COP3252 Advanced Java Programming

1
COP3252Advanced Java Programming

• 15-Apr-08
• Lecture Set 22
• Collections, Applet Game

2
Collections

• Provide standardized way to handle different
  types of object groups
• Typically, they represent data items that form a
  natural group, such as a poker hand (a collection
  of cards), a mail folder (a collection of
  letters), or a telephone directory (a mapping of
  names to phone numbers).
• Allows you to manipulate many objects as if they
  were a single object without having to add more
  code to handle the objects

3
Java Collections Framework

• Group of interfaces, implementations, and methods
  for representing and working with groups of data
  in a consistent way.
• Interfaces These are abstract data types that
  represent collections. Interfaces allow
  collections to be manipulated independently of
  the details of their representation. In
  object-oriented languages, interfaces generally
  form a hierarchy.
• Implementations These are the concrete
  implementations of the collection interfaces. In
  essence, they are reusable data structures.
• Algorithms These are the methods that perform
  useful computations, such as searching and
  sorting, on objects that implement collection
  interfaces. The algorithms are said to be
  polymorphic that is, the same method can be used
  on many different implementations of the
  appropriate collection interface. In essence,
  algorithms are reusable functionality.
• Main Interfaces
• Collection, Set, List, Map, Queue and Iterator
• The collections framework works between different
  APIs --- saving you from having to tailor your
  code to each API.

4
Set Interface

• Collection of items, having no duplicates, stored
  in any order
• Contains only methods inherited from Collection
• Types of sets
• SortedSet
• Extends Set
• Sorted in ascending (natural) order
• HashSet
• Implements Set
• Stores items within a hash table
• TreeSet
• General implementation of SortedSet
• Stores items in a Tree
• Searched for in ascending order
• Tree is balanced time it takes to change or
  search the tree increases at a rate of the
  logarithm of the size of the set.

5
Iterators

• Interface object that goes through the contents
  of a collection, one at a time, using its
  methods.
• hasnext Method causes interation to continue
• next Method retrieves each item
• remove method discards that most recent item
  retrieved.

6
Lists

• Allows for duplicates
• Contains items in a defined order
• Stores it items by integer index, starting with
  zero
• Extends the Collections interface and adds
• Positional Access Manipulated elements based on
  their numerical position in the list
• Search Searched for a specified object in the
  list and returns its numerical position
• Iteration Extends Iterator semantics to take
  advantage of the lists sequential nature

7
Classes that implement List

• ArrayList
• Stores items in an array that is resizable
• Has a specific capacity that grows automatically
• LinkedList
• Data can be added at the beginning or end of the
  list
• Good for working with stacks, queues, or
  double-ended queues.
• Must go through each index (starting at beginning
  or end, depending which is closed to the desired
  index) to retrieve a specific index
• Vector
• Like a ArrayList but synchronized to work with
  Threading

8
Maps

• Allows you to create functionality using data
  stored as keys that are mapped to a value
• Contains keys that map to one value, in any
  order, but whose values can map to multiple keys
• Does not extend Collection, but can be viewed as
  a Collection

9
Sorted Map

• Contains keys that map to one value in a
  particular order, but whose values can map to
  multiple keys.
• Must implement the Comparable interface or use
  Comparator for sorting purposes

10
Comparable

• This interface imposes a total ordering on the
  objects of each class that implements it.
• This ordering is referred to as the class's
  natural ordering, and the class's compareTo
  method is referred to as its natural comparison
  method.
• Lists (and arrays) of objects that implement this
  interface can be sorted automatically by
  Collections.sort (and Arrays.sort).
• Objects that implement this interface can be used
  as keys in a sorted map or as elements in a
  sorted set, without the need to specify a
  comparator.

11
Comparator

• A comparison function, which imposes a total
  ordering on some collection of objects.
• Comparators can be passed to a sort method (such
  as Collections.sort or Arrays.sort) to allow
  precise control over the sort order.
• Comparators can also be used to control the order
  of certain data structures (such as sorted sets
  or sorted maps), or to provide an ordering for
  collections of objects that don't have a natural
  ordering.

12
Applets Simple game development

• In this final lecture note section, we will work
  a bit with applets, animation, sound and images
  to create a very basic applet game.

13
Applets The basic structure

• // import necessary packages
• import java.applet.
• import java.awt.
• // Inherit the applet class from the class Applet
• public class FirstApplet extends Applet
• // Now you should implement the following
  methods
• // init - method is called the first time you
  enter the HTML site with the applet
• public void init() ...
• // start - method is called every time you
  enter the HTML - site with the applet
• public void start() ...
• // stop - method is called if you leave the
  site with the applet
• public void stop() ...

14
Simple animation in an applet

• In this example, we will move a red ball across
  the applet.
• Note The animation looks horrible --- but we
  will learn how to fix that!
• See BallAnimate.java and BallAnimate.html

15
Smoothing the Animation

• Ball was flickering because repaint() completely
  clears and redraws the applet screen.
• We see a blank screen (for just a milisecond)
• We can use double buffering to stop this

16
Quick note about repaint()

• repaint does not call paint()
• It calls a method named update(), which clears
  the screen completely and then calls paint()
• This repaints the entire background and then our
  circle

17
Double Buffering

• Generates a new off-screen image
• Draw everything on the offscreen image
• Copy this image over to the existing image
• Basically, the picture is already painted before
  it is drawn to the screen
• Removes flicker, but produces a large amount of
  data (each picture is essentially drawn twice)

18
Double Buffering

• See BallAnimateSmooth.java and BallAnimateSmooth.h
  tml
• Note This update method can be used
  (basically as-is) in any applet that has animation

19
Changing movement (bouncing the ball)

• Now we will see how to update our code to make
  the ball bounce between the left and right side
• We will need to stop the ball from leaving the
  applet area by reversing direction when we reach
  a side

20
Bouncing Ball

• See BallAnimateSmoothBounce.java and
  BallAnimateSmoothBounce.html
• We have added a speed variable and updated the
  code to make a bouncing pattern

21
Simple Key Events

• We can handle key events using methods if of
  Applet
• This example is going to use the old keyDown
  method
• The newer (more correct) way is to use
  processKeyEvent

22
Adding sound

• We can easily add a bounce sound to the game
• See BallAnimateSmoothKeysAudio.java and
  BallAnimateSmoothKeysAudio.html

23
A pong-like game

• This next example turns our code into a very
  simple game
• See BallGame.java and BallGame.html
