Agenda

1
(No Transcript)
2
Agenda

• Introduction - Understanding, Team, Personnel
• Project Approach - Ensuring Success and Achieving
  Goals
• Scope of Work
• Examples of Relevant Experience
• Closing

3
Introduction of Presenters

• Christopher Webb, Project Manager, MN
• Clark Stevens, RoTo Architects
• Mark Carpenter, KTUA Not Present Today

4
Project Understanding

• The Lagoon Water Quality Is Impaired
• Upstream Freshwater Inputs Are Significant
• Lagoon Area Is Constrained
• Habitat Quality Is Compromised
• Lagoon Hydraulics Are Not Optimal
• The Site Is High-Profile (Surfing and Public Use)
• An Opportunity Exists for a Significant
  Ecological and Public Benefit

5
MN TeamOrganization
QA/QC
PRINCIPAL-IN-CHARGE
MICHAEL McCARTHY, P.E.
ALAN ALCORN, P.E.
PROJECT MANAGER
CHRISTOPHER WEBB
PROJECT ENGINEER
RUSSELL BOUDREAU, P.E.
RESTORATION ENVIRONMENTAL PLANNING
WETLANDS ENGINEERING
BIOLOGY
BIOGEOCHEMICAL CYCLING
LANDSCAPE ARCHITECTURE GIS
KTUA MIKE SINGLETON, L.A. Landscape MARK
CARPENTER Habitat Landscape Design
DAVID DYKSTRAEngineering WEIXIA JIN, Ph.D.,
P.E. CRAIG FRAMPTON Hydrology/Ecology GEE LIM,
P.E. Dredging/Earthwork Plans JOSEPH LITCHFIELD,
P.E.Quantity and Cost Estimates SCOTT
WHIPPLESpecifications
Merkel Associates KEITH MERKEL HOLLY
HENDERSON Moffatt Nichol CRAIG
FRAMPTON Entrix CAMM SWIFT
Swanson Hydrology NICOLE BECK, PH.D.
CHRISTOPHER WEBB Merkel Associates PHILIP
HINSHAW
MEETING FACILITATION
RoTo Architects CLARK STEVENS
6
STAFFING PLAN
7
Approach Plan Formulation

• Identify Opportunities and Constraints
• Plan the Ultimate Project
• Address High Priority, Short-Term Lagoon
  Restoration in Detail
• Focus on Simple, Holistic Solutions
• Design to Facilitate Construction

8
Privately Owned Land-Not Part of Project
(inclusive of B1)
9
Hydrogeomorphics

• Issue
• Pass the Flood
• Improve Circulation
• Anticipate Sediment Delivery

• Solution
• Remove Constrictions
• Design a Functional Lagoon
• Identify Sources, Design for Sedimentation

10
Water Quality

• Issue
• High Temperature and Bacteria Concentration
• Low Dissolved Oxygen
• Grease, Oils, Metals Input
• Septic Leaks
• Poor Nutrient Cycling

• Solution
• Increase Lagoon Volume, Circulate
• Increase Circulation
• Filter All Drainage
• Circulate Water
• Increase Nutrient Uptake

11
Habitat

• Issue
• Degraded Habitat
• Monotypic Habitat
• Establishment of Exotics
• Intrusion From Adjacent Areas

• Solution
• Optimize Physical and Chemical Conditions
• Diversify Brackish Marsh
• Remove Exotics and Install Natives
• Provide Buffering

12
Access and Educational Opportunities

• Issue
• Access not Optimal for Restoration
• Potential Educational Opportunities not yet
  Realized
• Public Interface not yet Optimized

• Solution
• Modify Access According to Restoration
  Alternatives
• Plan Educational Opportunities to Realize the
  Sites Potential
• Design Public Interface System to Maximize
  Benefits, Reduce Impacts

13
(No Transcript)
14
Alternatives Development

• Range From Least to Greatest Modifications
• Increase Circulation and Minimal Lagoon Change
• Increase Circulation With Major Lagoon
  Modification South of PCH
• Increase Circulation With Improvements Both South
  and North of PCH as Appropriate and/or
• A Combination of These Options

15
Maintenance and Monitoring

• Create a Self-Sustaining System by Employing
  Simple, Long-Lasting Solutions
• Monitor Water Quality (DO, Temperature, Bacteria,
  Nutrients), Hydraulics, Sedimentation, Habitat
• Maintain by Circulating, Removing Exotics,
  Clearing Stormwater Filters, Repairing Access
  Trails

16
(No Transcript)
17
Carpinteria Salt Marsh
18
Bolsa Chica Wetlands

• Preparation of Restoration Plan Report
• Phasing-in of Multiple Parcels
• Project Planning Work throughout Final
  Engineering
• Final Engineering for Construction of Large
  Wetlands Project in the Region
• High Profile
• Inlet, Dredging and Disposal, Beach Nourishment,
  Berms, Culverts, Nesting Islands
• Addressed Impacts to Surfing in Initial Planning
• MN and MA

19
EXISTING
PHASE 1
PHASE 2
PHASE 4
PHASE 5
PHASE 6
20
Famosa Slough Enhancement Plan Wetland

• Restoration Plan Report
• Community-Based Enhancement Planning
• Phased Restoration with Adaptive Management
  Elements
• Water Quality Wetlands are a Key Element of Work
• Work has Included Design, Engineering, and
  Implementation
• Agency Coordination RWQQCB, USFWS, Coastal
  Commission, USACE
• Salt Water Wetland Restoration
• Treatment Wetlands
• Permitting
• Public Meeting Coordination
• MA and KTUA

21
Batiquitos Lagoon

• Successfully Constructed and Functioning Wetland
  Restoration
• Agency and Community Coordination and Permitting
  Support
• Final Engineering and Construction Support
• Comprehensive Post-Construction Monitoring
• On-Going Consulting Services to Support Client
  During Site Evolution
• Innovative Material Disposal in an Overdredged
  Pit
• High Profile With Improved Surfing at the Mouth
• Dredging and Nesting Islands
• Environmental Constraints/Windows
• MN (Phase 1), MA and KTUA (Phase 2)

22
(No Transcript)
23
(No Transcript)
24
(No Transcript)
25
Project Benefits to Heal the Bay

• Successful Restoration of High Profile
  Restoration Project That
• Improves Water Quality
• Does Not Affect Existing High Quality Surfing
  Resources
• Results From Consensus-Building With Stakeholder
  Groups
• Depth of Resources to Apply to the Challenge
• Collaboration With Agencies

26
