Modulo 25

1

• Modulo 25
• Power Capacitors
• Presented by Iconopower

2
(No Transcript)
3

• Configuration
• Cylindrical 3 phase capacitors for
  Power Factor correction
• 3 capacitive elements internally connected in
  either STAR or DELTA
• Once connected, these 3 elements are placed
  inside a plastic glass
• Impregnation is with polyurethane resin and a
  very fast polymerization process
• All agents are environmentally friendly

4

• General Characteristics
• Cylindric Aluminum Can
• Very Low Loss Dielectric ( 0.3 W/kvar)
• Insulation level IP20 (IP54 by terminal cover
  available)

5

• Technology
• Metallized Polypropylene film
• 2 polypropylene films are wound together
  resulting in the capacitive elements
• Self Healing capabilities
• Capacitors can restore their electrical
  properties after an internal short circuit
• Dry Technology
• dry capacitors are impregnated with a highly
  stable synthetic resin

6

• Typical Applications
• Power Factor Correction
• Static Compensation
• Wind Turbines

7

• Protection and Security Advantages
• Double insulation
• Perfect Impregnation
• Double Ring Overpressure device
• The function of the device is to interrupt the
  short circuit when the capacitor is no longer
  able to regenerate itself

8

• Product Specifications
• 220 to 800 V (50 / 60 Hz)
• 5 kvar to 30 kvar
• Dimensions 75 x 220 to 100 x 370 (mm)
• External discharge resistors
• M12 Mounting Stud

9

• Iconopowers mandate
• Stocking distributor
• Support end users in line with Ducati engineering
• North American exclusive Distributor for Ducati
  energia

10

• Iconopower Partnership Program (IPP)
• IPP advantages
• Immediate support of technicians and engineering
• Short lead time (all stock in North America)
• Aggressive Pricing
• Quality products
• Capacitors are stored at our Montreal facility

11

• Conclusion
• Iconopower can eliminate many lead time and
  delivery issues by offering stock packages in
  North America
• Iconopower can offer aggressive and competitive
  pricing for all Ducati capacitors

12
Fine Grazie
