Title: Cervical


1
Cervical Incompetence

Dr.Ashraf K. fouda
Domiatte General Hospital
2
DEFINITION
  • Condition in which the cervix fails to retain the
    conceptus during pregnancy.
  • There are arguments about the occurrence and
    incidence of incompetent cervix

3
Prevalence
  • Affects around
  • 1 of pregnant patients

4
Cervical incompetence
  • Cervical incompetence has long been recognized as
    a potential cause of preterm delivery recurrent
    mid trimister abortionns.

5
Cervical incompetence
  • It is believed that cervical incompetence is the
    cause of 20 - 25 of all second trimester losses

6
AETIOLOGY
  • Idiopathic (most cases).
  • Congenital disorders (congenital mullerian duct
    abnormalities eg. Septate uterus, Bicornuate
    uterus).
  • DES exposure in utero.
  • Connective tissue disorder (Ehlers- Danlos
    syndrome).
  • Surgical trauma
  • Conization,( resulting in substantial loss of
    connective tissue) or
  • Traumatic damage to the structural integrity of
    the cervix (repeated forced cervical dilatation
    associated with DC).

7
AETIOLOGY
  • The cervical competence is an active, not
    passive, phenomenon, and it is a specific entity
    involving not just an abnormality or defect of
    cervical collagen, but is also due to either
  • Absence of the usual cervical musculature in
    cases of congenital cervical incompetence, or
  • Injury or damage to the cervical musculature
    caused by previous trauma.

8
Symptoms
  • Women with incompetent cervix typically present
    with "silent" cervical dilatation (i.e., with
    minimal uterine contractions) between 16 and 28
    weeks of gestation.

9
Symptoms
  • Patient present with significant cervical
    dilatation (2 cm or more) and minimal symptoms.
  • When the cervix reaches 4 cm or more, active
    uterine contractions or rupture of membranes may
    occur.

10
Pathogenesis
  • The function of the cervix during pregnancy
    depends on the regulations of connective tissue
    metabolism.
  • Collagen is the principal component in the
    cervical matrix, others are (proteoaminoglycans,
    elastin and glycoproteins, like fibronectin).

11
Pathogenesis
  • The biochemical events implicated in the cervical
    ripening are
  • Decrease in total collagen content,
  • Increase in collagen solubility and
  • Increase in collagenolytic activity.

12
Diagnosis
  • It is a clinical diagnosis marked by gradual,
    painless dilatation and effacement of the cervix
    with membranes visible through the cervix.
  • This history establishes the diagnosis,
    eventually, women with this cervical status may
    develop membrane rupture labor.
  • Short labors with the delivery of an immature
    fetus or loss of the pregnancy at progressively
    earlier gestational ages in successive
    pregnancies is characteristic of reduced
    competence.

13
Diagnostic Criteria
  • Historical factors
  • History of painless cervical dilatation with
    preterm delivery
  • History of forceful cervical dilatation and
    evacuation
  • History of obstetric trauma cervical
    lacerations, prolonged second stage followed by
    cesarean
  • Prior cervical surgery cone, loop
  • DES exposure in utero
  • Cervical sonography
  • Short cervical length
  • Cervical funneling

14
IMPROVMENTS IN DIAGNOSIS
  • The diagnosis is at present largely subjective
    and retrospective.
  • If possible, an objective (i.e. measurable)
    diagnosis, made before pregnancy or in the early
    stages (first or early second trimester) would
    provide
  • An accurate incidence of cervical incompetence,
  • Allow treatment to be targeted appropriately and
  • Also provide the basis for definitive trials of
    treatment.

15
Diagnosis
  • Dilators or balloons to determine cervical
    resistance and/or hysterosalpingograms to measure
    the width of the cervical canal between
    pregnancies are neither sensitive nor specific.
  • Digital examination of the cervix is highly
    subjective.
  • Sonography has provided a reproducible method of
    evaluating the cervix.

16
Ultrasonography
  • Initial use of ultrasound to observe the cervix
    was transabdominal but the necessity for a full
    bladder to visualize the cervix elongates the
    cervix to such a degree as to make objective,
    reproducible measurements difficult.
  • The development of transvaginal scanning (TVS)
    allowed for accurate cervical measurements with
    an empty bladder and no distortion .

17
Transvaginal ultrasound
  • 'funneling' or 'breaking' of the internal
    cervical os
  • ( at rest or particularly in response to
    transabdominal pressure on the uterine fundus )
  • is the ultrasonographic appearance of cervical
    incompetence .

18
Cervical measurements
19
Transvaginal ultrasound
  • Provide a significant advance in the diagnosis of
    cervical incompetence
  • In contrast to the hysteroscopic evaluation of
    the cervix, it is
  • non-invasive, repeatable over time and can be
    performed during pregnancy.

20
Sonographic findings
  • Funneling of the cervix with the changes in forms
    T, Y, V, U (correlation between the length of the
    cervix and the changes in the cervical internal
    os). (Trust Your Vaginal Ultrasound)
  • Cervix length lt 25 mm
  • Protrusion of the membranes.
  • Presence of fetal parts in the cervix or vagina

21
(No Transcript)
22
(No Transcript)
23
2 images of the same cervix, 20 seconds apart,
without and with applying pressure
  •

24
Am J Obstet Gynecol 1997177660-5.
  • Sonographic serial evaluation
  • ( every two weeks) of the cervix for funneling
    and shortening in response to transfundal
    pressure has been found to be useful in the
    evaluation of incompetent cervix.

25
TREATMENTS
  • Surgical repair of the cervix using a vaginal or
    abdominal approach.
  • Other alternatives that have been considered have
    included
  • Bed rest, for which no trial has been conducted
    and for which little evidence of effectiveness
    exists, and
  • The use of vaginal pessaries to elevate and close
    the cervix.

26
TREATMENTS
  • The initial descriptions of cervical cerclage for
    cervical incompetence came with Shirodkar and
    McDonald in the 1950s, when both developed
    techniques for physical support for what was
    presumed to be a structurally weak cervix.

27
Surgical approaches to cervical incompetence
is, at present, the mainstay of treatment
28
Am J Obstet Gynecol 1982 Mar 1142(5)506-12
,Obstet Gynecol 1989 Feb73(2),Am J Obstet
Gynecol 1993 Nov169(5)1125-9  PMID 8238171,J
Reprod Med 1994 Nov39(11)880-2 PMID
  • Cerclage is not indicated solely based on risk
    factors or prior cerclage placed for doubtful
    indications.

29
(No Transcript)
30
Prophylactic Cerclage
  • Prophylactic cerclage sutures (Shirodkar,
    McDonald )may be placed at 12 to 16 weeks'
    gestation.
  • Do not use tocolytics at the time of prophylactic
    cerclage, but give perioperative antibiotics.
  • Intercourse, prolonged standing (gt90 minutes),
    and heavy lifting are omitted following cerclage.
  • Follow these patients with periodic vaginal
    sonography to assess stitch location and
    funneling.

31
Prophylactic Cerclage
  • No additional restrictions are recommended as
    long as the stitches remain within the middle or
    upper third of the cervix without the development
    of a funnel, and the length of the cervix is
    greater than 25 mm.
  • For patients who have not been successful with a
    vaginal suture despite aggressive care and
    sonographic surveillance, a transabdominal
    cerclage may be appropriate.

32
Emergency Cerclage
  • Care of the patient with newly detected reduced
    cervical competence in the second trimester is
    both difficult and controversial.
  • When the diagnosis is made before cervical
    dilatation has occurred and when there is still
    10 to 15 mm or more of cervical length, admit the
    patient for 24 hours of treatment with
    perioperative indomethacin and broad-spectrum
    antibiotics before placing the cerclage sutures,
    and observe the patient for 48 to 96 hours
    postoperatively.

33
Emergency Cerclage
  • However, if the cervix has dilated to allow
    visualization of the membranes, the patient may
    remain hospitalized for several days after
    cerclage placement.
  • The prognosis for these patients is better than
    generally expected, with many women delivering a
    "viable" (usually defined as gt1,000 g) infant,
    but aggressive therapy may be required to achieve
    these results.
  • The prognosis is influenced by the gestational
    age at the time when the suture is placed.

34
Emergency Cerclage
  • In the case of advanced dilatation with bulging
    membranes, several techniques may be helpful
  • Pre cerclage amniocentesis to remove sufficient
    fluid to reduce the bulging membranes can be
    helpful.
  • Overfilling the bladder with 1,000 ml of saline
    may help by elevating the membranes out of the
    operative field, but may also obstruct the
    surgeon's view.
  • Place a Foley catheter balloon inside the cervix,
    and overfill it with at least 50 ml of saline to
    gently push the membranes out of the lower
    segment.
  • The cerclage suture can then be placed and tied
    as the balloon fluid is evacuated.

35
Emergency Cerclage
  • Cerclage is rarely performed after 24 to 25 weeks
    of pregnancy.
  • The great risk of inducing PROM or preterm labor
    and the ability to prolong gestation with bed
    rest and suppressive medications argue against
    surgical intervention in such cases.
  • The cerclage is removed at 37 weeks' gestation or
    at the onset of labor.

36
Indication for cerclage
  • History compatible with incompetent cervix AND
  • Sonogram demonstrating funneling OR
  • Clinical evidence of extensive obstetric trauma
    to cervix

ACOG Criteria Number 17 October 1996, ACOG
Criteria Number 18 October 1996
37
Contraindications
  • 1.Uterine contractions.
  • 2.Uterine bleeding
  • 3.Chorioamnionitis
  • 4.Premature rupture of membranes
  • 5.Fetal anomaly incompatible with life

38
Cerclage procedures
  • There are five different techniques for
    performing the cerclage
  • McDonald procedure
  • Shirodkar operation
  • Wurm procedure (Hefner cerclage)
  • Transabdominal cerclage
  • Lash procedure
  • The two most common are the McDonald and
    Shirodkar.

39
McDonald procedure
  • The McDonald procedure is done with a 5 mm band
    of permanent suture is placed high on the cervix.
  • This is indicated when there is significant
    effacement of the lower portion of the cervix.
  • It is generally removed at 37 weeks, unless there
    is a reason to remove it earlier, like infection,
    preterm labor, premature rupture of the
    membranes, etc.
  • It is also shown that this has very little impact
    of the chance for vaginal delivery.

40
McDonald operation
  • The McDonald technique requires no bladder
    dissection, and the cervix is closed using four
    or five bites with the needle to create a purse
    string around the cervix.

41
McDonald operation
42
(No Transcript)
43
Shirodkar operation
  • The Shirodkar is also a frequently used
    technique.
  • However, this was previously a permanent purse
    string suture that would remain intact for life.
  • There are physicians performing modified
    techniques, where the delivery does not
    necessarily have to be by cesarean, nor the
    suture left intact.

44
Shirodkar operation
  • Place the suture as near the internal os as,
    opening the anterior fornix and dissecting away
    the adjacent bladder, before placing the suture
    submucosally, tied anteriorly and the knot buried
    by suturing the anterior fornix mucosal opening.
  • The original intention with the Shirodkar method
    was to leave the suture in place and aim for
    delivery by caesarean section.

45
Shirodkar operation
46
Shirodkar and McDonald
  • Both initially started suturing with catgut, but
    Shirodkar turned to fascia lata and McDonald
    turned to ( 0 )silk as they realized the
    importance of a permanent cervical support.
  • One significant difference since then has been
    the present day use of Mersilene tape as the
    suture material.

47
Shirodkar and McDonald
  • Both the McDonald and Shirodkar cervical sutures
    are equally effective as a vaginal approach to
    cervical cerclage.
  • McDonald suture is generally easier to perform
    with no major difference in success.

48
Wurm procedure
  • The Hefner cerclage, also known as the Wurm
    procedure, is used for later diagnosis of the
    incompetent cervix.
  • It is usually done with a U or mattress suture,
    and is of benefit when there is minimal amounts
    of cervix left.

49
Trans abdominal cerclage
  • One further development in the 1960s was the
    description of the transabdominal cerclage by
    Benson and Durfee in 1965 a technique now
    largely used after the failure of vaginal
    cerclage procedures or in the presence of
    congenital anomalies, particularly those produced
    by diethylstilboestrol exposure.

50
Trans abdominal cerclage
  • The original intention with the transabdominal
    approach was that the suture was inserted between
    pregnancies or in early pregnancy, and left in
    situ for the rest of the woman's reproductive
    life, delivery being undertaken by caesarean
    section for each pregnancy.

51
Trans abdominal cerclage
  • In this method, a midline or Pfannenstiel
    abdominal incision allows access to the
    vesicouterine fold of peritoneum, which is
    divided and the bladder reflected caudally.
  • The uterine vessels are then identified and a
    Mersilene tape suture is passed through the broad
    ligament below the uterine vessels in the
    potential 'free space' between the uterine
    vessels and the ureter, with the suture tied
    anteriorly or posteriorly (anterior being
    reported as surgically easier) and the bladder
    replaced.

52
Trans abdominal cerclage
53
Lash procedure
  • The last procedure, the Lash, is performed in the
    non-pregnant state.
  • It is typically done after cervical trauma that
    has caused an anatomical defect.

54
Lash procedure
  • Lash described techniques aimed at the repair of
    a specific anterior cervical structural defect.
  • The cervical mucosa was opened anteriorly, the
    bladder reflected and the cervical defect
    repaired with interrupted transverse sutures
    before closing the vaginal mucosa.

55
Preoperative evaluation
  • Ultrasound for anomaly and viability
  • MS-AFP( Alpha Fetopritein) if appropriate
  • Wet mount.( For vaginal infections).
  • G Beta Streptococci, Gonococci, and Chlamydia
    cultures.
  • Treat appropriately for infection.

56
ORDERS
  • Admit for cerclage
  • NPO after midnight
  • Bed rest.
  • Trendelenberg if cervix is effaced or dilated.
  • Surgical consent
  • A 100-mg dose of indomethacin may be given per
    rectum during the operative period, followed by a
    50-mg oral dose every 6 hours

57
ORDERS
  • McDonald cerclage
  • Postop. ,Transfer to postpartum for observation
  • Regular diet
  • Bed rest 12-24 hours
  • May discharge if no uterine contractions, vaginal
    bleeding, or rupture of membranes during
    observation.

58
Risks of Cerclage
  • Premature rupture of membranes (1-9)
  • Chorioamnionitis (Infection of the amniotic sac,
    1-7) (This risk increases as the pregnancy
    progresses and is at 30 for a cervix that is
    dilated more than 3 cms.)
  • Preterm Labor
  • Cervical laceration or amputation (This can be at
    the procedure or at the delivery, from scar
    tissue that forms on the cervix.)
  • Bladder Injury (rare)
  • Maternal hemorrhage
  • Cervical dystocia
  • Uterine rupture

59
Risks of Cerclage
  • For elective cerclage at the beginning of the
    second trimester, the risk of infection is small,
    estimated at less than 1 percent.
  • Later in the pregnancy, displacement of the
    suture also can occur (3 to 12 percent).
  • A second cerclage has a much lower success rate.

60
Risks of Cerclage
  • Late complications of cerclage include PROM or
    preterm labor and chorioamnionitis.
  • When fluid leakage occurs in a patient with a
    cerclage, removal of the suture, to reduce the
    risk of infection is controversial.

61
Risks of Cerclage
  • Finally, even though cerclage placement is
    considered a benign procedure, a maternal death
    secondary to sepsis in a patient with retained
    cerclage has been reported.
  • The liberal use of this surgical procedure should
    be carefully balanced against potential harm, in
    particular for patients in whom the indications
    for cerclage are not clear.

62
Efficacy of Cerclage
  • Cerclage seems to be a very effective treatment
    for incompetent cervix.
  • The success rates can be very high (80-90),
    particularly when done earlier in a pregnancy.

63
RCOG Guidelines
  • Cervical incompetence is often over-diagnosed as
    a cause of mid-trimester miscarriage.
  • Cervical cerclage should only be considered when
    the history of miscarriage is preceded by
    spontaneous rupture of membranes or painless
    cervical dilatation.
  • The MAC/RCOG trial of the use of cervical
    cerclage reported a small decrease in preterm
    birth, but no significant improvement in fetal
    survival.
  • (Grade B recommendation)

64
RCOG Guidelines
  • Transabdominal cerclage performed preconceptually
    has been advocated as a treatment for second
    trimester miscarriage and the prevention of early
    preterm labour.
  • The reported improvement in pregnancy outcome is
    difficult to assess in the absence of a control
    group.

65
Thank you
Write a Comment
User Comments (0)
About PowerShow.com
