Defeasible Security Policy Composition for Web Services

1
Defeasible Security Policy Composition for Web
Services

• Adam J. Lee, Jodie P. Boyer, Lars E. Olson,
• and Carl A. Gunter
• University of Illinois at Urbana-Champaign
• 3rd November 2006

2
Motivation

• Security policies
• Tend to be large and difficult to understand
• Do not always have a well-defined means of
  composition
• May be governed by multiple organizations or
  entities
• Can we provide an intuitive way to specify and
  compose security policies?
• Approach Defeasible security policy composition

3
What is Defeasible Logic?

• A computationally efficient non-monotonic logic
• Why non-monotonic logic?
• Allows for jumping to conclusions but later
  retracting conclusions if contradictory evidence
  comes to light
• Models human reasoning

4
Defeasible Theories

• Defeasible theories have three parts
• Facts
• dog(Sam)
• Three types of rules
• Strict rules terrier(X) -gt dog(X)
• Defeasible rules dog(X) gt bark(X)
• Defeater rules sick(X) gt bark(X)
• A superiority relationship
• Prioritizes rules to eliminate conflicts

5
Example Superiority Relationship

• The logical theorybasenji(Jasmine)basenji(X)
  -gt dog(X)r dog(X) gt bark(X)r basenji(X)
  gt bark(X)r gt r
• Note What happens without r gt r?

6
Solution Overview

• Each entity specifies a defeasible logic meta
  policy
• Group of entities determine a precedence
  hierarchy
• Policies are merged using a composition function,
  ?
• Resultant composed policy is converted into its
  XML representation using a projection function, ?

7
Graphical Composition Overview
Entity 1
A Resource Policy
A meta policy
Local Resource
?
8
Graphical Composition Overview
?
?
9
What Does a Meta-Policy Look Like?

• A meta-policy, P, is a tuple P (Preas, Preq)
• The reasoning theory, Preas, is a theory in the
  defeasible logic
• The requirements theory, Preq, is a propositional
  logic theory
• Used as a sanity check after merging to ensure
  this entitys requirements are met
• If the conclusions drawn during the merge can
  prove the statement SATISFIED in Preq, the
  defining entity is, well, satisfied with the
  outcome

10
Predicate Syntax

• Security Token
• securitytoken(Type, Issuer, Claims)
• Integrity
• integrity(Algorithms, TokenInfo, Claims,
  MessageParts)
• Confidentiality
• confidentiality(Algorithms, KeyInfo,
  MessageParts)

11
Examples of Predicate Syntax

• securitytoken('x509','uiuc',C)
• Represents an X.509 certificate issued by UIUC
  with no restrictions on the claims.
• confidentiality(algorithm('encryption','rsa'),
  securitytoken(T,'uiuc',C), messageparts('xpath',S
  ,'/body'))
• Represents RSA encryption of the ltbodygt element
  using a security token issued by UIUC.

12
Composition using ?

• Define ? recursively in terms of a two policy
  composition function ?
• Two cases for ?(p1, p2)
• p1 and p2 unrelated by partial order
• p1 dominates p2
• ? can be used iteratively to compose any
  collection of partially ordered meta-policies

13
Projection Using ?

• Derive C, the set of all conclusions that can be
  defeasibly proven from the composite reasoning
  theory
• For each Ci ? 2C that satisfies the requirements
  theories, add Ci to the set of sets S
• Fail if S is empty, otherwise generate XML

14
XML Generation

• Find I, the intersection of each s ? S
• Insert the elements of I into an ltAllgt clause in
  the WS-SecurityPolicy
• Create an ltExactlyOnegt clause
• For each s ? S, construct an ltAllgt clause
  containing each conclusion in the set (s \ I)
• Add this ltAllgt clause as an item to the new
  ltExactlyOnegt clause

15
Example

• 2 organizations want to deploy a joint web
  service
• Organization 1
• Wants X.509 to be used as the security token.
• Allows a combination of tokens to replace X.509
  when resources are constrained in mobile apps
• Organization 2
• Deploys mobile apps
• Requires Confidentiality
• The organizations are unrelated in the partial
  ordering

16
Example Policy (Part 1)

• Req
• hassecuritytoken -gt satisfied.
• securitytoken('x509','uiuc',C) -gt
  hassecuritytoken.
• securitytoken('saml',I,C),securitytoken('unt',I,C
  ) -gt hassecuritytoken.
• Reas
• R1 gt securitytoken('x509','uiuc',C).
• R2 gt securitytoken('saml',I,C).
• R3 gt securitytoken('unt',I,C).
• R4 mobile gt securitytoken('x509',I,C).
• R5 securitytoken('x509',I,C) gt
  securitytoken('saml',I,C).
• R6 securitytoken('x509',I,C) gt
  securitytoken('unt',I,C).
• R4 gt R1. R5 gt R2. R6 gt R3.

17
Example Policy (Part 2)

• Req
• hassecuritytoken,hasconfidentiality -gt
  satisfied.
• securitytoken('saml','uiuc/cs/dais',C) -gt
  hassecuritytoken.
• confidentiality(algorithm('encryption','aes128cb
  c'), securitytoken('unt',I,C)),
  messageparts('xpath',S,'/body')) -gt
  hasconfidentiality.
• Reas
• mobile.
• R1 gt securitytoken('saml','uiuc/cs/dais',C).

• R2 gt confidentiality(algorithm('encryption'
  ,'aes128cbc'), securitytoken(T,I,C),
  messageparts('xpath',S,'/body')).

18
Merged Reasoning Theories

• R1_1 gt securitytoken('x509','uiuc',C).
• R1_2 gt securitytoken('saml',I,C).
• R1_3 gt securitytoken('unt',I,C).
• R1_4 mobile gt securitytoken('x509',I,C).
• R1_5 securitytoken('x509',I,C) gt
  securitytoken('saml',I,C).
• R1_6 securitytoken('x509',I,C) gt
  securitytoken('unt',I,C).
• R1_4 gt R1_1. R1_5 gt R1_2. R1_6 gt R1_3.
• mobile.
• R2_1 gt securitytoken('saml','uiuc/cs/dais',C
  ).
• R2_2 gt confidentiality(algorithm('encryptio
  n', 'aes128cbc'), securitytoken(T,I,C),
  messageparts('xpath',S,'/body')).

19
Set of Possible Conclusions

• securitytoken('saml','uiuc/cs/dais',C)
• securitytoken('unt',I,C)
• confidentiality(algorithm('encryption','aes128cbc
  '), securitytoken('unt',I,C),
  messageparts('xpath',S,'/body'))

20
Expected WS-Policy Output

• ltwspPolicygt
• ltwspAllgt
• ltwsseSecurityTokengt
• ltwsseTokenTypegtwsseSAMLAssertionlt/wsseToken
  Typegt
• ltwsseTokenIssuergtuiuc/cs/daislt/wsseTokenIssu
  ergt
• lt/wsseSecurityTokengt
• ltwsseSecurityTokengt
• ltwsseTokenTypegtwsseUsernameTokenlt/wsseToken
  Typegt
• lt/wsseSecurityTokengt
• ltwsseConfidentialitygt
• ltwsseAlgorithm Type"wsseAlgSignature"
• URI"...AES128_CBC"/gt
• ltwsseKeyInfogt
• ltwsseSecurityTokengt
• ltwsseTokenTypegtwsseUsernameTokenlt/wsseT
  okenTypegt
• lt/wsseSecurityTokengt
• lt/wsseKeyInfogt
• ltwsseMessageParts Dialect"...XPath"gt /Body

• lt/wsseMessagePartsgt

21
Web Services and Beyond

• This policy composition method is not only useful
  for merging WS-SecurityPolicy documents
• Reliable messaging policies
• WS-RM Policy specification
• Investigating the interplay between security and
  reliable messaging policies would be an
  interesting area
• Firewall policies
• Example Multiple groups sharing lab space
• Efficiency of defeasible logic makes temporal
  firewall rules possible

22
Conclusion

• Presented a system to compose security policies
• Preferences for composition are encoded in
  meta-policies
• Single operation for composition
• Allow organizations to specify long term
  meta-policies
• can be used for local resource policies
• can be composed to determine the policy for a
  shared resource

23
Thank you for your attention.
http//seclab.cs.uiuc.edu/ampol
24
Example Policy (Part 1)

• Req
• hassecuritytoken,hasintegrity -gt satisfied.
• securitytoken('x509','uiuc',C) -gt
  hassecuritytoken.
• securitytoken('saml',I,C),securitytoken('unt',I,C
  ) -gt hassecuritytoken.
• integrity(algorithm('signature','rsa'),algorithm
  ('transform','enveloped'), securitytoken(T,'uiuc'
  ,C1), C2, messageparts('xpath',S,'/')) -gt
  hasintegrity.
• integrity(algorithm('signature','hmac'),algorith
  m('transform','enveloped'), securitytoken('unt',I
  ,C1), C2, messageparts('xpath',S,'/')) -gt
  hasintegrity.
• Reas
• R1 gt securitytoken('x509','uiuc',C).
• R2 gt securitytoken('saml',I,C).
• R3 gt securitytoken('unt',I,C).
• R4 mobile gt securitytoken('x509',I,C).
• R5 securitytoken('x509',I,C) gt
  securitytoken('saml',I,C).
• R6 securitytoken('x509',I,C) gt
  securitytoken('unt',I,C).
• R4 gt R1. R5 gt R2. R6 gt R3.
• R7 securitytoken('x509',I,C) gt
  integrity(algorithm('signature','rsa'),algorithm(
  'transform','enveloped'), securitytoken(T,I,C1),
  C2, M).
• R8 securitytoken('unt',I,C) gt
  integrity(algorithm('signature','hmac'),algorithm
  ('transform','enveloped'), securitytoken('unt',I,
  C), C2, M).
• R9 integrity(algorithm('signature','rsa'),
  securitytoken(T,'uiuc',C1), C2, M) gt
  integrity(algorithm('signature','hmac'), S,
  C3, M).
• R10 integrity(algorithm('signature','hmac'),
  securitytoken('unt',I,C), C2, M) gt
  integrity(algorithm('signature','rsa'), S, C2,
  M).

25
Example Policy (Part 1)

• Req
• hassecuritytoken,hasintegrity -gt satisfied.
• securitytoken('x509','uiuc',C) -gt
  hassecuritytoken.
• securitytoken('saml',I,C),securitytoken('unt',I,C
  ) -gt hassecuritytoken.
• integrity(algorithm('signature','rsa'),algorithm
  ('transform','enveloped'), securitytoken(T,'uiuc'
  ,C1), C2, messageparts('xpath',S,'/')) -gt
  hasintegrity.
• integrity(algorithm('signature','hmac'),algorith
  m('transform','enveloped'), securitytoken('unt',I
  ,C1), C2, messageparts('xpath',S,'/')) -gt
  hasintegrity.
• Reas
• R1 gt securitytoken('x509','uiuc',C).
• R2 gt securitytoken('saml',I,C).
• R3 gt securitytoken('unt',I,C).
• R4 mobile gt securitytoken('x509',I,C).
• R5 securitytoken('x509',I,C) gt
  securitytoken('saml',I,C).
• R6 securitytoken('x509',I,C) gt
  securitytoken('unt',I,C).
• R4 gt R1. R5 gt R2. R6 gt R3.
• R7 securitytoken('x509',I,C) gt
  integrity(algorithm('signature','rsa'),algorithm(
  'transform','enveloped'), securitytoken(T,I,C1),
  C2, M).
• R8 securitytoken('unt',I,C) gt
  integrity(algorithm('signature','hmac'),algorithm
  ('transform','enveloped'), securitytoken('unt',I,
  C), C2, M).
• R9 integrity(algorithm('signature','rsa'),
  securitytoken(T,'uiuc',C1), C2, M) gt
  integrity(algorithm('signature','hmac'), S,
  C3, M).
• R10 integrity(algorithm('signature','hmac'),
  securitytoken('unt',I,C), C2, M) gt
  integrity(algorithm('signature','rsa'), S, C2,
  M).
