IT Basics for Supply Networks/5

1
IT Basics for Supply Networks/5
Dr. Withalm 24-Feb-15
2
Lectures at the University of Bratislava/Autumn
2014

• 30.09.2014 Lecture 1 Introduction in CNOs
  Basics of Supply Networks
• 07.10.2014 Lecture 2 Kanban Essential Supply
  Chain Processes
• 21.10.2014 Lecture 3 Business Processes
  Semantic Web
• 11.11.2014 Lecture 4 SOA and SOA basing on J2EE
• 18.11.2014 Lecture 5 B2B Cloud Computing
  including SaaS

3
Summarizing of Lecture/1

• Business Aspects
• Fundamental Definitions of CNOS Examples
• Assessments
• CMMI
• ECMM
• Serious Gaming
• COIN as Paradigm Project
• ITA COIN Collaboration
• Kanban
• SCPP (Supply Chain Process Platform)
• Challenges Requirements on CDCP
• DCP (Demand Capacity Planning)
• CDCP (Collaborative Demand Capacity Planning

4
Summarizing of Lecture/2

• Brief introduction of ARIS
• Connection SOA with ARIS
• Event Control Event Driven Process Chain (EPC)
• Function Allocation Diagram
• Information Flow Diagram
• Event Diagram
• Function Organization Data
• EPC/PCD
• Semantic WEB
• Example
• Ontology
• Connection to WS
• Overview of SOA
• SOA and WS and related Technologies
• Future of WEB Applications
• Event-Driven Business Processes
• SOA basing on J2EE
• Change of Architectures
• SOA Concept

5
Todays Agenda

• B2B Frameworks
• Overview
• Conclusions
• Cloud Computing
• Definition
• Service Delivery Levels
• Deployment Models
• Architecture
• Standards
• Example

• SaaS
• Origin
• Major Trends
• Back Ground Context
• Business Strategies
• Business Models
• Metaphor
• Ingredients
• Premises
• IBMs View
• Methodology

6
B2B Frameworks/1Overview/1

• The first step towards this goal has already been
  taken in the past using Electronic Data
  Interchange (EDI) concept.
• However, the increasing use of Web protocols,
  such as HTTP, and the remarkable success of HTML
• have favoured more flexible solutions, notably
  XML.
• Hence, most B2B frameworks are built heavily on
  XML.
• Typically a B2B framework is a XML-based and
  middleware-neutral document specification
• though most of the B2B frameworks require the use
  of Internet and Web protocols
• such as HTTP, SSL, and MIME.

7
B2B Frameworks/2Overview/2

• Originally, B2B frameworks focused solely on
  developing vendor-independent specifications
• for a set of documents to be exchanged between
  business partners.
• Lately, the frameworks realised the need to
  coordinate the actions of different business
  partners
• so that, business partners should definitely
  agree on the structure of documents they exchange
• but they should also know when to exchange those
  documents
• and how to articulate those external exchanges
  with their internal business processes.

8
B2B Frameworks/3Overview/3

• As a result, B2B frameworks have begun focusing
  both on document format and on CBPs (Cross
  organizational Business Processes)
• that concern the exchange of those documents.
• Some of these B2B frameworks specify the
  infrastructure required for business partners
• to implement those exchanges.
• In other words, some frameworks specify both
  message format and exchange sequence
• and some specify the message format and an
  infrastructure
• which allow business partners to define and
  implement their own interactions.

9
B2B Frameworks/4Summary/1

• Electronic business is not an invention of the
  Web
• Already in the 80s a standard for Electronic
  Data Interchange (EDI) was established
• Mainly focusing on business data
• Technological driver of B2B frameworks was XML
• United Nations bodies, OASIS (Organization for
  the Advancement of Structured Information
  Standards) and vendors fostered the development
  of standards
• Partly standards are focusing on business data
• Whereas the others tried to standardize business
  processes
• Between the involved companies of electronic
  business

10
B2B Frameworks/5Summary/2

• To the first group belong
• ebXML which focuses on CPP (Collaboration Partner
  Profile) and CPA (Collaboration Partner
  Agreement)
• Are in some way a superset of WSDL
• cXML defining structures of purchase orders or
  order acknowledgment
• UBI ended in a standard and is more or less
  successor of EDI

11
B2B Frameworks/6Summary/3

• To the second group belong
• RosettaNet providing dictionaries, PIP (Partner
  Interface Processes), and TPAs (Trading Partners
  Agreement) -including 5 modules
• OBI entailing a buying organization
• Biztalk specifies message formats that encloses
  documents provided on MS servers
• Bolero.net is running on a server owned by an
  independent third party-focusing on trading
  processes
• tpaML provides a special language to express
  agreements between business partners

12
B2B Frameworks/7Summary/4

• Two of them are meta frameworks
• eCO architecture is an abstract architecture for
  B2B frameworks
• XCBL is a set of XML building blocks and a
  document framework

13
B2B Frameworks/8Summary/5

• There are some of B2B frameworks such as
• ebXML, RosettaNet, OBI, cXML, BizTalk, bolero.net
• The most relevant important standards are ebXML,
  RosettaNet and cXML
• even if they are very different.
• Web service standards defines a standard
  infrastructure
• for locating and invoking remote application
  services
• within and between organisations.
• This is a primitive set of standards
• really an approach to application development,
  similar to older standards
• such as distributed objects and component-based
  programming
• but easier to understand and deploy.

14
B2B Frameworks/9Summary/6

• The ebXML, RosettaNet and to a lesser extent cXML
  standards
• generally speaking, relate to, how information
  moves between companies
• including format and process.
• cXML and UBL offer a standard definition of
  commonly used business documents.
• From the largest software companies
• to new industry solution providers
• to open source projects
• providers of such tools are world-wide.

15
Cloud Computing/Definition

• The notion of what exactly is cloud computing is
  ... cloudy -- numerous definitions exist. A
  rather well-founded definition is provided by the
  US National Institute for Standards and
  Technology (NIST)
• Cloud computing is a model for enabling
  convenient, on-demand network access to a shared
  pool of configurable computing resources
• e.g., networks, servers, storage, applications,
  and services
• that can be rapidly provisioned and released
• with minimal management effort or service
  provider interaction.
• As most other definitions, NIST's definition
  describes three service-delivery models for cloud
  computing

16
Cloud Computing/Service Delivery Levels

• Cloud Software as a Service (SaaS)
• The capability provided to the consumer is to use
  the provider's applications running on a cloud
  infrastructure and accessible from various client
  devices through a thin client interface such as a
  Web browser (e.g., web-based email).
• Cloud Platform as a Service (PaaS)
• The capability provided to the consumer is to
  deploy onto the cloud infrastructure
  consumer-created applications using programming
  languages and tools supported by the provider
  (e.g., java, python, .Net).
• Cloud Infrastructure as a Service (IaaS)
• The capability provided to the consumer is to
  provision processing, storage, networks, and
  other fundamental computing resources where the
  consumer is able to deploy and run arbitrary
  software, which can include operating systems and
  applications.

17
Cloud Computing/SaaS Layer

• The SaaS layer is regarded as the application
  layer, delivering applications over the browser
  or composite high-level services.
• It's important to mention that cloud computing is
  not stuck to thin-clients.
• The smart phone shows that the smart client is
  used in practice. Therefore, new client
  technology, running as plug-in in the browsers,
• for example Microsoft's Silverlight, Adobe's AIR,
  Flash, Java FX,Google Chrome, are required to
  deliver the required user experience.
• Prominent examples are, Microsoft online (BPOS)
  and live, Goggle Apps, Salesforce CRM,
• SuccessFactors, Apple's AppStore and many more.

18
Cloud Computing/PaaS Layer/1

• The PaaS layer consists of a platform technology
  and typical foundation infrastructure services.
  This could be split up in the platform and
  service.
• The architectural platform aspect can be compared
  to a typical desktop operating system and
  infrastructure services to typical network
  services required in an enterprise environment.
• The platform part covers the abstraction for
  resource management
• computation, storage, network
• The service part covers services for
• directories, search, billing.

19
Cloud Computing/PaaS Layer/2

• Current examples are Windows Azure, Goggle App
  Engine, Force.com. All three offerings can be
  regarded as PaaS, but are very different.
• Windows Azure is much like an .net operating
  system open for developing like for an on-premise
  OS
• Google App Engine is intended to allow glue logic
  in Java and Python for Google Apps
• Force.com is a fully proprietary platform with
  specific programming language and useful services
  in the CRM domain.
• The common advantage of cloud platforms is their
  focus on scalability, reliability and low
  operating cost.
• Existing applications cannot be transferred from
  on-premise to cloud
• platforms
• they typically have to be reengineered in order
  to gain the benefit of seamless Internet scale.

20
Cloud Computing/IaaS Layer

• The IaaS layer covers all the current offerings
  in the virtualization domain.
• The market leader is Amazon (Elastic Cloud)
• typically offering hosted operating systems like
  Windows or Linux.
• These virtualized offerings allow fast scale of
  virtualized hardware, but does not scale up
  applications, if they are not developed for
  scalability already.
• But also the new types of services, called
  storage services are related to the
  infrastructure level.
• Prominent offerings are Amazon Simple Storage
  (S3), SimpleDB, Windows Azure Storage, Google
  Storage.
• Furthermore, infrastructure services for
  synchronization are provided.

21
Cloud Computing/Deployment Models

• Private cloud
• The cloud infrastructure is operated solely for
  an organization. It may be managed by the
  organization or a third party and may exist on
  premise or off premise.
• Community cloud
• The cloud infrastructure is shared by several
  organizations (e.g. SC, CNO) and supports a
  specific community that has shared concerns
  (e.g., mission, security requirements, policy,
  and compliance considerations). It may be managed
  by the organizations or a third party and may
  exist on premise or off premise.
• On-premises software is installed and run on
  computers on the premises (in the building)
• off-premises software is commonly called
  "software as a service" or "computing in the
  cloud."
• Public cloud
• The cloud infrastructure is made available to the
  general public or a large industry group and is
  owned by an organization selling cloud services.

22
Cloud Computing/Hybrid Cloud

• These deployment models can be mixed as a "hybrid
  cloud"
• the cloud infrastructure is a composition of two
  or more clouds (private, community, or public)
  that remain unique
• entities but are bound together by standardized
  or proprietary technology that enables data and
  application portability (e.g., cloud bursting).

23
Service View vs. Architecture View

• The big number of different definitions and the
  current buzz around cloud computing, leads to
  different interpretations of cloud computing.
• Therefore, a cloud computing reference
  architecture model is introduced which allows
• relating technological and architectural aspects
  to service view aspects.
• Cloud computing novelty comes from the
  composition of existing technologies combined
  with new business models for software and service
  selling. It's not a single new technology.

24
Cloud Computing Architecture
25
Cloud Computing/Standards

• Cloud computing heavily relies on Web standards
  (protocols, e.g. SOAP and REST, security, e.g.
  SAML (Security Assertion Markup Language ),OAuth
  (Open Authorization) , etc.)
• but there are no specific cloud computing
  standards for elements and processes
• such as APIs, the storage, data import and
  export, and backup.
• Furthermore, application portability is
  difficult, because the platform concepts differ
  in resource scheduling and resource access and
  control from current on-premise concepts.

26
Cloud Computing _at_ SIS

• Establishing an all over concept of Cloud
  Computing
• Dynamic delivery of ICT services in the form of
• Applications (SaaS)
• Platform services (PaaS)
• Infrastructure services (IaaS)
• The three blocks SaaS, PaaS and IaaS should
  not be looked at in isolation they have mutual
  interrelationships that have to be taken into
  account in forming business models.

27
Cloud Computing /Framework of NISTNationale
Institute of Standards and Technology
28
Cloud Computing _at_ SIS
29
Cloud Computing _at_ SIS
30
Cloud Infrastructure/Siemens
31
From a Linear Value Chain to a Cloud Computing
Ecosystem
32
Business Models
33
Maturity Model

• The business models can be classified and
  assessed by means of a maturity models and the
  value chain. The maturity model has different
  service level development stages in SaaS, PaaS
  and IaaS.

34
Cloud Computing/Success Factors/1

• Generic cloud computing aspects
• Low price
• Flexible contractual models
• Relevant factors in SaaS
• Best-of-breed support for the company processes
  that are mapped
• The providers economic reliability
• Integration and migration interfaces
• References and flexible price models

35
Cloud Computing/Success Factors/2

• Key aspects for PaaS providers
• Size of the community entrusted with developing
  the technology in question
• Simplicity of service deployment
• Architecture frameworks that support automatic
  scaling
• Key aspects for IaaS providers
• Leveraging economies of scale
• Advantages in price/performance ratio
• Availability
• Security
• Network connections bandwidth

36
Cloud Computing/Examples/1CAPPER Supply C3 (CSC3)

• CAPPER Supply C3 (Cloud, Common Processes and
  Collaboration) describes an elastic cloud of
  common processes within defined and structured
  communications patterns for sharing business
  process information
• CSC3 is at the center of a new movement in
  software called Cloud Computing and Platform as a
  Service in which the application framework is
  provided as customizable web-based services.
• Integrated portfolio for CAPPER Supply C3
• Software as a Service - provides many business
  applications that can be deployed out of the box,
  or used as templates for supporting the
  development of custom ones. All applications can
  be used independently from each other, while
  leveraging a common set of components and
  features.
• Platform as a Service - offers an integrated
  platform for developing cloud applications that
  are natively elastic and multi-tenant.
• Infrastructure as a Service - provides an
  elastically scalable infrastructure for the
  deployment of applications and the storage of
  data and documents.

24.02.2015
36
37
Cloud Computing/Examples/2CSC3 Services

• CSC3 Services are designed for business processes
  that have event-driven needs within their
  applications and require a flexible, reliable,
  cost-effective communication solution that can
  scale seamlessly.
• Characteristics
• Platform independent communication manner
• Collection of operations accessible via
  standardized messaging networks
• Simple set up, operation and notification from
  any infrastructure
• Highly scalable, flexible, and cost-effective
  capability to publish messages
• CSC3 Services
• CSC3 Data Model
• CSC3 Workflow Logical Model
• CSC3 Permissions Model
• CSC3 Integration Model

24.02.2015
37
38
Cloud Computing/Examples/3CSC3 Elastic
Collaboration

• Cloud Deployment Models
• Privat Cloud
• Community Cloud
• Public Cloud
• CSC3 Single Node
• Elastic Collaboration with a Central Hosting
  Solution (DB)
• CSC3 Multi Node
• Elastic Collaboration Cluster with a one-to-one
  mapping to an Elastic Cloud Cluster
• CSC3 Dynamic Node
• Elastic Collaboration with a dynamic mapping and
  a cluster to cluster allocation

24.02.2015
38
39
Cloud Computing/Examples/4CSC3 Products

• CSC3 SPACE
• Supply Chain Collaboration Processes
• Customer Demand Management
• Capacity Management
• Vendor Demand Management
• Partner Management
• Group Management
• Alert Management3SPACE
• Link https//space.csc3.org
• Interregional Planning Solutions
• Creation of innovative networks and solutions
  between
• regional development planning,
• architecture,
• economy and
• governmental and academic partners
• Delivery of e-services and e-government solutions
  across borders

24.02.2015
39
40
SaaS (Software as a Service)/2Overview

• Origin
• Major Trends
• Back Ground Context
• Business Strategies
• Business Models
• Metaphor
• Ingredients
• Premises
• IBMs View
• Methodology

41
SaaS (Software as a Service)/1Origins

• Some ideas are coming from the Big Iron
• also some similar ideas as Thin Clients and
  Application service providing are going back to
  the late nineties
• The primary idea of SaaS is the following
• provide the user with application functionality
  via web clients
• instead to force to install the whole application
  on his PC.

42
SaaS (Software as a Service)/3Mayor Trends
43
Background and Context Distinguishing ASP from
SaaS
Application Hosting Model Software as a Service Model
Customer pays on delivery of software Customer pays for delivery of functional services
Customer responsible for software performance Provider responsible for software performance
Customer responsible to customize software to business requirements Customer responsible to configure software to business requirements
Customer pays maintenance to fix software Provider fixes software or pays penalty for failure to meet service levels
Customer buys upgrades to keep current Provider ensures currency of solution
Source Summit Strategies, Inc Software
Powered Services Net-native SaaS Transforms the
ISV Business Model Feb, 2005
44
Background and Context A tentative Roadmap
towards SaaS-U
45
Business Strategies

• Intellectual property
• Bundling
• Standards
• Open source
• Long tail
• Free
• FUD (Fear, Uncertainty and Doubt)

46
Utility based business models Issues Questions
Issues Questions Market its Rules
Ownership nothing is owned Who to buy from? Who comprise the SaaS-U value chain? How many providers, service publishers, intermediaries? Will there be gatekeepers?
Pricing and Licensing value based and dynamic How to determine value? How to measure usage? What gets metered? (Customers) How to price SW based on, e.g. Number of cars built, Number of cars hired, Number of airline passengers, Number of banking deposits, etc (Providers) How to meter based on, e.g. business processes, peak/off peak pricing, tariffs, auctions, location hosting discounts, forecasting penalties, others?
Payment pay only for what is used What exactly gets billed? How many meters? How to get an invoice? How to pay? Alignment between pricing and metering? One meter per product, per service? What are the payment and clearance mechanisms? Who gets paid?
Standards and Interoperability What are the guaranteed properties for Availability Accessibility Security Reliability Interoperability Usability Others? SLA between customers and providers/third parties SLA between providers SLA between third parties Customer expectations and industry norms Oversight and governance
47
Utility based business models SaaS business
model for an Independent SW Vendor (ISV)

• Software as a Service is the business of
  delivering software-powered services, not
  delivering software
• The ISVs mission is no longer the creation of
• packaged software for the customer to
  install.
• Instead, they ISVs create functional
  services
• and applications for customers to use
• delivered to agreed performance levels
• throughout the life of the service
  contract. Summit Strategies

Key Attributes
Key Components
Key Enablers

• Usage based pricing
• One to many Web delivery
• Modular components
• Bus. functionality centric

• ISVs
• Web native providers
• Business service providers
• Web as Service integrator

• Flexible, scalable infrastructure
• Web centric applications
• Remote application management
• Multi-tenant and multi-instance
• Multitenancy refers to a principle in
• software architecture where a single instance
• of the software runs on a server,
• serving multiple client organizations ...

48
MetaphorElectricity

• Infrastructure, i.e. cables (network, servers
  ...)
• Different kinds of plug-ins (interfaces, no
  international standards)
• Different adapters to appliances (integration of
  legacy systems)
• Different utilities, i.e. high/low voltage
• Different business models, i.e. business/private
  customers

49
MetaphorAMADEUS IT Provider in Tourism

• Infrastructure
• A dedicated network, which provides different
  booking offers (flights, hotels, packages, events
  ...)
• TOMA interface is the connector to the utilities
• Utilities are different booking offers as
• Flights, Packages are provided by different
  organizations as airlines, tour operators, hotels
  ...
• Business models consist of
• Access price, which is a fixed price for a period
• Booking fee, which is an amount of the whole
  booking price

50
Ingredients

• Infrastructure containing
• Payment services
• Maintenance services
• Monitoring services
• Building of domain clusters / sub webs
• Providing of domain specific services, which are
  separated in
• Basic, horizontal, vertical ones
• Services are built on the four cornerstones
• Web2.0
• Web services, SOA
• Semantic Web
• Ontology
• which induces the separation in domains
• Interfaces to make services to be integrated with
  ERP and legacy systems

51
Premises

• Technological
• Eclipse, IBM Websphere, Microsoft Team Foundation
  Server
• Semantic Web languages (OWL, RDF, etc.)
• Domain competency
• Especially in Automotive, Healthcare, Energy
• Ontology
• Basic knowledge how ontology could be
  established,
• which in turn also requires deep domain knowledge.

52
IBMs ViewManaged Hosting and Support for SaaS
Solution
Governance Project Management
Application Management Services
Application Operations
OS Management
Helpdesk Level 2
Service Management Reporting
CustomerEnd-user Helpdesk (Level 1)
Storage Tape HW Infra Mgmt
OS Security Mgmt
Transition
Monitoring (alerting, escalations)
Server Hardware Infra Operations

Data centre LAN infra Operations
Internet connectivity Operations
IBM
ISV
53
MethodologySaaS/1

• EI Services which are available on the GSP
  (Generic Service Platform) will be provided via
  the SaaS concept.
• which is an emerging concept for current and
  future networked enterprises
• SaaS is a model for SW deployment with the
  following characteristics
• application is hosted as a service provided to
  customers across the Internet.
• application must neither be installed nor run on
  the customer's own computer
• alleviates the customer's burden of software
  maintenance, ongoing operation, and support.
• customers relinquish control over software
  versions or changing requirements.
• conceivably reduce that up-front expense of
  software purchases
• through less costly, on-demand pricing.

54
MethodologySaaS/2

• From the software vendor's standpoint following
  issues are from importance
• it has the attraction of providing stronger
  protection of its intellectual property
• establishing an ongoing revenue stream
• may host the application on its own web server
• this function may also be handled by a
  third-party application service provider (ASP).
• This way, end users may reduce their investment
  on server hardware too.

55
MethodologySaaS/3

• Many types of software are well suited to the
  SaaS model
• where customers may have little interest or
  capability in software deployment, but do have
  substantial computing needs.
• Such Application areas are for instance
• Customer relationship management (CRM) i.e.
  Salesforce
• Video conferencing
• Human resources
• IT service management
• Accounting
• IT security
• Web analytics
• Web content management
• e-mail are
• These are the initial markets showing SaaS
  success

56
MethodologySaaS/4

• SaaS solutions were developed specifically to
  leverage web technologies
• such as the browser, thereby making them
  web-native.
• Both data design as well as architecture of SaaS
  applications are specifically built with a
  'multi-tenant' backend
• Multi-tenancy refers to a principle in software
  architecture where a single instance of the
  software runs on a server, serving multiple
  client organizations (tenants).
• thus enabling multiple customers or users to
  access a shared data model.
• This further differentiates SaaS from
  client/server or 'ASP' (Application Service
  Provider) solutions
• because SaaS providers are leveraging enormous
  economies of scale
• in the deployment, management, support and
  through the Software Development Lifecycle.

57
MethodologySaaS/5

• A new implementation of the SaaS vision is
  expected
• supporting the various collaborative business
  forms, from supply chains to business ecosystems
• and becoming for them like a utility, a
  commodity, the so-called Interoperability Service
  Utility (ISU)
• ISU will not just create a service platform
• but mainly a new business concept the
  Software-as-a-Service Utility (SaaS-U) model.

58
MethodologySaaS-U/1

• can be seen as a software application delivery
  model
• where a software vendor develops Web-native
  software services
• hosting and operating them for use by its
  customers over the Internet.
• Customers do not pay for owning the software
  itself any longer but rather for using it
  on-demand.
• They use it through an API accessible over the
  Web and often written using Web services.
• fits also well with modern SOA architectures
• aiming to promote software development in a way
  that leverages the construction of dynamic
  software systems
• which can easily adapt to volatile user
  environments and be easily maintained as well.

59
MethodologySaaS-U/2

• SOA enables flexible connectivity of applications
  by representing every application as a service
  with a standardized interface.
• enabling to exchange structured information
  quickly and flexibly.
• This flexibility enables new and existing
  applications to be easily and quickly combined
• to address changing business needs, and the
  ability to easily combine and choreograph
  applications
• allowing IT services to more readily reflect
  business processes

60
MethodologySaaS-U/3Open Issues/1

• Are there success stories/lessons learned in
  specific domains concerning experience of
  ISU/SaaS-U?
• SaaS-U will undergo further transformation
• In business models for SaaS-U the providing of
  platforms should be taken into account
• Whats the borderline between value added
  services and utility services concretely is
  payment an utility service?
• Do utility services belong to horizontal
  services?
• Consider the differentiation between horizontal
  and vertical services.
• Assessment respectively certification authorities
  could be another type of stake holder especially
  in the crucial issues as QoS (Quality of
  Service), liability, reliability, SLA (Service
  Level Agreement).
• There are doubts that ISU will bring intelligence
  in the network.
• Discussions about the different types of
  metaphors especially concerning the tab is
  mixture of cold and warm water really a metaphor
  for ISU?
• Distinguish among cost based and market based
  prices
• IPR (and patents) also for SW solutions are
  encouraged by CMMI assessments could this fact
  increase prices for ISU

61
MethodologySaaS-U/3Open Issues/2

• Legal aspects must be solved
• Above all liability issues
• The crucial issue seems to be the Ontology.
• Without Ontology UDDI will not work properly.
• So no customer will really find the respective
  services!
• Its also very questionable, if Ontology will be
  standardized.
• Some fears are concerning the quality of
  services.
• Are they again technical services at the end of
  the day?
• as we experienced with objects

62
MethodologySaaS-U/3Open Issues/3

• Another hype?
• Ontology neither exists nor chance to agree on
  it.
• Often on political reasons (i.e. Automotive
  sector Odette)
• Services dont meet the expectations of end
  users.
• Neither value proposition nor relevant business
  models are met.
• Interfaces/connectors to ERP/legacy systems are
  too heavy to be implemented.
• Are there enough technicians or business experts
  available?

63
Thank youfor your attention!
64
Farbpalette mit Farbcodes
Primäre Flächenfarbe
Akzentfarben
R 255 G 210 B 078
R 229 G 025 B 055
R 245 G 128 B 039
R 000 G 133 B 062
R 000 G 000 B 000
R 000 G 084 B 159
R 255 G 255 B 255
R 255 G 221 B 122
R 236 G 083 B 105
R 248 G 160 B 093
R 064 G 164 B 110
R 064 G 064 B 064
R 064 G 127 B 183
Sekundäre Flächenfarben
R 130 G 160 B 165
R 170 G 190 B 195
R 215 G 225 B 225
R 255 G 232 B 166
R 242 G 140 B 155
R 250 G 191 B 147
R 127 G 194 B 158
R 127 G 127 B 127
R 127 G 169 B 207
R 220 G 225 B 230
R 145 G 155 B 165
R 185 G 195 B 205
R 255 G 244 B 211
R 248 G 197 B 205
R 252 G 223 B 201
R 191 G 224 B 207
R 191 G 191 B 191
R 191 G 212 B 231
R 255 G 250 B 237
R 252 G 232 B 235
R 254 G 242 B 233
R 229 G 243 B 235
R 229 G 229 B 229
R 229 G 238 B 245
