PHENIX Silicon Endcap Physics

1
PHENIX Silicon Endcap Physics
Open Charm Measurement DgtmX, D?DgtmeX,
D?Dgtm m- X
p-p
A-A
cc??(displaced)X
bb?e/?displaced
B?J/?Xg
Open Beauty Measurement B gt J/ygtmm-
p-A
cc??(displaced)X
bb?e/?displaced
B?J/?X
2
PHENIX Silicon Endcap

• Executive Summary
• Four umbrella stations on each side
• Mini-strips of 50mu 2.2 -13 mm
• Readout via new PHX chip from Fermilab
• Data push via 3 Gigabit optical links
• Total channel count 2 Million channels
• Total chip count 4000 chips

3
Si Vertex - Preliminary Design
Conceptual Integration Design by LANL/Hytec
4
Si Umbrella Layout
Preliminary 7/03

• 50 mu radial pitch (z vertex reconstruction)
• 2816 (2048) mini-strips
• 3.5 cm lt r lt 18 (14) cm
• 48 double towers in phi
• mini-strips from
• 2.2 mm to 13.0 mm
• 2 rows of strips in one
• double tower, readout by one chip series
• 4 half-towers in wedge (later slide)
• 24 wedges in one umbrella
• 2 4 umbrellas ( 22 degree tilt)

r 18.0 cm
r 14.0 cm
r 3.5 cm
1
5
Collaboration with FNAL

• Started to work with Ray Yaremas group
• They did D0 and CDF silicon readout (SVX)
• They developed Btev prototype (FPIX)
• Propose to build PHX, combine technologies
• Did simulations for ministrips
• Produced preliminary chip layout
• Solved readout bus challenge
• Presented at PHENIX Nashville collaboration
  meeting
• Second round of discussions at FEE2003
• Displaced Vertex Trigger
• Propose to use FNAL infrastructure to prototype,
  test and assemble chips and detectors

6
FPIX2 Features

• Advanced mixed analog/digital design
• 128 rows x 22 columns (2816 channels)
• 50 µm x 400 µm pixels
• High speed readout intended for use in Level 1
  trigger. Up to 840 Mbits/sec data output.
• Very low noise
• Excellent threshold matching
• DC coupled input
• Fully programmable device

7
Pixel Cells 50 x 400 um
12 µm bump pads
Preamp
2nd stage disc
Kill/ inject
ADC encoder
Digital interface
ADC
8
FPIX2 Status
Ray Yarema, FNAL, June 9th

• Produced 3168 chips in engineering run
• Minor tweaking of design needed before production
• Mixed analog/digital design has excellent
  performance with insignificant interference and
  cross talk.
• Chip size is 8.96 mm x 10.2 mm (91 mm2)
• Yield is high
• Chip and readout can be used as is in other
  pixel applications

9
FPIX2 noise at C 0is about 60 erms
FPIX2Threshold Distribution_at_ Cin 0 pfis 125
erms
FPIX Measured Performance from Prototype Run
Reminder MIP in 300 mu Silicon gives 24,000
electrons !!!!
10
Pixel/Strip Sizes
Ray Yarema, FNAL, June 9th

• FPIX 50 x 400 um Cin .25 pF
• Phenix 50 x 2000 to 11000 um Cin .2-1.1 pF?
• SVX 50 x 105 to 3x105 um Cin 10-30 pF

Design for Phenix will be optimized for correct
detector capacitance
11
Bits and Pieces for Phenix ChipPHX
Ray Yarema, FNAL, June 9th

• Use modified FPIX2 front end
• Use relaxed bump bonding connections
• Use pipeline and sparcification concepts from
  SVX4
• Use backside contact for ground return (as done
  in SVX4)
• Use slow programming control from FPIX2
• May use modified output drivers from FPIX2
• rather data push from FPIX for trigger
  purposes

12
Ray Yarema, FNAL, June 9th
First Simulations for Phenix at FNAL
Simulated FPIX2 first and second stage response
for detector capacitances from 0 to 2 pF in 0.25
pF steps
13
Possible Layout Diagram for PHX Chip
Ray Yarema, FNAL, June 9th
Bump bonds
Programming interface
1st and 2nd stage and discriminator
Pipeline
Digital interface
14
PHX Chip Layout 2 columns 256
channels/column 3.8 mm x 13 mm 49.4 mm2 Bump
bonds on 200 um pitch 50 µm dia bumps 512 bumps
plus inter-chip bumps for the
bus
FPIX2 Layout for comparison Chip area 91
mm2 Bump bonds on 50 µm pitch 12 µm dia
bumps 2816 bumps
15
PHX Possible Tower Section
Ray Yarema, FNAL, June 9th


Carbon Wedge Support and Cooling
16
Only 2 ½ Silicon Detector types
Outside Detector (II)
Outside Detector (III)
Inside Detector (I)
3 chips 1536 strips
5 chips 2560 strips
6 chips 3072 strips
17
Wedge Assembly Idea
3 mm carbon wedge for assembly and cooling
Reason Eliminate dead silicon areas by
overlapping 1 mm along edges .
18
From Wedges to Umbrellas
X 24
19
Proposed PHX Design Plan
Ray Yarema, FNAL, June 9th

• Build first prototype using multiproject
  submission (40 chips)
• Multiple front end designs
• Use full sparsification and I/O
• Add numerous test points
• Chip size 3.8 mm x 6.5 mm (or full size at
  higher cost to understand IR drops)
• Fabricate Engineering Run with optimized front
  end and final digital design (12 wafers)

20
Production Needs
Ray Yarema, FNAL, June 9th

• 11/8 ships per double tower
• 24 wedges with 2 double towers each
• 1006716 channels north and 1006716 channels south
• 2 Million channels total
• 4000 chips total ? need 6000 tested good chips

21
Production Needs (cont.)
Ray Yarema, FNAL, June 9th

• Useable wafer area 31,416 x .85 26,700 mm2
• Chip size 3.8 x 13 49.4 mm2
• 26,700/49.4 540 chips per wafer
• Assume 75 yield
• Get 405 good chips per wafers
• Need 6000/405 15 wafers
• Typical engineering run delivers 10-12 wafers

22
PHX Schedule
Ray Yarema, FNAL, June 9th

• Design specifications completed 10/03
• Start design 12/03
• Submit prototype 7/04
• Prototype testing completed 12/04
• Redesign completed for engineering run 1/05
• Engineering run back 3/05

23
PHX Cost
Ray Yarema, FNAL, June 9th

• Chip design/testing 2 man-years - 275K
  (includes all overhead costs)
• Prototype chip fabrication- 40K (small chip)
• Test board 5K
• Engineering run (10-12 wafers) 200K
• 5 Extra wafers using same masks - 25K
• Production wafer level testing engineering, tech
  time, circuit board, probe card - 60K
• Contingency tbd

15 wafers total
24
Endcap Summary

• Readout and bus via PHX from Fermilab
• Bump bonded assemblies
• Wedge design
• Umbrella endcap
• Integreation by LANL/Hytec
