Packet Switching Case

• What is the probability of more than 100 users
  being active?

The probability of 101 users being active plus,
102 users being active, plus, ., 200 users being
active, which is
We conclude that if there are 200 users, then in
pretty much always things will work fine
Suppose that there are 300 users
Might be acceptable performance
Suppose that there are 400 users
Therefore circuit switching could support 100
users, while packet switching can support 400
users. A factor of 4 more!!!
5
Losses and delay in packet switched networks

• Losses
• Transmission losses
• In fiber links, bit-error is 10-12 or better
  (i.e., less).
• What is the probability of packet error when
  there are 1400 bytes in a packet?
• In wireless links, the bit-error rate can be very
  high
• Congestion losses.
• If too many packets arrive at the same time, then
  the buffers will fill up and packets are lost.
• Increasing the link speeds or reducing the number
  of users can reduce the probability of loss.
• Increasing the size of the buffer reduces losses,
  but also increases delay.
• Delay
• Queuing delay
• Transmission delay
• Propagation delay
• Processing delay

6
In the news

• News sources
• www.lightreading.com (general networks)
• www.unstrung.com (wireless and mobile)
• www.darkreading.com (network security)
• www.alleyinsider.com (general tech business news)
• arstechnica.com (general tech news)

7
The Protocol Stack

• The application layer includes network
  applications and network application protocols
• e.g. of applications web, IM, email
• e.g., application protocols OSCAR, http, smtp,
  ftp, DNS.
• Provide a service to a user or another
  application.
• Require service from the lower layers, but
  typically only interact with the transport layer.

8
The Protocol Stack

• The transport layer (typically) transports
  messages from and to applications
• Different transport layer protocols provide
  different types of services.
• Types of services MAY include
• Reliability the sender application can be
  assured that the data is correctly received, or
  receives an error message.
• Congestion and flow control attempt to send data
  quickly but not so quickly to cause congestion in
  the network or at the receiving host
• Error detection / correction
• In order delivery
• Break long messages into small chunks suitable
  for transmission over the network
• Multiplexing so that multiple transport layer
  connections can occur simultaneously
• Note that when a transport protocol provides
  these services, the application does not have to.

• This makes implementation of applications easier.
• This allows careful design of transport
  protocols, following the divide and conquer
  approach
• The transport layer uses the network layer to
  deliver packets, but does not require any type of
  service guarantees from the network layer
• In practice, the transport layer hopes for in
  order delivery.

9
Transport layer protocols TCP and UDP

• TCP and UDP are the most widely used transport
  protocols.
• Other protocols include SCTP (UD and Cisco are
  active in developing SCTP), RTP (for multimedia
  such as VoIP)
• TCP and UDP will be covered in great detail
  later. But for now
• TCP provides many services
• Congestion control
• Flow control
• Reliability
• Multiplexing
• Error detection
• UDP provides few services
• Error detection
• Multiplexing
• The application must implement any other services
  that it requires.
• TCP requires a connection to be established, UDP
  does not

10
Transport Multiplexing

• Transport layers use ports to provide
  multiplexing
• A two hosts can have multiple simultaneous
  connections by using ports.
• Well known ports can be used to specify a
  particular application
• E.g., web servers will accept TCP connections on
  port 80
• A host can have two connections with a web server
  by using different ports

host (web server)
host
TCP
UDP
TCP
UDP
0
0
0
0
4567
80
4568
216-1
216-1
216-1
216-1
11
Sockets gateway between the app layer and the
transport layer

• process sends/receives messages to/from its
  socket
• socket analogous to door
• sending process shoves message out door
• sending process relies on transport
  infrastructure on other side of door which brings
  message to socket at receiving process

12
TCP Sockets

• An application accesses TCP and UDP through
  sockets.
• TCP is connection based so one host must be
  listening and the other must be connecting
  (calling)
• The basic steps for a TCP listener
• Define socket variable as a TCP socket
• Bind socket to a port (the bind function)
• If some other application is or was recently (120
  sec) listening on this port, this function will
  fail.
• The application must check that this command
  succeeds.
• Listen on this port (the listen function)
• When a the other host connects, the listen
  function completes and data can be send or
  received.
• Close socket
• Basic steps for TCP caller
• Define socket variable as a TCP socket
• No port is given, the OS will assign which ever
  port is available. The application has no control
  over the port
• Connect
• Send data
• Close socket

13
UDP Sockets

• UDP are connectionless.
• A host sends a packet when it wants.
• There is no concept of one host connecting to
  another.
• There is only the concept of one host sending a
  packet and the other host receiving the packet.
  And either host can send or receive
• Steps to send and then receive a UDP message
• Define socket as a UDP socket
• Bind socket to a port
• If this port is in use, bind will fail
• Send message
• Wait for message
• There are two ways to wait for messages, blocking
  or non-blocking
• A blocking function will wait for a message to
  arrive. It might wait forever.
• A non-blocking will return immediately, but if no
  message was waiting in the transport layer, then
  no message is returned
• select function allows a time out to be set. So
  the function will wait until a message arrives or
  the timeout time to elapse.
• Close socket
• Steps to receive a UDP message
• Define socket as a UDP socket
• Bind socket to a port
• If this port is in use, bind will fail

14
Project 1
Due 9/16

• In this project messages will be sent over TCP
  and UDP.
• The project is description currently at
• http//www.eecis.udel.edu/bohacek/Classes/CPEG419
  _2005/Proj1/project1_part1.htm
• All the required information should be online.
• This project can be completed by cut and pasting
  from the web site. But try to understand the
  steps.
• Let me know if there are typos.

15
The Protocol Stack

• The network layer routes packets (datagrams)
  through the network
• The network layer gets packets from the transport
  layer or from the link layer.
• Depending on the destination address, the network
  layer will give the packet to the transport
  protocol or to a specific link layer to send on a
  specific link
• The network layer also provides fragmenting of a
  large packet into chunks suitable for the link
  layer

16
The Protocol Stack

• The link layer moves packets (frames) between two
  hosts
• However, the link layer may provide a wide range
  of services including
• Media access control
• Error detection / correction
• Routing over layer 2 networks
• Reliability (where the network layer is informed
  if the transmission fails)

17
The Protocol Stack

• The physical layer moves packets (frames) between
  two connected hosts
• This requires putting the bits onto a physical
  medium and decoding them from the medium.
• In this course we mostly neglect the physical
  layer and assume that is works correctly (each
  layer always assumes that the other layers work
  correctly)
• But the performance of a protocol at a layer
  often dependent on the other layers.
• One approach is for cross-layer design

18
Encapsulation
source
message
application transport network link physical
segment
datagram
frame
switch
destination
application transport network link physical
router
19
Chapter 2 The Application Layer
20
Goals of this Chapter

• To understand common application protocols work
• Web (http)
• Email (smtp)
• FTP
• DNS
• P2P
• IM
• To understand how the design alternatives for
  application design
• A network application runs on many hosts, it is a
  distributed application
• This chapter discusses several designs of
  distributed applications

21
Road Map

• Application basics
• Web
• Email
• FTP
• DNS
• P2P
• Graph theory
• State diagrams
• P2P design
• IM

22
Road Map

• Application basics
• Web
• Email
• FTP
• DNS
• P2P
• Graph theory
• State diagrams
• P2P design
• IM

23
Creating a network app

• write programs that
• run on (different) end systems
• communicate over network
• e.g., web server software communicates with
  browser software
• No need to write software for network-core
  devices
• Network-core devices do not run user applications

• applications on end systems allows for rapid app
  development, propagation

24
An App-layer protocol defines

• Types of messages exchanged,
• e.g., request, response
• Message syntax
• what fields in messages how fields are
  delineated
• Message semantics
• meaning of information in fields
• Rules for when and how processes send respond
  to messages

• Public-domain protocols
• defined in RFCs
• allows for interoperability
• e.g., HTTP, SMTP
• Proprietary protocols
• e.g., Skype

25
Ports

• An application is identified by the hosts IP
  address, transport protocols, and port
• E.g., A web server has a particular IP address,
  listens with TCP on port 80.
• A web browser on a host will connect a request a
  file from the web server. The browser is
  identified by the hosts IP address and a TCP
  port.

26
What transport service does an app need?

• Throughput
• some apps (e.g., multimedia) require minimum
  amount of throughput to be useful (i.e., in
  order for the user to gain utility)
• other apps (elastic apps) make use of whatever
  throughput they get
• Security
• Encryption, data integrity,

• Data reliability
• some apps (e.g., audio) can tolerate some loss
• other apps (e.g., file transfer, telnet) require
  100 reliable data transfer

• Timing
• some apps (e.g., Internet telephony, interactive
  games) require low delay to be effective

27
Transport service requirements of common apps
Application file transfer e-mail Web
documents real-time audio/video stored
audio/video interactive games instant messaging
Throughput elastic elastic some what
elastic audio 5kbps-1Mbps video10kbps-5Mbps same
as above few kbps up elastic
Time Sensitive no no not really yes, 100s
msec yes, few secs yes, 100s msec yes and no
Data loss no loss no loss no loss loss-tolerant
loss-tolerant loss-tolerant no loss
28
Internet transport protocols services

• TCP service
• connection-oriented setup required between
  client and server processes
• reliable transport between sending and receiving
  process
• flow control sender wont overwhelm receiver
• congestion control throttle sender when network
  overloaded
• does not provide timing, minimum throughput
  guarantees, security

• UDP service
• unreliable data transfer between sending and
  receiving process
• does not provide reliability, flow control,
  congestion control, timing, throughput guarantee,
  or security
• Does not require connection set-up
• Packets can be sent at any rate desired (but this
  might be cause considerable congestion)

29
Internet apps application, transport protocols
Application layer protocol SMTP RFC
2821 Telnet RFC 854 HTTP RFC 2616 FTP RFC
959 HTTP (eg Youtube), RTP RFC 1889 SIP, RTP,
proprietary (e.g., Skype)
Underlying transport protocol TCP TCP TCP TCP TCP
or UDP typically UDP
Application e-mail remote terminal access Web
file transfer streaming multimedia Internet
telephony
30
Road Map

• Application basics
• Web
• Email
• FTP
• DNS
• P2P
• Graph theory
• State diagrams
• P2P design
• IM

31
Web and HTTP

• Web page consists of objects
• Object can be HTML file, JPEG image, Java applet,
  audio file,
• Web page consists of base HTML-file which
  includes several referenced objects
• The browser first requests the base file
• The base file species text and URLs of objects
• The browser requests these objects, where ever
  they are (not always on the same server)
• HTTP is used to request the base file and all the
  other files
• Note, that HTTP can be used for other
  applications besides web
• Each object is addressable by a URL
• Example URL

32
HTTP overview

• HTTP hypertext transfer protocol
• Webs application layer protocol
• client/server model
• client browser that requests, receives,
  displays Web objects
• server Web server sends objects in response to
  requests

33
HTTP overview (continued)

• Uses TCP
• client initiates TCP connection (creates socket)
  to server, port 80
• server accepts TCP connection from client
• HTTP messages (application-layer protocol
  messages) exchanged between browser (HTTP client)
  and Web server (HTTP server)
• TCP connection closed

• HTTP is stateless
• server maintains no information about past client
  requests

aside

• Protocols that maintain state are complex!
• past history (state) must be maintained
• if server/client crashes, their views of state
  may be inconsistent, must be reconciled

34
HTTP connections

• Nonpersistent HTTP
• At most one object is sent over a TCP connection.

• Persistent HTTP
• Multiple objects can be sent over single TCP
  connection between client and server.

35
Nonpersistent HTTP

• Suppose user enters URL www.someSchool.edu/someDep
  artment/home.index

(contains text, references to 10 jpeg images)

• 1a. HTTP client initiates TCP connection to HTTP
  server (process) at www.someSchool.edu on port 80

1b. HTTP server at host www.someSchool.edu
waiting for TCP connection at port 80. accepts
connection, notifying client
2. HTTP client sends HTTP request message
(containing URL) into TCP connection socket.
Message indicates that client wants object
someDepartment/home.index
3. HTTP server receives request message, forms
response message containing requested object, and
sends message into its socket
5. HTTP client receives response message
containing html file, displays html. Parsing
html file, finds 10 referenced jpeg objects
4. HTTP server closes TCP connection.
time
6. Steps 1-5 repeated for each of 10 jpeg objects
36
Non-Persistent HTTP Response time

• Definition of RTT time for a small packet to
  travel from client to server and back.
• Response time
• one RTT to initiate TCP connection
• one RTT for HTTP request and first few bytes of
  HTTP response to return
• file transmission time
• total 2RTTtransmit time

initiate TCP connection
RTT
request file
RTT
file received
time
time
37
Persistent HTTP

• Nonpersistent HTTP issues
• requires 2 RTTs per object
• OS overhead for each TCP connection
• browsers often open parallel TCP connections to
  fetch referenced objects

• Persistent HTTP
• server leaves connection open after sending
  response
• subsequent HTTP messages between same
  client/server sent over open connection
• client sends requests as soon as it encounters a
  referenced object
• as little as one RTT for all the referenced
  objects

38
HTTP request message

• two types of HTTP messages request, response
• HTTP request message
• ASCII (human-readable format)

request line (GET, POST, HEAD commands)
GET /somedir/page.html HTTP/1.1 Host
www.someschool.edu User-agent
Mozilla/4.0 Connection close Accept-languagefr
(extra carriage return, line feed)
header lines
Carriage return, line feed indicates end of
message
39
HTTP request message general format
40
HTTP response message
status line (protocol status code status phrase)
HTTP/1.1 200 OK Connection close Date Thu, 06
Aug 1998 120015 GMT Server Apache/1.3.0
(Unix) Last-Modified Mon, 22 Jun 1998 ...
Content-Length 6821 Content-Type text/html
data data data data data ...
header lines
data, e.g., requested HTML file
41
HTTP response status codes
In first line in server-gtclient response
message. A few sample codes

• 200 OK
• request succeeded, requested object later in this
  message
• 301 Moved Permanently
• requested object moved, new location specified
  later in this message (Location)
• 400 Bad Request
• request message not understood by server
• 404 Not Found
• requested document not found on this server
• 505 HTTP Version Not Supported

42
Trying out HTTP (client side) for yourself

• 1. Telnet to your favorite Web server

Opens TCP connection to port 80 (default HTTP
server port) at cis.poly.edu. Anything typed in
sent to port 80 at cis.poly.edu
telnet cis.poly.edu 80
2. Type in a GET HTTP request
By typing this in (hit carriage return twice),
you send this minimal (but complete) GET request
to HTTP server
GET /ross/ HTTP/1.1 Host cis.poly.edu
3. Look at response message sent by HTTP server!
43
Wireshark (ethereal)

• Wireshark captures all packets that pass through
  the hosts interface
• To run Wireshark , libpcap (linux) or winpcap
  (windows) must be installed. It comes with
  wireshark package
• Then, run wireshark
• Select Capture
• Find the active interface
• E.g., mot generic dialup, nor vnp, nor packet
  scheduler, but wireless . With IP address
• Then select prepare
• Lets watch TCP packets on port 80
• Next to capture filter, enter TCP port 80
• Select update in realtime and autoscroll
• Might need to enable or disable capture in
  promiscuous mode
• Press start
• Press close
• Load www.eecis.udel.edu page in browser
• Press stop in Wireshark
• Find http request to 128.4.40.10.
• Right click and select follow TCP stream

44
Web caches (proxy server)
Goal reduce network utilization by satisfying
client request without involving origin server

• user sets browser Web accesses via cache
• browser sends all HTTP requests to cache
• object in cache cache returns object
• else cache requests object from origin server,
  then returns object to client

origin server
Proxy server
client
client
origin server
45
More about Web caching

• cache acts as both client and server
• typically cache is installed by ISP (university,
  company, residential ISP)

• Why Web caching?
• reduce response time for client request
• reduce traffic on an institutions access link.
• Internet dense with caches enables poor
  content providers to effectively deliver content
  (but so does P2P file sharing)

46
Caching example
origin servers

• Assumptions
• average object size 100,000 bits
• avg. request rate from institutions browsers to
  origin servers 15/sec
• delay from institutional router to any origin
  server and back to router 2 sec
• Consequences
• utilization on LAN 15
• utilization on access link 100
• total delay Internet delay access delay
  LAN delay
• 2 sec minutes milliseconds

public Internet
1.5 Mbps access link
institutional network
10 Mbps LAN
institutional cache
47
Caching example (cont)
origin servers

• possible solution
• increase bandwidth of access link to, say, 10
  Mbps
• consequence
• utilization on LAN 15
• utilization on access link 15
• Total delay Internet delay access delay
  LAN delay
• 2 sec msecs msecs
• often a costly upgrade

public Internet
10 Mbps access link
institutional network
10 Mbps LAN
institutional cache
48
Caching example (cont)
origin servers

• possible solution install cache
• suppose hit rate is 0.4
• consequence
• 40 requests will be satisfied almost immediately
• 60 requests satisfied by origin server
• utilization of access link reduced to 60,
  resulting in negligible delays (say 10 msec)
• total avg delay Internet delay access delay
  LAN delay .6(2.01) secs
  .4milliseconds lt 1.4 secs

public Internet
1.5 Mbps access link
institutional network
10 Mbps LAN
institutional cache
49
Conditional GET
server
cache

• Goal dont send object if cache has up-to-date
  cached version
• cache specify date of cached copy in HTTP
  request
• If-modified-since ltdategt
• server response contains no object if cached
  copy is up-to-date
• HTTP/1.0 304 Not Modified

HTTP request msg If-modified-since ltdategt
object not modified
HTTP request msg If-modified-since ltdategt
object modified
HTTP response HTTP/1.0 200 OK ltdatagt
50
Road Map

• Application basics
• Web
• FTP
• Email
• DNS
• P2P
• Graph theory
• State diagrams
• P2P design
• IM

51
FTP the file transfer protocol
file transfer
user at host
remote file system
local file system

• transfer file to/from remote host
• client/server model
• client side that initiates transfer (either
  to/from remote)
• server remote host
• ftp RFC 959
• ftp server listens on port 21

52
FTP is weird separate control and data
connections

• FTP client contacts FTP server at port 21, TCP is
  transport protocol
• client authorized over control connection
• This is done in clear text (i.e., unencrypted)
• So if some one if sniffing packets, your password
  might be learned.
• Sniffing packets is difficult on ethernet,
  encrypted wifi, and DSL, but is possible on cable
  modems
• client browses remote directory by sending
  commands over control connection.
• Data is transferred over different connections.
  Two approaches
• Active
• Passive

• Active mode is a problem for firewalls
• If my desktop is not a server, if should not
  receive any requests for connections.
• But FTP servers will make such a requests

• Active
• The client opens a TCP socket with on some port
  (port number gt1024)
• The client sends the server the port
• The server connects to the clients port where
  the servers source port is 20

53
FTP Passive mode

• When a file is to be transferred, the server
  opens a port (numbergt1024 and not 20)
• The server sends this port number information
  over the command connection
• The client connects to the servers over this port.

• Drawback of passive
• Some enterprises (companies) like to control
  which applications are used
• E.g., web browsing is ok, but skype is not
• One way to do this is to block out going
  connections based on the port.
• However, this will cause FTP to fail, unless the
  device that blocks connections is smart

54
Road Map

• Application basics
• Web
• FTP
• Email
• DNS
• P2P
• Graph theory
• State diagrams
• P2P design
• IM

55
Email Protocol Design

• Basic assumption weak user agents and strong
  mail servers
• The user wants to send the mail and leave
• The user wants to get the mail
• The user may come and go whenever (e.g., roaming
  laptop)
• It should be possible to send mail to a user even
  if neither user is online at the same time.
• We conclude that there must be a middle man/mail
  server.
• Servers are not that strong The protocol must be
  as robust as possible to servers being offline
• No single server why
• Single point of failure
• The server would have to be too big (congestion)
• We conclude that there should be many mail
  servers
• Two types of hosts
• Users
• Mail servers
• Each user has a mail box in its mail server
• Users retrieve mail from their mail server at
  there convenience
• Users give mail to their mail servers to deliver
  the mail

56
Email Protocol Design

• Two types of hosts
• Users
• Mail servers
• Each user has a mail box in its mail server
• Users retrieve mail from their mail server at
  there convenience
• Users give mail to their mail servers to deliver
  the mail
• Mail servers communicate with
• The users that have mail boxes in the server
• Other mail servers

Destination user requests emails from mailbox
User composes mail and sends it to its mail
server (or a mail server that will send mail for
it)
Mail server finds the destination mail server and
attempts to send the mail
Destination server gives mails to user
57
Email Protocol Design

• Two types of hosts
• Users
• Mail servers
• Each user has a mail box in its mail server
• Users retrieve mail from their mail server at
  there convenience
• Users give mail to their mail servers to deliver
  the mail
• Mail servers communicate with
• The users that have mail boxes in the server
• Other mail servers

Destination user requests emails from mailbox
User composes mail and sends it to its mail
server (or a mail server that will send mail for
it)
Mail server finds the destination mail server and
attempts to send the mail
Destination server gives mails to user
SMTP
SMTP
POP3 IMAP
58
Electronic Mail Details
outgoing message queue
user mailbox

• Three major components
• user agents
• mail servers
• simple mail transfer protocol SMTP
• User Agent
• a.k.a. mail reader
• composing, editing, reading mail messages
• e.g., Eudora, Outlook, elm, Mozilla Thunderbird
• Put outgoing on server (with SMTP)
• Get incoming messages from server

SMTP
mail server
SMTP
SMTP
59
Electronic Mail mail servers

• Mail Servers
• mailbox contains incoming messages for user
• message queue of outgoing (to be sent) mail
  messages
• SMTP protocol between mail servers to send email
  messages
• client sending mail server
• server receiving mail server
• Reliable several attempts and provide
  notification if delivery fails

60
Electronic Mail SMTP RFC 2821

• uses TCP to reliably transfer email message from
  client to server, port 25
• direct transfer sending server to receiving
  server
• Emails are pushed to servers (but users pull
  messages from servers)
• three phases of transfer
• handshaking (greeting)
• transfer of messages
• closure
• command/response interaction
• commands ASCII text
• response status code and phrase
• messages must be in 7-bit ASCII
• Makes it difficult to send attachments

61
Scenario Alice sends message to Bob

• 4) SMTP client sends Alices message over the TCP
  connection
• 5) Bobs mail server places the message in Bobs
  mailbox
• 6) Bob invokes his user agent to read message

• 1) Alice uses UA to compose message and to
  bob_at_someschool.edu
• 2) Alices UA sends message to her mail server
  message placed in message queue
• 3) Client side of SMTP opens TCP connection with
  Bobs mail server

1
2
6
3
4
5
62
Sample SMTP interaction
Client connects to server
S 220 hamburger.edu C HELO crepes.fr
S 250 Hello crepes.fr, pleased to meet
you C MAIL FROM ltalice_at_crepes.frgt
S 250 alice_at_crepes.fr... Sender ok C RCPT
TO ltbob_at_hamburger.edugt S 250
bob_at_hamburger.edu ... Recipient ok C DATA
S 354 Enter mail, end with "." on a line
by itself C Do you like ketchup? C
How about pickles? C . S 250
Message accepted for delivery C QUIT
S 221 hamburger.edu closing connection
63
Try SMTP interaction for yourself

• telnet mail.eecis.udel.edu 25
• see 220 reply from server
• enter HELO, MAIL FROM, RCPT TO, DATA, QUIT
  commands
• above lets you send email without using email
  client (reader)

64
SMTP final words

• SMTP uses persistent connections
• SMTP requires message (header body) to be in
  7-bit ASCII
• SMTP server uses CRLF.CRLF to determine end of
  message

• Comparison with HTTP
• HTTP pull
• SMTP push
• both have ASCII command/response interaction,
  status codes
• HTTP each object encapsulated in its own
  response msg
• SMTP multiple objects sent in multipart msg

65
Mail access

• POP3 and IMAP are two protocols for access mail
  on a mail server
• Web-based mail works differently, the web mail
  server and the mail server can be integrated, so
  that there is no user agent.

66
Mail access protocols
SMTP
access protocol
receivers mail server

• SMTP delivery/storage to receivers server
• Mail access protocol retrieval from server
• POP Post Office Protocol RFC 1939
• authorization (agent lt--gtserver) and download
• IMAP Internet Mail Access Protocol RFC 1730
• more features (more complex)
• manipulation of stored msgs on server
• HTTP gmail, Hotmail, Yahoo! Mail, etc.

67
Road Map

• Application basics
• Web
• FTP
• Email
• DNS
• P2P
• Graph theory
• State diagrams
• P2P design
• IM

68
DNS domain name system

• Change names, like www.yahoo.com into IP address.
• Services provided by DNS
• Name to address translation
• Host aliasing
• A host relay1.west-coast.yahoo.com could have two
  aliases, yahoo.com and www.yahoo.com.
• In this case, the canonical hostname is
  relay1.west-coast.yahoo.com.
• DNS can provide canonical host names
• Mail server aliasing
• When a mail server wants to send a mail to
  Me_at_udel.edu, it does not send it to www.udel.edu,
  but to mail.udel.edu. Or maybe udmail.udel.edu.
  DNS can translate udel.edu to mail.udel.edu
• (Cheap) Load distribution
• Cnn.com has several servers.
• DNS will respond with all address,
• but it will reorder the addresses every time.
• If the client uses the first address listed, then
  each client will use different servers.
• Content distribution networks (CDN) are better
  ways of load balancing

69
DNS - structure

• Centralized DNS?
• Pros somewhat easy to maintain (there is only
  one system). But it must always be online
• Cons
• Single point of failure (the system crashes -gt no
  web)
• Congestion
• Server would be far from some hosts (delay)
• Database would be too big
• The register bohacek-pc1.pc.udel.edu would
  require interacting with the big server
• Instead, a distributed hierarchical database is
  used.

70
Domain Hierarchy
edu
com
gov
mil
org
net
uk
in
UD
upenn
yahoo
cisco
whitehouse
nasa
navy
arpa
acm
art
eecis
bohacek_pc10
bohacek_pc1
71
Administrative Zones in the Domain Hierarchy
root
edu
com
gov
mil
org
net
uk
in
yahoo
cisco
whitehouse
nasa
UD
upenn
navy
arpa
acm
art
eecis
bohacek_pc1
bohacek_pc10
It is possible that .edu and .gov are
administered together Note that UD administered
art but not eecis Some times a single service
provider will administer the domains for a large
number of .coms
72
Root servers

• Each layer in the hierarchy knows about the
  domain names below it
• The highest level is the root.
• There are 13 root servers
• Each of these servers is actually several
  servers, and some of the machines that comprise a
  server are distributed geographically.

a Verisign, Dulles, VA c Cogent, Herndon, VA
(also LA) d U Maryland College Park, MD g US DoD
Vienna, VA h ARL Aberdeen, MD j Verisign, ( 21
locations)
k RIPE London (also 16 other locations)
i Autonomica, Stockholm (plus 28 other
locations)
m WIDE Tokyo (also Seoul, Paris, SF)
e NASA Mt View, CA f Internet Software C. Palo
Alto, CA (and 36 other locations)
13 root name servers worldwide
b USC-ISI Marina del Rey, CA l ICANN Los
Angeles, CA
73
overview

• Top-level domain (TLD) servers
• There are around 200 top-level domains
• These include com, edu, mil, info, in, uk, cn,
• Currently,
• network solutions maintains the TLD servers for
  com
• Educause maintains the TLD servers for edu
• The root servers know the addresses and names of
  all top level servers
• Organizations have a hierarchy of DNS servers

74
DNS queries

• Suppose a host needs the IP address of
  bohacek-pc1.eecis.udel.edu
• If this IP address is not in cache, the host asks
  its local DNS server.
• If the DNS server does not have it in cache, it
  checks if is had the IP address of the DNS server
  of eecis.udel.edu in cache
• If not, it checks if IP address of the dns server
  of udel.edu in cache
• If not, it check if it has the IP address of the
  top-level domain server of edu in cache
• It not, it asks the root server for the IP
  address of the edu TLD server
• The DNS server always has the IP address of the
  root servers
• The local DNS server asks the edu TLD server for
  address of bohack-pc1.eecis.udel.edu.
• The TLD server does not know that IP address, but
  instead gives the IP address of the dns server
  for UD
• The local DNS server asks the UD dns server for
  the address of bohack-pc1.eecis.udel.edu.
• The UD dns server does not know the address, but
  instead returns the address of the eecis dns
  server.
• The local DNS server asks the eecis dns server
  for the address of bohacek-pc1.eecis.udel.edu
• Eecis dns server replies with the address.
• This address is returned to the host that
  orginally asked the question.

75
DNS Queries
Root server (IP address are always known)
Browser wants to show www. eecis.udel.edu
What is the IP address of www.eecis.udel.edu?
Root server does not know. Instead, it responds
with dns server that might, specifically, the TLD
server for .edu
Browser needs the IP address of www.
eecis.udel.edu
TLD server for .edu
What is the ip address of www.eecis.udel.edu?
Host asks local DNS server for IP address of www.
eecis.udel.edu
TLD server does not know. Instead replies with
the name and IP address of the UD DNS server
What is the ip address of www.eecis.udel.edu?
It is 128.4.1.2
UD dns server does not know. Instead it replies
with the name and IP address of the eecis dns
server.
What is the ip address of www.eecis.udel.edu?

• Local DNS server checks if it has the IP address
  of www.eecis.udel.edu in cache.
• If not, it checks if is had the IP address of the
  DNS server of eecis.udel.edu in cache
• If not, it checks if IP address of the dns server
  of udel.edu in cache
• If not, it check if it has the IP address of the
  top-level domain server of edu in cache
• .if not, ..

It is 128.4.1.2
76
DNS Queries
Root server (IP addresses are always known)
What is the IP address of www.eecis.udel.edu?
Root server does not know. Instead, it responds
with name and address of a server that might,
specifically, the TLD server for .edu
Browser wants to show www.eecis.udel.edu
Browser needs the IP address of
www.eecis.udel.edu
Host asks local DNS server for IP address of
www.eecis.udel.edu
What is the IP address of www.eecis.udel.edu?
TLD server for .edu
TLD server does not know. Instead replies with
the name and IP address of the UD DNS server
What is the ip address of www.eecis.udel.edu?
It is 128.4.1.2
UD DNS server does not know. Instead it replies
with the name and IP address of the eecis dns
server.
UD DNS server
What is the IP address of www.eecis.udel.edu?

• Local DNS server checks if it has the IP address
  of www.eecis.udel.edu in cache.
• If not, it checks if is had the IP address of the
  DNS server of eecis.udel.edu in cache
• If not, it checks if it has the IP address of the
  DNS server of udel.edu in cache
• If not, it checks if it has the IP address of the
  top-level domain server of edu in cache
• .if not, ..

It is 128.4.1.2
eecis DNS server
77
DNS Queries
Browser wants to show www.eecis.udel.edu
Browser needs the IP address of
www.eecis.udel.edu
Host asks local DNS server for IP address of
www.eecis.udel.edu
It is 128.4.1.2

• Local DNS server checks if it has the IP address
  of www.eecis.udel.edu in cache.
• If yes, then return it

78
DNS Queries
Browser wants to show www.eecis.udel.edu
Browser needs the IP address of
www.eecis.udel.edu
Host asks local DNS server for IP address of
www.eecis.udel.edu
It is 128.4.1.2
What is the IP address of www.eecis.udel.edu?

• Local DNS server checks if it has the IP address
  of www.eecis.udel.edu in cache.
• If not, it checks if is had the IP address of the
  DNS server of eecis.udel.edu in cache
• If yes, query it

It is 128.4.1.2
eecis DNS server
79
DNS Queries
Browser wants to show www.eecis.udel.edu
Browser needs the IP address of
www.eecis.udel.edu
Host asks local DNS server for IP address of
www.eecis.udel.edu
What is the IP address of www.eecis.udel.edu?
TLD server for .edu
TLD server does not know. Instead replies with
the name and IP address of the UD DNS server
What is the ip address of www.eecis.udel.edu?
It is 128.4.1.2
UD DNS server does not know. Instead it replies
with the name and IP address of the eecis dns
server.
UD DNS server
What is the IP address of www.eecis.udel.edu?

• Local DNS server checks if it has the IP address
  of www.eecis.udel.edu in cache.
• If not, it checks if is had the IP address of the
  DNS server of eecis.udel.edu in cache
• If not, it checks if it has the IP address of the
  DNS server of udel.edu in cache
• If not, it checks if it has the IP address of the
  top-level domain server of edu in cache
• .if so, then query it

It is 128.4.1.2
eecis DNS server
80
Attack on DNS

• Hackers have tried to bring down DNS by
  performing a DoS on the root servers
• DoS denial of service. Sends more packets or
  requests for service than the server can
  accommodate. Resulting in poor service for normal
  users.

• This failed because
• There are many very strong root servers and have
  firewalls/filters
• The attacks used ICMP ping packets
• DNS requests would have been more effective
• It is rare that a root server is needed
• Usually only the TLD server is needed
• Or only a domain server.

81
DNS Message Details

• DNS Record
• (Name, Value, Type, Class, TTL)
• If Type A
• Name is the host name
• Value is the IP address of the host
• If Type NS
• Name is a domain name
• Value is the name of the DNS server for the
  domain
• E.g., (udel.edu, dns.udel.edu, NS, , )
• Type MX
• Name is the domain name
• Value is the name of the mail server for the
  domain
• E.g., (udel.edu, mail.udel.edu, MX, , )
• Type CName
• Name is a host name
• Value is the canonical name of the host
• E.g., (www.yahoo.com, relay-east.yahoo.com,
  CName, , )
• TTL is the time to live, so DNS caches can be
  timed out
• Class is no longer used, it is set as IN

82
DNS query

• (Name, Type, Class)
• (UDel.edu, MX, IN)
• Please provide the name of the UDs mail server
• (mail.UDel.edu, A, IN)
• Please provide the IP address for mail.udel.edu

83
DNS message format

• DNS protocol query and reply messages, both
  with same message format

• msg header
• identification 16 bit for query, reply to
  query uses same
• flags
• query or reply
• recursion desired
• recursion available
• reply is authoritative

84
DNS message format
Name, type fields for a query
RRs in response to query
records for authoritative servers
additional helpful info that may be used
85
DNS Queries
Root server (IP addresses are always known)
Browser wants to show www.eecis.udel.edu
Browser needs the IP address of
www.eecis.udel.edu
TLD server for .edu
UD DNS server

• Local DNS server checks if it has the IP address
  of www.eecis.udel.edu in cache.
• If not, it checks if is had the IP address of the
  DNS server of eecis.udel.edu in cache
• If not, it checks if it has the IP address of the
  DNS server of udel.edu in cache
• If not, it checks if it has the IP address of the
  top-level domain server of edu in cache
• .if not, ..

eecis DNS server
86
DNS Flags

• The DNS header has a query ID
• The query has this ID and the server copies this
  ID into the response
• Flag indicating query or answer
• Flag indicating whether the server is the
  authoritative server for the answer (as oppose to
  a cached answer)
• A recursive desired flag indicating that the
  host/server would like the server to perform the
  recursive DNS lookup
• A recursive available flag indicating whether the
  server is available to to the recursive lookup

87
DNS

• Which transport protocol should DNS use?
• Why?

88
Peer-to-peer file sharing

• About P2P
• 30 or more of the bytes transferred on the
  Internet are from P2P users
• Skype is a very successful P2P VoIP app
• Written in 3-4 months
• Topics covered
• Scalability
• P2P querying
• Case study
• BitTorrent
• Skype

89
Pure P2P architecture

• Review What is the difference between
  peer-to-peer and client/server?
• Each hosts acts as both a server and a client.
• no always-on server
• arbitrary end systems directly communicate
• peers are intermittently connected and may change
  IP addresses
• Pure P2P has significant drawbacks.
• P2P-like systems with some central servers are
  more common.
• But in all cases, the file transfer is between
  peers, not from servers.

90
File Distribution Server-Client vs P2P

• Question How much time to distribute file from
  one server to N peers?

us server upload bandwidth
Server
ui peer i upload bandwidth
u2
d1
u1
d2
us
di peer i download bandwidth
File, size F
dN
Network (with abundant bandwidth)
uN
91
File distribution time server-client

• Time for the server to send a copy to a single
  client
• F/us
• Time for the server send N copies
• NF/us time
• client i takes F/di time to download

Server
u2
F
d1
u1
d2
us
Network (with abundant bandwidth)
dN
uN
92
File distribution time P2P
Server

• server must send one copy
• F/us time
• client i download time
• F/di
• Total data to be downloaded
• NF

u2
F
d1
u1
d2
us
Network (with abundant bandwidth)
dN
uN

• fastest possible transfer rate us Sui

Can you make a schedule for the download the take
this amount?
93
Server-client vs. P2P example
Client upload rate u, F/u 1 hour, us 10u,
dmin us
Conclusion P2P systems are scalable. But the
load is distributed to all users, so P2P users
have more load than clients in the client-server
model.
94
Peer-to-peer Querying

• While the file is transferred from the peer, how
  to find the file
• Options
• Centralize directory
• Napster
• Single point of failure
• Performance bottleneck
• Target for the RIAA
• Always up
• Easy to find
• Easy protocol
• Query flooding
• Gnutella
• Hosts find other host and form a network of
  neighbors (overlay network)
• Search for a file (covered next)
• How to set up the network bootstrap?
• Have a central list of peers
• Have distributed lists of peers
• Search out a peer by scanning like in project

95
Querying Flooding State Diagram
Inform user of file location
User Request for File
Inform user that query failed
Set AttemptCounter 0
AttemptCounter
AttemptCountergtMaxAttempts
TimergtTO
else
Send out a request for file to all neighbors Set
Timer0
wait
Reply from peer
96
Listening Peer
wait
Request arrives
Have seen request before
Get request ID
Check for file in directory
Send request to all neighbors
File is in local dir
Send response to peer that requested file
97
Expanding ring
98
(hierarchical peer-to-peer network)

• KaZaA
• Not all peers are equal super peers (?)
• Super peers (group leaders) have higher bit-rate
  connections, are more stable, etc.
• Peers connect to group leaders
• The group leaders keep a list of file shared by
  all their children peer.
• group leaders connect to a small number of other
  group leaders
• A child host will ask its group leader for a
  file, if the group leader does not know where it
  is, it will flood the network of group leaders.
  The response from other group leaders follows a
  reverse path to the asking group leader (so other
  leader can cache the response)
• A file is identified with a ID (e.g., MD5) that
  can take a string (file) and come to a unique ID.
  A small change in the file causes a large change
  in the ID. It is not possible to construct two
  files that have the same ID. The ID is a finger
  print.
• Since files are ID-ed, multiple copies of the
  same file can be found and these copies can be
  downloaded from multiple hosts in parallel.
• Note the if you are downloading while other are
  uploading, the uploading slows down the
  downloading, but only a little bit.

99
BitTorrent

• Centralized P2P
• A centralized server, or tracker, tracks the
  clients involved in the P2P transfer
• This is similar to Napster
• Companies that host these site get sued and are
  attacked by DDoS
• Components of BitTorrent System
• Torrent Files
• Trackers
• Seeders
• Peers

100
Torrent File

• Required to download
• Can be found on web sites or sent by email
• Contains information about the file and the
  tracker
• Announce the URL of the tracker
• Creation date
• Info
• Length of file
• Name of file
• Length of each piece (except for the last)
• Pieces the 20B SHA-1 value of each piece
• Note, the number of pieces can be determined
  counting the number of bytes in the pieces field
  and dividing by 20
• If the download contains multiple files, then a
  single torrent file will contain information
  about all files.

101
Tracker

• Make a HTTP Get request to the tracker specifying
  the SHA-1 hash of the file to be downloaded
• The request also includes the number of bytes
  downloaded and the number uploaded
• If the client does not upload enough, the tracker
  might not provide a reply
• The reply contains
• The time when the tracker information should be
  refreshed (usually 30 minutes)
• A list of the peers
• IP address and port (usually 6881)
• Peer ID

102
File distribution with BitTorrent
tracker tracks peers participating in torrent
103
BitTorrent (1)

• file divided into 256KB chunks.
• peer joining torrent
• has no chunks, but will accumulate them over time
• registers with tracker to get list of peers,
  connects to subset of peers (neighbors)
• while downloading, peer uploads chunks to other
  peers.
• peers may come and go
• once peer has entire file, it may (selfishly)
  leave or (altruistically) remain

104
BitTorrent (2)

• Sending Chunks tit-for-tat
• Alice sends chunks to four neighbors currently
  sending her chunks at the highest rate
• re-evaluate top 4 every 10 secs
• every 30 secs randomly select another peer,
  starts sending chunks
• newly chosen peer may join top 4
• optimistically unchoke

• Pulling Chunks
• at any given time, different peers have different
  subsets of file chunks
• periodically, a peer (Alice) asks each neighbor
  for list of chunks that they have.
• Alice sends requests for her missing chunks
• rarest first
• So rarest chunks are spread, and chunks are
  uniformly common

105
BitTorrent Tit-for-tat
(1) Alice optimistically unchokes Bob
(2) Alice becomes one of Bobs top-four
providers Bob reciprocates
(3) Bob becomes one of Alices top-four providers
With higher upload rate, can find better trading
partners get file faster!
106
BitTorrent Pros/Cons

• Centralized server
• Slow to get the transfer started
• Web transfers start much faster and will achieve
  a sustained rate
• Peers must upload
• Some peers might not be in position to upload
  (e.g., mobile phone)
• Chunks can be corrupted
• HBO distributed fake chunks
• Since the SHA-1 hash does not match what is given
  in the Torrent File, the chunk is dropped after
  it is downloaded
• This wastes bandwidth and can greatly increase
  download time
