM

14
BIM in practice
Conversion 2D -gt BIM
Model CAD 3D Facilities Management
Electrical domain
Collision detection
Thermal domain
HVAC domain
Source German IAI for building Services
15
3. IFC and AEC-FM life-cycle
IFC full AEC-FM life-cycle
16
ICT and the Construction Industry
e-Watch e-Business Index 2005 by sector
  • e-Business activity is less developed in
    construction industry than in other (analysed)
    manufacturing sectors.
  • Most companies in tend to organise work around
    individual construction projects which led to a
    fragmentation in ICT use and e-business activity,
    characterised by a lack of commonly accepted
    standards, technical specifications and labels.
  • Many companies prefer to be re-active rather than
    pro-active in ICT use. Slow ICT uptake in a
    sector dominated by SMEs. Large enterprises in
    industry and new sector entrants have adopted ICT
    based production methods.
  • There are a multitude of standards, technical
    specifications, labels, and certification marks.
  • Construction industry yet to show the same level
    of ICT driven improvement of productivity as in
    other industries.
  • Great potential for ICT uptake, e.g. production
    planning systems, ERP-systems with financial
    components, inventory management systems, SCM,
    mobile solutions.
  • Business process integration (may be) a key
    driver for ICT adoption in the future.
  • Based on 16 ICT indicators (weighted by
    employment), aggregated into two sub-indices.
  • Population firms using computers from 7 EU
    countries
  • CZ, DE, ES, FR, IT, PL, UK
  • Size of the bubble persons employed in a sector
    (in relation to other sectors)
  • Green Manufacturing / Blue Services / Red
    Construction

(1) The European e-Business Report 2005 edition,
4th Synthesis Report of the e-Business W_at_tch,
November 2005, http//www.ebusiness-watch.org/reso
urces/synthesis.htm
17
4. IFC and ICT technologies
  • Support innovation in construction via integrated
    innovative model-based design processes
  • Support multi-disciplinary approaches toward
    sustainability,
  • Support design and delivery of lifecycle values
    of the facility.
  • Enable better visualisation and simulation
    capabilities to serve the client
  • Enable clients and designers to review and
    evaluate alternative design options using digital
    building simulation models before commencing
    construction.
  • Support efficient management of project data and
    workflow within and between companies
  • Enable software infrastructure that supports
    collaboration.
  • Enable automatic and seamless data transfer
    between applications and over the web.
  • Extend existing knowledge into new areas and
    applications
  • Integrate client briefing into digital model
    based design build planning processes,
  • Integrate digital model based supply-chain
    manufacturing data in design build planning
    processes,
  • Integrate digital model based building code
    checking process into the design build processes,
  • Integrate digital model based urban
    infrastructural data (terrain, road, bridges) in
    design build processes,
  • Integrate digital model based information into
    operational and facility management practice.

IFC is the backbone for the ICT visions of today
and tomorrow in AEC-FM industries
18
How IFC works? Who uses IFC?
Application domains to IFC
Business to Business (B2B)
Other companies
Project
Education to Business (E2B)
Business to Administration (B2A)
(Public) Administration
Education Research
19
Practical Design (Cooperative) using IFC (for
today)
DMS Document Management System Project Managemen
t System
20
Improved Design (Collaborative) scenario using IFC
IFC Model Server
21
eGovernment best-practice using IFC
? Fully Automated Code/Regulation Checking
  • Implemented in Singapore
  • In development at Norway
  • Under consideration in Scotland

Designer
PublicAdministration
Estimate Costing (in small projects) - Printing
costs of drawings 48-165 per submission
(excluding resubmissions) - Costs in each
submission 7-41 per request
22
Who uses IFC?
  • Architects (seamlessly) use IFC
  • Building Services Engineers (seamlessly) use IFC
  • Civil Engineers (seamlessly) use IFC
  • Contractors personnel (seamlessly) use IFC
  • Facility personnel (seamlessly) use IFC
  • Owners (seamlessly) use IFC
  • All involved in life-cycle uses IFC... but none
    should be aware that they are using IFC.

23
IFC Statements
  • IFC is a truly global effort in AEC-FM industries
  • IFC has become the most recognized standard for
    BIM
  • IFC is supported by most global CAD software
    vendors
  • IFC is supported by many downstream applications
  • IFC is currently being used on many real and
    pilot projects with international coverage.

24
IFC future in view of Interoperability evolution
buildingSMART evolution
International
Legal
Inter-community
Inter-connectivity
Political / Human
Organisational
EnterpriseModelling
Data Integration
Operational
Semantic
Semantic
Semantic
Access
Constructive
Technical
Content Management
Technical
Technical
Architectures Platforms
Programmatic
UKOLN
European Interoperability Framework
UKeGIF
EU/IST Interoperability Technologies
1990s prior
US DoD
25
Future Bridging IFC with other relevant domains
Building Information - IFC -
OGC / TC 211 ? IFC for GIS
landXML? ? IFC for Civil Engineering
STEP ? IFC for STEP
Civil Engineering (E.g. Roads, Bridges, etc)
Products
Geographical Geospatial Information
26
IFC Summary Sheet
IFC Business case
IFC Scope
  • Process change in Building Construction
  • Establish a neutral BIM
  • Industry led effort
  • Planning, Design, Construction, FM
  • Building w/ elements, structure, systems, ...
  • From high-level to very semantic detail
  • Properties, Classification, Materials, Shape 2D/3D

Outside Scope
Supporting Applications
  • GIS, and other supporting processes
  • Drafting
  • Major CAD in Building Construction
  • HVAC, Structural, Analysis, Checking
  • CAFM, cost planning, programming
  • Libraries

27
(No Transcript)
Write a Comment
User Comments (0)
About PowerShow.com
