Title: Maximum Allowable Cooling Capacity


1
Maximum Allowable Cooling Capacity
  • Bruce Wilcox, BSG
  • Ken Nittler, Enercomp

2
Overview
  • Air conditioners operating on peak in
    Californias hot central valley climates
    typically draw 1.7 kW/ton of rated capacity
  • Field data indicates that oversizing is common
  • The most reliable way to capture peak electrical
    demand savings from envelope and duct measures
    required under the standards is to ensure that
    air conditioners are appropriately sized

3
Proposed Changes
  • Proposal expands current sizing requirements to
    include calculation of a Maximum Allowable
    Cooling Capacity
  • Goal is to prevent gross oversizing
  • Alternative Calculation Method software will be
    required to do calculations
  • Procedures allow calculations based either on
    whole building or for each separate cooling
    system
  • Tradeoff for systems with larger cooling capacity
    but same peak demand

4
Proposed Language
  • Standards
  • Section 150(h)3 establishing the maximum
    allowable cooling capacity
  • Two exceptions
  • ACM Manual
  • Appendix L - Procedure for calculating design
    cooling capacity
  • Appendix M - Procedure for calculating maximum
    allowable cooling capacity
  • Appendix N Procedure for calculating electrical
    input exception

5
Exception 1 Systems not Covered
  • No cooling system installed
  • Cooling system is not an electrically driven
    compression based system

6
Appendix L Design Cooling Capacity
  • Follows ASHRAE 2001 Fundamentals Chapter 28
    Residential Loads
  • Using
  • Region X Design Data
  • Block Loads either whole building or by cooling
    system
  • Specific Rules to select Tables
  • Title-24 U-factors, SHGC values, Infiltration,
    Duct Efficiencies, Radiant Barriers
  • Load is adjusted to rating conditions to get
    Design Cooling Capacity

7
Capacity at Standard Rated Conditions
  • 95 ?F outdoor dry bulb
  • 67 ?F indoor wet bulb
  • Capacity Load / (0.88 0.002286 x ?T)
  • Where
  • Capacity Design Cooling Capacity (Btu/hr)
  • Load Sensible Design Cooling Load (Btu/hr)
  • ?T Outdoor Cooling Design Temperature (?F) 95

8
Appendix M Maximum Capacity
  • Uses Design Cooling Capacity from Appendix L
  • Allows next largest size to be selected
  • For buildings with more than one cooling system
    that have the design cooling capacity calculated
    for the entire building
  • Maximum Allowable Cooling Capacity
  • Design Cooling Capacity (6000 x Number of
    Cooling Systems)

9
Maximum Allowable Cooling Capacity
10
Multiple Orientations
  • Maximum Allowable is the highest of the four
    cardinal orientations
  • For buildings with more than one cooling system,
    the orientation may be different for each system

11
Exception 2 Electrical Input Exception
Appendix N
  • Allowed to exceed maximum allowable cooling
    capacity if the proposed total electrical input
    of the oversized system is less than or equal to
    the standard electrical input
  • Standard total electrical input is equal to 0.117
    x Design Cooling Capacity
  • Proposed electrical input includes compressor and
    fan energy
  • Proposed electrical input is from CEC Directories
    of Certified Equipment
  • Proposed fan energy is 0.017 W per Btu of design
    cooling capacity or may be measured as part of
    new duct measurement procedure

12
Standard Electrical Input
Btu/Watt Cooling Capacity for Split Air
Conditioners in the CEC Directory
