Title: Radiocarbon Dating of Groundwater


1
Radiocarbon Dating of Groundwater
  • Elisabetta Boaretto
  • Radiocarbon Dating and Cosmogenic Isotopes
    Laboratory
  • Kimmel Center for Archaeological Sciences,
  • Weizmann Institute of Science
  • and
  • Dept of Land of Israel Studies and Archaeology
  • Bar Ilan University

2
low isotopic concentration 10-12-10-16 long
half-life
3
Our Idea
Surface collected raw material high 10Be

Blade from Qesem Cave
low 10Be Deep quarried raw material
4
(No Transcript)
5
(No Transcript)
6
Dendrochronology
7
12.4 26 kyr BP marine data corals, foraminifera
0 -12.4 kyr BP Tree-Ring data set
8
(No Transcript)
9
Radiocarbon
  • Activity is expressed in Pmc percent modern
    carbon
  • Age is calculated with the Decay Law
  • Precision of 0.5-0.3 40-25 years
  • Range 50,000 year (LSC 60,000 year)
  • Isotopic fractionation between 12C, 13C and 14C
    d13C
  • (13C/12C)sample-(13C/12C)sta
    ndard
  • d13C -----------------------------------
    ---- x1000

  • (13C/12C)standard

10
How does carbon and radiocarbon get in the
groundwater?
CO2(gas)root --- aq
100 pmc d13C -25
CaCO3
0 pmc d13C 0
11
Different water environments
12
(No Transcript)
13
Several alive specimen were measured with the
water were they lived
14
(No Transcript)
15
How does carbon and radiocarbon get in the
groundwater?
CO2(gas)root --- aq
100 pmc d13C -25
14C in groundwater - Relative ages between
aquifers - Aquifer-flow velocities - Study of
mixed system - Establishment of flow modes which
are related to environmental problems connected
with recent pollution
CaCO3
0 pmc d13C 0
16
Hvinningdal Aquifer - Raised plain 80 m asl -
800 mm/y precipitation - gt200 mm/y ca. recharge
- Matrix Tertiary quartz sand covered with
quaternary meltwater sand/gravel - Low carbonate,
some tertiary lignite and reworked black org
material - pH ca. 6 - T 8-10 ºC - O2 12 mg/l
saturation value - Some wells have
nitrate -Tritium (15-62 TU) is present in almost
all the wells indicating post-bomb groundwater
origin.
17
18 wells analyzed. Tritium 15-62 TU post-bomb
18
18 wells analyzed. Tritium 15-62 TU post-bomb
Matrix carbonate is negligible
Strong disagreement with the T data
n. 3.1 ?
Boaretto et al., Radiocarbon 1998
19
Oxygen as possible candidate for organic material
oxidation
T ºC O2 mg/l 7 11.8 8
11.5 9 11.2
20
n. 3.1, DOC ca. 3 mg/l
DOC ca. 0.3 mg/l
21
high O2 high 14C
Low O2 low 14C
22
Acorr diss Am(-25)/d13Cm
23
F (44/32) (12-O2)/SCO2
Acorr dissOx Am(-25)/(d13Cm25 F)
Fluctuation in gw table
24
  • CONCLUSION
  • Most of the sample Acorr is above or close to 100
    pmc ---- agreement with Tritium
  • Extremely low value 32 pmc is due probably to
    fresh exposure of organic material to atmosphere
  • Nitrate contribution to oxidation of organic
    matter
  • Age not more than few hundreds year

0 TU
25
Radiocarbon Dating in Water Environments
Very important for -control and use of
hydrological resources -chronologies
Variables are several modeling is necessary
