Adaptive Server Enterprise and Linux

1

E129ASE for Linux

• Wim ten Have
• Staff S/W Development
• ESD ASE kernel
• wtenhave_at_sybase.com

2
History on the Linux Open Source platform

• Just for the Fun!
• Linux started of in 1991 featuring with kernel
  0.3
• Where did it come from?
• O/S research projects done by Universities
• MIT Mach - turned later into OSF/1 and NeXT
  Step now Mac/XOS.
• Berkeley UCB BSD - turned later into 386BSD,
  FreeBSD, NetBSD, BSDI and BSD Lite.
• VU Amsterdam Amoeba study workgroups were
  trained writing a small PC implementation named
  Minix.

3
History on the Linux Open Source platform

• Just for the FUN!
• Minix a hybrid kernel design using message
  passing, targeting cheap/small x86 hardware
  without support for virtual memory management.
• Linux - Early 1991 Linus Torvalds created a new
  monolithic kernel model and announced his work in
  the comp.os.minix news group.
• Many computer fanatics seeking a PC UNIX home
  alternative switched from Minix to Linux.

4
History on the Linux Open Source platform

• Just for the FUN!
• There is no roadmap but development efforts seem
  to follow market demands.
• Where does it go?
• Linux distributions turn it into a professional
  platform adding support and allowing for
  commercial applications.
• Competition between different Linux distributors
  may risk the platform to divert within time.

5
History on the Linux Open Source platform

• The Open Source distribution battle field.
• Major Linux distributors
• Red Hat
• S.u.s.e, Mandrake, Caldera, Pacific Hightec
• Other Linux distributions
• Debain, JBLinux, K12LTSP, MCC, Rock, aXon,
  beehive, blackcat cLIenUX, conectiva, coyote,
  deeplinux, engarde, X/OS, finnix, yellowdog,
  spinix, ,

6
Sybase products available on Linux
Backup Server
Monitor Server
XP Server
7
Sybase products available on Linux

• ASE 11.0.3.3 ESD2 Sep 1998 1st FREE release
• Adaptive Server Enterprise accompanied with
  Backup Server together with 10.0.3 Open Client /
  -Server Software Development Kits
• Ported under Red Hat 5.2
• Kernel 2.0.36 / Glibc 2.0.27
• No support for Raw or Asynchronous disk I/O (did
  not exist)
• Maximum shared memory segment size 128 MByte
• Released as a FREE release for development and
  deployment

8
Sybase products available on Linux

• ASE 11.0.3.3 ESD6 Jun 2000 2nd FREE release
  (rollup)
• Adaptive Server Enterprise accompanied with
  Backup Server, Monitor Server together with
  10.0.4 Open Client / -Server SDKs
• Rollup under RH6.2 with 11.9.x obtained
  experience and fixes.
• Kernel 2.2.14 / Glibc 2.1.3-7
• Raw bound devices are supported
• SGI ProPack 1.2 Kernel Asynchronous disk I/O is
  supported
• SHM_REMAP the shared memory segment gaining 1.4
  GByte
• Released as a FREE release for development and
  deployment

9
Sybase products available on Linux

• ASE 11.9.x Jun 1999 1st SUPPORTED release
• Adaptive Server Enterprise accompanied with
  Backup Server, XP Server, Monitor Server together
  with 11.1.1 Open Client / -Server, ESQL/C SDKs
• Ported under RH 5.2 making full engineering
  certification
• Kernel 2.2.5-14 / Glibc 2.0.7-29
• No support for Raw or Asynchronous disk I/O (did
  not exist)
• Added support for dynamic loadable shared objects
  XP Server
• SHM_REMAP the shared memory segment gaining 1.4
  GByte

10
Sybase products available on Linux

• ASE 12.5 Nov 2000 Jun 2001 SUPPORTED release
• Adaptive Server Enterprise accompanied with
  Backup Server, XP Server, Monitor Server and
  Historical Server, ASE JVM, 12.5 Open Client /
  -Server and ESQL/C SDKs
• Ported under Red Hat 6.2
• Kernel 2.2.18 / Glibc 2.1.3-15
• Support for Raw bound devices
• Undocumented support for Asynchronous disk I/O
  (as it showed instable)

11
Porting Adaptive Server Enterprise
JVM ASE Embedded Java support
Server procedures, tasks handlers
SQL layer Query Parse Execute
DBMS layer Data cache
ASE Kernel
ASE drivers
GNU run-time Library
Linux kernel
12
Sybase products available on Linux

• ASE 12.5.0.1 - May 2002 SUPPORTED release
• Adaptive Server Enterprise accompanied with
  Backup Server, XP Server, Monitor Server and
  Historical Server, ASE JVM, 12.5 Open Client /
  -Server and ESQL/C SDKs
• Ported under Red Hat 6.2
• Kernel 2.2.18 / Glibc 2.1.3-15
• Support for Raw bound devices
• Undocumented support for Asynchronous disk I/O
  (instable)
• Linux shared memory issues are fixed allowing for
  2.3 Gbyte
• Support added for Large Files (LFS databases gt
  2 GByte) when EXT3 or ReiserFS are in place.

13
Porting ASE Memory layout
14
Sybase products available on Linux

• ASE 12.5.0.1 SBE/DE/EE - Jul 2002 SUPPORTED
  release
• Adaptive Server Enterprise accompanied with
  Backup Server, XP Server, Monitor Server and
  Historical Server, ASE JVM, 12.5 Open Client /
  -Server and ESQL/C SDKs
• Ported under Red Hat 7.2
• Kernel 2.4.9 / Glibc 2.2.4
• Support for Raw bound devices
• Support for Asynchronous disk I/O per librt
• Support for ASE Native user threads per
  libpthread
• FREE development and deployment
• Developers Edition (DE)
• Small Business Edition (SBE)

15
The Linux platform
16
New O/S features added to ASE 12.5

• Kernel 2.4.x and run-time 2.2.x features
• Latest distributions show enough stability
  allowing ASE to enable complex O/S features it
  can support.
• Raw disk I/O
• EIDE, SCSI and RAID devices are supported
• Adaptive Server Enterprise utilities with
  internal support
• SYBASE/SYBASE_ASE/bin/srvbuild
• SYBASE/SYBASE_ASE/bin/backupserver
• SYBASE/SYBASE_ASE/bin/dataserver

17
New O/S features added to ASE 12.5

• Kernel 2.4.x and run-time 2.2.x features
• Latest distributions show enough stability
  allowing ASE to enable complex O/S features it
  can support.
• LWP - Native O/S threads per Posix 1003.1c
• Early versions of libpthread show instable
• Required is libpthread-0.9 with glibc-2.4.4
• Posix Async disk I/O per librt
• Early versions of librt show instable.
• Required is librt-2.4.4 with libpthread-0.9 and
  glibc-2.4.4

18
New O/S features added to ASE 12.5

• Kernel 2.4.x and run-time 2.2.x features
• Latest distributions show enough stability
  allowing ASE to enable complex O/S features it
  can support.
• LFS Large File Support
• Ext3FS, ReiserFS, vxFS must be in place.
• Physical Tape Support for Backup Server
• Generic SCSI I/II hardware needs to be present.
• Backup Server supports auto hardware
  configuration.

19
Linux System Administration - RPM

• Releasing ASE using a package manager
• Guarantee a linux compliant and consistent
  software model

20
Linux System Administration - RPM

• Installing and upgrading Linux
• Major distributions target the platform when
  installing or upgrading software components with
  RPM.
• The Redhat Package Manager
• Software components are described with much
  detail.
• Package contents are registered in a RPM specific
  database.
• It allows for smart update methods.
• It uses compression to minimize distribution
  size.
• It uses an internal CRC (md5) checking assuring
  software is free from distribution defects when
  installing.

21
Linux System Administration - RPM

• Installing and upgrading Linux
• The Redhat Package Manager - continued
• Packages are computed for run-time dependencies.
• Up on installation run-time and environmental
  checks are performed assuring minimum and correct
  platform requirements.
• Packages can internally be programmed with
  package embedded shell scripts to control
  automatic configuration procedures.
• RPM provides system administrators with tools to
  perform software integrity and consistency
  checks.

22
Linux System Administration - RPM

• Using RPM
• RPM Query command
• Query the package header
• rpm -qip package-name-x.i386.rpm (file)
• rpm -qi package-name-x (installed)
• Query package contents
• rpm -qlp package-name-x.i386.rpm (file)
• rpm -ql package-name (installed)

23
Linux System Administration - RPM

• Using RPM
• RPM Query command
• Query an installed element for its package
• rpm -qf /opt/sybase-12.5/ASE-12_5/bin/dataserver
• Query all packages installed on a node
• rpm -qa
• Query a package install prefix
• rpm -q --queryformat installprefix \
  sybase-common-12.5.0.1-1.i386.rpm

24
Linux System Administration - RPM

• Using RPM
• Installing, Upgrading and Uninstalling software
• Install or Upgrade software contents.
• rpm Uhv sybase-common-12.5.0.1-i386.rpm
• Uninstalling software from the system
• rpm e sybase-common-12.5.0.1
• The smart installers always uses -U !
• Never remove package installed software with
  rm(1) !!!

25
Linux System Administration - RPM

• Using RPM
• BIG hammer approaches
• Installing software which fails dependencies
• rpm -ihv --nodeps package-name-x.yyy.rpm
• Installing software which does not register
• rpm -ihv --force package-name-x.yyy.rpm
• Use the above only if all other methods fail and
  the package contents need to be installed.

26
Linux System Administration - RPM

• Using RPM
• What to do when the RPM database got errnoneous
  information?
• Reinstall the system under the upgrade method
• Rebuild the RPM database
• rpm rebuild
• Distributing the installed system by repackaging
  all installed components.
• /usr/sbin/mkkickstart

27
Linux System Administration - filesystem

• The Linux supported filesystems
• EXT, EXT2, EXT3, ReiserFS, Minix, adfs, affs,
  bfs, coda, cramfs, fat, vfat, hpfs, isofs, jfs,
  procfs, romfs, smbfs, sysvfs, ufs, udf, umsdos
• Sybase preferred file systems
• Default file system kernel 2.2.x (RH6.2) EXT2
• Max file size limited to 2 GByte
• Default file system kernel 2.4.x (RH7.2) EXT3
• Max file size 2 TByte

28
Linux System Administration filesystem

• The Linux supported file systems
• Administrating a file system using a LABEL.
  Advantage is that if the device changes when
  additional hardware is added the LABEL will take
  care of its /etc/fstab administration.
• Building the file system
• mkfs t fstype fs-options device size
• Adding a file system LABEL for its reference
• tune2fs L volume-label device
• Administrating the LABEL under /etc/fstab
• /world /myworld ext3 defaults 0 0
• Performing an file system consistency check on
  this device
• fsck /world

29
Linux System Administration - rawdevice

• Linux Raw device administration
• Linux Raw devices are bound devices.
• Devices bind via /dev/rawctl
• Device entries appear under directory /dev/raw
• /usr/bin/raw /dev/raw/raw1 /dev/sdd1
• Query device administration with raw command
• /usr/bin/raw -q /dev/raw/raw1
• /usr/bin/raw -qa

30
Linux System Administration - rawdevice

• Linux Raw device administration
• Main administration is done from
  /etc/sysconfig/rawdevices
• /dev/raw/raw1 /dev/sdd1
• /dev/raw/raw2 /dev/sdd2
• /dev/raw/raw3 /dev/sdc1
• /dev/raw/raw4 /dev/hde2
• Enable Raw device at system boot time
• /sbin/chkconfig rawdevices on
• Manually start / stop rawdevice binding
• /etc/init.d/rawdevices startstop

31
Linux System Administration SCSI Tape

• Linux SCSI Tape administration
• Main administration is done from /etc/stinit.def
• Backup Server does need 2 EOF MTIO setting
• two-fms1
• Reinitialize the tape setup after any physical
  device change
• /sbin/stinit -v

32
Linux System Administration - networking

• LINUXCONF
• A helpful configuration editor
• Areas for network administration
• Client administration
• Hostname
• Network device with IPaddr
• DNS administration

33
Linux System Administration - networking

• Linux network administration
• Main client network administration is done from
• /etc/sysconfig/network
• Enable networking
• Specify HOSTNAME
• Specify GATEWAY
• Specify GATEWAYDEV
• Optinally NIS administration
• Optionally IPX administration
• /etc/sysconfig/networking
• Loopback interface configuration per ifcfg-lo

34
Linux System Administration - networking

• Linux network administration
• Main client network administration is done from
• /etc/sysconfig/networking/devices
• Specific network device bindings
• /etc/sysconfig/networking/profiles
• Hosts table for /etc/hosts
• Network table for /etc/networks
• DNS table for /etc/resolv.conf
• /etc/sysconfig/network-scripts
• Administrative actions when interfaces are on- /
  off-lined

35
Linux System Administration - networking

• Linux network administration
• server network administration
• Providing telnet, rlogin, rsh, ftp, rsync,
  services
• /sbin/chkconfig telnet on
• /sbin/chkconfig rlogin on
• Providing dhcp services
• Edit /etc/dhcp.conf
• /sbin/chkconfig dhcpd on
• /etc/init.d/dhcpd start

36
Linux System Administration - networking

• Linux network administration
• server network administration (cont)
• Providing samba services
• Edit /etc/samba/smb.conf
• /sbin/chkconfig smb on
• /etc/init.d/smb start
• Providing httpd services
• Edit /etc/httpd/conf/httpd.conf
• /sbin/chkconfig httpd on
• /etc/init.d/httpd start

37
Linux System Administration - networking

• Linux network administration
• Network firewall and masquarade administration
• /etc/sysconfig/ipchains
• Linuxconf allows for simple high, medium no
  firewall administration
• /usr/share/doc/ipchains-/HOWTO.html describes
  detailed filewall setup.
• /sbin/chkconfig ipchains on
• /etc/init.d/ipchains start
• Whitepaper available from http//www.xos.nl/

38
Linux as a Magnifying glass - procfs

• The Process file system - /proc
• /proc is a virtual file-system allowing access to
  kernel data using ordinary read(2) and write(2)
  system-calls.
• Most data can be examined and tuned using the
  cat(1) command.
• System specific data
• Kernel, memory and network tunable parameters
• User processes

39
Linux as a Magnifying glass - procfs

• The Process file system - /proc
• The GNOME and KDE desktop manager provide several
  tools to examine the /proc file system
• Ksysguard
• Strongest tool to focus on hardware and software
  related topics.
• Provides a daemon process to monitor multiple
  machines at once.
• Kpm
• Strong tool to zoom in on processes and monitor
  process related resources like file-descriptors,
  sockets and signal disposition
• Gtop
• Strong tool to monitor processes and make a
  graphical representation on storage and memory
  usage.

40
Linux as a Magnifying glass - procfs

• Ksysguard

41
Linux as a Magnifying glass - procfs

• The Process file system - /proc
• What hardware and hardware specific statistics
  does my system provide?
• System hardware specific data.
• /proc/cpuinfo
• Number of CPUs physically installed.
• Per CPU brand, model, cache size, frequency.
• Specific details per CPU on known h/w defects.
• CPU bogomips performance indicator measured at
  system boot.
• /proc/interrupts
• Active IRQ processing within the machine.

42
Linux as a Magnifying glass - procfs

• The Process file system - /proc
• System hardware specific data
• /proc/pci
• PCI cards detected during system boot providing
  information on hardware manufacturer, brand,
  model
• /proc/bus/pci
• PCI cards as detected separated into subsections
  per card allowing card specific operations.

43
Linux as a Magnifying glass - procfs

• The Process file system - /proc
• System hardware specific data
• /proc/iomem
• Physical memory address ranges
• /proc/ioports
• Controller port address ranges
• /proc/dma
• DMA request levels as assigned

44
Linux as a Magnifying glass - procfs

• The Process file system - /proc
• What software and software specific statistics is
  arranged for?
• System software specific data
• /proc/devices
• Software driver major number assignment.
• /proc/filesystems
• Filesystems supported on this installation.
• /proc/meminfo
• Virtual memory statistics currently in effect.

45
Linux as a Magnifying glass - procfs

• The Process file system - /proc
• System software specific data
• /proc/partitions
• Complete overview of partitions overview known by
  the running kernel.
• /proc/swaps
• Specific arranged partitions for virtual memory
  arrangement.

46
Linux as a Magnifying glass - procfs

• The Process file system - /proc
• Kernel global obtainable data and tunable
  parameters
• Parameters in the interest of ASE server setups
• /proc/sys/kernel
• ctrl-alt-del - disable/enable response to a 3
  finger salute
• shmmax - maximum shared memory heap size
• threads-max - maximum number of LWP available in
  this system

47
Linux as a Magnifying glass - procfs

• The Process file system - /proc
• Tuning the linux kernel
• Tuning directly per /proc
• /bin/echo numeric-value gt /proc/sys/kernel/shmmax
• Administrate fixed tuning under /etc/sysctl.conf
• Listing all or interactive tuning kernel
  parameters
• /sbin/sysctl a
• /sbin/sysctl w kernel.shmmax2097152

48
Linux as a Magnifying glass - procfs

• The Process file system - /proc
• Examining user processes via the process file
  system
• User process related data.
• /proc/PID/ - PID Process ID
• Direct access to the user binary
• Finding the process current work directory
• Arguments and environment
• Memory utilization
• Memory layout
• File descriptors and permissions
• Signal disposition

49
Linux as a Magnifying glass - procfs

• The Process file system - /proc
• User process related data.
• /proc/PID/exe
• Symbolic link to the program binary.
• /proc/PID/cwd
• Current work directory.
• /proc/PID/cmdline
• Representing the argv stored Arguments
• /proc/PID/environ
• Representing the env accessible Environment

50
Linux as a Magnifying glass - procfs

• The Process file system - /proc
• User process related data.
• /proc/PID/status
• Current and effective process UID and GID
• Virtual memory statistics
• Signal disposition
• /proc/PID/maps
• Memory segment mappings
• /proc/PID/fd (directory)
• File descriptors open

51
Linux as a Magnifying glass

• Run-time configured instrumentation.
• Applications and erroneous memory allocation
• An environment variable MALLOC_CHECK_ enables
  run-time library detecting for erroneous malloc()
  / free() administration.
• Silently ignore (default).
• MALLOC_CHECK_0
• Report to STDERR but keep running.
• MALLOC_CHECK_1
• Abort the application and produce a core file.
• MALLOC_CHECK_2

52
(No Transcript)
53
Sybase Developer Network (SDN)

• Additional Resources for Developers/DBAs
• Single point of access to developer software,
  services, and up-to-date technical information
• White papers and documentation
• Collaboration with other developers and Sybase
  engineers
• Code samples and beta programs
• Technical recordings
• Free software
• Join today www.sybase.com/developer or visit
  SDN at TechWaves Technology Boardwalk
