Viewshed and Watershed

1
Viewshed and Watershed

• Exercise 7 Background and Process

2
Viewshed

• Viewshed is all cells that can be seen from a
  view point or collection of view points
• By human or animal eyeballs
• By Cell tower radiation
• By microwave radiation
• Use INITIAL and UPDATE to create the target images

3
Watershed

• Watershed is all the cells above a target or
  drain cell that drain water into that cell 2
  methods
• Automatic for entire image by cells
• User-defined from seeds in an image that is 0
  elsewhere
• Use INITIAL and UPDATE to create the seed images

4
VIEWSHED Defined

• Finds all pixels that are in view of a viewpoint
• A viewpoint is any number of pixels that are in
  an image that is otherwise 0 (zero)
• If you have more than one viewpoint what is the
  resulting viewshed?
• All cells viewable from all viewpoints?
• All cells viewable from any viewpoint?
• Thats why you should be careful of more than one
  target cell -- like roads

5
Viewshed parameters

• A DEM (modified for barriers)
• A View Source image the viewpoint(s)
• A Viewer height value the height of the viewers
  eyeball (5 feet?) or the height of an antenna
  above the surface over which the viewshed is
  being run
• A Search distance cant see forever and cell
  phone microwaves only go about 10 miles or so

6
Viewshed What is the surface?

• In our case we are looking at the propagation of
  microwaves over the vegetated surface of Nifkin
• This surface is the DEM plus the average height
  of the vegetation in the area
• Height of vegetation can be based on
• Landuse
• Satellite imagery
• Orthophotos
• The image of vegetation height is called the
  Structural Height

7
Viewshed

• From book
• Area in view
• Area NOT in view
• (this done at higher resolution than indicated
  here!)

8
(A sees B) (B sees A)?
Where would you rather be in a gun fight?
9
Viewer Height

• Tower height e.g. 100 feet
• The viewer height parameter for towers is its
  height ABOVE the vegetation.
• If forest has a height of 40 and the tower is
  100 tall then for viewshed the viewer height is
  60 above the structural surface

Earths surface
40 forest
10
The Dialog

• Structural Surface
• Viewpoint
• Point
• Line
• Area
• Output
• Viewer height
• Distance
• Boolean? Proportional?

11
Basic Process
INITIAL
UPDATE R12C28
12
ViewShed
13
Boolean vs. Proportional
Boolean Any pixel seen by any viewpoint is 1,
rest are 0
14
Water
15
Watershed

• Idea in watershed is to
• find all the cells in a DEM which drain into a
  selected drain
• OR
• Find all the watersheds in the DEM image
• The additional functions are
• Flow calculates flow direction FROM a pixel
• Runoff calculates the accumulation of flow

16
Basins or ArcHydro

• Basins is a Hydrologic modeling system based on
  raster images
• Pit fill
• Watersheds
• Flow direction (Flow in IDRISI)
• Flow accumulation (Runoff in IDRISI)
• Rain drop tracing (Not in IDRISI)
• So these are pretty basic tools for the
  hydrologist and pollution modeler

17
Watershed Automatic

• Does a pit fill automatically
• Finds all the watersheds in a DEM image that are
  enclosed by the image
• That is, their outlets are in the image
• You have to specify the minimum size of
  watersheds to be identified
• Each watershed is given a unique serial

18
Automatic
Watersheds of minimum size 50 pixels
19
Seedy (drain point)
100 pixel sheds
20
Flow
21
Runoff (flow accumulation)
22
Runoff streams?
23
How does watershed work?

• First find the cells which drain into the
  startingdrain
• Next find the cells which drain into the previous
  set of cells which drained into the drain
• And so on until there are no more cells that
  drain, eventually, into the drain!
• For example

24
W
A
T
E
R
S
H
E
D
25
W
A
T
E
R
S
H
E
D
26
W
A
T
E
R
S
H
E
D
27
W
A
T
E
R
S
H
E
D
28
W
A
T
E
R
S
H
E
D
29
W
A
T
E
R
S
H
E
D
30
W
A
T
E
R
S
H
E
D
31
Problems with watershed

• Sometimes you get only ½ of the watershed
• If that happens pick two cells for drains OR pick
  the stream if one available
• The old way to get watersheds was to draw them on
  a Topo map and digitize the vector outlines
  based on height of land
• Now watershed delineation on a DEM is more common
• Despite the fact that both Topo maps and DEMs
  have unknown accuracy!

32
Summary

• Both Viewshed and Watershed functions are in
  common useage
• Best done in a raster system
• Both are based on the accuracy of a DEM and that
  is a problem
• LIDAR is probably the best but costs lots of
• In Exercise 7 you get to use both!
