Implementing Complex Algorithms in FPGAs

1
Implementing Complex Algorithms in FPGAs
Workshop Dr Steve Chappell
Director Apps Engineering
2
Workshop Materials

• For the Labs
• Course Workbook, Tutorials and Application Notes
• DK integrated help system
• On your Workstations
• DK, PDK
• Target Platforms
• RC100, RC1000

3
Contents

• Introductions
• About Celoxica
• The Basics
• Opportunities with a HW Coprocessor
• Target Boards
• Design Flows DK and Handel-C in brief
• Handel-C Language
• Tool Connectivity
• Platform Developers Kit
• Platform Abstraction
• Codesign
• Appendices
• Technology, Applications, CUP

Lab1
Lab2
Labs3,4
4
About Celoxica

• System EDA company
• Design Tools, FPGA Boards, Consultancy and
  Services
• Incorporated on the 25th September 2000 (Formerly
  ESL)
• Market leader in complete solutions for
  software-compiled system design
• Core Technology is DK incorporating the Handel-C
  programming language
• A senior management wealth of EDA and electronics
  industry experience
• Industry leading partners
• Strong Links with Research Development
• Technology and expertise based upon decades of
  research into state-of-the-art at The University
  of Oxford
• Chief Science Officer Ian Page, visiting
  Professor at the Imperial College of Science,
  Technology Medicine, London
• Established and active University Program (700
  institutions world-wide)
• Investors
• Premier league investors including

Intel
5
Supporting Argonne

• Augmented Cluster supplied by Linux Networks
• Incorporating Tarari CPP cards and Software
  drivers
• Celoxica Development Kit for FPGA content
• Ensuring successful deployment and evaluation
• Cluster support by Linux Networks
• Augmented Application and CPP card support by
  Celoxica

6
The Basics

• Opportunities and Challenges
• Essence of an FPGA
• Design Flows

7
Opportunities with a HW Co-processor

• Algorithm Acceleration
• Exploit the parallelism in algorithms to increase
  performance with implementation in custom
  (parallel) hardware
• Algorithm Offload
• Exploit the coprocessor to free CPU resource
• e.g., in an SSL proxy, the CPU can always handle
  more TCP traffic if algorithms such as RSA and
  3DES are moved to a coprocessor
• For PCI-based coprocessor cards candidate
  algorithms include ones where CPU execution time
  far exceeds data transfer time over PCI
• Full analysis needs to consider
• Time required to perform the algorithm in the
  Co-processor
• System application performance improvement
  Amdahls Law

8
Opportunities with FPGAs

• FPGA architecture
• What it means for applications
• Soft Hardware
• Reconfigurability/Programmability
• Integer processors (FP is resource expensive)
• Wide data paths
• Parallel Computation
• Challenges to deployment in enterprise computing
• Development complexity
• IP deployment and integration
• Design Framework and methods
• Data Bandwidth to/from coprocessor
• Choosing the right applications

9
Essence of an FPGA
gt SRAM Field Programmable Gate Array
CLBsIOBsInterconnect Matrix
10
Target Boards

• RC100, RC1000, RC2000 Tarari CPP

11
RC-100

• Xilinx Spartan2-200 FPGA
• 2MB ZBT SRAM, in 2 36-bit banks. 8MB Flash RAM
• 50 pin expansion header, PS/2 mouse/keyboard,
  parallel port
• Video input decoder, VGA output DAC
• Two 7-segment LED displays
• 80MHz maximum clock

12
RC-1000

• PCI card, DMA transfers gt 110 MB/sec sustained
• Xilinx Virtex-2000 FPGA
• 8MB SRAM, in 4 32-bit banks
• 2 PMC slots
• 50 auxiliary I/O pins
• Programmable clock

13
RC-1000
13
14
RC-2000

• Virtex II 2V3000-4, 2V6000-4 and 2V6000-6 FPGAs
• 64bit 66MHz PCI bus
• 6 banks of ZBT SRAM offering a total of either
  12Mb or 24Mb
• Front-panel I/O up to 146 lines, dependant on
  options
• 64 I/O lines via PMC connector
• 16Mb Flash for configuration storage
• 2 Programmable clocks
• Options include
• 16Mb additional ZBT SRAM in 2 banks
• 128Mb DDR Ram

15
RC-2000
15
16
CPP Basic Board Architecture

• Two CPEs Content Processing Engines
• Virtex-II 1000 FPGA
• Eight LEDs
• 2x 1MB SRAM
• Connection to CPC
• CPC Content Processing Controller
• 256MB DDR SDRAM
• PCI Bus to Host

17
Design Flows

• DK and Handel-C

18
Designing acceleration IP

• Traditional Options HDL based design
• Purchase FPGA (HW) development tools
• Hire/use HW engineers
• Pay 3rd Party development fees
• The Alternative Software Compiled System
  Design
• Use Celoxica Content Processing Development Kit
• Development framework with Example Acceleration
  IP
• Comprehensive Hardware-Software Co-simulation
  environment
• Tool and Language Connectivity
• Enable SW engineers and/or increase HW engineer
  productivity

19
Why a Software Language Based Approach for System
Design?

• Some problems are better expressed as a software
  algorithm
• Software Reference designs can be utilized
• Designs are often specified by a C/C executable
• Simplifies and delays hardware-software
  partitioning
• Software development techniques can be used
• Brings hardware and software teams closer
  together
• New Possibilities

20
RC100

• RC100 prototyping board
• 10 FPGA
• Commodity memory chips
• Video Input and Output

1
21
RC100

• RC100 prototyping board
• 10 FPGA
• Commodity memory chips
• Video Input and Output

2
22
CPDK for developing acceleration IP

• The Content Processing Development Kit includes
• Celoxica DK and supporting libraries
• Consisting of
• Software Compiled System Design environment
• Simple design flow with integrated Simulation and
  direct implementation
• Similar SW/HW design methods simplifies design
  exploration and optimal allocation of
  functionality between SW and HW
• Verification and Debug using a Symbolic Debugger
• Connectivity and co-simulation with SW and HDL
  cores
• APIs to hide complexity
• Enabling your software and hardware developers
• To rapidly develop acceleration IP

23
Celoxica DK1 Rapid Design

• Handel-C direct to FPGA, Minimum Tool Chain
• Easy-to-learn language ISO-C (ANSI-C)
• Design of hardware and software in parallel with
  co-simulation

Simulate
Handel-C
Compile
Final Hardware
Netlist
Configure
24
Supported FPGA/PLD Devices
25
Development Flow
Specification

Algorithm Definition
LIBS
SW Tool
DK
C
Handel-C
HW
SW
Partition
BSP
BSP
OS
Develop
HLL Co-Verification
Implementation
HDL
C
EDIF
LIB
Compile
EDIF
OBJ
Host CPU
CPP
26
APIs Enable Rapid Co-verification
Specification

DK
Nexus
C
Handel-C
HW
SW
BSP
BSP


HDL-Simulator
SW and/or ISS
Virtual Platform
Implementation

• Virtual Platform for Co-simulation and
  Co-design
• Cycle-accurate HLL simulator for Acceleration IP
  modelling
• Extendable Co-Sim to C/C, HDL, System-C, ISS

27
DK User Interface
Simulate
Build
Syntax highlighting
Break-points Multithreaded Debug
File view
Symbol view
Watch variables
Clock Cycles
Info
28
Handel-C in Brief

• Handel-C is based on ANSI C
• Well-defined semantics similar to
  OCCAM/CSP
• Additions
• support for parallelism
• channels for communications between parallel
  processes
• operators for detailed control of hardware
• constructs for RAM, ROM, interfacing, etc.

29
HW-SW Co-Design
30
Handel-C Language
31
Core Language Features

• Standard C (if, while, switch etc) including
• Functions
• Structures
• Pointers
• par construct for parallelism
• Simple model of timing
• each assignment is one clock cycle
• Arbitrary widths on variables
• Enhanced bit manipulation operators
• Sharing/Copying expressions
• Support for hardware constructs
• Multiple clock domains, RAM, ROM, external
  interfaces

32
Handel-C describes Hardware!

• No side effects in expressions
• i.e. statements like a bc are not supported
• No floating point
• Floating point not directly supported by
  Handel-C.
• Library support provided for fixed and floating
  point arithmetic
• No run-time recursion
• Due to the absence of any kind of call stack in
  hardware.
• Limited standard library (i.e. no printf, fopen
  etc.)
• However, DK1.1 allows direct calls to external
  functions written in C/C, and these could
  incorporate file I/O, user interaction,
  recursion, etc.

33
Variables

• Handel-C has one basic type - integer
• May be signed or unsigned
• Can be any width, not limited to 8, 16, 32 etc.

Variables are mapped to hardware registers.
34
Bit Manipulation Operators

• Extra operators have been added to allow more
  hardware like bit manipulation

ltlt Shift Left b altlt2 gtgt Shift Right b
agtgt1 lt- Take least significant bits b
alt-5 \\ Drop least significant bits b a\\5 _at_
Concatenate bits b a_at_c Bit
Selection b a41
35
Example Bit Manipulation
36
Bit Manipulation 2

• Other bit manipulation examples

signed int 4 a signed b,c,d a 0b1100 b
altlt1 // b 0b1000 b agtgt1 // b
0b1110 c a21 // c 0b10 c alt-2 // c
0b00 c a\\2 // c 0b11 d a _at_ a // d
0b11001100
37
Timing model

• Assignments and delay statements take 1 clock
  cycle
• Combinatorial Expressions computed between clock
  edges
• Most complex expression determines clock period
• Example takes 1n cycles (n is number of
  iterations)

index 0 // 1 Cycle while
(index lt length) if(tableindex
key) foundindex // 1 Cycle else index
index1 // 1 Cycle
38
Parallelism

• Handel-C blocks are by default sequential
• par executes statements in parallel
• par block completes when all statements complete
• Time for block is time for longest statement
• Can nest sequential blocks in par blocks

39
More Parallelism

• Example array initialisation
• Sequential version takes 20 clock cycles
• for() loop has 1 cycle overhead for increment
• Parallel version takes 1 clock cycle
• Replicated par() builds hardware to execute
  all 20 iterations in a single cycle
• Allows trade-off between hardware size and
  performance

40
Channels

• Allow communication and synchronisation between
  two parallel branches
• Semantics based on CSP unbuffered (synchronous)
  send and receive
• Declaration
• Specifies data type to be communicated

41
Sharing Hardware for Expressions

• Functions provide a means of sharing hardware for
  expressions
• By default, compiler generates separate hardware
  for each expression
• Hardware is idle when control flow is elsewhere
  in the program
• Hardware function body is shared among call sites

x xa b y yc d
int mult_add(int z,c1,c2) return zc1 c2
x mult_add(x,a,b) y
mult_add(y,c,d)
42
Replicating Hardware for Expressions

• Inline Functions are expanded at the call site
• Provide for functional abstraction of complex
  hardware

inline complex mult_complex(complex
x,y) complex z par z.re x.rey.re
x.imy.im z.im x.rey.im
x.imy.re return z complex
x1,y1,x2,y2,z1,z2 par z1
mult_complex(x1,y1) z2 mult_complex(x2,y2)

43
Macro procedures

• macro proc is similar to an inline function, but
  is expanded at compile time.
• They also allow for arbitrary bit width
  calculations
• The following generates a reusable timer

macro proc usleep(ms) define TENTH_SEC
CLOCK_RATE/10 unsigned (log2ceil(TENTH_SEC))
Counter Counter TENTH_SEC (0_at_ms)
while (Counter) Counter--
44
Signals

• A signal behaves like a wire - takes the value
  assigned to it but only for that clock cycle.
• The value can be read back during the same clock
  cycle.
• The signal can also be given a default value.

45
Interfaces - Introduction

• Interfaces allow Handel-C designs to connect to
  external hardware and logic.
• Three types of interfaces
• Buses used for connecting to external pins
• Ports used for creating connection points for
  external logic.
• e.g. Creating the ports for a VHDL entity
• User Defined used for including external logic
  blocks inside a Handel-C design.
• e.g. Including an EDIF black box inside a deign.

46
Interfaces Buses

• Makes connections to pins on the FPGA.
• Bus types
• Output
• Input direct, clocked and latched input
• Tri-state direct, clocked and latched tri-state

interface bus_in(int 4) Address() with
dataP1,P2,P3,P4 xAddress.in
47
Interfaces Ports

• Allows connection points for external logic to be
  specified. e.g. Defining the ports for a black
  box VHDL entity
• Port types Input, Output

//Declare Ports interface port_in(int 4 Input1)
InputPort1() interface port_in(int 4 Input2)
InputPort2() interface port_out() OutputPort(int
4 Output OutReg)
48
Interfaces User Defined

• Allows external logic blocks to be used inside a
  Handel-C design. e.g. Using an EDIF core.

//Instantiate connections to core interface
pipe_mult(int 4 Result) Multiplier( int 4 A, int
4 B)
49
Multiple Clock Domains - example
Domain1.c
Domain2.c
50
Handel-C Summary

• Handel-C is based on ANSI C
• Well-defined semantics similar to OCCAM/CSP
• Additions
• support for parallelism
• channels for communications between parallel
  processes
• operators for detailed control of hardware
• constructs for RAM, ROM, interfacing, etc.

51
Lab 1

• Quick Start DK1, Handel-C and the RC100

52
Tool Connectivity

• The Whole Y-Chart

53
Tool Connectivity
Co-Simulation HDL Implementation
RTOS / ISS
54
Black Boxes - Xilinx CoreGen
55
Co-Simulation with HDL
55
56
Co-Simulation with ISS
57
HW-SW Co-Simulation Virtual Platforms
58
MatLab Simulink
dll
Filter.hcc
Sfunc.cpp
59
Co-Simulation with System-C
60
Lab 2

• Advanced Features

61
PDK Platform Dev Kit

• PDK, PAL and DSM

62
Introduction to PDK

• PDK Platform Developers Kit
• Goal to provide an integrated package of tools,
  support libraries and implementations to simplify
  application development and verification using
  DK1
• Insulate developer from hardware details
• Improve portability and maintainability
• Provide key pre-packaged valueadding
  functionality
• Allow simulation of the complete environment from
  modelling through to hardware implementation
• Benefits
• Reduce development time
• Allow development focus on application added
  value

63
Introduction to PDK

• PDK Three major components
• DSM
• Integration between processors and FPGA/PLD
• PAL
• A consistent API for portable board-level
  Handel-C implementations
• PSL
• Provides board, hardware or development tool
  specific support for DK1 and Handel-C

64
Introduction to PDK

• Each PDK component provides four functional
  areas
• Simulation
• Provides hardware independent simulation of DSM
  and PAL APIs and co-simulation with external
  tools and simulators
• Kit
• Provides key components and/or templates to allow
  development of new, platform specific,
  implementations
• Platform
• Platform specific implementations of DSM, PAL and
  PSL components
• Cores
• Implementations of added-value functionality,
  demos or examples

65
Platform Abstraction Layer (PAL)
Handel-C Application
PAL-Core
Platform Abstraction Layer Application
Programming Interface
Platform Support Library (PSL)
Board
Peripheral 1
Peripheral 2
66
DSM Data Stream Manager
67
Labs 3 and 4

• PDK
• PAL and DSM

68
Summary

• High performance gains with HW acceleration cards
• For appropriate algorithms
• Development kit enabling rapid design using a
  software-like development framework
• Celoxica DK and Handel-C
• Consultancy and Services
• For More gt www.celoxica.com

69
CPDK for the Tarari CPP
70
Development Framework Stack
APP(S)
Host CPU
Agent Device Driver(s)
Base Driver
SW
SW Tool
DK Tool
HW BSP
HW
AGENT(S)
Dev Kit - Examples - Supplied Base Driver/HW BSP
71
HW Development in DK
1MB SRAM
256MB DDR
CPP.hcl
CPP_ZBT
BSP and API calls
CPC
AGENT(S)
Handel-C APP
CPP_LED
8x LED
CPP_SAI CPP_ABI
CPP_ZBT
PCI
1MB SRAM
72
Appendices

• Technology Behind DK
• Consultancy, Services, Projects
• Case studies
• University Programme

73
The Technology Behind DK
74
The Technology Behind DK

• Simple Hardware constructs
• Compilation Flow
• Optimisations

75
The Hardware Description

• Data Path
• Circuitry to Move/Manipulate/Store Data
• Control Path
• Circuitry to schedule operations

76
Control and Assignment

• Variables are mapped to hardware registers
• The control start signal forms the clock enable
  signal for the destination register of the
  assignment.

void main(void) RExp
77
The IF Construct

void main(void) if BE
S1 else
S2
78
Sequential Composition

void main(void) S1 S2 S3
79
Parallel Composition

void main(void) par S1 S2 S3

80
Compilation Flow - Optimisations

• Generate AST from Source code
• Macro Expansion
• Width Inferencing
• Design Checking
• Compilation to High Level Netlist
• Expansion to technology specific netlist

81
Re-Writing

• Logical equivalence
• (a) Constant 1 input to AND Gate removed
• (b) Gate removed with unused output
• (c) Block removed with unused output

82
Conditional Re-Writing

• Logical equivalence by testing for impossible
  Conditions
• Gates removed for circuit with output independent
  of y

83
Common Sub-Expression Elimination

• Test for common logic
• Duplicate AND gate removed

84
DK1 Optimisation Settings
85
Customer Highlights

• Consultancy, Services, Projects
• Case studies

86
Celoxica Expertise

• Technical Strengths
• Design Methodologies and Hardware Compiler
  technology
• FPGA board design and prototyping
• Image, Data processing and Multimedia
• Encryption
• Compression/Decompression
• Video Processing
• Telecommunications
• Routers/Switches
• Protocol stacks IPv6, VoIP (H323, SIP), ATM
• Software defined radio UMTS, 3G, DAB
• Business Consultancy
• Analysis, Marketing and Strategy
• Venture capital
• Services and Support

87
Marconi Celoxica Technology Demonstrator

• Internet Reconfigurable Hardware from Software
• FPGA based, no microprocessor or operating system
• Different applications from the same hardware
• Can be reconfigured over internet to new
  applications
• MMT 2000
• IP Phone
• MP3 player
• Games console
• Graphic display

88
High Speed Video Prototyping System

• Customer Requirement
• to shorten the evaluation time of video filter
  algorithms as candidates for use in DTVB
• Solution
• FPGA-based system comprising
• Wealth of analogue and digital video I/O
• COTS boards and custom
• Development kit DK and Video framework libraries
  (SW/HW)
• Outcome
• Real-time evaluation system rather than slow
  software models
• Algorithm Evaluation times reduced from 12 to 3-6
  months
• Prototypes for ASIC process rather than software
  models

89
EuroSkyWay Multimedia Satellite Ground Traffic
Simulator

• for system verification and end-to-end perf.
  testing
• generation of total network traffic (ATM, IP)
• full implementation of ESW protocols (layer
  1/2/3)
• digital baseband transmission

• Services 512, 2048 kb/s, 8...32 Mb/s (provider)
• fixed and mobile users (aircraft, busses,
  vessels)
• service launch in 2004

90
JPEG2000 MQ encoder implementation

• SCSD version
• Slices 1,999
• Device utilization 18
• Speed (MHz) 115.5
• Lines of code 330
• Design time (days) 10 2
• Av cycles per code block (000s) 108
• Processing time (ms) 0.939
• Simulation time for Lena jpeg 5 minutes

Xilinx Virtex
Wind River SBC405 GP

• Traditional HDL Implementation
• Slices 620
• Device utilization 6
• Speed (MHz) 76
• Lines of code 800
• Design time (days) 30
• Av cycles per code block (000s) 67.5
• Processing time (ms) 0.888
• Simulation time for Lena jpeg XXX

IBM Power PC
Proteus FPGA daughter card
91
Customer highlights
"The DK1 suite enables us to work at a high
level, quickly optimise C code for hardware
implementation, prototype using FPGAs and will
ultimately provide the HDL output for our ASIC
design. Shigeru Kawada, General Manager, NEC
Electronics Singapore's technology centre
"The real value of the Celoxica tools is the
quick re- engineering capability and
smooth transfer to a production platform. The DK1
methodology allows us to accomplish tasks in a
time frame that conventional design methods
cannot handle. Dennis Hazel, Director of
Engineering, Foxboro
"Our evaluation of DK1 clearly demonstrated that
the flow increases our engineering throughput,
and allows us to make better use of our scarce
hardware engineering resources. Using Celoxica's
Handel-C to hardware flow, our software engineers
can take a software solution through to hardware
allowing the hardware designer to focus on system
integration and optimisation." Andy Davey,
senior engineer at Cogent Defence Systems
A new joint development team to create powerful,
flexible and scaleable application specific
servers was announced today. Celoxica Ltd,
Motorola and StrongBow Technologies are working
together to create servers that embed
applications, such as transaction processing for
credit cards, directly in hardware Without
Celoxicas tools, this would not have been
possible, Alan Prouse, CEO and founder of
StrongBow Technologies.
Our original project plan was slated for 12-18
months using the traditional HDL design
methodology. By adopting the Handel-C high
level design language methodology, we were able
to finish the project in 6 months with DK1 design
suite and Xilinx ISE software targeting Xilinx
VII-6000 FPGAs. We put in minimum development
resource, but still met the design specification,
timing far ahead of the schedule. Anyone can use
the DK1 design suite to design efficient
hardware. Gary Mallaley, Manager of Strategy
Development at Northrop Grumman.
I visited Celoxica's headquarters. While there, I
re-implemented our existing VHDL solution using
the DK1 suite in just one day. I was hooked. Jan
Mennekens, chief technical officer M-TEC WIRELESS.
92
CUPCeloxica University Programme

• Recent Highlights

93
Introduction to CUP

• CUP has been active since the company was formed
• 700 universities worldwide registered with a
  multi-disciplinary user base
• Strategic relationship with XUP
• University specific products and services
• Heavily discounted
• Focused upon supporting innovative teaching and
  research
• Comprehensive Website
• www.celoxica.com/programs/university/index
• Register Now!

94
Benefits to Universities

• Rapid Design Exploration
• Fit more interest into time dependent project
  work through rapid prototyping and productivity
  improvements
• Port protoyped C designs to Handel-C for
  implementation in FPGAs
• For Computer Science disciplines
• Familiar software environment
• Parallel programming environment
• Computer architecture exploration build your
  own instruction sets
• Exploring hardware accelerated systems
• For EE disciplines
• Cycle accurate interactive simulation
• SW/HW co-design, system design and SOC
• Integration with HDLs
• Creates a bridge for increased collaboration
  between different disciplines

95
Update on University activity

• Research Articles
• Customising Floating-Point Designs, Imperial
  College, Xilinx.
• Accelerating Radiosity Calculations using
  Reconfigurable Platforms, Altaf Abdul Gaffar and
  Wayne Luk, Imperial College
• A Hardware Implementation of a Genetic
  Programming System Using FPGAs and Handel-C,
  Peter Martin, University of Birmingham
• Teaching Programmes
• VDEC Japan now support DK1/Handel-C
• HARDWARE/SOFTWARE CO-DESIGN A SHORT COURSE FOR
  UNBELIEVERS, A. Downton et al, University of
  Essex

96
IGOL Framework

• What is it?
• COM based Framework for Development and
  Distribution of Hardware Acceleration
• Testing and debugging for development
• Runtime services and packaging for deployment
• Application Examples
• Premier, Photoshop, WinAmp, VirtualDub,
  DirectShow

• Demonstrates
• Ease of Development and Deployment of Hardware
  Acceleration
• Separation of concerns
• Hardware developers only develop hardware
• Application developers only develop software
• Re-use of hardware and software components
• Simply updating and patching
• Automatic application support for new components
