Antibody microarrays for allergen standardization

1
Antibody microarrays for allergen standardization
2
How do we measure potency?

• Total protein (hymenoptera)
• Overall allergen (grasses, mites)
• Pooled human antibody
• Specific allergen (cat, ragweed)
• Sheep antibody

3
Radial immunodiffusion assay with monospecific
antiserum

• Examples cat, ragweed
• Advantages
• quantitative
• monospecific
• Disadvantages
• need to identify relevant allergen(s)

4
Competition ELISA with pooled allergic human sera

• Examples mites, grasses
• Advantages
• quantitative
• reflects spectrum of allergen recognition
• does not require identification of relevant
  allergens
• Disadvantages
• use of pooled sera
• effects of fluctuations in individual allergens
  difficult to measure

5
Specific loss of a single allergen
6
The dilemma of these potency measures

• In order to measure specific allergens, we need
  to know which allergens are relevant
• If we measure overall allergenicity, we are
  unable to detect the absence of specific (and
  potentially important) allergens

7
Two possible solutions

• Divide the signal by
• Separating the allergens, or
• Separating the antibodies

8
Western blot with pooled allergic human sera

• Advantages
• identification of individual protein bands
• reflects spectrum of allergen recognition
• does not require identification of relevant
  allergens
• Disadvantages
• qualitative
• use of pooled sera
• no definite identification of allergens
• cross-reactivity

9
Antibody microarray

• Advantages
• quantitative
• reflects spectrum of allergen recognition
• does not require identification of relevant
  allergens
• Disadvantage
• New technology initial development will be labor
  intensive and expensive

10
Aims

• To develop an antibody microarray method for
  profiling complex allergen mixture
• Apply this technique to German cockroach allergen
  standardization

11
We are NOT developing allergen microarrays

• Deinhofer et al. Microarrayed allergens for IgE
  profiling. Methods. 2004 Mar32(3)249-54.
• Jahn-Schmid et al. Allergen microarray
  comparison of microarray using recombinant
  allergens withconventional diagnostic methods to
  detect allergen-specific serum immunoglobulin E.
  Clin Exp Allergy. 2003 Oct33(10)1443-9.
• Beyer. Characterization of allergenic food
  proteins for improved diagnostic methods. Curr
  Opin Allergy Clin Immunol. 2003 Jun3(3)189-97.
  Review.
• Fall et al. Microarrays for the screening of
  allergen-specific IgE in human serum. Anal Chem.
  2003 Feb 175(3)556-62.
• Harwanegg et al. Microarrayed recombinant
  allergens for diagnosis of allergy. Clin Exp
  Allergy. 2003 Jan33(1)7-13. Review.
• Kim et al. Quantitative measurement of serum
  allergen-specific IgE on protein chip. Exp Mol
  Med. 2002 May 3134(2)152-8.
• Hiller et al. Microarrayed allergen molecules
  diagnostic gatekeepers for allergy treatment.
  FASEB J. 2002 Mar16(3)414-6.

12
but antibody microarrays

• Glokler and Angenendt. Protein and antibody
  microarray technology.J Chromatogr B Analyt
  Technol Biomed Life Sci. 2003 Nov
  25797(1-2)229-40.
• Haab. Methods and applications of antibody
  microarrays in cancer research. Proteomics. 2003
  Nov3(11)2116-22.
• Hallborn and Carlsson. Automated screening
  procedure for high-throughput generation of
  antibody fragments. Biotechniques. 2002
  DecSuppl30-7. Review.
• Schweitzer and Kingsmore. Measuring proteins on
  microarrays.Curr Opin Biotechnol. 2002
  Feb13(1)14-9. Review.
• Borrebaeck. Antibodies in diagnostics - from
  immunoassays to protein chips. Immunol Today.
  2000 Aug21(8)379-82. Review.

13
Antibody microarray plan
14
Need clonal antibodies

• Standard monoclonal antibody generation, or
• Phage-display technology
• Hyperimmunize chickens or rabbits
• RNA from spleens/bone marrow
• RT-PCR and PCR to generate cDNA libraries with
  expression of antibody on phage surface
• Select and enrich for allergen-specific cDNA
  using phage panning
• Express selected antibodies

15
Advantages of phage-display technology

• Theoretically cloning the entire immunoglobulin
  repertoire
• Large quantities of allergen-specific antibodies
  are potentially available for
• Structural studies
• Allergen purification
• Definition of the B-cell epitopes of major
  allergens
• Analysis of complex protein mixtures by antibody
  microarray
• Retrieved antibodies can be expressed in E. coli
  or yeast
• The use of several species can mean the
  generation of fragments with considerably
  different specificities.

16
Which animal models and why? Why not mice?

• We decided on two animal models rabbit and
  chicken.
• Mice provide small samples and have a large
  number of V-region families (complex PCRs to
  construct libraries).
• Rabbits provide large quantities of sera, and
  have a small set of V-region families (simpler)
  and are a well-established model for recombinant
  antibody generation.
• Chickens are useful as
• They often respond strongly to mammalian antigens
  which generate a weak response in mammals
  (cat/dog allergens).
• They do not require bleeding. IgY collected from
  egg yolk.
• The chicken genome encodes only two
  immunoglobulin variable domains! This means a
  very small primer set, reduction of primer bias
  in library construction.

17
Use of Fabs versus scFv in phage-display
scFv single chain Fragment variable Fab
Fragment antibody binding.
18
(No Transcript)
19
(No Transcript)
20
Complete Fab product
21
Fab fragment display on phage surface protein p3
22
Methods used for panning phage libraries.
23
Current directions for antibody phage display in
LIB

• Generation of mono-specific recombinant antibody
  fragments from rabbit and chicken to allergenic
  proteins Fel d 1, Amb a 1 and whole yellow jacket
  venom.
• Generation of antibody fragments from rabbit and
  chicken to the allergenic proteins of German and
  American cockroaches.

24
Animal libraries built so far.
25
Animal libraries built so far.
26
(No Transcript)
27
(No Transcript)
28
(No Transcript)
29
Chicken scFv exhibits excellent specificity and
sensitivity in Western Blot.
In each blot (left to right) Markers, Yellow
Jacket Venom, Ragweed extract, Cat hair extract.
30
Conclusions

• We can raise chicken antibodies against multiple
  antigens from a single immune library.
• Panning against multiple proteins at once can
  work effectively.
• Antibodies raised against rFel d 1 recognize nFel
  d 1.
• Chicken scFv molecules secrete well in E. coli.
• His-purified scFv functions effectively in ELISA
  and Western blot.

31
Animal libraries built so far.
32
(No Transcript)
33

• Apply scFv anti-Amb a 1 OR scFV anti-Fel d 1 to
  nitrocellulose slide
• Block with ovalbumin
• Incubate with
• ragweed extract or
• cat hair extract or
• negative control (ova)
• Polyvalent rabbit serum R91 (anti-Amb a 1
  anti-Fel d 1 anti-YJV)
• Anti-rabbit conjugate

34
Animal libraries built so far.
35
(No Transcript)
36
Microarray development plan

• Develop a quantifiable fingerprint of complex
  allergen mixtures using clonal allergen-specific
  scFvs and polyvalent sera
• Advance to more complex allergen extracts
• Yellow jacket venom
• German cockroach
• American cockroach
• How are we going to assure that our arrays
  recognize diverse allergens/epitopes?
• BstOI and Western analyses
• cluster analyses

37
Key players

• Jonny Finlay, PhD
• Nicolette deVore, PhD
