Optimization of Zebra Danio Performance

1
Optimization of Zebra DanioPerformance
BY Dallas E. Weaver, Ph.D. Scientific
Hatcheries Huntington Beach, Ca
2
The Devil is in the Details

• The biology of zebra fish interacts with the
  culture system, water chemistry, husbandry
  details and nutrition.

3
Aquatic Animals vs. Land Animals

• Designing and operating zebra systems is a lot
  like trying to design and operate mice systems in
  zero G. You dont have gravity to separate the
  waste products from the animals.

4
Performance

• Definition of performance
• Egg production and fertility
• Embryo development and hatching
• Larval survival and initial growth
• Growth rate
• Maturation -- egg to egg time

5
Egg production and fertility

• Number of eggs per gm of female
• Fertilization percentage
• Cannibalism
• Egg health -- yoke size

6
Factors impacting egg production

• Water quality
• Metabolic waste products -- non-detectable
• Ammonia, nitrite lt 0.05 ppm in tank input water
• Other chemicals
• Nitrate 0 to 75 ppm
• Salinity 100 to 2,000 ppm
• pH 6.0 to 8.0
• Temperature 20.5 ºC to 28.5 ºC
• Pushing the limit on one variable reduces the
  range of other variables.

7
Factors impacting egg production

• Nutrition
• No real research into zebra maturation diets
• Quality aquaculture diets all have short shelf
  life problems. Age dating, inventory cycling.
• Omega-3 fatty acid requirements
• Vitamin requirements
• Water soluble (C, B, etc) -- leaching problem
• Oil soluble (E)

8
Factors impacting egg production

• Nutrition practice by Scientific Hatcheries
• Dry diet of custom formulated modified salmon
  diet. High fishmeal protein, unsaturated fats
  (high omega-3 fats).
• Frozen adult artemia
• Live moina, rotifers, artemia for maximum
  production.

9
Factors impacting egg production

• Cycling
• Observation that off cycle fish have low
  fertility.
• May be related to over-ripe eggs
• Density
• At densities gt 10,000 / M2 of spawning surface
  fertility decreases.

10
Performance

• Definition of performance
• Egg production and fertility
• Embryo development and hatching
• Larval survival and initial growth
• Growth rate
• Maturation -- egg to egg time

11
Embryo development

• Impacts on development
• Chemical stress from water quality
• Non-viable embryo problem -- static systems
• Toxins from materials
• Interaction between embryos may impact sex ratio
• Unstable microbiology -- bacterial/fungal attack
  on the embryos

12
Embryo development

• Chemical stress from water quality
• Static systems
• Non-viable embryos source of pollutants
• Food supply for bacteria
• Ratio of volume per embryo critical
• Depth irrelevant
• Surface tension will be relevant at hatch
• Flowing system
• Water quality determined by source water.

13
Toxins from materials

• Bioassay all materials
• Test materials with embryos and larva
• Problems materials
• Rubber -- black rubber
• Vinyl tubing, brass valves at low alkalinity
• Cleaning solutions and sterilization solutions
• Solutions
• Rinsing, leaching and materials selection
• Flowing water

14
Embryo development

• Interaction between embryos may impact sex ratio
• Static systems can have interactions
• Many researchers have sex ratio problem
• Hypothesis developing embryos can release
  chemicals that can impact the development of
  other embryos exposed to those chemicals.

15
Embryo development

• Unstable microbiology -- bacterial/fungal attack
  on the embryos
• Static systems -- dishes, beakers, etc.
• Dead embryos and non-viable embryos provide
  nutrients for bacteria and fungal growth
• Once fungal or bacterial attach on non-viable,
  attack on viable embryos is possible
• Flowing systems
• Upflow system -- not a problem
• Non-upflow -- fungal problems

16
Embryo development

• System options
• Static systems
• All the problems
• Easier to work with embryos
• Fluidized Bed Hatchers
• Eliminates the problems of static system
• Automatic non-viable removal
• Automatic fungus egg removal

17
Embryo Development

• What is a Fluidized bed Hatcher
• A fluidized column of glass bead media with a
  fluidized column of embryos behaving like a
  second phase fluid
• With a constant up-flow velocity, non-viable
  embryos swell up and float out of the hatcher.
• Every embryo has a constant supply of clean water
  which decreases developmental differences caused
  by oxygen differences in static systems.

18
(No Transcript)
19
(No Transcript)
20
Performance

• Definition of performance
• Egg production and fertility
• Embryo development and hatching
• Larval survival and initial growth
• Growth rate
• Maturation -- egg to egg time

21
Larval survival

• Ideal is 100 survival for all normal embryos
• Factors causing unnecessary mortality
• Water quality
• Nutrition
• Weak larva

22
Larval survival

• Factors causing unnecessary mortality
• Water quality
• Normal pollutants, ammonia, nitrite and metabolic
  waste products, low oxygen
• Surface tension -- oil film -- swim bladder
  inflation
• Toxic chemicals
• Bacterial/protozoan explosion

23
Larval survival

• Factors causing unnecessary mortality
• Water quality (continued)
• Surface tension -- oil film -- swim bladder
  inflation
• Zebra fish need surface access for filling the
  swim bladder.
• Common problem with other aquaculture species
  (striped bass, white bass, etc.)
• Solution is keeping the surface free of oil
• Tank depth is irrelevant.

24
Larval survival

• Factors causing unnecessary mortality
• Water quality
• Nutrition
• Weak larva

25
Larval survival

• Factors causing unnecessary mortality
• Nutrition
• First food is critical
• Notes from Aquaculture
• Larval fish/shrimp production is a multi-billion
  business
• Dry diets cant replace 100 of live feeds for
  all small larva species. Dry diets are only
  supplements to cut the cost of live feeds.
• When dry diets appear to work, it is often the
  bacterial/protozoan contamination of that diet
  that allows it to work.
• Leaching of critical nutrients from dry diets is
  very fast

26
Larval survival

• Factors causing unnecessary mortality
• Nutrition (continued)
• Notes from Aquaculture (continued)
• Rotifers (brackish water species) is the most
  common small live feed. For species where new
  hatched artemia is too large.
• Rotifers are often enriched before feeding with
  algae or prepared omega-3 fat blends.
• Rotifers can be packed with antibiotics or other
  chemicals.
• Can be purchased alive or produced locally.

27
Larval survival

• Factors causing unnecessary mortality
• Nutrition (continued)
• Notes from Aquaculture (continued)
• Artemia napulii
• Easy to hatch
• Nutrition value decreases with time when un-fed
• Nutrition value variable
• Enrichment is a common practice -- improved fatty
  acid profiles and amino acid profiles are
  possible
• Digestive enzymes are limited in many larval fish
• Depend upon live food to provide

28
Larval survival

• Factors causing unnecessary mortality
• Water quality
• Nutrition
• Weak larva

29
Larval survival

• Factors causing unnecessary mortality
• Weak Larva
• Can be caused by poor adult nutrition
• Stressing the larva during development
• Stressing the larva with high density
• Social interaction problem
• Too much turbulence wasting energy reserves
• A problem with McDonald jars for hatching

30
Performance

• Definition of performance
• Egg production and fertility
• Embryo development and hatching
• Larval survival and initial growth
• Growth rate
• Maturation -- egg to egg time

31
Growth rate

• Factors impacting growth rates
• Temperature
• Water quality
• Nutrition
• Density

32
Growth rate

• Factors impacting growth rates
• Temperature
• There is a maximum above which metabolism is
  greater than digestible feed consumption.
• With a low quality diet, the rearing temperature
  could be above the maximum.
• Apparently parameters are not available for a
  zebra fish bio-energetic model.

33
Growth rate

• Factors impacting growth rates
• Temperature
• Water quality
• Nutrition
• Density

34
Growth rate

• Factors impacting growth rates
• Water quality
• Low Oxygen levels decrease growth
• Very high unionized ammonia levels
• gt 20 ppb unionized
• Pheromones give an apparent density dependence
  that is not real.

35
Growth rate

• Factors impacting growth rates
• Temperature
• Water quality
• Nutrition
• Density

36
Growth rate

• Factors impacting growth rates
• Nutrition
• This is a critical element
• Live feeds are the best
• Enrichment is desired
• All they can eat all the time
• 7 days a week
• Excess feed and old feed may decrease growth rate
  and support enteric diseases.

37
Growth rate

• Factors impacting growth rates
• Temperature
• Water quality
• Nutrition
• Density

38
Growth rate

• Factors impacting growth rates
• Density
• Often misinterpretation of observations
• Apparent impacts from water quality
• Apparent impacts from nutrition
• Real impacts result from social interaction
• Real impact density gt 35/liter for zebra fish or
  1.5 zebra fish in the water
• Below those levels, apparent density impacts of
  slow growth, growth variation, etc. are artifacts
  of other problems.

39
Performance

• Definition of performance
• Egg production and fertility
• Embryo development and hatching
• Larval survival and initial growth
• Growth rate
• Maturation -- egg to egg time

40
Maturation -- egg to egg time

• Putting it all together and adapting commercial
  aquaculture technology to zebra fish
• Use a standard Aquaneering FBB rack system
• Use standard zebra research artemia hatching tank
  -- tank for automated feeding
• Use de-chlorinated tap water at 28.5 ºC

41
Maturation -- egg to egg time

• Special additions
• Fluidized Bed Hatchers for development
• Black tanks for experiment on tank color
  (significant for many species of fish)
• Peristaltic feed pump -- automated feeding
• Timer, rotifer supply, artemia supply (enriched)
• Inlet diffuser for mixing feed with main flow
• Turbulent flow control valves on each tank
• Fine discharge screen baffles -- 300 µ

42
Maturation -- egg to egg time

• Additions (continued)
• Air injection behind screen (improved oxygen
  transfer without excessive turbulence)
• Monitoring of salinity -- live food additions
  were with brackish water

43
Maturation -- egg to egg time

• The experiment
• Four clear tank, Four Black, Four density classes

44
(No Transcript)
45
(No Transcript)
46
ResultsEGG to EGG 49 days
47
(No Transcript)
48
(No Transcript)
49
(No Transcript)
50
(No Transcript)
51
(No Transcript)
