Title: Cortez UV Disinfection


1
Cortez UV Disinfection
  • Steven M. Ravel, P.E.
  • Travis E. Meyer, P.E.
  • Richard P. Arber Associates

2
Introduction
  • Background
  • Selection of UV Lamp Type
  • Specifying UV Dose
  • Verification of UV Dose

3
Background
  • New WWTP for Cortez Sanitation District
  • Treatment Train
  • Headworks
  • Extended Aeration
  • Secondary Clarification
  • UV Disinfection

4
Background
  • Design Flows
  • Average 1.8 mgd
  • Peak Month 2.1 mgd
  • Peak Hour 7 mgd

5
UV Lamp Types Considered
  • Medium Pressure
  • Low Pressure / Low Intensity
  • Low Pressure / High Intensity

6
Medium Pressure
  • Advantages
  • Lowest Number of Lamps Required
  • UV Intensity Adjustable
  • Sleeve Wipers Available
  • Low Space Requirement
  • Open Channel and Closed Pipe Systems Available

7
Medium Pressure
  • Disadvantages
  • Low Efficiency (Approximately 10 - 20
  • Higher Capital Cost (for these flow rates)
  • Require warm-up period on start-up

8
Low Pressure / Low Intensity
  • Advantages
  • Low Capital Cost
  • High Efficiency (Approximately 40)
  • Simple Design / Simple Operation

9
Low Pressure / Low Intensity
  • Disadvantages
  • Highest Number of Lamps Required
  • UV Intensity Not Adjustable
  • Sleeve Wipers Not Available
  • High Maintenance (Lamp Replacement and Cleaning)
  • High Space Requirement

10
Low Pressure / High Intensity(Selected)
  • Advantages
  • Low Capital Cost
  • High Efficiency (Approximately 40)
  • Less Lamps Required than Low/Low (Approximately
    1/4)
  • UV Intensity Adjustable
  • Sleeve Wipers Available

11
Low Pressure / High Intensity(Selected)
  • Disadvantages
  • Relatively Short Track Record Compared to Low/Low
    and Medium
  • More Lamps Required than Medium

12
Specifying UV Dose
  • EPA UVDIS Computer Model
  • BioAssay
  • Performance Based

13
UVDIS Computer Model
  • Advantages
  • Computer program easy and fast to run
  • Theoretical model developed by EPA

14
UVDIS Computer Model
  • Disadvantages
  • Program designed for Low/Low systems
  • May not be as applicable for Low/High or Medium
    Systems
  • Model results must be adjusted using high safety
    factors to ensure system will perform as required

15
BioAssay
  • Advantages
  • System sized based on dose response curve for
    actual equipment to be installed
  • Dose response curve developed for site specific
    wastewater effluent quality

16
BioAssay
  • Disadvantages
  • No Standard Protocol for BioAssay
  • Detailed protocol must be developed to compare
    results for different systems
  • Expensive and Time-Consuming
  • If MS-2 Phage used for bioassay, correlation must
    be developed to translate results for fecal
    coliform

17
Performance Based
  • Advantages
  • Specify what you want the system to do, let
    manufacturers design their system to do it
  • Most direct method to specify

18
Performance Based
  • Disadvantages
  • Relying on manufacturers to design adequate
    system
  • Must determine a method to check performance in
    the field

19
Cortez Sanitation District
  • Pre-selection of UV System based on
  • Primary UV Dose Criteria Performance for Fecal
    Coliform
  • In 500,000/100 mL
  • Out 200/100 mL
  • Secondary UV Dose Criteria
  • Min UV Dose of 30,000 µw/cm2 based on UVDIS

20
Cortez Sanitation District
  • Other Design Criteria
  • Minimum Flow 1 mgd
  • Average Flow 1.8 mgd
  • Peak Hydraulic Flow 7 mgd
  • Peak Process Flow 5 mgd
  • UV Transmittance 65
  • TSS 30 mg/l
  • Number of Channels 2
  • Number of Banks/Channel 2

21
Comparison of UV Systems
Mfr A Mfr B of Lamps 48 64 Capital
Cost 100,000 110,000 Annual OM
Costs Electricity 1,400 3,000 Lamps 1,900 3,
200 Total 3,300 6,200 NPV (20 yrs,
6) 140,000 180,000 Includes Separate
Sunshade Structure for Ballast and Controls
22
Verifying UV Dose
  • During Performance Test, Need to Account for
    Differences (Design vs. Actual) in
  • Flow
  • UV Transmittance
  • Lamp Age (70 output)
  • Fecal Coliforms

23
Flow Adjustment
  • Adjust UV system output in proportion to
    difference in flow
  • Example Design flow 5 MGD, Actual flow 1
    mgdAdjust UV system output to 20 of maximum

24
Transmissivity Adjustment
  • Adjust UV system output based on correlation
    between design UVT and actual UVT

25
Fecal Coliform Adjustment
  • Two Options
  • Spike UV influent to bring fecal coliform up to
    design number
  • Lower effluent fecal coliform requirement to
    achieve same log reduction as design

26
Cortez Sanitation District
  • Turn down UV system output to min during
    performance test.
  • Schedule test for highest flow, lowest UVT,
    highest Fecal
  • Record Flow Rate
  • Test Fecal Coliforms (In vs.Out)
  • Test UVT
  • Make determination of performance based on
    available data

27
Conclusions
  • Low Pressure / High Intensity best solution for
    Cortez
  • Performance based spec on fecal coliform with min
    UV dose based on EPA UVDIS
  • Verification of UV Dose using best available data
    at time of performance test
