FLEA

1
FLEA

• Prof. dr. ir. J. Hellendoorn

2
Decision making

• Decision making takes place in all areas of life
• Sometimes, results of decision making are visible
  sooner or later, sometimes the results cannot be
  judged
• Many different decision problems
• Number of deciders
• Number of decision steps
• Uncertainty

3
Number of decision makers

• Individual decisions, more person or group
  decisions
• One common target or different targets (game
  theory)
• Separation in central and decentral decisions and
  decisions on different levels

4
Number of decision steps

• One step decisions
• Multi-step decisions
• Series of consecutive and mutually dependent
  decision steps.
• Time can play a role, like in dynamic programming
  (Bellman).
• The final decision is taken in several steps

5
Dynamic programming automaton
x t
z t
System
One time storage
z t1
Minimize (or maximize) f (x1,,xN)
6
Optimal policy

• An optimal policy has the property that whatever
  the state the system is in at a particular stage,
  and whatever the decision taken in that state,
  then the resulting decisions are optimal for the
  subsequent state.
• An optimal policy is made up of optimal
  subpolicies.
• An optimal policy from any state is independent
  of how that state was achieved and comprises
  optimal subpolicies from then on.

7
Routing example
16
B
E
16
15
18
22
H
23
22
18
19
16
A
C
F
J
11
22
29
I
15
19
15
13
22
D
G
8
Recurrence relation
If f n(in) the cost of an optimal policy when
there are n stages remaining and the decision is
in state in then f n(in) min p(in , in-1)
f n-1(in-1) in-1 where p(a ,
b) is the premium associated with the single
stagecoach journey from a to b
9
The example in numbers
f 1(H) 23 f 0(J) 23 0 23 f 1(I)
29 f 0(J) 29 0 29
f 2(E) min(16 f 1(H), 18 f 1(I))
min(16 23, 18 29) 39 f 2(F)
min(18 f 1(H), 11 f 1(I))
min(18 23, 11 29) 40 f 2(G) min(15 f
1(H), 13 f 1(I)) min(15 23,
13 29) 38
10
The example II
f 3(B) min(16 f 2(E), 15 f 2(F))
min(16 39, 15 40) 55 f 3(C)
min(22 f 2(E), 16 f 2(F) , 22 f 2(G))
56 f 3(D) min(19 f 2(F), 22
f 2(I)) min(19 40, 22 38) 59
f 4(A) min(22 f 3(B), 19 f 3(C) , 15 f
3(D)) 74
Route A - D - F - I - J
11
Extensions

• Negative premiums
• Stop when ?i. f n(i) f n-1(i), with p(i,i)
  0
• Approximation

12
Knapsack problem
Vehicle with capacity of 10 tons and four products
13
Other notation

• Maximize the sum 8x1 12x2 15x3 19x4,
  subject to two kinds of restriction, that 2x1
  3x2 4x3 6x4 ? 10, and x1, x2, x3, x4 should
  be equal to 0 or 1.
• As long as the problem is small enough it is
  possible to examine all the ways of deciding.
• Now we focus on the principle of dynamic
  programming

14
In formula
f n(T) max(f n-1(T), Vn f n-1(T -
Wn)), if T ? Wn f n(T) f n-1(T) , else f
0(T) 0, ?T
In words the best that we can do in stage n and
with state T is the better of not loading any of
product n (f n-1(T)) and loading product n and
facing the next decision with a state reduced by
its weight (f n-1(T - Wn)) provided that T is
large enough to allow this to happen.
15
The recurrent process
f 1(T) 19, if T ? 6 f 1(T) 0, if T lt
6 f 2(10) max(f 1(10) ,15 f 1(6)) 34 f
2(9) max(f 1(9) ,15 f 1(5)) 19 f
2(1) f 1(1) 0 f 2(0) 0
16
The recurrent process II
f 3(10) max(f 2(10) ,12 f 2(7)) 34 f
3(9) max(f 2(9) ,15 f 2(5)) 31 f
3(1) f 2(1) 0 f 3(0) 0
17
The recurrent process III
18
Extensions

• Nonlinearity
• Adding more dimensions volume, price,
• Sensitivity analysis

19
Uncertainty

• Uncertainty makes decision making interesting and
  difficult
• Decision processes
• Processes with precise information
• Processes with uncertain, imprecise, or
  incomplete information

20
Level of knowledge

• Processes with precise information
• Target either known or uncertain
• Processes with uncertain, imprecise, or
  incomplete information
• Probabilistic uncertainty with known distribution
  function
• Statistical or stochastic methods
• Interval of uncertainty
• Vague, fuzzy knowledge

21
This course

• Single step decisions
• Single person decisions
• Usage of uncertain information
• Not of complete fuzzy sets
• Usage of fuzzy decision matrices

22
Example of fuzzy sets in DA I
m
A
B
1
B is better then A
0
Perf
m
A
B
1
Intuitively, B is better then A
0
Perf
23
Example of fuzzy sets in DA II
m
B
1
What is better, A or B ?
A
0
Perf
m
A
B
1
Can A and B be compared?
0
Perf
24
The decision problem

• Number of alternatives a1, a2, , an
• Number of criteria c1, c2, , cm
• Number of weight factors w1, w2, , wm , each
  weight factor belongs to the corresponding
  criterion
• Decision function D, D ?(wi , ci )

25
How to determine ?

• Uncertainty in available alternatives
• Relative importance of each aspect
• Evaluation of each alternative with regard to
  each aspect
• Role of traditional arguments
• Value of prize money

26
Examples from sport tennis

• Number of won sets is decisive
• Not the number of won games
• Not the number of won rally's
• The playing field is crisp, the ball is either in
  or out
• A net service may be regarded as neither right
  nor wrong

27
Examples from sport decathlon

• Each of the numbers (100m, 400m, steeple chase,
  jump, javelin) delivers points
• The sum of the points determines the winner
• Participants can determine their own personal
  playing and training scheme to achieve an optimal
  result

28
Skating

• Four distances 500m, 1500m, 5000m, and 10000m.
• Measured times t500, t1500, t5000 , t10000.
  These times are calculated back to 500m.
• The evaluation criterion
• The person with the least K is winner

29
Skating alternatives

• Alternative decision functions to determine a
  winner
• Ranking on each distance, mean or sum of the
  rankings
• Similar, but 10 points for the winner, 6 or 8
  points for number two, etc. Compare Formula 1
• Take the mean of the whole field, and compare
  results with the mean, deviation from the mean
  brings points. Compare bridge. Disadvantage
  complex for the audience.

30
Decision problem dice and coin

• Decide between two alternatives
• Throwing a coin
• Throwing a dice
• When one throws a coin, there are two
  possibilities
• Heads 4 points
• Tails 5 points

31
Throwing a dice

• Number of points is equal to the number of dots,
  but 1 means throw again and 6 delivers 11 points.

Heads 4
Tails 5
Coin
1 throw again
2 2
DA
3 3
Dice
4 4
5 5
6 11
32
Chances
H4
½
C5
Coin
½
1
1
1/6
22
DA
1
1/6
33
1
1/6
Dice
44
1/6
55
1/6
1/6
611
33
Choices 1 and 2

• Maximum of the mathematical expectation
• Coin
• Dice
• Choice is for dice, optimistic.
• Maximum of minimal profit
• Coin minimum 4
• Dice minimum 2
• Choice is for coin, careful, pessimistic.

34
Choices 3 and 4

• Maximum of the maximal profit
• Coin maximum 5
• Dice maximum 11
• Choice is for dice, opportunistic.
• Minimum of maximal spread
• Coin largest spread 1
• Dice largest spread 9
• Choice is for coin, careful, sure.

35
Lottery

• Three different lotteries
• 10 lottery tickets, 1/ticket, 1st price 8.
• 10 lottery tickets, 1/ticket, 1st price 12.
• 1,000,000 lottery tickets, 1,000,000/ticket,1st
  price 1,200,000,000,000.
• A. seems unattractive with a mathematical
  expectation of 0.8. This is, however, extremely
  high for a lottery.

36
Mathematical expectation risk

• Lottery B has a mathematical expectation of 1.2,
  so the lottery loses money. Very attractive for
  gamblers.
• Lottery C also has a mathematical expectation of
  1.2, however, who buys a ticket?
• Repeat the coin-dice example for higher amounts
  of money.

37
Decision operator

• The decision to play or buy something (like in a
  lottery, gambling, betting) is dependent of the
  mathematical expectation and
• the character (careful, optimistic, reckless)
• the circumstances (rich, poor, lonesome, tension,
  charity)

38
Savings

• Suppose you saved 100,000.
• Offer you put everything on one number of the
  roulette. If you win, you get 10,000,000.
• Expectation
• This is excellent, why not do it?

39
Personal utility

• According to Bernouilli personal utility is not
  dependent of the amount of money but the value of
  money for the person in question.
• Bernouilli assumes that the value (use) of money
  is proportional to the logarithm of the amount of
  money.
• Does not take into account personal circumstances.

40
Personal utility example

• A possesses 100,000 and gambles x.
• In case of loss 100,000 x.
• In case of profit 100,000 100x.
• Utility before playing
• Utility after playing

41
Decision to play

• If Ubefore lt Uafter then the personal
  expectation value is positive.
• If x 100000, Ubefore5, Uafter ? dont play.
• If x 500, Ubefore5, Uafter 5.0026 play.
• We did not take into account personal, subjective
  factors.

42
General decision problem

• Alternatives A a1, a2, , an
• Criteria C c1, c2, , cm
• Weights W w1, w2, , wm
• Target D

43
Decision table

• The decision problem can be described by a table
  or matrix

44
Three different approaches I, II

• For each alternative ai the function Dis
  calculated. The best value (the maximum value) of
  D determines the best alternative.
• For each criterion the alternatives are mutually
  compared. The best alternative is closest to an
  optimum or far from the worst alternative.

45
Three different approaches III

• Build up a knowledge base that compares
  subjectively the alternatives and delivers a
  (vague) conclusion.

46
The max-min criterion

• Max-min is the oldest method
• The best choice is

47
Example

• Consider two alternatives, what is the best
  alternative when throwing heads?
• Clearly a1, but this seems too careful and
  pessimistic.

48
Alternative from Savage

• Calculate the amount of money that is missed in
  case of a wrong choice.
• With a1 and tails one missed a2 and tails, i.e.,
  10000.
• So one regrets (use again max-min)

49
General decision operator

• Best alternative is i, where
• D is a monotonous, non-decreasing function in s

50
Several instantiations

• Intersection
• Harmonic mean
• Geometric mean
• Algebraic mean

51
Several instantiations II

• Quadratic mean
• Union
• Generally if sltt then Di(s)lt Di(t), so

harm. mean
geom. mean
algebr. mean
quad. mean
min
max
s
-?
?
-1
0
1
2
52
What is s?

• s can be regarded as a measure of optimism or
  carefulness.
• When s?-? the decision is based only on the
  minimum of the membership degrees very
  pessimistic!
• When s?? the decision is based only on the
  maximum of the membership degrees very
  optimistic!

53
What is s? II

• For s lt 1 negative values (weak properties) have
  relatively high influence
• For s 1 the decision operator D is sensible for
  absolute changes in ?
• For s 0 the decision operator D is sensible for
  relative changes in ?

54
Hurwicz-operator

• Another method to describe the optimism index is
  by
• Disadvantage of this method is that it regards
  only extreme values of ?ij

55
Example of the influence of s
56
Several values of s

• s ? -?, minimumhence alternative a1
• s ? 0, geometric mean, hence alternative a2
• s ? 1, algebraic mean, hence alternative a3

57
Several values of s II

• s 2, quadratic meanhence alternative a4
• s ? ?, maximum,hence alternative a5

58
In figure as a function from s
59
Zooming in

• Important mean values lie around s ? 0
• We therefore map -? lt s lt ? on 0 ? r ? 1

60
Functions r1, r2, and r3
pessimistic
optimistic
r
0
0.5
1
61
Zooming in, in figure
well distinguishing functions
