Programmable Logic Controllers

1
Programmable Logic Controllers

• Day 2 Presentation
• PLC Design Choices
• And Platforms

2
Agenda
PLC Architecture Major PLC Manufacturers Minor
PLC Manufacturers Types of PLCs PLC
Languages PLC Control Methods PLC Uses In Industry
3
PLC Architecture
CPU Memory Programming Interface Communication
Interfaces I/O Power Supply
4
Major PLC Manufacturers (by US market share)
Allen Bradley (Rockwell) Modicon
(Schneider) General Electric Fanuc Siemens Omron
Mitsubishi
5
Minor PLC Manufacturers(alphabetical)
Cutler Hammer Enertron Keyence Koyo Reliance Toshi
ba Yokogawa (83 more PLC Manufacturers)
6
Types of PLCs
Fixed vs. Variable Size Pico or
Nano Micro Small Large Specialty I/O
7
PLC Languages
Ladder Logic Function Block Diagram Structured
Text Instruction List Sequential Function Chart
8
PLC Control Methods
Discrete Analog Sequential (Drum) Recipe
9
PLC Uses in Industry
Automotive Building Automation Cement Glass
Chemical Electrical Electronic Electric
Power Fabricated Metals Food Beverage
Machinery Metals Mining Oil Gas
Pharmaceuticals Pulp Paper Refining
Water Wastewater
10
Next Class!
PLC Languages
