Singer SimilarityA Brief Literature Review

• Catherine Lai
• MUMT-611 MIR
• March 24, 2005

1
2
Outline of Presentation

• Introduction
• Motivation
• Related research
• Recent publications
• Kim Whitman, 2002
• Liu Huang, 2002
• Tsai, Wang, Rodgers, Cheng Yu, 2003
• Bartsch Wakefield, 2004
• Discussion
• Conclusion

2
3
Introduction

• Motivation
• Multitude of audio files circulation on the
  Internet
• Replace human documentation efforts and organize
  collection of music recordings automatically
• Singer identification relatively easy for human
  but not machines
• Related Research
• Speaker identification
• Musical instrument identification

3
4
Kim Whitman, 2002.

• Singer Identification in Popular Music
  Recordings Using Voice Coding Features (MIT
  Media Lab)
• Automatically establish the I.D. of singer using
  acoustic features extracted from songs in a DB of
  pop music
• Perform segmentation of vocal region prior to
  singer I.d.
• Classifier uses features drawn from voice coding
  based on Linear Predictive Coding (LPC)
• Good at highlight formant locations
• Regions of resonance significant perceptually

4
5
Kim Whitman, 2002.Detection of Vocal Region

• Detect region of singing detect energy within
  frequencies bounded by the range of vocal energy
• Filter audio signal with band-pass filter
• Used Chebychev IIR digital filter of order 12
• Attenuate other instruments fall outside of the
  vocal range regions e.g. bass and cymbals
• Voice not only remaining instrument in the region
• Discriminate the other sounds e.g. drums use a
  measure of harmonicity
• Vocal segment is 90 voiced is highly harmonic
• Measure harmonicity of filtered signal within
  analysis frame and thresholding the harmonicity
  against a fixed value

5
6
Kim Whitman, 2002.Feature Extraction

• 12-pole LP analysis based on the general
  principle behind LPC for speech used for feature
  extraction
• LP analysis performed on linear and warped scales
• Linear scale treats all frequencies equally on
  linear scale
• Human ears not equally sensitive to all
  frequencies linearly
• Warping function adjusts closely to the Bark
  scale approx. frequency sensitivity of human
  hearing
• Warp function better at capture formant location
  at lower frequencies

6
7
Kim Whitman, 2002.Experiments

• Data sets include 17 different singer 200 songs

• 2 classifier Gaussian Mixture Model (GMM) and SVM
  used on 3 different feature sets
• Linear scaled, warped scaled, both linear and
  warped data
• Run on entire song data and on segments
  classified as vocal only

7
8
Kim Whitman, 2002.Results

• Linear frequency feature tend to outperform the
  warped frequency feature when each used alone
  combined best
• Song and frame accuracy increases when using only
  vocal segments in GMM
• Song and frame accuracy decreases when using only
  vocal segments in SVM

Kim Whitman, 2002
8
9
Kim Whitman, 2002.Discussion and Future Work

• Better performance of linear frequency scale
  features vs. warped frequency scale features
  indicate
• Machine find increased accuracy of the linear
  scale at higher frequencies useful
• Contrary to human auditory system
• The performance of the SVM decreased is puzzling
• Finding aspects of the features not specifically
  related to voice
• Add high-level musical knowledge to the system
• Attempt to I.D. song structure such as locate
  verses or choruses
• Higher probability of vocals in these sections

9
10
Liu Huang, 2002.

• A Singer Identification Technique for
  Content-Based Classification of MP3 Music
  Objects
• Automatically classify MP3 music objects
  according to singers
• Major steps
• Coefficients extracted from compressed raw data
  used to compute the MP3 features for segmentation
• Use these features to segment MP3 objects into a
  sequence of notes or phonemes
• Waveform of 2 phonemes
• Each MP3 phoneme in the training set, its MP3
  features extracted and stored with its associated
  singer in phoneme DB
• Phoneme in the MP3 DB used as discriminators in
  an MP3 classifier to I.D. the singers of unknown
  MP3 objects

Liu Huang, 2002
10
11
Liu Huang, 2002.Classification

• Number of different phonemes a singer can sing is
  limited and singer with different timbre possess
  unique phoneme set
• Phonemes of an unknown MP3 song can be associated
  with the similar phoneme of the same singer in
  the phoneme DB
• kNN classifier used for classification
• Each unknown MP3 song first segmented into
  phonemes
• First N phonemes used and compared with every
  discriminators in the phoneme DB
• K closest neighbors found
• For each of the k closest neighbor,
• If its distance within a threshold, a weighted
  vote given
• KN weighted votes accumulated according to
  singer
• Unknown MP3 song is assigned to the singer with
  largest score

11
12
Liu Huang, 2002.Experiments

• Data set consists of 10 male and 10 female
  Chinese singers each with 30 songs
• 3 factors dominate the results of the MP3 music
  classification method
• Setting of k in the kNN classifier (best k 80
  result 90 precision rate)
• Threshold for vote decision used by the
  discriminator (best threshold 0.2)
• Number of singer allowed in a music class (larger
  no. higher precision)
• Allow 1 singer in a musical class
• Grouping several singers with similar voice
  provide ability to find songs with singers of
  similar voices

12
13
Liu Huang, 2002.Results and Future Work

• Results within expectation
• Songs sung by a singer with very unique style
  resulted in the highest precision rate ( 90)
• Songs sung by a singer with a common voice
  resulted in only 50 of the precision rate
• Future work to use more music features
• Pitch, melody, rhythm, and harmonicity for music
  classification
• Try to represent MP3 features according to syntax
  and semantics of the MPEG7 standards

Liu Huang, 2002
13
14
Tsai et al., 2003.

• Blind Clustering of Popular Music Recordings
  Based on Singer Voice Characteristics (ISMIR)
• Technique for automatically clustering
  undocumented music recording based on associated
  singers given no singer information or population
  of singers
• Clustering method based on the singers voice
  rather than background music, genre, or others
• 3-stage process proposed
• Segmentation of each recording into
  vocal/non-vocal segments
• Suppressing the characteristics of background
  from vocal segment
• Clustering the recording based on singer
  characteristic similarity

14
15
Tsai et al., 2003.Classification

• Classifier for vocal/non-vocal segmentation
• Front-end signal processor to convert digital
  waveform into spectrum-based feature vectors
• Back-end statistical processor to perform
  modeling, matching, and decision making

15
16
Tsai et al., 2003.Classification

• Classifier operates in 2 phases training and
  testing
• During training phase, a music DB with manual
  vocal/non-vocal transcriptions used to form two
  separate GMMS a vocal GMM and non-vocal GMM
• In testing phase, recognizer takes as input
  feature vectors extracted from an unknown
  recording, produces as output the frame
  log-likelihoods for the vocal GMM and the
  non-vocal GMM

16
17
Tsai et al., 2003.Classification

• Block diagram

Tsai, 2003
17
18
Tsai et al., 2003.Decision Rules

• Decision for each frame made according to one of
  three decision rules 1. frame-based, 2.
  fixed-length-segment-based, and 3.
  homogeneous-segment based decision rules.

Assign a single classification per segment
Tsai, 2003
18
19
Tsai et al., 2003.Singer Characteristic Modeling

• Characteristics of voice be modeled to cluster
  recordings
• V v1, v2, v3, be features vectors from a
  vocal region, is a mixture of
• solo feature vectors S s1, s2, s3,
• background accompaniment feature vectors B b1,
  b2, b3,
• S and B unobservable
• B can be approximated from the non-vocal segments
• S is subsequent estimated given V and B
• A solo and a background music model is generate
  for each recording to be clustered

19
20
Tsai et al., 2003.Clustering

• Each recording evaluated against each singers
  solo model
• Log-likelihood of the vocal portion of one
  recording tested against one solo model computed
  (for all solo models)
• K-mean algorithm used for clustering
• Starts with a single cluster and recursively
  split clusters
• Bayesian Information Criterion employed to decide
  the best value of k

20
21
Tsai et al., 2003.Experiments

• Data set consists of 416 tracks from Mandarin pop
  music CD
• Experiments run to validate the vocal/non-vocal
  segmentation method
• Best accuracy achieved was 78 using the
  homogeneous segment-based method

21
22
Tsai et al., 2003.Results

• System evaluation on the basis of average cluster
  purity
• When k singer population, the highest purity
  0.77

Tsai, 2003
22
23
Tsai et al., 2003.Future Work

• Test method on a wider variety of data
• Larger singer population
• Richer songs with different genre

23
24
Discussion and Conclusion

• Singer similarity technique can be used to
• Automatically organize a collection of music
  recordings based on lead singer
• Labeling of guest performers information usually
  omitted in music in music database
• Replace human documentation efforts
• Extend to handle duets, chorus, background
  vocals, other musical data with multiple
  simultaneous or non-simultaneous singers
• Rock band songs with parts sung by the guitarist,
  drummer band members can be identified

24
25
Bibliography

• Bartsch, M. and G. Wakefield (2004). Singing
  voice identification using spectral envelope
  estimation. IEEE Transactions on Speech and Audio
  Processing, vol. 12, no. 2,100-9.
• Kim, Y. and B. Whitman (2002). Singer
  identification in popular music recordings using
  voice coding features. In Proceedings of the 2002
  International Symposium on Music Information
  Retrieval.
• Liu, C. and C. Huang (2002). A singer
  identification technique for content-based
  classification of mp3 music objects. In
  Proceedings of the 2002 Conference on Information
  and Knowledge Management (CIKM), 438-445.
• Tsai, W., H. Wang, D. Rodgers, S. Cheng, and H.
  Yu (2003). Blind clustering of popular music
  recording based on singer voice characteristics.
  In Proceedings of the 2003 International
  Symposium on Music Information Retrieval.

25
