Enhances Collaboration between G

1
Enhances Collaboration
between GG and Drilling

• Nigel Deeks / Emmanuelle Regrain
• Schlumberger

2
enables Schlumberger
Operations

• InterACT
• Full 1.2 and 1.3.1 API - (GetFrom, AddTo,
  UpdateInStore)
• DataHub scaleability, agregation and
  synchronisation
• Server to Server transfer (Push and Pull)
• WITSML Data Browsing
• Operation Support Centers (OSC)
• Internal Support, Collaboration, Remote Control
• Commercial Schlumberger Silver, Gold Platinum
  OSCs
• Answer Products Enabled for WITSML via Real
  Time DataLink
• Drilling Optimisation Perform Toolkit
• Geosteering RTGS
• Petrophysics Interactive Petrophysics
• Seismic to Simulation - Petrel

3
in Petrel 2007

• Seismic to Simulation Software is now open to
  Drilling
• Planning workflow
• Drilling Risks and Events Exchange
• Drilling Risk and Events in the Geological Model
• Execution workflow
• Trajectory in Real Time
• Logs and Risks in Real Time

4
WITSML in Petrel 2007 Planning WorkflowDrilling
Risks in the Geological Model
5
WITSML in Petrel 2007 Planning WorkflowDrilling
Risks in the Geological Model
6
WITSML in Petrel 2007 Execution
WorkflowTrajectory, Log, Risks in Real-Time
7
WITSML in Petrel 2007 Execution
WorkflowTrajectory, Log, Risks in Real-Time
8
WITSML Enhances Collaboration in Petrel 2007

• Seismic to Simulation Software is now open to
  Drilling
• Share the Risks for Easier, Faster Collaborative
  Planning
• Follow the Trajectory and the Logs for Easier,
  Faster Decision Making in the Execution Phase
• .. A First Step in a New Direction
