Nursing care for the Pt. with Pacemaker
???????? ???????????????
Sub CCU Maharaj Nakorn Chiangmai Hospital
2
?????????????????????????(Pacemaker)
An artificial pacemaker is an electronic device
to provide repetitive electrical stimuli to the
heart muscle in order to control the heart rate
Pacemaker system -???????????????????????? (pulse
generator) ??????? ????????? ???????????? -???????
(lead) ??????????????????????????????????????????
????????????????????? (electrode)
3
Types of Pacemakers

• Temporary
• Prophylactic-used until the condition resolves in
  symptomatic bradycardia
• Pacemaker have the power source outside the body
• Permanent Pacemaker
• Conditioned persists despite adequate therapy
• implanted entirely within the body

4
Pacemakers Code

• Identification Code - 5 letters
• 1st - Chamber(s) paced
• 2nd - Chamber(s) sensed
• 3rd - Response to sensing
• 4th - Rate Modulation Programmability
• 5th - Antitachycardia Pacing Function

5
The NASPE/BPEG Generic (NBG) Code
Position
I
II
III
IV
V
Category
Chamber(s) Paced
Response to Sensing
Programmability, rate modulation
Antitachy- arrhythmia Function(s)
Chamber(s) Sensed
Letters Used
O-None P-Simple Programmable M-Multi- Programmab
le C-Communicating R-Rate modulation
O-None A-Atrium V-Ventricle D-Dual (AV)
O-None A-Atrium V-Ventricle D-Dual (AV)
O-None T-Triggered I-Inhibited D-Dual (TI)
O-None P-Pacing (antitachy- arrhythmia) S-Shock
D-Dual (PS)
Manufac- turers Designation Only
S- Single (A or V)
S- Single (A or V)
NASPE North American Society for Pacing
Electrophysiology BPEG British Pacing
Electrophysiology
6
Pacing mode

• Single chamber modes
• -AAI
• -VVI
• -VVIR
• Dual chamber modes
• -DDD
• -DDDR

7
AAI
I

8
VVI
I

9
DDD
T / I

I

10
Pacemaker Indication

• Sinus node dysfunction (SSS)
• AV Block 3AVB Symptom, Intermittent
  Symptomatic 2AVB, Symptomatic Adv. AVB with AF or
  flutter
• Sinus node disease with AV Block
• Chronic Atrial fibrillation with AV Block

11
Temporary Pacemakers

• Insertion
• External - applied emergently at the bedside
• Epicardial - leads are placed by the cardiac
  surgeon in the operating room
• Transthoracic - Usually attempted emergently, as
  a last resort, after other temporary pacing
  methods have failed. Physician inserts a
  pericardial needle through the subxyphoid area of
  the thorax into the right ventricle and advances
  the lead wire through the needle in order to
  achieve contact with the endocardium
• Transvenous - May be inserted at the bedside,
  preferably under fluroscopy. Usually inserted
  into the subclavian or jugular vein, but can be
  inserted into the antecubital or femoral vein

12
Temporary Pacemakers

• Transvenous pacing
• If initiated through antecubital or femoral vein,
  limit mobility of the extremity
• Determine sensitivity and pacing thresholds
• Set pacemaker settings
• Initiate pacing
• Follow hospital procedure protocol for
  initiating and adjusting pacemaker settings

13
Pacer-related Complications

• Pacer lead dislodgement/ broken lead
• Cardiac perforate tamponade
• Pneumothorax hemothorax
• Infection Phlebitis, pacer pocket ,
  endocarditis
• Ventricular arrhythmia after initial cath.
  Insertion
• Abdominal twitching or hiccups
• Pacemaker malfunction
• Pacemaker syndrome loss of AV synchrony,
  retrograde conduction, inappropriate AV delay
• - Low CO
• - S/S of HF Shortness of breath, dizziness,
  fatique, anxiety, palpitation, chest pain or
  confusion

14
Failure to pace
Pacemaker programmed to 830 ms / 72 ppm
15
Failure to pace
Pacemaker programmed to 830 ms / 72 ppm
16
Failure to Capture
Automatic Interval
Escape Interval
QRS to QRS
800 ms
800 ms
1600 ms
Sensed
Sensed
Sensed
Noncapture
Noncapture
Noncapture
Noncapture
17
UNDERSENSING
Intrinsic Refractory Period
Automatic Interval
800 ms
Undersensing
Capture
Capture
Capture
Capture
18
OVERSENSING
Lack of Pacing Spike
Lack of Pacing Spike

• Sources
• Myopotentials
• Environment
• Intrinsic Cardiac Signals

19
BATTERY DEPLETION
Automatic Interval
Intrinsic Refractory Period
Fusion
1000 ms
Capture
Undersensing
Capture
Undersensing
Pacemaker programmed to 830 ms / 72 ppm
20
Temporary Pacemakers

• Troubleshooting
• Failure to pace- cant see pacemaker spikes
  during periods of asystole or bradycardia
• Loose connections in the pacing system
• Failure of pacemaker battery or pulse generator
• Fracture of the pacing lead wire
• Lead wire dislodgement
• Failure to capture - pacemaker spike is not
  followed by a P wave or QRS as appropriate
• Loose connections in the pacing system
• Increased pacing threshold
• Fracture of the pacing lead wire
• Lead wire dislodgement
• Failure of pacemaker battery or pulse generator

21
Temporary Pacemakers

• . Undersensing - pacemaker fires with no regard
  to the patients own rhythm. Dangerous because it
  may lead to ventricular tachycardia and/or
  ventricular fibrillation
• Inadequate QRS signal
• Myocardial ischemia, fibrosis, electrolyte
  imbalances, bundle branch block, or a poorly
  positioned lead
• Oversensing - pacemaker thinks it detects a QRS
  complex, inhibits itself and doesnt fire
• Tall or peaked P waves or T waves
• Myopotentials (electrical signals produced by
  skeletal muscle contraction as with shivering or
  seizures)

22
Temporary Pacemakers

• Patient Management
• ECG monitoring
• Hemodynamic monitoring
• Assess pacemaker function
• Electrical safety
• Reassess functioning after defibrillation
• Pacing insertion site care
• Assure pacemaker controls are protected from
  accidental adjustment
• Provide information regarding pacemaker therapy
  to the patient and family
• If temporary wires exist-coil and tape to chest
  when not in use

23
Permanent Pacemakers

• Components
• Pulse generator - consists of lithium batteries
  and electrical micro circuitry encased in
  titanium. Lithium batteries last about 6-12
  years, depending on how much the pacemaker is
  used
• Lead wire - a catheter with electrodes at the
  tip. Ventricular wires are easier to secure than
  atrial wires
• Electrode(s) - remember the negative electrode is
  the one that paces

24
BIPOLAR LEAD
UNIPOLAR LEAD
25
BIPOLAR
UNIPOLAR
26
Permanent Pacemakers

• Lead Placement
• Epicardial
• Usually placed during heart surgery
• Leads placed in contact with epicardium
• Pulse generator in a subcutaneous pocket in
  abdomen
• Endocardial (Transvenous)
• Most common
• Pacing catheter inserted percutaneously via
  subclavian vein and advanced to the right atrium
  or apex of right ventricle
• Leads placed in contact with endocardium
• Pulse generator in subcutaneous pocket in the
  subclavian area

27
Dual chamber Pacemaker
28
Permanent Pacemakers

• Examples
• Single Chamber VVI Pacemakers
• Advantages - simple one lead system where the
  lead wire is placed in the right ventricle
• Limitations - loss of AV synchrony, lack of rate
  variability
• usually placed in patients who have chronic
  atrial fibrillation with SVR
• VVIR pacers were developed to achieve rate
  variability - there is a sensor in the pulse
  generator that senses skeletal muscle activity

29
Permanent Pacemakers

• Dual Chamber DDD Pacemakers
• Advantages - two lead system with one lead wire
  in the atrium and one lead in the ventricle,
  capable of pacing the atria and ventricles,
  preserves AV synchrony,
• Limitations -
• Patients with atrial fibrillation or atrial
  flutter - it cant capture the atrium. Pacer is
  confused by the atrial activity. This will not
  cause harm to the patient, but will deplete the
  batteries faster. Should be reprogrammed.
• Lack of rate variability - DDDR pacers were
  developed to achieve rate variability. As the
  sensor picks up skeletal muscle activity, the
  DDDR pacer will increase the atrial pacing rate.

30
CXR Pt. With DDD
31
Paced QRS Morphology
Lead Position QRS Morphology
QRS Axis
32
Permanent Pacemakers

• Troubleshooting
• Failure to capture
• Reasons
• Lead dislodgement
• Lead fracture
• Loose connections between pulse generator and
  lead wire
• Fibrosis at the tip of the lead causing changes
  in the pacing threshold
• Treatment
• Obtain a chest x-ray to determine lead position
• Reposition or replace lead if dislodged or
  fractured
• Reprogram pacer if fibrosis is cause of failure
  to capture
• SQ pocket may need to be reopened to check
  connections
• Have atropine and external pacemaker at bedside
  in case patient develops a symptomatic bradycardia

33
Permanent Pacemakers

• Failure to sense
• Reasons
• Electromagnetic interference
• Lead fracture
• Loose connections between the pulse generator and
  the lead wire
• Battery failure
• Treatment
• Move away from magnetic field
• Obtain a chest x-ray to determine lead position
• Reposition or replace lead if dislodged or
  fractured
• SQ pocket may need to be reopened to check
  connections
• Replace generator if needed
• If undersensing or oversensing and generator is
  programmable, need to reprogram

34
Permanent Pacemakers

• Failure to pace
• Reasons
• Electromagnetic interference
• Lead fracture
• Loose connections between the pulse generator and
  the lead wire
• Circuitry or battery failure
• Treatment
• Move away from magnetic field
• Obtain a chest x-ray to determine lead position
• Reposition or replace lead if dislodged or
  fractured
• SQ pocket may need to be reopened to check
  connections
• Replace generator if needed
• Have atropine and external pacemaker at bedside
  in case patient develops a symptomatic
  bradycardia

35
Permanent Pacemakers

• Patient Management
• Pre-op
• - Pre-op Physical Emotional social
• Avoid placing ECG monitoring electrodes over the
  right or left subclavian areas
• Assess S/S, Lab CBC,BUN Cr e,PT,PTT,AntiHIV,
  CXR, EKG
• Clean shave both shoulders groins
• On PSS locked or IV fluid
• Patient and family teaching
• NPO after midnight or before at least 4 hr.
• Where procedure will be done and about how long
  it will take
• Pre-op medications - sedative and antibiotic
• Local anesthesia rather than general

36
Permanent Pacemakers

• Immediate Post-op
• Patient and family teaching
• Frequent vital signs until stable
• Bedrest up to 24 hours
• Limited range of motion in the affected arm and
  maintain pressure dressing 48 hr.
• Be careful about incision site
• Administration of antibiotics
• Encourage coughing and deep breathing

37
Permanent Pacemakers

• Post-op Nursing Management
• Document type of pacer and settings
• Run an initial strip and then more often if
  pacing in noted on monitor 24 hours
• Record V/S every 15 4 times until stable
• Obtain a 12 leads ECG
• Monitor for signs symptoms of pacemaker
  malfunction
• Observe pressure dressing for signs of infection
  bleeding 48 hr then simple dressing OD 7 days
• Administer antibiotics as prescribed
• Assess pain and offer pain medicine prn if
  necessary
• Minimal arm shoulder activity prevent
  dislodgement of new leads 2 wk
• Follow up CXR PA lt. Lateral view
• D/C on day 4 after implantation if no
  complication

38
Permanent Pacemakers

• Discharge Teaching
• Watch insertion site for signs of infection
• If sutures, they will be removed in one week. If
  steristrips, they will gradually fall off
• Avoid lifting affected arm for at least 2 weeks
• Return to activities gradually (prevent frozen
  shoulder)
• Activities allow avoid avoid contact sports
• How to take a pulse
• Signs symptoms of pacemaker malfunction
• Importance of follow-up visit to PPM check up
• Life of batteries usually 6-12 years
• New medications

39
Permanent Pacemakers

• Carry Pacemaker ID card containing pacemaker
  information show to doctors, dentists, etc.
• Avoid electromagnetic interference (EMI)
• all household appliances, including microwave
  ovens, are OK to use
• avoid welding equipment power transmitters
  large generators radio, television, and radar
  towers - antennas at home are safe, but not CB
  and ham operator antennas
• avoid leaning directly over any running engines
  or motors - can create magnetic fields
• Avoid carrying cellular phones in pocket near
  pacemaker site 6 inch

40
(No Transcript)
41
(No Transcript)
42
Permanent Pacemakers

• avoid electrocautery and diathermy
• No radiation therapy to the chest (pacemaker
  generator should be shield)
• No MRI scan performed for other medical
  conditions (Pt. Need to have CT scan done
  instead)
• Inform other physician that they have a
  pacemaker, particularly dentists
• ?????????????????? at airport metal detectors.
  Need to inform them to be careful of hand-held
  wands as they may have magnets in them and should
  therefore not be held over the pacemaker
  generator for a long period of time
• Defibrillation/cardioversion ??????
  paddles????????????????????????? 10 ??.

43
Any Question?
Thank you
Common Rosefinch
