Week%204

1
Multimedia

• Week 4
• LBSC 690
• Information Technology

2
Agenda

• Questions
• Muddiest Points
• XML
• Images
• Audio
• Transmission
• Project teams

3
Muddiest Points

• Using other peoples pages
• Using FTP to get a Web page someplace
• Internal anchors
• Structure vs. appearance

4
Whats Wrong with the Web?

• HTML
• Confounds structure and appearance (XML)
• HTTP
• Cant recognize related transactions (Cookies)
• URL
• Links breaks when you move a file (PURL)

5
Discussion Point Describing the Structure of
Text

• Entities
• Span
• Type/Attributes
• Relationships
• Part-whole
• Is-a

6
Whats a Document?

• Content
• Structure
• Appearance
• Behavior

7
History of Structured Documents

• Early standards were typesetting languages
• NROFF, TeX, LaTeX, SGML
• HTML was developed for the Web
• Too specialized for other uses
• Specialized standards met other needs
• Change tracking in Word, annotating manuscripts,

• XML seeks to unify these threads
• One standard format for printing, viewing,
  processing

8
Goals of XML

• Meta language
• A toolkit for design markup languages
• Unambiguous markup
• Clear span of tags
• Separate markup from presentation
• Style info gt stylesheet, so easy to change
• Be simple

9
A Family of Standards

• Definition DTD
• Names known types of entities with labels
• Defines part-whole and is-a relationships
• Markup XML
• Tags regions of text with labels
• Markup XLink
• Defines hypertext (and other) link
  relationships
• Presentation XSL
• Specifies how each type of entity should be
  rendered

10
XML Example

• View The Song of the Wandering Aengus
• http//glue.umd.edu/rba/COURSES/TECHNOLOGY/XML/DT
  D/
• Built from three files
• yeats01.xml
• poem01.dtd
• poem01.xsl

11
An XML Example
lt?xml version"1.0"?gt lt!DOCTYPE POEM SYSTEM
"poem01.dtd"gt lt?xml-stylesheet type"text/xsl"
href"poem01.xsl"?gt ltPOEMgt ltTITLEgtThe Song of
Wandering Aenguslt/TITLEgt ltAUTHORgt
ltFIRSTNAMEgtW.B.lt/FIRSTNAMEgt
ltLASTNAMEgtYeatslt/LASTNAMEgt lt/AUTHORgt ltSTANZAgt
ltLINEgtI went on to the hazel wood,lt/LINEgt
ltLINEINgtBecause a fire was in my
head,lt/LINEINgt ltLINEgtAnd cut and peeled a hazel
wand,lt/LINEgt lt/STANZAgt lt/POEMgt
12
Document Type Definition (DTD)
lt!ELEMENT poem ( (title, author, stanza) )gt
lt!ELEMENT title (PCDATA) gt lt!ELEMENT author
(firstname, lastname) gt lt!ELEMENT firstname
(PCDATA) gt lt!ELEMENT lastname (PCDATA) gt
lt!ELEMENT stanza (line linein) gt lt!ELEMENT
line (PCDATA) gt lt!ELEMENT linein (PCDATA) gt
PCDATA span of text a,b a followed by
b ab either a or b a 0 or more as a 1 or more
as
13
Specifying Appearance XSL
ltxsltemplate match"POEM"gt ltHTMLgt ltBODY
BGCOLOR"FFFFCC"gt ltxslapply-templates/gt
lt/BODYgt lt/HTMLgt lt/xsltemplategt
ltxsltemplate match"TITLE"gt ltH1gt ltFONT
COLOR"Green"gt ltxslvalue-of/gt
lt/FONTgt lt/H1gt lt/xsltemplategt
14
An XLink Example
ltpoem xmlnsxlink"http//www.w3.org/1999/xlink
"gt ltauthor xlinkhref"yeatsRDFS3.xml
xlinktype"simple"gtW. B. Yeatslt/authorgt
ltpoemsgt ltpoem1 xlinkhref"http//www.geocities.
com/Athens/5379/yeats_index.html"
xlinktype"simple"gtThe Roselt/poem1gt ltpoem2
xlinkhref"http//www.geocities.com/Athens/5379/y
eats_index.html" xlinktype"simple"gtThe
Towerlt/poem2gt lt/poemsgt lt/poemgt .
15
Some XML Applications

• Text Encoding Initiative
• For adding annotation to historical manuscripts
• http//www.tei-c.org/
• Encoded Archival Description
• To enhance automated processing of finding aids
• http//www.loc.gov/ead/
• Metadata Encoding and Transmission Standard
• Bundles descriptive and administrative metadata
• http//www.loc.gov/standards/mets/

16
Whats Wrong with the Web?

• HTML
• Confounds structure and appearance (XML)
• HTTP
• Cant recognize related transactions (Cookies)
• URL
• Links breaks when you move a file (PURL)

17
Cookies

• Servers know users by IP address and port
• Because thats where they send the Web pages
• Cookies preserve state
• Server sends data to the browser
• Browser later responds with the same data
• A unique code (server-side state)
• Information about the user (client-side state)

18
Uniform Resource Names (URN)

• Persistent URLs (www.purl.org)
• http//purl.oclc.org/OCLC/PURL/FAQ/

My Browser
PURL
PURL Sever
URL
URL
Resource Sever
Page
19
Summary

• Learning to build simple Web pages is easy
• Which is good news for the homework!
• All documents are structured documents
• XML is a flexible markup language toolkits
• The key is to understand its capabilities
• XML editors can hide much of the complexity

20
(No Transcript)
21
(No Transcript)
22
Visual Perception

• Closely spaced dots appear solid
• But irregularities in diagonal lines can stand
  out
• Any color can be produced from just three
• Red, Blue and Green additive primary colors
• High frame rates produce apparent motion
• Smooth motion requires about 24 frames/sec
• Visual acuity varies markedly across features
• Discontinuities easily seen, absolutes less
  crucial

23
Basic Image Coding

• Raster of picture elements (pixels)
• Each pixel has a color
• Binary - black/white (1 bit)
• Grayscale (8 bits)
• Color (3 colors, 8 bits each)
• Red, green, blue
• Screen
• A 1024x768 image requires 2.4 MB
• So a picture is worth 400,000 words!

24
Monitor Characteristics

• Technology (CRT, Flat panel)
• Size (15, 17, 19, 21 inch)
• Measured diagonally
• For CRT, key figure is viewable area
• Resolution
• 640x480, 800x600, 1024x768, 1280x1024 pixels
• Layout (three dot, lines)
• Dot pitch (0.26, 0.28)
• Refresh rate (60, 72, 80 Hz)

25
Some Questions

• How many images can a 64 MB flash card store?
• But mine holds 120. How?
• How long will it take to send an image at 64kb/s?
• But my Web page loads faster than that. How?
• But in reality images dont have these problems
• How do we get around these problems?

26
Compression

• Goal reduce redundancy
• Send the same information using fewer bits
• Originally developed for fax transmission
• Send high quality documents in short calls
• Two basic strategies
• Lossless can reconstruct exactly
• Lossy cant reconstruct, but looks the same

27
Palette Selection

• Opportunity
• No picture uses all 16 million colors
• Human eye does not see small differences
• Approach
• Select a palette of 256 colors
• Indicate which palette entry to use for each
  pixel
• Look up each color in the palette

28
Run-Length Encoding

• Opportunity
• Large regions of a single color are common
• Approach
• Record of consecutive pixels for each color
• An example of lossless encoding

29
GIF

• Palette selection, then lossless compression
• Opportunity
• Common colors are sent more often
• Approach
• Use fewer bits to represent common colors
• 1 Blue 75 75x1 75 75x2150
• 01 White 20 20x2 40 20x2 40
• 001 Red 5 5x3 15 5x2 10
• 130
  200

30
JPEG

• Opportunity
• Eye sees sharp lines better than subtle shading
• Approach
• Retain detail only for the most important parts
• Accomplished with Discrete Cosine Transform
• Allows user-selectable fidelity
• Results
• Typical compression 201

31
Variable Compression in JPEG
37 kB (20)
4 kB (95)
32
Discussion Point JPEG vs GIF in Web images

• Which format should I use for images in my web
  pages?
• Photos
• text images
• drawings

33
Hands on Point Convert between formats

• Load and save two images
• http//www.umiacs.umd.edu/daqingd/image1.jpg
• http//www.umiacs.umd.edu/daqingd/image2.gif
• Download the two images, use MS photo editor
  convert each to the other format, and compare the
  quality and the size.
• Increase the compression rate for image1.jpg, and
  compare the quality

34
Discussion Point When is Lossless Compression
Important?

• For images?
• For text?
• For sound?
• For video?

35
Basic Video Coding

• Display a sequence of images
• Fast enough for smooth motion and no flicker
• NTSC Video
• 60 interlaced half-frames/sec, 512x486
• HDTV
• 30 progressive full-frames/sec, 1280x720

36
Video Compression

• Opportunity
• One frame looks very much like the next
• Approach
• Record only the pixels that change
• Standards
• MPEG-1 Web video (file download)
• MPEG-2 HDTV and DVD
• MPEG-4 Web video (streaming)

37
Basic Audio Coding

• Sample at twice the highest frequency
• One or two bytes per sample
• Speech (0-4 kHz) requires 8 kB/s
• Standard telephone channel (1-byte samples)
• Music (0-22kHz) requires 88 kB/s
• Standard for CD-quality audio (2-byte samples)

38
Speech Compression

• Opportunity
• Human voices vary in predictable ways
• Approach
• Predict whats next, then send only any
  corrections
• Standards
• Real audio can code speech in 6.5 kb/sec
• Demo at http//www.data-compression.com/speech.htm
  l

39
Music Compression

• Opportunity
• The human ear cannot hear all frequencies at once
• Approach
• Dont represent masked frequencies
• Standard MPEG-1 Layer 3 (.mp3)

40
Transmission

• Download
• Transfer the whole file, then start replay
• Can be very slow for large files
• Streaming
• Play the file as it is received
• Also suitable for live broadcasts
• Requires a sufficiently fast connection

41
The Last Mile

• Traditional modems
• 56 kb/sec modems really move 3 kB/sec
• Digital Subscriber Lines
• 384 kb/sec downloads (38 kB/sec)
• 128 kb/sec uploads (12 kB/sec)
• Cable modems
• 10 Mb/sec downloads (1 MB/sec)
• 256 kb/sec uploads (25kB/sec)

42
Streaming Audio and Video

• Buffering a portion of audio/video
• Playing along with receiving
• Interrupted when Rebuffering.

Media Sever
Buffer
Internet
43
Hands On RealPlayer

• View streaming real video at http//www.glue.umd.e
  du/oard/teaching/690/fall03/syllabus.html
• Pay attention to buffering
• Look at the dropped packet statistics and the
  bandwidth monitor
• Go to Tools/playback statistics

44
Project

• Teams of 3
• Best if you have complementary skills
• Solve a real problem
• Choose the standard one, or invent your own
• Must integrate at least two technologies
• Web, database, streaming media, programming

45
The Apollo Archives

• Text
• Transcripts, press releases, manuals, flight
  plans, reports, books, oral histories
• Video
• Launch, movie film, television, splashdown
• Audio
• Radio, onboard recordings, interviews, press
  conferences
• Images
• Preflight, launch, onboard, splashdown,
  postflight
• http//www.hq.nasa.gov/alsj

46
Possible User Groups

• Museum visitors, in person
• General public, over the Web
• Children, on CDROM in school
• Historians, with a search system
