Storage

1
Storage
2
Parts of a computer

• For purposes of this talk, we will assume three
  main parts to a computer
• Main memory, once upon a time called core, but
  these days called RAM (Random Access Memory)
• RAM consists of a very long sequence of bits,
  organized into bytes (8-bit units) or words
  (longer units)
• Peripheral memory, these days called disks (even
  when they arent) or drives
• Peripheral memory consists of a very, very long
  sequence of bits, organized into pages of words
  or bytes
• Peripheral memory is thousands of times slower
  than RAM
• The CPU (Central Processing Unit), which
  manipulates these bits, and moves them back and
  forth between main memory and peripheral memory

3
Its all bits

• Everything in a computer is represented by a
  sequence of bitsintegers, floating point
  numbers, characters, and, most importantly,
  instructions
• Bits are the ultimate flexible representationat
  least until we have working quantum computers,
  which use qubits (quantum bits)
• Modern languages use strong typing to prevent you
  from accidentally treating a floating point
  number as a boolean, or a string as an integer
• A weakly typed language provides some protection,
  but there are ways around it
• But it wasnt always this way...

4
Storage is storage

• At one time, words representing machine
  instructions and words representing data could be
  intermixed
• Strong typing was a thing of the future
• It was the programmers responsibility to avoid
  executing data, or doing arithmetic on
  instructions
• Both of these things could be done, either
  accidentally or deliberately
• Machine instructions are just a sequence of bits
• They can be manipulated like any other sequence
  of bits
• Hence, programmers could change any instruction
  into any other instruction (of the same size), or
  rewrite whole blocks of instructions
• A self-modifying program is one that changes its
  own instructions

5
Self-modifying programs

• Once upon a time, self-modifying programs were
  thought of as a good thing
• Just think of how flexible your programs could
  be!
• ...yes, and smoking was once considered good for
  your health
• The usual way to step through an array was by
  adding one to the address part of a load or store
  instruction
• You could write some really clever self-modifying
  programs
• But, as the poet Piet Hein says
• Heres a good rule of thumbToo clever is dumb.

6
Preparation for next example

• In the next example, we will talk about how a
  higher-level language might be translated into
  assembly languages
• Here are some of the assembly instructions we
  will use
• The load instruction copies a value from a memory
  location into a special register called the
  accumulator
• Example load 53 gets whatever is in location 53
  and puts it into the accumulator
• The enter instruction puts a given value into the
  accumulator
• Example enter 53 puts 53 itself into the
  accumulator
• All arithmetic is done in the accumulator
• Example add 53 adds the contents of location 53
  to the accumulator
• The store instruction copies a value from the
  accumulator into memory
• Example store 53 puts whatever is in the
  accumulator into location 53

7
Procedure calls

• Consider the following
• a add(b, c)...function add(x, y)
  return x y
• Heres how it might have been translated to
  assembly language in the old days (red values are
  filled in as the program runs)
• 42 0 // a43 10 // b44 15 // c

• 20 load from 43 // addr of b21 store in
  7122 load from 44 // addr of c23 store in
  7224 enter 27 // the return addr25 store in
  addr part of 7026 jump to 7327 store in 42
  // addr of a
• 70 jump to 27 // gets return addr71 10 //
  will receive b72 15 // will receive c73
  load value at addr 7174 add value at addr
  7275 jump to 70

8
Problems with the previous code

• In this example, storage was staticyou always
  knew where everything was (and it didnt move
  around)
• If you called a function, you told it where to
  return to, by storing the return address in the
  function itself
• Hence, you could call the function from (almost)
  anywhere, and it would find its way back
• You stored the parameter values in the function
  itself
• This worked fine until recursion was invented
• Recursion requires
• Multiple return addresses
• Multiple copies of parameters and local variables
• In other words, recursion requires dynamic storage

9
The end of an era

• What really killed off self-modifying programs
  was the advent of timesharing computers
• Multiple users, or at least multiple programs,
  could share the computer, taking turns
• But there isnt always enough main memory to
  satisfy everybody
• When one program is running, another program (or
  parts of it) may need to be copied to disk, and
  brought back in again later
• This is really, really slow
• If only the data changed, not the program, we
  wouldnt have to save the program (which is often
  the largest part) over and over and over...
• Besides, with the new emphasis on understandable
  programs, self-modifying programs were turning
  out to be a Really Bad Idea
• Besides, think about what a security nightmare
  self-modifying programs could be!

10
An asidecompilers and loaders

• Although self-modifying code is a bad idea, it is
  still necessary for computers to be able to
  create and modify machine instructions
• This is what a compiler doesit creates machine
  instructions
• A loader takes a compiled program and puts it
  somewhere in a computer memory
• It cant always put it in the same place, so it
  has to be able to modify the addresses in the
  instructions
• Still, compilers and loaders dont modify
  themselves

11
Static and dynamic storage

• In the beginning, storage was staticyou declared
  your variables at the beginning of the program,
  and that was all you got
• A procedure or function with, say, three
  parameters, got three words in which to store
  them
• The parameters went in a fixed, known location in
  memory, assigned to them by the compiler
• Recursion had not yet been invented
• The programming language Algol 60 introduced
  recursive functions and procedures
• Parameters went onto a stack
• Hence, parameters were dynamically assigned to
  memory locations, not by the compiler, but by the
  running program itself
• Storage was dynamically allocated and deallocated
  as needed

12
Stacks

• Stacks obey a simple regimenlast in, first out
  (LIFO)
• When you enter a function or procedure or method,
  storage is allocated for you on the stack
• When you leave, the storage is released
• In Java, this is even more fine-grainedstorage
  is allocated and deallocated for individual
  blocks, and even for for statements
• Since this is so well-defined, your compiler
  writes the code to do it for you
• But its still dynamicdone by your running
  program
• Since virtually every language supports recursion
  these days (and all the popular languages do),
  computers typically provide machine-language
  instructions to simplify stack operations

13
Heaps

• Stacks are great, but they have their limitations
• Suppose you want to write a method to read in an
  array
• You enter the method, and declare the array, thus
  dynamically allocating space for it
• You read values into the array
• You return from the method and POOF! your array
  is gone
• You need something more flexiblesomething where
  you have control over allocation and deallocation
• The invention that allows this (which came
  somewhat later than the stack, Im not sure when)
  is the heap
• You explicitly get storage via malloc (C) or new
  (Java)
• The storage remains until you are done with it

14
Stacks vs. heaps

• Stack allocation and deallocation is very regular
• Heap allocation and deallocation is unpredictable

• Stack allocation and deallocation is handled by
  the compiler
• Heap allocation is at the whim of the programmer
• Heap deallocation may also be up to the
  programmer (C, C) or by the programming
  language system (Java)
• Values on stacks are typically small and uniform
  in size
• In Java, arrays and objects dont go in the
  stackreferences to them do
• Values on the heap can be any size
• Stacks are tightly packed, with no wasted space
• Deallocation can leave gaps in the heap

15
Implementing a heap

• A heap is a single large area of storage
• When the program requests a block of storage, it
  is given a pointer (reference) to some part of
  this storage that is not already in use
• The task of the heap routines is to keep track of
  which parts of the heap are available and which
  are in use
• To do this, the heap routines create a linked
  list of blocks of varying sizes
• Every block, whether available or in use,
  contains header information about the block

• We will describe a simple implementation in which
  each block header contains two items of
  information
• A pointer to the next block, and
• The size of this block

16
Anatomy of a block

• Here is our simple block

• Java Objects hold more information than this (for
  example, the class of the object)
• Notice that our implementation will return a
  pointer to the first word available to the user
• Data with negative offsets are header data
• ptr-1 contains the size of this block, including
  header information
• ptr-2 will be used to construct a free space list
  of available blocks

17
The heap, I

• Initially, the user has no blocks, and the free
  space list consists of a single block
• In our implementation, we will allocate space
  from the end of the block
• To begin, lets assume that the user asks for a
  block of two words

18
The heap, II

• The user has asked for a block of size 2
• The free block is reduced in size from 20 to 16
  (two words asked for by the user, plus two for a
  new header)
• The new block has size 4 and the next field is
  not used
• Next, assume the user asks for a block of three
  words

19
The heap, III

• The user has asked for a block of size 3
• The free block is reduced in size from 16 to 11
  (three words asked for by the user, plus two for
  a new header)
• The new block has size 5 and the next field is
  not used
• Next, assume the user asks for a block of just
  one word

20
The heap, IV

• The user has asked for a block of size 1
• The free block is reduced in size from 11 to 8
  (one word for the user, plus two for a new
  header)
• The new block has size 3 and the next field is
  not used
• Next, the user releases the second block (at 13)

21
The heap, V

• The user has released the block of size 5
• The freed block is added to the front of the free
  space list
• Its next field is set to the old value of free
• free is set to point to this block
• Next, the user requests a block of size 4
• The first block on the free list isnt large
  enough, so we have to go to the next free block

22
The heap, VI

• The user requests a block of size 3
• The size of the first free block is now 3, and
  its next field does not change
• The user gets a pointer to the new block
• Now the user releases the smallest block (at 10)
• Again, this will be added to the beginning of the
  free space list

23
The heap, VII

• The user releases the smallest block(at 10)
• The freed block is added to the front of the free
  space list
• Its next field is set to the old value of free
• free is set to point to this block
• Now the user requests a block of size 4
• Currently, we cannot satisfy this request
• We have enough space, but no single block is
  large enough
• However, free blocks 10 and 13 are adjacent to
  each other
• We can coalesce blocks 10 and 13

24
The heap, VIII

• Blocks at 10 and 13 have now been coalesced
• The size of the new block is the sum of the sizes
  of the old blocks
• We had to adjust the links
• Now we can give the user a block of size 4

25
Pointers

• Allocating storage from the heap is easy
• Person p new Person ( )
• In Java, you request storage from the heap with
  new there is no other way to get storage on the
  heap
• All Objects are on the heap
• In C and C you get a pointer to the new
  storage in Java you get a reference
• The implementation is identical the difference
  is that there are more operations on pointers
  than on references
• C and C provide operations on pointers
• C and C let you do arithmetic on pointers, for
  example, p
• Pointers are pervasive in C and C you can't
  avoid them

26
Advantages/disadvantages

• Pointers give you
• Greater flexibility and (maybe) convenience
• A much more complicated syntax
• More ways to create hard-to-find errors
• Serious security holes
• References give you
• Less flexibility (no pointer arithmetic)
• Simpler syntax, more like that of other variables
• Much safer programs with fewer mysterious bugs
• Pointer arithmetic is inherently unsafe
• You can accidentally point to the wrong thing
• You cannot be sure of the type of the thing you
  are pointing to

27
Deallocation

• There are two potential errors when de-allocating
  (freeing) storage yourself
• De-allocating too soon, so that you have dangling
  references (pointers to storage that has been
  freed and possibly reused)
• A dangling reference is not a null linkit points
  to something (you just dont know what)
• Forgetting to de-allocate, so that unused storage
  accumulates and you have a memory leak
• If you have to de-allocate storage yourself, a
  good strategy is to keep track of which function
  or method owns the storage
• The function that owns the storage is responsible
  for de-allocating it
• Ownership can be transferred to another function
  or method
• You just need a clearly defined policy for
  determining ownership
• In practice, this is easier said than done

28
Discipline

• Most C/C advocates say
• It's just a matter of being disciplined
• I'm disciplined, even if other people aren't
• Besides, there are good tools for finding memory
  problems
• However
• Virtually all large C/C programs have memory
  problems

29
Garbage collection

• Garbage is storage that has been allocated but is
  not longer available to the program
• It's easy to create garbage
• Allocate some storage and save the pointer to it
  in a variable
• Assign a different value to that variable
• A garbage collector automatically finds and
  de-allocates garbage
• This is far safer (and more convenient) than
  having the programmer do it
• Dangling references cannot happen
• Memory leaks, while not impossible, are pretty
  unlikely
• Practically every modern language, not including
  C, uses a garbage collector

30
Garbage collection algorithms

• There are two well-known algorithms (and several
  not so well known ones) for doing garbage
  collection
• Reference counting
• Mark and sweep

31
Reference counting

• When a block of storage is allocated, it includes
  header data that contains an integer reference
  count
• The reference count keeps track of how many
  references the program has to that block
• Any assignment to a reference variable modifies
  reference counts
• If the variable previously referenced an object
  (was not null), the reference count of that
  object is decremented
• If the new value is an object (not null), the
  reference count for the new object is incremented
• When a reference count reaches zero, the storage
  can immediately be garbage collected
• For this to work, the reference count has to be
  at a known displacement from the reference
  (pointer)
• If arbitrary pointer arithmetic is allowed, this
  condition cannot be guaranteed

32
Problems with reference counting

• If object A points to object B, and object B
  points to object A, then each is referenced, even
  if nothing else in the program references either
  one
• This fools the garbage collector, which doesn't
  collect either object A or object B
• Thus, reference counting is imperfect and
  unreliable memory leaks still happen
• However, reference counting is a simple technique
  and is occasionally used

33
Mark and sweep

• When memory runs low, languages that use
  mark-and-sweep temporarily pause the program and
  run the garbage collector
• The collector marks every block
• It then does an exhaustive search, starting from
  every reference variable in the program, and
  unmarks all the storage it can reach
• When done, every block that is still marked must
  not be accessible from the program it is garbage
  that can be freed
• In order for this technique to work,
• It must be possible to find every block (so they
  are in a linked list)
• It must be possible to find and follow every
  reference
• The mark has to be at a known displacement from
  the reference
• Again, this is not compatible with arbitrary
  pointer arithmetic

34
Problems with mark and sweep

• Mark-and-sweep is a complex algorithm that takes
  substantial time
• Unlike reference counting, it must be done all at
  oncenothing else can be going on
• The program stops responding during garbage
  collection
• This is unsuitable for many real-time applications

35
Garbage collection in Java

• Java uses mark-and-sweep
• Mark-and-sweep is highly reliable, but may cause
  unexpected slowdowns
• You can ask Java to do garbage collection at a
  time you feel is more appropriate
• The call is System.gc()
• But not all implementations respect your request
• This problem is known and is being worked on
• There is also a Real-time Specification for Java

36
No garbage collection in C or C

• C and C do not have garbage collectionit is up
  to the programmer to explicitly free storage when
  it is no longer needed by the program
• C and C have pointer arithmetic, which means
  that pointers might point anywhere
• There is no way to do reference counting if the
  programming language does not have strict control
  over pointers
• There is no way to do mark-and-sweep if the
  programming language does not have strict control
  over pointers
• Pointer arithmetic and garbage collection are
  incompatible--it is essentially impossible to
  have both

37
The End
