Detecting ICMP RateLimiting

1
Detecting ICMP Rate-Limiting

• Les Cottrell
• Warren Matthews
• Mit Shah

2
Motivation 1

• Smurf Attacks IP spoofing and ICMP packets to
  an IP Broadcast group. Traffic to target
  multiplied by responses from each member
• Example Attacker on 768Kbps stream and a 100
  member Broadcast group generate 77Mbps of
  traffic and swamp target!
• Routers set to no ip directed-broadcast

3
Motivation 2

• Cisco introduces CAR (Committed Access Rate) in
  7200 and 7500 series routers. Later includes
  support in IOS 12.0
• access-list 102 permit icmp any any echo
• interface Serial3/0/0 rate-limit input
  access-group 102 256000 8000 8000 conform-action
  transmit exceed-option drop

4
ICMP Blocking - No Response!

• www.vincy.bg.ac.yu blocked 884 rounds of 10 ICMP
  packets each, out of 903
• islamabad-server2.comsats.net.pk blocked 554 out
  of 903 rounds
• leonis.nus.edu.sg blocked all packets it was sent
  (All examples from data for Dec 1999)
• Yet in reality, none of these servers was down!

5
New tools to the rescue

• SYNACK developed in-house
• Establishes TCP connections and measures time
  taken by target to respond
• Cleans up connections
• Highly visible to system admins

• STING developed by Stefan Savage
• TCP cant ack out-of-order packets
• Data-seeding and Hole-filling (reliable)
• Need to change one line of kernel code

6
Results from Sting Synack

• Both tools based on TCP/IP, hence appear to
  router to be normal traffic
• Results
• The Singapore node responds ONLY to 568 byte
  packets
• Both the other nodes were alive-and-kicking with
  low loss rates!

7
Utility of Sting as an aid

• These are 5 sites that were responding to pings
  very infrequently, and neglecting entire sets of
  10 pings more than 50 of the time
• Sting showed that they were alive on port 80!

8
Tail-Drop Behavior

• Rate-limiting kicks in after the first few
  packets and hence later packets are more likely
  to be dropped
• This node no longer displays tail-drop behavior!

9
Frequency Analysis

• Calculate the packet drops as a function of
  packet-numbers
• Calculate the slope and identify extremes
• Implemented by Warren as a metric
• Some encouraging early results!

10
Some Candidates
11
CAR (Committed Access Rate)

• Tokens removed in proportion to size of packet
• Maximum number of tokens in bucket Normal Burst
  Size
• Extended Burst mechanism to make drops more
  RED-like

12
RED (Random Early Detection)

• Tail-drop causes packet-loss across all TCP
  streams when traffic is too heavy
• Causes all TCP-streams to sense congestion and
  start recovery
• Small, bursty TCP streams also have to restart
• Solution drop packets randomly BEFORE
  congestion strikes!

13
Extended Burst Mechanism in CAR

• Stream allowed to borrow more tokens if
  extended-burst value gt normal-burst
• Compounded debt computed as sum of a(j) where
  j denotes the jth packet that tries to borrow
  tokens since last packet drop and a(j) denotes
  actual debt value
• Packet dropped if CD gt extended-burst and CD set
  to 0

14
Detecting CAR the good news

• A stream at constant rate R, above the
  configured-rate C, will exhaust tokens in bucket
  after B/(R-C) sec, at most
• From this point on, borrowed packets at jth
  packet j(R-C) and beyond jE/(R-C), actual
  debt gt extended-burst and all packets will be
  dropped
• Pattern is non-random!

15
Detecting CAR A trial

• Analyzed the first-order differences in
  packet-numbers of dropped packets to see if there
  was a pattern hoping that site-specific CAR might
  have set packet-size gt normal_burst_size
  extended_burst_size
• Not surprisingly, no results
• False alarm 10th packet being dropped but data
  was TOO clean!

16
Detecting CAR the bad news

• It appears that most sites will impose a
  traffic-limit on TOTAL icmp traffic
• Predicting when a packet drop occurs akin to
  predicting the rest of the traffic on that router
  at that moment - a known hard problem!
• Solution Aggressive pinging, your
  traffic-stream dominates! High signal-to-noise!!!

17
Further study

• Pinging with variable-sized packets (less than
  MTU) and detect whether packet-loss varies
  linearly with size
• trivial to determine MTU?
• How important are other effects like being more
  likely to be dropped from queue?
• Set up a router that implements CAR, simulate
  icmp traffic, and study patterns
