Title: Traumatic Injuries of the Upper Extremity


1
Traumatic Injuries of the Upper Extremity
  • Kevin deWeber, MD
  • MAJ, MC
  • Primary Care Sports Medicine

2
ObjectivesYou should be able to treat...
  • AC joint sprains
  • Anterior shoulder dislocations
  • Clavicular fractures
  • Radial head fractures
  • Skiers thumb
  • Scaphoid fractures
  • TFCC tears
  • And know referral criteria for complications

3
(No Transcript)
4
(No Transcript)
5
Normal axillary view
6
AC joint sprains
  • AKA separated shoulder
  • Mechanism
  • Blow to top of shoulder
  • May result from fall onto outstretched arm or
    elbow
  • Focal tenderness and pain with shoulder motion
  • Cross-chest adduction test usually positive

7
Cross-Chest Adduction Test
  • AC joint
  • Adduct shoulder
  • Patient pushes elbow up against resistance
  • Pain in AC test
  • false test in RC pathology

8
Types of AC joint sprains
9
AC joint sprainsRadiology eval
  • Standard AP shoulder views inadequate
  • usually over-penetrate the AC joint
  • Image both sides for comparison
  • Get specific AC joint view (Zanca)
  • AP with 10 cephalic incline
  • Axillary view can show posterior dislocation

10
Normal AC joint
11
Grade II AC joint sprain
12
Grade III AC joint sprain
13
  • Weighted AC x-rays seldom unmask unstable injures
  • Bossart PJ et al. Lack of efficacy of weighted
    radiographs in diagnosing acute acromioclavicular
    separations. Ann Emerg Med 1988 11720-24.

14
Management of mild AC joint sprains (types I and
II)
  • Ice, analgesia
  • Sling 1-3 weeks
  • Early ROM as pain permits
  • Strength exercises after full ROM achieved
  • Return to sports after pain-free function achieved

15
Management of type IIIAC joint sprints
  • Initially same as for I and II
  • Referral to ortho advisable within 72 hours
  • Most authors advocate conservative management
  • Outcome just as good as surgery, with quicker
    recovery time

16
Acute management of severe AC joint sprains
(types IV, V, VI)
  • Ice, analgesia
  • Management of any complications (type VI
    associated with clavicle fxs, rib fxs, and
    brachial plexus injuries)
  • Sling/swath
  • Early referral

17
Clavicular Fractures
  • One of the most common fractures
  • Classification
  • Middle third - most common (thinnest section)
  • Distal third
  • Proximal third
  • Image with AP thorax and 45 AP cephalic tilt
  • Rule out neurological or vascular compromise
    pneumothorax in 3

18
(No Transcript)
19
Lateral third clavicle fracture, type II
displaced)
20
ER Management ofClavicular Fractures
  • Ice, analgesics, arm support for all
  • Referral rule
  • Any displaced, non-middle-third fractures
  • Non-displaced fxs sling ROM prn comfort
  • Displaced middle-third fractures figure 8
    splint
  • Re-image in 7 days to assure reduction. If not,
    refer for shoulder spica cast

21
Shoulder dislocations
  • Most commonly dislocated large joint
  • Anterior in 97
  • Mechanism force on abducted/externally rotated
    shoulder
  • Exam
  • Shoulder externally rotated
  • Fullness anteriorly acromion prominent post.
  • Neurovascular testing

22
Radiology of shoulder dislocations
  • AP and axillary views optional scapular lateral
    (Y)
  • Location of humeral head w.r.t glenoid
  • Look for fractures (not a contra-indication to
    reduction)
  • Always pre-reduction x-rays in primary cases
  • Optional pre-reduction x-rays in recurrent cases
  • Always post-reduction x-rays

23
Anterior shoulder dislocation
24
Anterior shoulder dislocation
25
Posterior shoulder dislocation
26
Hill-Sachs deformity
27
Bankart lesion
28
Shoulder dislocation reduction techniques
  • Types of maneuvers
  • Traction (Stimson, self-reduction, Hippocrates,
    Eskimo,Milch)
  • Scapular manipulation
  • Leverage (Kocher)
  • Combined maneuvers (slump, Snowbird)
  • No comparative research

29
The Stimson technique for anterior
shoulder dislocation reduction.
30
Post-reduction treatment for shoulder dislocation
  • Ice 72 hrs, NSAID 7-14 days
  • Immobilization 3-6 weeks
  • Capsule needs time to heal
  • Physical Therapy referral for rehab
  • Less immobilization (1 week) and quicker rehab in
    pts gt40 (to prevent stiffness) and in recurrent
    dislocators

31
Indications for early orthopedic referral for pts
with shoulder dislocation
  • Displaced greater tuberosity fxs (gt1 cm
    post-reduction)
  • Glenoid rim fxs displaced gt5mm
  • Irreducible dislocations (soft tissue
    interposition)
  • Young athletes

32
Elbow trauma
  • Fractures
  • Dislocations
  • Ligament sprains
  • Look for compartment syndrome
  • Rule out neurovascular injury

33
(No Transcript)
34
(No Transcript)
35
(No Transcript)
36
(No Transcript)
37
Axioms in elbow trauma radiograph evals
  • Look for fat pads signs (capsular effusion)
  • Anterior fat pad (from coronoid fossa) may be
    normal compare to other side
  • Posterior fat pad (from olecranon fossa) is
    always abnormal
  • Compare to x-rays of other side in children
  • If elbow cant be extended, obtain AP/lat of both
    humerus and forearm

38
(No Transcript)
39
Fat pad signs
40
Elbow fractures
  • Supracondylar, epicondylar
  • Radial head/neck
  • Olecranon
  • Coronoid process
  • Consult current texts or your friendly local
    orthopedist for treatment of each.

41
Radial head/neck fractures
  • Common fracture in adults
  • FOOSH usually
  • Detection may require oblique view
  • Assure proper alignment of head on capitellum
    (radiocapitellar line)

42
  • Radial head fracture types
  • Type I less than 2 mm displacement
  • Type II angulated or gt2 mm displaced
  • Type III comminuted

43
Radiocapitellar line
44
Radial head fracture
45
Radial head fracture
46
ER treatment ofRadial head/neck fractures
  • Consider aspiration of hemarthrosis to relieve
    pain
  • Type I
  • Posterior splint a few days
  • Sling AROM when tolerated
  • Physical therapy in 3 weeks
  • Types II and III - splint and refer

47
(No Transcript)
48
Skiers Thumb
  • Pathoanatomy
  • Sprain of ulnar collateral ligament of thumb MCP
  • Grades I, II, and III
  • I no laxity
  • II laxity but intact
  • III complete tear

49
Skiers Thumb
  • Mechanism of injury
  • Forced abduction and hyperextension of thumb
  • FOOSH with thumb caught in extension
  • Diagnosis
  • History
  • Radiographs
  • Physical exam

50
Skiers Thumb
51
Skiers thumb exam
  • Anesthesia (block)
  • Valgus stress to MCPJ in extension
  • Over 20 opening is probably grade III tear

52
Stener Lesion
53
Skiers Thumb
  • Stener lesion
  • 64 of Grade III injuries
  • Adductor aponeurosis interposed
  • Prohibits reattachment of ligament
  • MRI and arthrogram are sensitive

54
Skiers ThumbTreatment
  • Grades I II
  • Thumb spica splint 2-4 weeks, then
  • Splint or tape 3 months
  • Grade III
  • Controversial
  • Surgery
  • Refer to Ortho

55
Scaphoid Fracture
  • History
  • FOOSH
  • Dull, deep, ache in radial side of wrist

56
Scaphoid FractureAnatomy
  • Blood supplied from distal pole
  • The more proximal the fracture, the greater the
    risk of avascular necrosis (AVN) or delayed union

57
(No Transcript)
58
Scaphoid FractureExamination
  • Minimal swelling
  • Tenderness in snuff box
  • Pain with axial load

59
Scaphoid tubercle fracture
60
Scaphoid fracture Radiographs
  • AP
  • Lateral
  • Oblique
  • Scaphoid view
  • Normal plain films dont rule out a scaphoid
    fracture

61
(No Transcript)
62
(No Transcript)
63
Scaphoid FractureTreatment
  • Non-displaced fracture of waist or distal pole
  • Long arm thumb spica cast 6 weeks
  • Then, short arm thumb spica cast for 2-6 weeks
  • Replace cast/get x-rays Q2 wks to assess healing

64
Scaphoid FractureTreatment (cont)
  • Clinically suspected fracture with normal plain
    films
  • Treat as non-displaced fracture
  • PRICE
  • Short-arm thumb spica cast
  • F/U in 10 days for repeat x-rays
  • Consider bone scan/MRI if x-rays neg but fx
    suspected

65
Scaphoid FractureReferral criteria
  • Proximal fractures
  • Angulated displaced gt1mm
  • Scapholunate dissociation
  • Presentation gt 2 wks
  • Early return to play necessary
  • Non-union or AVN

66
Triangular Fibrocartilage Complex (TFCC) Tear
  • Mechanism of injury
  • Fall on dorsiflexed and ulnar deviated wrist
  • Axial load with forearm in hyperpronation
  • Patient c/o ulnar sided wrist pain, swelling,
    loss of grip strength

67
TFCC tear
68
TFCC
  • Thickened pad of connective tissue that functions
    as a cushion for ulnar axial loads

Articular disc
Meniscus
Ulnar collateral ligament
69
TFCC tearExamination (cont)
  • Tenderness just distal to ulnar styloid

70
TFCC tearExamination (cont)
  • Press test
  • Patient presses arms of chair to lift body off
    seat
  • 100 sensitive

71
TFCC tearExamination (cont)
  • TFCC load test
  • Pain is a test

72
TFCC tearExamination (cont)
  • Rule out injury to distal radio-ulnar joint
    (DRUJ)
  • Squeeze radius/ulna together and passively rotate
    forearm
  • Painful in DRUJ injury
  • No pain in isolated TFCC tear

73
TFCC TearRadiography
  • Plain films
  • Positive ulnar variance (ulna 1-5 mm longer than
    radial articular surface) a/w TFCC tear
  • Assess for fracture or ulnar subluxation
  • MRI or Arthrography optional to confirm

74
MRI TFCC tear
75
TFCC TearTreatment
  • Long arm cast with forearm neutral for 4-6 weeks
  • Referral criteria
  • Associated injuries including DRUJ instability
  • Persistent pain after immobilization

76
Review
  • Refer all vertically displaced AC joint sprains
  • Refer any displaced, non-middle-third
    claviclular fractures
  • Pick and KNOW 1-2 shoulder reduction methods
  • Conservatively treat non-displaced radial head
    fractures
  • Refer all Skiers thumb that gap gt20
  • Treat suspected scaphoid fxs even if xrays neg
  • Treat TFCC tears with 6 wks long arm cast
