SEDIMENTARY ARCHIVES

1
SEDIMENTARY ARCHIVES
Sedimentary Structures Sole marks
2
SEDIMENTARY ARCHIVES
Sedimentary Structures Flute casts
3
SEDIMENTARY ARCHIVES
Sedimentary Structures Tool marks
4
SEDIMENTARY ARCHIVES
Sedimentary Structures Flame Structures
5
SEDIMENTARY ARCHIVES
Sedimentary Structures Geopetal Structures or
Which Way is UP? Load structures
6
SEDIMENTARY ARCHIVES
Sedimentary Structures Geopetal Structures or
Which Way is UP? Mudcracks
7
SEDIMENTARY ARCHIVES
Sedimentary Structures Geopetal Structures or
Which Way is UP? Planar Cross-beds
8
SEDIMENTARY ARCHIVES
Sedimentary Structures Geopetal Structures or
Which Way is UP? Trough Cross-beds
9
SEDIMENTARY ARCHIVES
Sedimentary Structures Geopetal Structures or
Which Way is UP? Oscillation ripples
10
SEDIMENTARY ARCHIVES
Sedimentary Structures Geopetal Structures or
Which Way is UP? Tool marks
11
SEDIMENTARY ARCHIVES
Sedimentary Structures Geopetal Structures or
Which Way is UP? Fossils
12
SEDIMENTARY ARCHIVES
Sedimentary Structures Geopetal Structures or
Which Way is UP? Fossils
13
SEDIMENTARY ARCHIVES
Sedimentary Structures Geopetal Structures or
Which Way is UP? Raindrop Impressions
14
SEDIMENTARY ARCHIVES
Interpretation of Sedimentary Rocks Provide
information about conditions in and near the
site of deposition Such as source area from
composition amount of transport erosion Qtz
vs. Feldspar (clay and iron compounds) vs
Ferromagnesians Immature vs mature
15
SEDIMENTARY ARCHIVES
Classification of Sedimentary Rocks
"Systems of classification are not hatracks,
objectively presented to us by nature. They are
dynamic theories developed to express particular
views..." Stephen Jay Gould
16
(No Transcript)
17
SEDIMENTARY ARCHIVES
Classification of Sedimentary Rocks
18
SEDIMENTARY ARCHIVES
Classification of Sedimentary Rocks
19
SEDIMENTARY ARCHIVES
Classification of Sedimentary Rocks
TEXTURE
20
SEDIMENTARY ARCHIVES
Classification of Sedimentary Rocks
21
SEDIMENTARY ARCHIVES
Classification of Sedimentary Rocks

• gt90 Quartz
• Cement silica
• calcite

Quartz Arenite
22
SEDIMENTARY ARCHIVES
Classification of Sedimentary Rocks

• gt25 Feldspar
• Granitic source
• Remainder is quartz
• Cement clay
• calcite
• iron oxides

Feldspathic Arenite Arkose
23
SEDIMENTARY ARCHIVES
Classification of Sedimentary Rocks

• gt33 rock fragments
• Immature sandstone
• Poorly sorted, angular
• Remainder is quartz,
• feldspar
• Cement very little
• mostly clays

Lithic Arenite Greywacke
24
SEDIMENTARY ARCHIVES
Classification of Sedimentary Rocks
25
SEDIMENTARY ARCHIVES
Classification of Sedimentary Rocks
Carbonates
Composition Carbonate rocks consist of limestone
and dolostone. The minerals present in each are
Limestone Calcite Aragonite Dolostone
Dolomite
26
SEDIMENTARY ARCHIVES
Classification of Sedimentary Rocks
Carbonates Most of marine origin Directly or
indirectly related to biological
processes Skeletal remains may be visible Can
be evaporites Changes in water temp.,
alkalinity, CO2 conc. Clear, shallow tropical
waters
27
SEDIMENTARY ARCHIVES
Classification of Sedimentary Rocks
Carbonates Characteristics of most marine
carbonate environments Warm water Tropical
climate (30 N - 30 S of equator) Shallow
water (less than 200 m deep) Clear water (low to
no terrigenous input) Sunlight required for
photosynthesis by algae
