MULTIENGINE

1
MULTIENGINE AERODYNAMICS
By Diego M. Alfonso
2
(No Transcript)
3
DISCLAIMER JUST IN CASE WE MAY HAVE A DIFFERENCE
OF OPINION, ALL THE INFORMATION USED FOR THIS
PRESENTATION HAS BEEN OBTAINED FROM THE FOLLOWING
FAA PUBLICATIONS AC61-21A, FAA-8083-3 AC61-23C,
AIM, FARS AND THE PRACTICAL TEST STANDARDS
BOOKLETS. P.T.S.
4
IT HAS NOTHING TO DO WITH WHAT I LIKE OR WHAT I
THINK IT SHOULD BE DONE.
5
DEMONSTRATING THE EFFECTS OF VARIOUS AIRSPEEDS
AND CONFIGURATIONS DURING ENGINE INOPERATIVE
PERFORMANCE
6
TWO PROCEDURES
7
VYSE AND DRAG DEMO
8
WHY DO WE HAVE TO PERFORM VYSE AND DRAG DEMO?
9
AS IN ALL MANEUVERS WE DEVELOP
KNOWLEDGE
PLANNING
TIMING
COORDINATION
ASSOCIATING WHAT HAS BEEN LEARNED, UNDERSTOOD AND
APPLIED WITH PREVIOUS OR SUBSEQUENT LEARNING
10
I FIND THIS IS ONE OF THOSE MANEUVERS THAT IS
PERFORMED MECHANICALLY. WITH NO IDEA OF WHY WE
ARE DOING IT?
11
Objective OF VYSE DEMO
12
To determine that the applicant 1.
Exhibits knowledge of the elements related to the
effects of various airspeeds and configurations
during engine inoperative performance by
describing -
13
(a) selection of proper altitude for the
demonstration.
NOT NECESSARILY 3,000
14
(b) proper entry procedure to include pitch
attitude, bank attitude, and airspeed.
15
(c) effects on performance of airspeed changes
at, above, and below VYSE-
16
WHAT IS THE INTENT OF EXPERIMENTING WITH LOWER OR
HIGHER AIRSPEEDS?
17
THE PROGRAMMING IS TO EMPHASIZE AIRSPEED NOT
ALTITUDE
18
WHY 10 KNOTS ABOVE AND BELOW VYSE?
19
IT IS NOT TO SHOW THAT THE AIRPLANE WILL NOT
PERFORM SATISFACTORILY ABOVE OR BELOW BLUE LINE.
20
(No Transcript)
21
(No Transcript)
22
(No Transcript)
23
YOU ARE NEVER GOING TO OBTAIN THE PUBLISHED BEST
SINGLE ENGINE CLIMB PERFORMANCE AT BLUE LINE
UNLESS YOU ARE AT SEA LEVEL ON A STANDARD DAY.
24
KNOWN FACT
VYSE DECREASES WITH ALTITUDE
25
THEN THERE IS ANOTHER QUESTION
IS THE AIRSPEED INDICATOR ACCURATE?
26
HOW WILL THIS MANEUVER HELP US IN THE EVENT OF AN
ENGINE FAILURE?
27
THERE ARE ACTUALLY THREE PHASES TO THE RESPONSE
OF AN ENGINE FAILURE
28
ESTABLISH INITIAL CONTROLLABILITY AND PERFORMANCE
29
PART ONE
BLUE LINE
DIRECTIONAL CONTROL
INITIAL ZERO SIDE SLIP
30
PART TWO
TAKEOFF POWER UP CLEAN UP IDENTIFY VERIFY FE
ATHER
ENROUTE POWER UP CLEAN UP IDENTIFY VERIFY FI
X UP FEATHER
31
PART THREE
ESTABLISH BEST PERFORMANCE
32
HOW DO WE KNOW WE ARE GETTING THE
MOST PERFORMANCE DURING SINGLE ENGINE OPERATION?
33
MAXIMUM AVAILABLE POWER
NO UNNECESSARY DRAG
STRAIGHT FLIGHT
ACTUAL VYSE
ZERO SIDE SLIP
34
THE SIDE SLIP
35
STRAIGHT AND LEVEL FLIGHT
36
CLIMBING FLIGHT
37
X
ENGINE FAILURE
38
Relative Wind
X
ENGINE FAILURE
39
EFFECTS OF THE SIDE SLIP
40
(No Transcript)
41
Eliminating the Side Slip
42
X
ELIMINATING THE SIDE SLIP
43
X
ELIMINATING THE SIDE SLIP
44
IS ZERO SIDE SLIP COORDINATED OR UNCOORDINATED
FLIGHT
45
YES IT IS PERFECTLY SAFE TO TURN TOWARDS THE
INOPERATIVE ENGINE.
46
X
MUST MAINTAIN VYSE AND ZERO SIDE SLIP
47
WHY ARE WE DESCENDING?
48
YES WE CAN SLIP TO A LANDING IN A MULTIENGINE
AIRPLANE WITH ONE ENGINE INOPERATIVE
49
REALISTIC SCENARIOS
ENGINE FAILURE ON IFR DEPARTURE
ENGINE FAILURE ON A GO AROUND WITH FLAPS AND GEAR
DOWN
50
VMC
51
(No Transcript)
52
(No Transcript)
53
SPIRALING SLIPSTREAM
54
TYPICAL AIRPLANE VYSE 94 MPH
55
VYSE 94 MPH
137 PER SECOND
27 IN 1/5 OF A SEC.
AZTEC C
56
4
57
REACTION TO TORQUE
58
WE HAVE TRAINED FOR TOO LONG AT A DENSITY
ALTITUDE THAT WILL ALLOW THE AIRPLANE TO MAINTAIN
ALTITUDE
ARE WE ABOVE THE SINGLE ENGINE ABSOLUTE CEILING?
DURING TRAINING THE AIRCRAFT IS LIGHT AND IT MAY
PERFORM
