F03 48572 Zero Energy House

1
F0348572Zero Energy House

• Lecture 4 The Susquehanna House

2
Goals

• improve flexibility, affordability and quality
• improve energy performance and resource
  utilization and
• improve construction process within the existing
  framework

3
Systems Engineering

• A strong emphasis on
• the definition of the problem,
• the generation and analysis of alternatives and
• the integration of the individual system
  solutions to create the overall system

4
S. Oakland House

• Infill Row House, 1979
• Standard Platform Frame Super Insulation
• Air-based Solar Collector/ Rock Storage
• Night Time Window Insulation

5
(No Transcript)
6
(No Transcript)
7
Sheffield Street Solar Demonstration Project

• Three Infill Row House Buildings, 1981 in
  Manchester Hist. District
• 2 x 6 Platform Frame Super Insulation, Air
  Sealing
• Flat Plate Solar Collector for Domestic Water
  Heating/ Hi- Eff Furnace
• Direct Gain Space (Porch)

8
(No Transcript)
9
(No Transcript)
10
Susquehanna Objectives

• improved unit design
• flexible and adaptable technologies (HVAC,
  plumbing, wiring and interior finish)
• rationalized construction process

11
(No Transcript)
12
Interior Unit Configuration
13
Plan Permutations
14
Pattern Books
15
Exterior Configuration
16
Structure/ Enclosure

• Precast concrete foundation panels
• SIP walls, R-26
• Clear-span, open-web wood joists
• Attic trusses
• Cotton batt insulation
• Vinyl-clad steel siding
• Pella lowE, argon filled windows

17
(No Transcript)
18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
(No Transcript)
23
(No Transcript)
24
(No Transcript)
25
HVAC
26
(No Transcript)
27
(No Transcript)
28
Plumbing
29
Power/ Voice/ Data
30
Interior Systems
31
(No Transcript)
32
(No Transcript)
33
Improved Construction Process

• factory prefabrication field assembly
• wall panels, floor panels, interior finish
  systems and architectural "add-ons".
• elimination of "be-backs
• dis-entangled systems allow trades to complete
  each task w/o interference
• construction waste management

34
(No Transcript)
35
Lessons Learned

• Substantial design modifications were not
  attempted w/ this house but...
• key components are needed to improve spatial
  flexibility
• Demountable partitions
• Movable storage elements.

36
Clear Successes Supporting Design Flexibility

• the panelized foundation/ above grade wall
  systems,
• the clear-span open web floor joists,
• the floor plenums for HVAC distribution and
• the manifold plumbing system.

37
Potential Successes to Support Design Flexibility

• Raceway Power/ Voice/ Data but.
• improvements need to be made
• in the interface to the branch circuit feeds
• in the ability to go around doors/ windows
• in the need to incorporate switches and
• in the number and complexity of pieces in the
  system.

38
Problematic Components and/ or Processes

• the sealing details for the plenum
• the manufacturing tolerances for the foam
  insulated wall panels
• the complexity of the finish carpentry
• the vinyl coated steel siding installation
  process and details

39
Validate Consortium Assumptions w/ Future RD

• Improved affordability
• reduced construction time
• can be finished in stages by the homeowner.
• builder can develop shell in volume and rapidly,
  economically respond to individual preferences

40
Validate Consortium Assumptions w/ Future RD

• Improved energy performance
• high performance components and systems
  integration
• Improved design and construction techniques

41
Validate Consortium Assumptions w/ Future RD

• Improved resource utilization
• Minimize waste through
• improved unit design based on modular principles,

• control of the manufacturing process and
• construction site waste management.

42
(No Transcript)
