Presentation Agenda
Company History Personnel Products Battery Guard
Demonstration Customer Base
Click to continue
3
Company Profile
Intellitec UK is a division of the VIP Group of
Companies (Vehicle Improvement Products).Other
companies in the group include Truckalign Co
Ltd A specialist repairer of commercial
vehicles, Coaches PSVs Established in 1970,
Truckalign are probably the best known chassis
cab repairers in the UK. Compak
Ramps Established in 1999 the Compak brand has
rapidly become the No 1 Selling ramp in the UK
with all major bus operators in London specifying
the Compak Product. VIP Property Established
in 1984, commercial property refurbishment
company, with a number of fully let industrial
estates in the London area. Intellitec MV
Ltd Founded in 1994, Intellitec is a designer,
manufacturer supplier of electrical /
electronic systems to the specialty vehicle
sector.
Click to continue
4
Company Profile
Intellitec MV Ltd was founded in 1994 as a
distributor installer of automotivebattery
power management systems, manufactured by
Intellitec in the USA. See www.intellitec.com In
tellitec USA had developed a system called
Battery Guard for the motorhome RV
sector.Having a lot of experience in the
commercial truck, utility van PSV sector we
knew there was a huge and perennial flat battery
problem. In the year we founded Intellitec, the
biggest single cause of vehicle downtime was
flat batteries. In 2005 the problem is still the
same. Intellitec rapidly became known as the
Battery Guard company with many of the largest
vehicle operators in the UK specifying the
system on new vehicles. In 1995/1996 Intellitec
UK initiated there own RD study to develop
different variations of the Battery Guard ideally
suited to the European vehicle parc. Intellitec
UK signed a technology partnership with
Intellitec USA that would allow both companies to
work jointly on new product development and that
Intellitec MV Ltd would become the sole
exclusive application engineers for Intellitec
products outside of the USA.
Click to continue
5
Company Profile
In 1996 we began to discuss with Intellitec USA
the concept of a Programmable Logic System
specifically for the PSV / Emergency vehicle body
builders. Intellitec USA already had a number of
years experience in multiplex systems i.e. the
Smart Wheel for Paccarr which uses the
proprietary Intellitec protocol. We had a
conceptual system idea by the winter of 1996. We
decided that it would be a good idea to get
bodybuilder / vehicle operator input into our
concept, we arranged to take a number of vehicle
operators and bodybuilders to the Intellitec USA
facility during May 1997. Our concept was
approved by all concerned and Programmable
Multiplex Control was officially launched in
August 1997.
Click to continue
6
Personnel
Technical Director Paul Smith
Sales Director Duncan Hughes
Technical Service Engineer Simon Jeacock
EngineeringManager Lionel Snape
QualityManager Ian Roberts
OperationsManager Andrew Wallis
SalesManager Brian Aston
Export Sales Manager Tony Rodwell
Technician Mark Smith
Logistics Ops. Gordon Willett
Credit Control Sally Barratt
To contact any of the Intellitec team please
click on the name to send an email
Click to continue
7
Demonstration
With over one million Battery Guard systems sold
worldwide Intellitec can justifiably claim to be
the worlds number ONE in vehicle DC power
management.
Battery Guard Demonstration Click Here
Battery Guard Cost Savings Calculator Click Here
Click to continue
8
Products
The standard Battery Guard range is available for
both 12Volt and 24Vvolt applications and can
handle current up to 100A continuous (500 Amps
max) or 200A continuous (1200 Amps max). The
maximum period is for 30 seconds (i.e. cranking
loads). Features include a fully potted module
rated to IP67, and automatic or manual battery
isolation.
Click here for more information
Click here for more information
Click to continue
9
Products
The Tail lift Battery Guard is designed for use
with electro hydraulic power packs such as those
used in tail lifts. The system is installed
within the power pack and constantly monitors
available battery power.

• Key benefits are
• Easy OEM or retrospectiveinstallation to any
  tail lift
• Low Voltage Disconnection of
• tail lift motor to prevent flat battery
• Audible visual warningof impending shut off

Click to continue
10
Products
PSV Battery Guard was designed specifically for
the Bus Coach sector. Most bus chassis have an
electronically switched isolator installed. PSV
Battery Guard fits in series with the chassis
isolator to effect low voltage shutdown.

• Key benefits are
• Constantly monitors battery powerwhen engine is
  NOT running
• Voltage gt 24.1V uniformly for 2 minutes
  audible warning
• Voltage gt 24.1V uniformly for 4 minutes
  automatic isolation guarantee of restarting
  power
• Approved by major Bus Coach manufactures

Click to continue
11
Products
The ability to correctly charge two separate
banks of batteries from a vehicle alternator
system is often thought to be a simple task, in
reality this is rarely the case.. Very often a
simple relay is fitted between the battery banks,
and the alternator is expected to cope with the
subsequent resistance problems between the
battery voltages.The Intellitec Isolator Relay
Delay (IRD) and Battery Isolator Control (BIC)
are specificallydesigned for this application.
Click to continue
12
Products
Vehicle Programmable Logic Control (VPLC) has
been designed to provide a flexible switching and
control unit that is programmable by the
installer to perform a wide variety of functions
including remote switching and signalling. VPLC
has 10 solid state outputs all of which can be
programmed with a windows based program using
boolean logic. In addition the system has the
facility for three hard wired direct inputs, plus
temp input, voltage input again all of which can
be referenced in the software making VPLC a
powerful tool for the special vehicle builder.
Connectable to a 6way programmable switch pad via
multiplex protocol (3 wires).
Click to continue
13
Products
Programmable Multiplex Control (PMC) was designed
specifically for the PSV specialist vehicle
bodybuilder. Modular in design, PMC is becoming
the system mostbody builders are comfortable
with. A system consists of just one Central
Processing Unit (CPU) with 320 channels and a
series of input / output nodes that have been
designed to allow the system designer maximum
flexibility. Each module consists of 10 channels
with a CPU able to control 32 modules i.e. 32 X
10 320 physical channels, with the addition
of160 virtual channels and 160 timers. The
4Khz data transfer protocol used in PMC is
proprietary to Intellitec, this relatively slow
speed protocol allows the use of normal
automotive cable, there is no requirement
for twisted pair or screened cable. The
PMC Windows based software WINPMC package is
based on boolean algebra which is an easy to
understand series of AND OR NOT commands,
coupled with timers, virtual channels and voltage
logic.
Click to continue
14
Products
Central Processing Unit

• Key benefits are
• 320 channels controlling up to 32 physical input
  / output modules
• 160 virtual channels
• 160 timers
• RS232 communication port

Click to continue
15
Products
4 Input / 6 Output - Module 506 / 516

• Key benefits are
• Power switching, fusing and load distribution
  all in one module
• Solid state outputs
• Capable of controlling a total of 50A
• Operation LEDs on all outputs power, comms

Click to continue
16
Products
4 input / 6 self protecting outputs - Module 606
/ 616

• Key benefits are
• Power switching, fusing and loaddistribution all
  in one module
• 6 Solid state and self protecting outputs
• Capable of controlling a total 37A
• Operation LEDs on all outputs, power, comms

Click to continue
17
Products
10 channel output solid state self protected
FET,s - Module 600 / 610

• Key benefits are
• 10 solid state outputs self protected
• 50amps switching capability
• In the event of a short circuit output will
• switch off until short is rectified
• If the module senses a loss of ground
• in the system, as a safety measure the
• output will be switched off completely
• (preventing excessive heat generation)

Click to continue
18
Products
10 output module - Module 320

• Key benefits are
• Low cost output module
• Ten outputs for low wattage loads
• Can be used to drive buzzers, warning lights etc
• All loads are negative switchedto a local load
  earth

Click to continue
19
Products
10 input module - Module 100 / 110

• Key benefits are
• Low cost module designed for reading inputs
• Input connections for rocker, limit,or sensor
  switches
• Inputs can be switched to earth or battery

Click to continue
20
Products
Voltage Monitor - Module 809

• Key benefits are
• Load manager provides4 voltage inputs to the
  system
• Inputs can be used to switch selectedloads off
  according to battery voltage

Click to continue
21
Products
Rocker switch adapter 6 way Module 906 / 916

• Key benefits are
• 6 way rocker switch adapter
• Suitable for SWF, Britax, Carling
• Up to 48 hard wired switch connections
• reduced to only one mate lock plug

Click to continue
22
Products
Rocker switch adapters - Module 909 / 919

• Key benefits are
• 9 way rocker switch input adapter module
• Suitable for SWF, Britax, Carling
• Up to 72 hard wired
• switch connections
• reduced to only one
• mate lock plug

Click to continue
23
Products
Programmable Switch Panels

• Key benefits are
• 6 10 way design
• Backlit by LEDs which are also programmable
• Each switch can control up to 320 functions
• Each switch can have multiple functions
• Switch symbols produced on a standard PC to
• specific customer requirements

Click to continue
24
Products
Diagnostic System Tester Module 739

• Key benefits are
• Used to diagnose I/O and wiring problems on the
  vehicle
• Connects into any moduleover the 3 wire comms
  bus
• Can display status for every I/O in the system
• Outputs can be forced on via the 739 module

Click to continue
25
Products

• Additional modules available in the PMC range
• 4 input / 6 relay outputs - Module 406 / 416
• 10 channel relay outputs Module 410
• System status monitor (view status of all pmc
  channels) Module 738 (click here)
• 6 warning light plug in adaptor Module 806 /
  816 (click here)
• Serial port programming key Part No
  11-00624-110 (click here)
• Serial cable Part No 11-00624-200 (click here)

Click to continue
26
Products
Battery Charger Systems
Intellitec are the exclusive UK application
engineers for the high quality range of Ladac
specialist vehicle chargers. The comprehensive
range covers all vehicle applications and
includes chargers for the marine and wheelchair
markets.
These chargers are designed to be vehicle mounted
and are available to IP67 rating. Ladac are the
major suppliers of chargers for the marine
market with 75 of the worlds Lifeboats fitted
with a Ladac charger. Can accommodate parallel
loads of up to 15A
Click to continue
27
Customer Base
Bus Operators Metroline London First
London London General London Central London
United Docklands Light Railway Lothian
Transport Reading Bus Wilts Dorset East
Yorkshire Traction KMB National Express
Bus Bodybuilders / OEMs MCV Coach
Bus Alexander Dennis East Lancashire
Coachbuilders Mellor Coachcraft Salvedor Caetano
UK Scania Iveco Truck UK Isuzu Trucks UK Volvo
Truck Bus UK
Fire Truck OEMs Saxon Special Vehicles John
Dennis Coachbuilder Emergency One Angloco T.V.A.C.
Click to continue
28
Customer Base continued
Ryder Truck Rental Wincanton Coca-Cola McDonalds
Comet Lex Transfleet British Airways GFS British
Gas Transco Severn Trent Water Woolworths St
Johns Ambulance
West Country Ambulance Metropolitan
Police Sandringham Estate Royal Mail Ratcliff
Tail Lifts Ross Bonnyman Dhollandia Del Tail
Lifts ABP Ports Humber Pilots
Product Locator Guide Click to start
For further details about our company please
visit our web site
Click to continue
