SURGE PROTECTIVE DEVICES

1
Codes Standards Update 2009
SURGE PROTECTIVE DEVICES DON GROVE - MAY 13, 2009
2
Outline

• Codes and Standards Update
• UL 1449 Third Edition
• Nomenclature changes
• Testing enhancements
• What Will be Different with EFI Products?
• Questions Closing Remarks

3
Codes Standards

• UL 1449 3rd Edition Update

4
Codes Standards Update 2009
UL 1449 3RD EDITION CHANGES
5
Codes Standards UL 1449 3rd Edition / IEEE
C62.41

• Overview
• Effective September 29, 2009
• Name Change to Surge Protective Device
• Category A,B,C changes to Type 1,2,3,4
• New Product Testing Requirements
• Inclusion of Nominal Discharge Current In

6
Codes Standards UL 1449 3rd Edition

• Effective September 29, 2009
• All Surge Protective Devices manufactured after
  this date must be compliant with UL testing
  parameters and performance ratings
• Many manufacturers are opting to be tested at
  other NRTLs
• Make sure specifiers are aware of the difference
  when it comes to components and integral offers,
  i.e. if component is not Recognized or Listed by
  Underwriters Laboratories, the entire assemblys
  Listing may be in question. (local inspector
  may question, UL may not back entire assy)
• ALL EFI devices will be listed with Underwriters
  Laboratories by September 29, 2009

.
7
Codes Standards UL 1449 3rd Edition

• Category Device Name Change

TVSS is Changing to SPD Surge Protective
Device(s)
.
8
Codes Standards UL 1449 3rd Edition

• Category Replaced with Type Designations
• Type 1 Service Entrance, Permanently connected
  line and load
• Type 2 Load Side Branch Panel, Point of Use
  permanently connected
• Type 3 Point of Utilization, Plug In
• Type 4 Discrete components

9
Codes Standards UL 1449 3rd Edition / IEEE
C62.41
Old Category Designations
L
SPD
SPD
SPD
Load
N
Line Side of OCPD Service Entrance Arrester Load
Side of OCPD Category C
Distribution Category B
Branch Category B
Point of Use Category A
10
Codes Standards UL 1449 3rd Edition
New Type Designations
L
SPD
SPD
SPD
Load
N
Line Side of OCPD Service Entrance Type 1 Load
Side of OCPD Type 2
Distribution / Perm. Connected Type 2
Branch / Perm. Connected / P.O.U. Type 2
Perm. Connected P.O.U. Type 2 Plug-in / P.O.U.
Type 3
11
Codes Standards UL 1449 3rd Edition

• Product Testing Changes
• Measured Limiting Voltage title changes
• 2nd ED.- Surge Voltage Rating (SVR)
• 3rd ED.- Voltage Protection Rating (VPR)
• Testing parameters (Increased performance)
• 2nd ED.- 6kV/0.5kA
• 3rd ED.- 6kV/3kA (6 times the current level)
• 3 impulses per mode of 6kV, 3kA using 8/20 wave
  shape
• 15 impulses per mode of 6kV, NDC (In)
• 3 impulses per mode of 6kV, 3kA
• Product must be within 10 of baseline readings
  in determining In ratings

12
Codes Standards UL 1449 3rd Edition

• Product Testing Changes
• New Nominal Discharge Current (In) Values on
  label
• Type 1 10kA, 20kA
• Type 2 3kA, 5kA, 10kA, 20kA
• Type 3 3kA

13
Codes Standards UL 1449 3rd Edition
Measured Limiting Voltage
Minimum Voltage Protection Rating
VPRVoltage Protection Rating 6kV, 3kA Impulse
with theNominal Discharge Current (In) test
14
Codes Standards UL 1449 3rd Edition

• What Will Be Different with EFI Products?
• The only noticeable difference will be In and VPR
  ratings on product labels
• Form, Fit and Function and literature will remain
  the same throughout lineup
• Part numbers will not be changing
• The numbering protocol will remain the same
• Devices will remain EFI branded, not Schneider
  Electric

15
Transients A Problem of The Electronic Age
Expanded Use of Electronics

• Computerized Work Stations
• Telephone Systems
• Automated Assembly
• Medical Diagnostic Equipment
• Industrial Machine Tools
• Electronic Gas Pumps
• Automated Irrigation Controls
• Computers, Monitors Copiers
• Security Systems
• Motor Control Systems
• Communications

16
Problem Transients Cost Money
80B
Power related problems cost companies over 80
billion a year

• High Facility Maintenance Costs
• Lost Sales
• Production Delays
• System Downtime
• Late Deliveries
• Idle Workforce
• Catastrophic Facility Damage
• Increased Spoilage and Scrap

(Source Lawrence Berkeley National Laboratory)
17
Contact Information

• Technical Assistance Group
  1-800-577-7353tvsstag_at_us.schneider-electric.com

• Don Grove, Application Engineering Manager
  1-800-877-1174 James Moellmann, Application
  EngineerMaher Diab, Application Engineer
• www.efinet.com

18
Thank You
