PROJECT PREPARATION Tread Enhancements Module

1
PROJECT PREPARATIONTread Enhancements Module

• Specifying Trail Structures to stabilize/improve
  tread on Trails

2
Objective

• Objective of this topic is to educate those
  preparing projects on
• Trail structures that improves and protects tread
  functionality
• Being able to identify problems
• Prescribing efficient solutions

3
Enhancement Structures

• Puncheon
• Boardwalk
• Fords
• Bridges (discussed in another module)
• Rock Retaining Walls
• Log Retaining Walls
• Post and Plank Retaining Walls

4
Puncheon
5
932-01 Puncheon w/o Decking

• Design variations
• Material options

6
932-2 Puncheon w/ Decking

• Design variations
• Material options

7
Puncheon

• Intended Uses
• Carry trail over wet areas
• Limitations
• Availability of materials to construct
• Native materials have short life span
• Cost and enhancements
• Materials could be costly (treated building
  material)
• Assure that native logs are peeled
• Maintenance
• Need to keep clean of debris to avoid rot
• Assure that approaches do not become step downs

8
Puncheon Under construction, mud sills
9
Puncheon Log decking, unpeeled, span too long,
only two stringers
10
Puncheon Three stringers, peeled log decking
11
Puncheon Split decking
12
Puncheon Old decking with running plank To extend
life, step up approach
13
Puncheon Treated sawn decking, native curb logs
14
Puncheon Native logs with Soil deck, low life
expectancy
15
Puncheon Treated decking, looks good
16
Boardwalk
17
Boardwalk

• Intended Uses
• Carry trail over wet or sensitive areas
• Limitations
• Not appropriate in all ROS classes
• Cost and enhancements
• Costly to install
• Can use materials other than wood
• Maintenance
• Keep clean to prevent rot

18
Boardwalk without handrails, slightly elevated
19
Boardwalk Step and run
20
Constructed Ford
21
912-7 Stream Ford - Rock

• Design variations
• Material options

22
912-7 Stream Ford - Log

• Design variations
• Material options

23
Constructed Ford

• Intended Uses
• Provide safe stream crossings for intended user
  group
• Limitations
• May not be able to be used during certain seasons
  (spring run-off)
• Cost and enhancements
• Relatively cheap to install
• Maintenance
• Need to remove large rocks that could move into
  ford during spring run-off

24
Constructed Fords Minor construction
25
Constructed Fords Stepping stones for hikers
26
Constructed Fords Random crossing logs
27
Constructed Fords Armored approaches
28
Constructed Fords Appropriate? Possible?
29
Rock Retaining Wall
30
935-1 Rock Retaining Wall

• Design variations
• Material options

31
Rock Retaining Wall

• Intended Uses
• To support tread
• Can also be used as rip rap above tread
• Could be used as part of bridge abutments
• Limitations
• Source of rock needs to be within reason distance
• Cost and enhancements
• Could be expensive to build if source of rock is
  not close
• Maintenance
• Minimal maintenance

32
Rock Retaining Wall Supports tread
33
Rock Retaining Wall Supports tread
34
Rock Retaining Wall Supports fill slope
35
Log Retaining Wall
36
934-1 Log Retaining Wall

• Aka. Log Cribbing
• Design variations
• Material options

37
Log Retaining Wall

• Intended Uses
• To support tread
• Could be used as bridge abutment
• Limitations
• Source of building materials
• Should be built of treated boards
• Native materials could have short life span
• Cost and enhancements
• Could be expensive if source of materials is not
  close to building site
• Maintenance
• Periodic inspection to assure soundness of wood

38
Log Retaining Wall Cribbing across old landslide
39
Log Retaining Wall Cribbing across old landslide
40
Log Retaining Wall Cribbing to support bridge
41
Log Retaining Wall Cribbing across
landslide, Wire basket foundation
42
Post Plank Retaining Wall
43
Post Plank Retaining Wall

• Intended Uses
• To support tread
• Limitations
• Relatively short life span
• Use only in appropriate ROS
• Maintenance
• Periodic inspection to assure soundness of boards

44
Post Plank Retaining Wall Probably needs
upslope retaining wall
45
Post Plank Retaining Wall Across rock chute
46
Surfacing
47
941-1 Aggregate Surfacing

• Design variations
• Material options

48
942-1 Asphalt Surfacing

• Design variations
• Material options

49
944-1 Grid Unit Surfacing

• Design variations
• Material options

50
Surfacing

• Intended Uses
• Establish a firm tread by importing suitable
  material (does not include native material)
• Limitations
• Needs to meet ROS and setting (developed/wildernes
  s)
• Cost and enhancements
• Cost depends on the material and transportation
  of material
• Asphalt is costly
• Maintenance
• Depends on type of material but all types must be
  maintained

51
Asphalt Surfacing With treated retainers
52
Aggregate Surfacing With treated retainers
53
Aggregate Surfacing With treated log retainers
54
Aggregate Surfacing Using geoweb
55
Grid Unit Surfacing Very good wear resistance
56
Talus or Rubble Rock Section
57
912-3 Talus Rock Section

• Design variations
• Material options

58
Talus Rock Section

• Intended Uses
• Constructing a trail across a talus slope
• Limitations
• Size of rock can make construction difficult
• Cost and enhancements
• Normally need aggregate or smaller rock for tread
• Maintenance
• Large rocks roll on to tread
• Loss of aggregate in voids between larger rocks

59
Talus Rock Section Under construction
60
Talus Rock Section Finished product
61
Talus Rock Section Finished product
62
Stairs
63
933-2 Crib Ladder Stairway

• Design variations
• Material options

64
933-3 Rock Stairways

• Design variations
• Material options

65
933-5 Log Riser Stairway

• Design variations
• Material options

66
Stairs

• Intended Uses
• Rapid vertical gain over short horizontal
  distance
• Levels tread on steep slopes holds surfacing
  material in place
• Limitations
• ROS must be compatible
• Cost and enhancements
• Maintenance
• Replace surface material as needed
• Ensure water is drained from surface to prevent
  mud holes

67
Stairs Steel angle iron bolted to solid rock
68
Log Staircase With aggregate fill
69
Rock Staircase With handrail and rock retaining
walls
70
Armoring
71
Armoring

• Intended Uses
• Hardening a surface to support the traffic ex.
  Rock at edge of ford
• Covering loose material to help prevent it from
  moving ex. Rock placed on cut or fill
• Limitations
• Suitable material may need to be large
• Cost and enhancements
• Maintenance
• Add armoring material as needed

72
Slope Armoring Wire basket revetment
73
Barriers
74
953-1 Log Barrier

• Design variations
• Material options

75
953-5 Rock Barrier

• Design variations
• Material options

76
Barriers

• Intended Uses
• Passive control of traffic from areas where it is
  not wanted or desirable
• Limitations
• At times may appear obtrusive
• May not work
• Cost and enhancements
• Maintenance
• Replace structures removed by users

77
Barriers Stones are a little small
78
Rock Cairns
79
952-2 Rock Cairn

• Design variations
• Material options

80
Rock Cairns

• Intended Uses
• Reassurance markers in open areas where tread is
  indistinctive or snow covered
• Limitations
• Finding suitable material
• Cost and enhancements
• Depends on availability of suitable material
• Maintenance
• Replace rocks as needed low cost

81
Rock Cairn Appropriate size
82
Signs
83
952-1 Signs and Posts

• Design variations
• Material options

84
Signs

• Intended Uses
• Provide direction and distance to destination
• Identification of improvement (trail) or feature
  (lake)
• Map of trail system
• Provide general information
• Limitations
• Suitability of material compatible with ROS
• People like to take them home
• Cost and enhancements
• Metal signs more expensive than wood
• Maintenance
• Damage from firearms, animals, weather, wildfire

85
Trail Signs Good example
86
Lower sign states trail not maintained
87
Trail Signs
88
Pertainate Information?
89
Information unreadable
90
Shape of sign make these three identifiable
91
Trail Signs
92
Tree used for post
93
Wood Post
94
Older metal strip attached to wood board
95
Trail Signs
96
Trail Signs
97
Only one of these signs Is readable. It is so
high And the letters so small No one can read it.
98
How visible is this sign?
99
Trail Signs
100
Trail Signs
101
Trail Signs
102
End Tread Enhancements
