UIC Data Exchange System Objectives, Data Flow, Challenges

1
UIC Data ExchangeSystem Objectives, Data Flow,
Challenges

• Exchange Network National Meeting
• Marriott New Orleans Convention Center
• New Orleans, LA
• April 25-26, 2007

2
Agenda

• Quick Background
• UIC Program, Business Case for New Data System,
  Status of Development, Project Management
• 2. Proposed UIC System Design
• Design Objectives, System Framework, Data Model,
  End to End Flow thru CDX to Database
• 3. Data Flow In Initial Implementation
  Strategy
• Challenges and Progress

3
Part 1Quick Background UIC Program History,
State Primacy, Status of Development, Project
Management
4
UIC Program History

• UIC Program
• -- Regulated under the Safe Drinking Water Act.
  Regulations issued in 1980
• -- EPA works with states to regulate underground
  injection of fluids to prevent endangerment of
  underground sources of drinking water (USDW).
• -- More than 570,000 injection wells potential
  expansion for new waste streams (e.g., drinking
  water residuals, CO2 sequestration)
• Five UIC well classes
• -- Class I Most strictly regulated. Injection
  of hazardous or municipal waste into deep wells.
  Haz waste wells co-regulated under RCRA.
• -- Class II Brines other fluids associated
  with oil and gas production.
• -- Class III Fluids associated with solution
  mining of minerals
• -- Class IV Haz/rad wastes into or above a
  USDW. Banned in most cases.
• -- Class V Injection into or above USDW.
  Typically shallow systems
• Primacy may be granted to a state for all well
  classes or split by SDWA statutory authority
  (i.e., Section 1422, Section 1425). EPA Regions
  directly implement (DI) for those UIC programs
  not delegated to the states. See next slide.

5
State Primacy
6
Status of Development

• OGWDW made decision to proceed on development of
  new UIC database in June, 2006, based on a
  requirements analysis prepared over 2005 and
  2006.
• The final data model was approved in Nov 2006
  XML schema in testing, to be approved end of
  April, 2007
• An integrated project team (IPT), comprised of
  EPA HQ, Regions, States had 1st biweekly mtg Nov,
  2006.
• EPA is working with 10 states 9 DI Regions to
  map their data into UIC database by initial
  deployment date

7
Status of Development (contd)

• Completed to Date
• Mapping instructions
• XML schema
• Schematron Business Rules
• CDX Node
• UIC Oracle Database
• In Progress
• Integration testing underway
• IPT Pilot Testing 9 Regions, 10 states
• Data Warehouse Reports User Interface Dev
• Target date for initial deployment Aug 31, 2007

8
Project Management
Core Project Management Team Project
Manager Carl B. Reeverts Alternative Project
Manager Trang Le USER Access, Data
Security Towana Dorsey UIC Program Contact Robyn
Delehanty IT Team Leader Abe Siegel Data
Warehouse Team Leader Lee Kyle Associate Branch
chief Leslie Cronkhite, Roy
Simon
Integrated Project Team (proposed)
9
Part 2 Proposed UIC System Design System
Framework, Data Model, End to End flow thru CDX
to database
10
National UIC Database
System Framework
(11/2006 )
Validator
Data Sources site

• OGWDW Management
• 7520 summary info
• UIC PAM Measures
• UIC Inventory Reporting Sys
• SWP/UIC Integration
• Class I Special Needs
• Class V Invent. Initiative
• Congr/GAO/OMB Questions

70 Regional and state databases
XML Doc
(2)
ICIS
FRS
notification
(1)
CDX (XML Doc Repository)
Validator
Data Analysis and Report Generation (Monthly,
Quarterly, Yrly)
Staging Access Database
RCRAInfo
System Integration
Message Reports 1. Invalid data 2. Changes from
last data submission
TRI
Periodic Data Extraction
UIC Database
DWPD Data Warehouse
11
UIC Data Model ERD
12
Part 3Data Flow In Initial Implementation
Strategy
13
Initial Implementation
We are working initially with 10 states 9
Regional DI programs to map their data into the
new UIC database by the initial deployment
date. We have begun discussions through the
Regions and GWPC to reach agreement with all
other states to provide data in subsequent rounds.
State/DI Trading Partners Participating in
Initial Phase In Role of State/DI To be
initial State/DI programs to flow data to new UIC
DB by July 31, 2007 Proposed No. of States/DI
9-15 States, 9 DI Regions Project Period Sept
2006 Jul 31, 2007 Estimated Commitment Per
State/DI .15 FTE

• State/DI Programs (Proposed)
• Round 1 MT, WY, UT, DE, MS, Regions 3, 4, 6,
  7, 8, 9
• Round 2 (still in discussion) MA, FL, GA,
  NC, SC TCEQ, TRRC NE, ND, UT, AK, CA (5 other
  States with Network Exchange grants) Regions 2,
  5, and 10

14
Data Mapping Process

• 1. Agree on data to transfer review mapping
  instructions and agree on data to be transferred.
• 2. Perform logical mapping complete the EPA
  database mapping form.
• 3. Extract source data extract the source data
  and put it in a temporary file or staging tables.
• 4. Convert extracted data convert the source
  data extracted from step 3 to the EPA data
  format, which is defined in the UIC Data Model
  Version 7.5 and the Business Rules document, and
  load the converted data to either an Access
  database, or an XML file that conforms to the UIC
  XML schema.
• 5. Populate XML Data File if choosing step 4a,
  run the EPA XML conversion tool to convert data
  in the Access database into XML file. If
  choosing step 4b, develop and use an XML
  conversion tool.
• 6. Validate XML Data File run the EPA
  validation tool against the XML file and correct
  any invalid entries.

15
Part 4Challenges and Progress
16
Challenges

• Mapping to new database from 70 different State
  and Region databases
• UIC program resources sharply constrained to take
  on new task
• UIC programs and data are located in different
  state agencies, multiple databases or
  spreadsheets or paper files (particularly for
  Class V wells)
• Shift to electronic commerce to flow UIC data to
  EPA is a cultural change requiring unique
  state/EPA solutions

17
Progress

• Reached agreement on single national data model
  to meet well documented business case that
  conforms to EPA data standards
• EPA data needs will be met through mapping from
  existing State data bases.
• Four EPA Exchange Network grants underway and
  another 10 UIC state programs applied for grants
  in 2007.
• Integrated Project Team (IPT) established last
  Nov to guide and support UIC database dev.
• On target for deployment by end of fiscal year.
